Web Anywhere: Mobile Optimisation With HTML5, CSS3, JavaScript

  1. 1. Web AnywhereMobile Optimisation With HTML5, CSS3, JavaScriptBruce Lawson / SxSW/ 12 March 2011
  2. 2. introducinghtml5.com
  3. 3. Opera – one browser on many devices
  4. 4. "Our goal is to take the one true Web andmake it available to people on their terms." Jon S. von Tetzchner, Opera Co-founder "All I ask is access to the full Web, for everyone, everywhere. And some more beer." Me
  5. 5. Most-popular mobile browsers (Opera=red)
  6. 6. China “The proportion of [people] accessing the Internet by mobile increased enormously from 39.5% in late 2008 to 46% in June 2009, while the proportion of using desktops and laptops decreased”. (close to 150 million people). Statistical Report on Internet Development in China, p25-26, July 2009, www.ccnic.cn
  7. 7. USA - www.opera.com/smwTop 10 sites (unique users) Top 10 handsets, Jan 20111. google.com 1. Apple iPhone2. facebook.com 2. LG VM265 “Rumor2”3. youtube.com 3. BlackBerry 8520 “Curve”4. wikipedia.org 4. BlackBerry 9700 “Bold”5. yahoo.com 5. LG VM510 “Rumor Touch”6. my.opera.com 6. BlackBerry 8330 “Curve”7. accuweather.com 7. BlackBerry 8900 “Curve”8. twitter.com 8. BlackBerry 8530 “Curve”9. espn.go.com 9. Samsung SPH-M810 “Instinct S30”10.myspace.com 10.BlackBerry 9630 “Tour”
  8. 8. UKTop 10 sites Top handsets, January 20111. google.com 1. Apple iPhone2. facebook.com 2. Nokia C33. bbc.co.uk 3. BlackBerry 8520 “Curve”4. youtube.com 4. Nokia 2330c5. wikipedia.org 5. BlackBerry 9700 “Bold”6. live.com 6. Nokia 6700c7. my.opera.com 7. Nokia 2730c8. bing.com 8. BlackBerry 8900 “Curve”9. mobile2day.com 9. Nokia 630010.newsnow.net 10.Nokia 6303c
  9. 9. BurmaTop 10 site Top handsets1. google.com 1. Apple iPhone2. facebook.com 2. Nokia 5730s3. bbc.co.uk 3. Nokia 5800d4. my.opera.com 4. Sony Ericsson W8005. nytimes.com 5. Nokia X36. espn.go.com 6. Nokia X67. cnnmobile.com 7. Sony Ericsson U5i8. getjar.com 8. Nokia C39. topshareware.com 9. BlackBerry 9700 “Bold”10.zedge.net 10.Nokia N8
  10. 10. MenuPhilosophy3 MethodologiesOptimisation tipsand tricksFuture
  11. 11. Mobile Web philosophy
  12. 12. Three methodologies
  13. 13. 1. Special mobile site2. Do nothing at all3. Optimise for mobile
  14. 14. 1. Special mobile site2. Do nothing at all3. Optimise for mobile
  15. 15. refactored for small screen,not dumbed down for mobile
  16. 16. offer users choice:desktop or mobile?
  17. 17. beware browser sniffing photo: http://www.flickr.com/photos/timdorr/2096272747/
  18. 18. 1. Special mobile site2. Do nothing at all3. Optimise for mobile
  19. 19. not WAP or text anymore...
  20. 20. mobile browsersknow how to deal with the Web
  21. 21. JavaScript touch eventsaddEventListener(touchstart..) addEventListener(touchmove..)
  22. 22. CSS 3font control, text and box shadows, rounded corners, basic animations
  23. 23. -moz-transition: all 0.5s ease-in-out;-ms-transition: all 0.5s ease-in-out;-o-transition: all 0.5s ease-in-out;-webkit-transition: all 0.5s ease-in-out;transition: all 0.5s ease-in-out;
  24. 24. HTML5<!DOCTYPE html>
  25. 25. “...extending the language to better support Webapplications, since that is one of the directions the Web isgoing in and is one of the areas least well served by HTMLso far. ”Ian Hickson, Editor of HTML5http://lists.w3.org/Archives/Public/public-html/2009Jan/0215.html
  26. 26. <canvas>
  27. 27. canvas = “scriptable images”
  28. 28. <svg> or <canvas>?
