TOP 5 MISTAKES OF
                            MASSIVE CSS!

                            Nicole Sullivan & Stoyan Stefanov
...
FIND US AT...


                           @stubbornella
                          @stoyanstefanov



Thursday, June 24, 2...
WHY OPTIMIZE CSS?


    • It blocks progressive rendering

 test: http://www.phpied.com/files/css-loading/table.php
  ...
TOP 1000 STUDY


    1. Grab top Alexa sites
    2. Start Fiddler
    3. Load each site
    4. Export from Fiddler



Thur...
<?php

        $file = file('alexa.txt');

        foreach ($file as $url) {

                  launch($url);

        }

...
42% DON’T GZIP CSS




Thursday, June 24, 2010
44% HAVE MORE THAN 2
                 CSS FILES
                          56%

                                44%




Thu...
56% SERVE CSS WITH
                               COOKIES




Thursday, June 24, 2010
62% DON’T MINIFY




         would get more than 10% savings from YUI compressor
Thursday, June 24, 2010
21% HAVE >100K OF CSS
                                21%


                          11%
                          11%


...
HASTE TRACE-BASED PACKAGING




                                                            homepage     homepage
        ...
KUDZU
      Was introduced to the United States between 1935 and 1950
       by the Soil Conservation Service to prevent s...
CSS KUDZU!


Thursday, June 24, 2010
“OBJECT ORIENTED CSS
                   SOUNDS GREAT, BUT WE
                    HAVE A GIANT MESS!”
                     ...
FACEBOOK DECIDED TO
                  GO ON A DIET
                          The CSS was one piece of the puzzle




Thurs...
Jason Sobel -
                          Perf Manager Fu

                            MANY PIECES                    Nan Ga...
THEY REDUCED THEIR
            RESPONSE TIME BY HALF
                          in only six months




Thursday, June 24, 2...
WHAT IS OBJECT
                          ORIENTED CSS?
                          A philosophy? A framework? A tool?




Th...
MORE LIKE AN EVOLUTION
      OF THE LANGUAGE
                          it makes CSS more powerful




Thursday, June 24, 2...
HOW IS IT DIFFERENT?


                               ul{...}
                            ul li{...}
                     ...
HOW IS IT DIFFERENT?


                               ul{...}
                            ul li{...}
                     ...
HOW IS IT DIFFERENT?


                                    ul{...}
                                 ul li{...}
           ...
MUCH LESS CODE
                            easier to work with newbies




Thursday, June 24, 2010
GRIDS
    •   574 bytes

    •   14 lines of code

    •   Percentage widths adapt to
        different page sizes

    • ...
GRANULARITY FAIL
                             + STALE RULES
                          + UNPREDICTABILITY
                 ...
5                   Text


                            GRANULARITY FAIL
                          the CSS objects shouldn’...
Thursday, June 24, 2010
Thursday, June 24, 2010
Thursday, June 24, 2010
http://www.brickartist.com/
Thursday, June 24, 2010
http://www.brickartist.com/
Thursday, June 24, 2010
WE WANT TO DO THE
                SAME THING WITH CSS




Thursday, June 24, 2010
CREATE THE
                          BUILDING BLOCKS




Thursday, June 24, 2010
MOST SITES GET THE
               GRANULARITY WRONG
                          and their architecture is set up to fail



...
HOW? FIRST, A VISUAL
                     INVENTORY




Thursday, June 24, 2010
TAKE A PHP OBJECT
Thursday, June 24, 2010
BREAK IT DOWN
Thursday, June 24, 2010
7 SMALLER OBJECTS




Thursday, June 24, 2010
headings




Thursday, June 24, 2010
HEADINGS
   Heading      - 16px bold #3B5998
   Heading     - 16px normal #333333
   Heading     - 15px bold #3B5998     •...
IT’S ALL ABOUT PATTERN
                    MATCHING
                          but you have to take a step back




Thursda...
PHP OBJECTS != CSS OBJECTS
                          you will be tempted, beware!




Thursday, June 24, 2010
4        Text


                          STALE RULES
                              CSS gets crufty



Thursday, June 24, ...
STALE IS TWO THINGS



    ❖   Truly stale - rules that are no longer used on the site
    ❖   Rules used on subsequent PV...
WHAT KIND DO YOU
                               HAVE?




Thursday, June 24, 2010
WHAT KIND DO YOU
                               HAVE?


