Integrating the Solr search engine

symfony integra.on

Thomas Rabaix •  Symfony live 2009/2010/2011 •  Plugins –  swFunc8onalTestGenera8onPlugin –  mgI18nPlugin –  swCrossLinkApplica8onPlugin –  swCombinePlugin –  swToolboxPlugin –  sfSolrPlugin •  Bundle – sonata project –  AdminBundle (BaseApplica8onBundle) –  IntlBundle –  MediaBundle –  More to come …. •  « More with symfony » book •  Now working for Ekino – a french web tech-‐company

co-‐author Some slides have been wri1en and reviewed by a co-‐worker at Ekino -‐ Frédéric Cons a Java Architect

talk •  Introduc8on •  Schema design •  Indexing •  Searching •  Administra8on and deployment •  Conclusion

I. INTRODUCTION

what is a search engine ? •  Warning : search engine SELECT * FROM document LIKE %term%’ •  Search is about –  indexing informa8on –  filtering document –  presen8ng informa8on

indexing •  get rich content (webpage, ﬁles, database) •  parse the content •  analyse the parsed content •  store the informa8on into the index

ﬁltering •  get user input •  create a query •  retrieve matching documents against the index •  display results and ﬁltering op8ons

Solr -‐ a search engine •  Solr is an like a HTTP server with •  Lucene has been published in 2000 by Doug Cucng : It is a search engine : indexing, search algorithm and storage format •  25th january 2006 CNET grants the license to the Apache Sofware Founda8on •  Original source code : hgps://issues.apache.org/jira/ browse/Solr-‐1

Apache projects around Solr •  nutch : a web crawler •  tika : a ﬁle content extractor from doc/pdf/ xls ﬁles : diagnos8c tool

Lucene + Solr since 2010/03 the two teams have merged

Solr in a web architecture

II. SCHEMA DESIGN

document vs database •  A Solr index store only ONE kind of document deﬁni8on. •  A document has typed proper8es : string, date, integer …. •  sta8c deﬁni8on or dynamic type •  de-‐normalize your database into a structured document op8mized for the search requirements

document definiNon •  Defini8ons are set in the schema.xml file •  Type defini8on collec8on –  Name –  Class –  Tokenizer/Analyser/filter •  Property defini8on collec8on –  Name –  Type –  Indexed/stored/mul8Valued

type definiNon •  One tokenizer per field defini8on, the tokenizer is used to split a value into tokens "Symfony2 is awesome" => ‘Symfony2’, ‘is’, ‘awesome’ •  Filters are used to alter each token –  stemmer: merging => merge –  synonyms –  stopwords : remove word : a, the, ... –  accent removal: é > e

Type deﬁni@on can have a huge impact on performance

property deﬁniNon •  naming conven8on : many tables or many metadata (ﬁles) goes into one document •  Model Recipe and Model Ingredient => it is a good prac8ce to –  r_name or recipe_name! –  i_name or ingredient_name!

property deﬁniNon •  A value can be –  indexed : the ﬁltering result is stored into the index –  stored : the original value is stored into the index –  multiValued •  the property is similar to an array •  neat solu8on for storing a set of categories linked to a product or permissions linked to a document

Sample ﬁle

updaNng the schema.xml!•  not an easy task on big index •  some changes require reindexing documents ( add a new ﬁlter, change ﬁeld type) •  need to reload Solr or hot reload the Solr core

symfony integraNon •  Thanks to sfSolrPlugin •  Author : Thomas Rabaix •  Hosted on github hgp://github.com/rande/sfSolrPlugin •  Small history : –  It is a fork of sfLucenePlugin based on Zend Search (a php lucene implementa8on) originally wrote by Carl Vondrick. –  The underline communica8on API uses the SolrPhpClient project

iniNalizaNon and indexaNon tools •  Tasks –  to generate basic conﬁgura8on ﬁle (lucene:create-Solr- config) –  to start Jegy -‐ a small java container (lucene:service) –  to reindex informa8on (lucene:update-model-system) •  Behaviors –  to automa8cally update the index –  works with Doctrine –  works with Propel (pull request ?) •  Indexes –  index has a name and a culture –  one core per name/culture => my_index_fr

files locaNon •  Configura8on files are set in PROJECT_ROOT/config/solr/!•  Generated files by the lucene:create-solr-config task ! –  are located in PROJECT_ROOT/config/solr/index_name/ conf! and are generated once and are overwrigen by the task •  index files are set in PROJECT_ROOT/data/solr_index/ •  original Solr files : PROJECT_ROOT/plugins/sfSolrPlugin/lib/vendor/ solr/

plugin built-‐in definiNons •  sfl_guid : the document unique id •  sfl_title / sfl_descrip8on •  sfl_uri : the document uri on the website •  sfl_model: the model name linked to the document •  sfl_all : concatena8on of all field values -‐ ie: search all features •  Other deprecated fields (from sfLucenePlugin) : sfl_type, sfl_catefory, sfl_categories_cache!