  29. 29. Scalable Vector Graphics:● Supported in 4 modern desktop browsers, and IE9● Not supported in native Android browser, fine in Opera Mobile/Android● Vector graphics, therefore infinitely scalable● XML so text-based - can be made accessible● Keeps a DOM● Can author with Adobe Illustrator or Inkscape
  30. 30. geolocation
  31. 31. find out your location via JavaScriptnavigator.geolocation.getCurrentPosition(success, error);function success(position) { /* wheres Waldo? */ var lat = position.coords.latitude; var long = position.coords.longitude; ...}
  32. 32. Use for progressive enhancement
  33. 33. offline support
  34. 34. HTML5 forms<input type=email> <input required> <input type=url>
  35. 35. detect if a browsers goes offlinewindow.addEventListener(online, function(){ … }, true);window.addEventListener(offline, function(){ … }, true);
  36. 36. storage
  37. 37. localStorage/sessionStoragelike cookies...document.cookie = key=value; expires=Thu, 15 Feb 201023:59:59 UTC; path=/…/* convoluted string operations go here … */
  38. 38. localStorage/sessionStoragelike cookies...on steroids!localStorage.setItem(key, value);localStorage.getItem(key);localStorage.clear();localStorage.key = value;if (localStorage.key == …) { … }…
  39. 39. application cache
  40. 40. cache UI/resource files for offline use<html manifest=”blah.manifest”>CACHE MANIFEST# send this with correct text/cache-manifest MIMEimages/sprites.pngscripts/common.jsscripts/jquery.jsstyles/global.css
  41. 41. Server-sent Events Web Sockets
  42. 42. 1. Special mobile site2. Do nothing at all3. Optimise for mobile
  43. 43. “One Web means making, as far as is reasonable, thesame information and services available to usersirrespective of the device they are using. However, it doesnot mean that exactly the same information is available inexactly the same representation across all devices.”W3C Mobile Web Best Practices http://www.w3.org/TR/mobile-bp/#OneWeb
  44. 44. “responsive” design with CSS Media QueriesQuerying device capabilites (width, height,orientation, color, resolution, aspect ratio) notbrowser sniffing
  45. 45. CSS 3 Media Queries:@media screen and (max-width: 480px) { // insert CSS rules here}http://www.w3.org/TR/css3-mediaqueries/
  46. 46. http://mediaqueri.es
  47. 47. http://mediaqueri.es
  48. 48. http://mediaqueri.es
  49. 49. http://mediaqueri.es
  50. 50. Viewport metatag
  51. 51. physical vs virtual pixels
  52. 52. viewport meta<meta name="viewport"content="width=device-width"><meta name="viewport"content="width=320, initial-scale=2.3,user-scalable=no">http://developer.apple.com/safari/library/documentation/AppleApplications/Reference/SafariWebContent/UsingtheViewport/UsingtheViewport.html
  53. 53. <meta name="viewport" content="width=550">
  54. 54. If youre using Media Queries: <meta name="viewport"content="width=device-width"> If you have an explicit width: <meta name="viewport" content="width=550">
  55. 55. Tips n tricks
  56. 56. HTML tips:● Dont use <table>s for layout (dur)● Give dimensions of images in HTML: <img height=x width=y src=foo.pngalt="blah">● Consider <a href="tel:xxx"> for phone numbers
  57. 57. Code accessibly:Lots of similarities with accessibility techniques:Relationship between Mobile Web Best Practices(MWBP) and Web Content Accessibility Guidelines(WCAG) http://www.w3.org/TR/mwbp-wcag/
  58. 58. Minimise HTTP requests:● Combine JS into one file. Same with CSS.● Use CSS sprites to combine decorative images● Consider SVG or <canvas> for images
  59. 59. CSS optimisation:● ems instead of px for fonts● Fluid layouts: remember motion sensors● background-size / SVG background images● Turn off fancy shadows, transitions etc with Media Queries
  60. 60. CSS sprites#panel1b a:hover { background: transparent url(test-3.jpg) 0 -200px no-repeat;} #panel2b a:hover { background: transparent url(test-3.jpg) -96px -200px no-repeat;} www.alistapart.com/articles/sprites/
  62. 62. JavaScript tips:● Put <script> elements as far down the source aspossible● <script defer..>, <script async..>● If it must be in the <head>, put it after CSS● Feature detect – e.g. Modernizr
  63. 63. Web or Apps?
  64. 64. “…the browser run-time is perfect…you’re out of writing for WindowsMobile, Android, S60, each of which require testing...we want to abstractthat.All the cool innovation is happening inside the browser – you don’tneed to write to the native operating system anymore.”Mobile Entertainment Market, June, 2009
  65. 65. W3C Widgets – application development filled with web standards goodness, using browser engine as platform
  66. 66. Anatomy of a widgetindex.html, assets + config.xml, zipped and renamed .wgt
  67. 67. The future
  68. 68. W3C DAP(Devices and Protocols Working Group) WAC (http://www.wacapps.net/)
  69. 69. Defining JavaScript APIs:● Contacts (access address book)● Calendar API● Media Capture API (programmatic access tocamera/microphone)● Messaging API (email/ SMS)● accelerometer http://www.w3.org/2009/dap/
  70. 70. HTML5 <device>
  71. 71. Thank you Patrick Laukewww.opera.com/developer bruce.lawson@opera.com twitter.com@brucel
  72. 72. Mobile-friendly: The mobile web optimization guidedev.opera.com/articles/view/the-mobile-web-optimization- guide/ Opera Mini: web content authoring guidelines dev.opera.com/articles/view/opera-mini-web-content- authoring-guidelines/ Mobile Emulators & Simulators: The Ultimate Guide www.mobilexweb.com/emulators W3C Mobile Web Application Best Practices www.w3.org/TR/mwabp/

×