    ❖   Try dust-me selectors




Thursday, June 24, 2010
WHAT KIND DO YOU
                               HAVE?


    ❖   Try dust-me selectors
    ❖   Track them over time -
     ...
3            Text


                          UNPREDICTABILITY
               Make each object predictable and location in...
h3




Thursday, June 24, 2010
h3




Thursday, June 24, 2010
A      Heading should not become a          Heading

                                in another part of the page.




Thur...
AVOID
                                 EXAMPLE
                          #weatherModule h3{color:red;}
                   ...
HOW DO YOU TEST FOR
             UNPREDICTABLE CODE?
                          #foo h3{...}
                          #bar...
h1-h6
                     How many? You need site-wide headings




Thursday, June 24, 2010
511
                          declarations setting styles for h1-h6


  56% >10
  9% >100
Thursday, June 24, 2010
HEADINGS BEFORE



                            958
                              declarations h1-h6



                   ...
HEADINGS AFTER:



                              25
                                    Chad Little - Facebook
Thursday, J...
2                   Text


                           SPECIFICITY WARS
                          lobbing specificity grenad...
SPECIFICITY SCREWS UP
                  THE CASCADE
                          and the cascade kind of rocks, so how do we ...
SIMPLIFY SPECIFICITY




Thursday, June 24, 2010
.mod .hd{...}
.ie .mod .hd{...}
.weatherMod .hd {...}




                USE HACKS SPARINGLY
                          An...
.mod .hd{...}
           X
.ie .mod .hd{...}
.weatherMod .hd {...}




                USE HACKS SPARINGLY
               ...
#navigation{...}
    #header{...}




                          AVOID STYLING IDS
                          IDs impact spe...
X
    #navigation{...}
    #header{...}




                          AVOID STYLING IDS
                          IDs impa...
.nav {color: red !important;}




                          AVOID !IMPORTANT
                              except on leaf ...
.nav {color: red !important;}   X

                          AVOID !IMPORTANT
                              except on leaf...
!IMPORTANT



                           518
                          declarations using important



 12% have greater t...
div.error{...}




                          STYLE CLASSES
                               rather than elements




Thursda...
X
              div.error{...}




                          STYLE CLASSES
                               rather than elem...
X
              div.error{...}




                          STYLE CLASSES
                               rather than elem...
html body .myModule div .hd{...}
.myModule2 .hd {...}


                              GIVE RULES THE
                     ...
X
html body .myModule div .hd{...}
.myModule2 .hd {...}


                              GIVE RULES THE
                   ...
1           Text


                          DUPLICATION
                              CSS kudzu on steroids



Thursday, ...
GREP IS YOUR FRIEND
                    look at the stylesheets globally rather than per page




Thursday, June 24, 2010
margintoo many? You need reset.css




Thursday, June 24, 2010
518
                          declarations reset margin to zero


  64% > 10
 14% > 100
Thursday, June 24, 2010
float
                          too many? You need grids




Thursday, June 24, 2010
733
                          declarations floated elements


  56% > 10
 13% > 100
Thursday, June 24, 2010
font-size            headings may be disguised in class names




Thursday, June 24, 2010
FONT-SIZE



                             889
                          declarations changed the font-size


 78% >10
 23%...
HOW DID FACEBOOK
                REDUCE DUPLICATION?
                          let’s look at an example




Thursday, June...
MEDIA BLOCK EXAMPLE




Thursday, June 24, 2010
ALL OF THESE ARE THE
                       SAME OBJECT




Thursday, June 24, 2010
WHAT DO WE KNOW?

                          ❖ Can be nested
                          ❖ Optional right button

           ...
WHAT DON’T WE KNOW?

                          ❖ Image width and decoration vary
                          ❖ Right content...
SEPARATE STRUCTURE
                        FROM CHROME




Thursday, June 24, 2010
A FEW LINES OF HTML...

            <div class="media attribution">
              <a href="http://twitter.com/stubbornella...
4 LINES OF CSS...




Thursday, June 24, 2010
Thursday, June 24, 2010
HTML SIZE
                      reduced by 50%




                                   by Stefan Parker
Thursday, June 24, ...
“Due to these efforts, we cut our average
            CSS bytes per page by 19% (after gzip) and
            HTML bytes pe...
LET’S KEEP TALKING...
                                www.stubbornella.org
                                  @stubbornella...