search.yml files •  defining indexes and models •  Indexes are the first level defini8on –  index op8ons (host, cultures, base_url) –  models defini8on •  models defini8on op8ons –  the key is the property name –  op8ons : •  type! •  indexed •  stored (op8onal) •  multiValued (op8onal) •  boost (op8onal) •  alias (op8onal, method to call to retrieve property value) •  transform (op8onal, php callback func8on, ie: intval, strip_tags)

III. INDEXING

indexing data •  The index can be updated by diﬀerent mechanisms : –  XML data –  CSV –  DataImporterHandler

indexing process •  gathering data •  sent the data to Solr •  at this point the data are not yet "searchable" •  commit the data or rollback

indexing with curl •  We represent data and commands with a custom xml format •  This xml format is used under the hood by all language-‐speciﬁc clients

indexing with curl •  We now send this data to the solr server with the curl u8lity : curl http://mysolrurl/solr/update -H Content-type:text-xml --data-binary @myfile.xml!•  We commit with an explicit <commit /> command curl http://mysolrurl/solr.update -Fstream.body=<commit/>!

ImporNng with DataImportHandler •  DIH allows us to execute a sql query and map its result to a Solr schema •  Sql rows can be transformed on the way with Transformer objects : regular expressions, date formacng, templa8ng,... •  Its main use is to import databases, but it also works with other datasources such as ﬁles and urls

ImporNng with DataImportHandler

indexing with sfSolrPlugin •  Use the task •  Or the doctrine behavior

opNmizing indexing Nme •  Op8mize your search query –  by default the plugin uses a simple query –  tweak the query to do less queries

advanced indexing usage •  Document too complex ? –  Create a Recipe::getLuceneDocument method, this method is in charge of crea8ng the document

advanced indexing usage •  Model::isIndexable : return true or false if the model can be indexed ... –  Useful if you have a publishing workﬂow or complex rules that cannot be match by a SQL queries

doctrine behavior •  automa8cally create a document and commit it to all related indexes. •  Error are silently ignored

IV. SEARCHING

principles of search •  All we need to do is to send some query parameters to Solr –  Solr will respond with a xml-‐formaged response (its default format) •  Exemple query : ﬁnd the ten ﬁrst documents that match the keyword «test » http://solr/mycore/select?q=test&indent=on&start=0&rows=10!

query parameters : search •  q : the main query , the text to find •  q.op : the query operator (AND or OR), can also be configured on the server side •  df : the default field to search, can also be configured on the server side •  fq : a filter query, used to restrict the search result, not involved in the relevant score •  defType : the query parser defini8on, «lucene » or « dismax » (see next slide)

query parameters : output •  wt : the writer used to ouput the response. Defaults to xml, but can be json, xslt, php, ruby serializa8on •  start and rows: used for pagina8on •  sort : you can order your results on several ﬁelds values, ascending or descending •  debugQuery : gives an explana8on of the score •  fl: the list of ﬁelds to include in the response

configuring search Solr-‐side •  Solr uses so-‐called "Search handlers" to serve queries •  You can define your own handlers with specific parameters •  Parameters can be set by default, appended to the user query, or defined as invariants, i.e not modifiable by a user

query parsing •  Basically there are two op8ons to parse an user-‐entered query: –  The old-‐but-‐well-‐known query parser –  The query parser

query parsing : lucene •  The Lucene query parser performs all the Lucene syntax tricks : –  Logical opera8ons : term1 AND NOT term2,(term1 OR term2) and TERM3 –  Targe8ng a special field : my_field_name:term1 –  Range queries : date_field:[* TO NOW – 2 DAYS], int_field:[0 TO 50] –  Phrase queries : "term1 term2", or "term1 term2"~5 with a slop factor –  Keyword boos8ng : term1^1.5 term2

query parsing : dismax •  The dismax query parser, is less error-‐prone, and tries to be smarter –  Field boos8ng : ﬁeld1^1.5 ﬁeld^1.2 ( via the qf parameter) –  Automa8c phrase boos8ng : from term1 term2 to +(term1 term2) "term1 term2" –  Limited query syntax, so that user-‐entered queries are always valid Dismax is recommended for public websites, but power-‐users may feel frustrated by its syntax

faceNng •  Face8ng is the process of enriching search results with documents counts on predeﬁned categories. Think of count + group by sql query. •  To facet on a parameter named ﬁeld1, just add to your query : &facet=true&facet.field=field1 !•  The xml response now includes a new sec8on

faceNng types •  Facet on field, to group results according to a field value •  Facet on date interval •  Facet on query, for more specific needs

faceNng search You can fetch the whole content of a page with one Solr request : search results and facets values are deﬁned in a single xml response

search components •  HighlighNng : displays a snippet of the original text matching the user query, like most search engines do. &hl=true&hl.fragsize=200&hl.simple. pre=<b>&hl.simple.post=</b>!•  Query elevaNon : allows to ar8ﬁcially manipulate query results to force some documents to appear on top of the list. !

search components •  More Like This : searches for results similar to a given document based on sta8s8cal language processing. •  Spellchecking : can use a dic8onary or (even beger) the Solr index to suggest search terms to the end user.

search with sfLuceneCriteria •  Clean Fluent API through the sfLuceneCriteria!•  most helpful methods (use a table to render these methods) : –  select($field)! –  add($query) and addField($field, $query)! –  addPhrase($query) and addFieldPhrase ($field, $query)! –  addRange($from, $to) and addFieldRange ($field, $from, $to)! –  setOffset and setLimit! –  sortBy($field, $order)!

simple search

ﬁltering search

faceted search •  Crea8ng a faceted search is easy as other queries •  Exploi8ng the results

geolocalized search – opNon I •  Solr 1.4 : no na8ve support, use a hack with the range support (square results)

geolocalized search – opNon II •  Solr 4.0 : use the localsolr extension (circle results) -‐ patch from Julien Lirochon

advanced search usage •  All Solr query features are not implemented, but you can add any extra parameters to the sfLuceneCriteria!•  You can access to the lucene index with a sfLucene instance

V. ADMINISTRATION AND DEPLOYMENT

basic administraNon •  What are Solr Cores ? –  A core is a defini8on of an index, with its own schema and solrconfig files –  The main <SOLR_HOME>/solr.xml defines a list of cores served by a single instance

Solr Cores •  Using cores allows great flexibility in administra8on : hot reload of a core configura8on, hotswap of cores, merging of cores http://mySolrserver/solr/admin/cores?action=RELOAD&core=mycorename!http://mySolrserver/solr/admin/cores?action=SWAP&core=myoldcore&other=mynewcore!•  Weirdly enough, this is not the default Solr configura8on : use it now, even with a single index

core configuraNon •  Solrconfig.xml : is the main file, it defines the internal lucene secngs, the way Solr will handle indexing and searching, the cache secngs, and search components •  schema.xml : holds your schema defini8on, as seen in part 1 •  synonyms.txt : allow you to define word associa8ons : i-‐pod => ipod •  elevate.xml : forces top results for special keywords as seen previously •  stopwords.txt : defines «meaningless » words that are not to be indexed. •  spellings.txt : feeds Solr with a custom dic8onary.

caching for performance •  Cache requests with httpcache : send etags and / or 304 to clients •  Cache ﬁlter queries with filterCache : unordered documents lists for common ﬁlters (driven by the fq parameter) •  Cache queries results with queryResultCache : stores ordered documentIds for common queries (driven by the q parameter) •  Cache fieldValues with documentCache!

caching management •  All these caches can be monitored with JMX and the admin console •  All these caches can be warmed with a query at startup 8me and afer a commit :

scaling •  Replica8on: a whole index is replicated across mul8ple servers. Indexing is done by a master server, search is handled by slave servers. •  Sharding: a single index is split across mul8ple indexes, each one served by a separated instance. For a single query, load is balanced across mul8ple servers. This op8on is for *huge* indexes. •  Both: you can replicate your shards if you need to. the replica@on mechanism can also be used to make index backups

VI. CONCLUSION

upcoming features •  Language iden8fica8on (backed by 8ka) •  Improvements of the geolocalisa8on capabili8es (Spa8al support for mul8-‐valued fields, polygon search) •  Sql join-‐like queries •  Distributed indexing with SolrCloud •  Extended face8ng with hierarchical facets •  Field collapsing : the ability to group result by field value.

alternaNve •  Elas8c search –  Created by Shay Bannon, former Compass commiger and Gigaspaces employee –  Oriented toward distributed search –  Shares a lot of features with Solr : face8ng, json streams, many clients for many languages –  Bonus feature : a concept named “river”, which allows indexing of data con8nuously pulled from a datasource (rabbitmq, couchdb, twiger...) –  Warning : a one-‐man project, with sparse documenta8on

references •  hgp://lucene.apache.org/, home of lucene and its subprojects, including Solr •  hgp://www.dzone.com/mz/solr-‐lucene, the dzone for search-‐ oriented news , home of many lucene / Solr commigers (check the developers sec8on) , another shelter for Solr commigers (check the blog) •  hgp://solr.pl/en/, a polish blog with frequent updates

ques8ons ? hgp://github.com/rande/sfSolrPlugin twi1er: th0masr github: rande / sonata-‐project email: thomas.rabaix@ekino.com We are hiring !
