Graphs in the Database: Rdbms In The Social Networks Age

RDBMS in the social networks age CTEs and Window Functions Lorenzo Alberton PHP UK Conference, 26 February 2010

Lorenzo Alberton 2

Lorenzo Alberton MDB2 Calendar Pager Translation2 Mail_Queue DB_QueryTool 2

Foreword 3

Foreword S ( b, c) AS ﬁrst_not_null chyA COALESCE(a, ie IS NOT NULL r ar h UN E col2 WHERE O R SV N IBOU VER (PART U b D ITION R EC D ED BY de nt N PR ptno) TH SELECT * FROM table weighT)(*) AS c 2 ) http://www.alberton.info/talks I A age EC Nt ( a SUM ED W HA INN ER L ING E N JOIN L JOI VIWE t2 Nt NGX A COU T E TER A EPT C BE LEFTVG t2 ON t1.id = t2.id JOIN N MIN( (sal Oary) EPT OU I N EXC 50 > HT U 00 RIG 3

The Web Today 4

Social Networks YOU 5

Recommendation Systems Customers who bought this item also bought Music Recommended by Last.fm 6

Recommendation Systems Customers who bought this item also bought Music Recommended by Last.fm items linked by similar patterns in users’ behaviour 6

Recommendation Systems Customers who bought this item also bought Music Recommended by Last.fm 6

Recommendation Systems items linked by Customers who bought this item also bought similar features (e.g. genre) Music Recommended by Last.fm 6

Route Planning Systems 7

It’s a Graph! 8

Graph Theory The boring stuff... 9

Graphs nodes edges 10

Graphs nodes payload! Weight: 0.5 Name: 5 Type: Number Order: 3 edges 10

Graphs undirected directed 11

Graph Density complete 12

Graph Density complete dense 12

Graph Density sparse complete dense 12

Representing a Graph Adjacency List 1 1 2 3 4 2 1 3 2 4 4 2 3 13

Representing a Graph Adjacency Matrix 1 2 3 4 1 1 1 1 1 2 1 0 0 0 3 0 1 0 1 4 0 1 1 0 14

Graphs and Databases? 15

Graph Representation in the DB Adjacency Matrix Nodes N1 N2 N3 N1 N2 N3 ... Requires DDL statements ALTER TABLE nodes ADD n4 (...) 16

Graph Representation in the DB Adjacency Matrix Adjacency List Nodes N1 N2 N3 src dest N1 N2 N3 ... Requires DDL statements Only DML statements ALTER TABLE nodes ADD n4 (...) INSERT, DELETE, UPDATE 16

Nodes and Edges nodes CREATE TABLE nodes ( id INTEGER PRIMARY KEY, node name age name VARCHAR(10) NOT NULL, feat1 CHAR(1), -- e.g., age feat2 CHAR(1) -- school or company ); edges CREATE TABLE edges ( a INTEGER NOT NULL REFERENCES nodes(id) a b ON UPDATE CASCADE ON DELETE CASCADE, b INTEGER NOT NULL REFERENCES nodes(id) ON UPDATE CASCADE ON DELETE CASCADE, PRIMARY KEY (a, b) ); CREATE INDEX a_idx ON edges (a); CREATE INDEX b_idx ON edges (b); 17

Nodes and Edges -- Undirected Graphs: constraint on the uniqueness of the pair CREATE UNIQUE INDEX pair_unique_idx a b ON edges (LEAST(a,b), GREATEST(a,b)); 3 5 5 3 3 5 -- No self-loops (node linking to itself) ALTER TABLE edges ADD CONSTRAINT no_self_loops_chk CHECK (a <> b); 18

Nodes and Edges -- Undirected Graphs: constraint on the uniqueness of the pair CREATE UNIQUE INDEX pair_unique_idx a b ON edges (LEAST(a,b), GREATEST(a,b)); 3 5 5 3 3 5 x x -- No self-loops (node linking to itself) ALTER TABLE edges ADD CONSTRAINT no_self_loops_chk CHECK (a <> b); 18

Sample Graph x x w w 2 3 x z y w 1 4 x y 7 5 x 6 y x z 19

Sample Graph nodes edges node name feat1 feat2 a b 1 3 1 node1 x y 2 1 2 node2 x w 2 4 3 node3 x w 3 4 3 5 4 node4 z w 3 6 5 node5 x y 4 7 5 1 6 node6 x z 5 6 7 node7 x y 6 1 20

Traversing the Graph Select nodes connected to node 1 a b -- Directed Graphs 1 3 2 1 SELECT * FROM nodes n 3 6 LEFT JOIN edges e ON n.id = e.b WHERE e.a = 1; 4 7 5 1 5 6 21

Traversing the Graph Select nodes connected to node 1 a b -- Directed Graphs 1 3 2 1 SELECT * FROM nodes n 3 6 LEFT JOIN edges e ON n.id = e.b WHERE e.a = 1; 4 7 5 1 -- Undirected Graphs 5 6 SELECT * FROM nodes WHERE id IN ( SELECT CASE WHEN a = 1 THEN b ELSE a END FROM edges WHERE 1 IN (a, b) ); 21

Traversing the Entire Graph $nodes = select_friends($me); foreach ($nodes as $node) { $nodes2 = select_friends($node); foreach ($nodes2 as $node) { ... ... ... } } 22

Traversing the Entire Graph $nodes = select_friends($me); foreach ($nodes as $node) { $nodes2 = select_friends($node); foreach ($nodes2 as $node) { ... ... Loops ... } Loops Loops } Loops Loops 22

Traversing the Full Graph CREATE TEMPORARY TABLE reached ( id INT PRIMARY KEY ); INSERT INTO reached VALUES (@root_id); WHILE(@@rowcount > 0) BEGIN INSERT INTO reached (id) SELECT DISTINCT child_id FROM edges e JOIN reached p ON p.id = e.parent_id WHERE e.child_id NOT IN ( SELECT id FROM reached ) END; 23

Traversing the Full Graph CREATE TEMPORARY TABLE reached ( id INT PRIMARY KEY ); INSERT INTO reached VALUES (@root_id); WHILE(@@rowcount > 0) BEGIN INSERT INTO reached (id) Temporary SELECT DISTINCT child_id Table FROM edges e + JOIN reached p Stored ON p.id = e.parent_id WHERE e.child_id NOT IN ( Procedure SELECT id FROM reached ) END; 23

Common Table Expressions (CTE) -- VIEW CREATE VIEW undirected_graph (a, b) AS ( SELECT a, b FROM edges UNION ALL SELECT b, a FROM edges ); SELECT a, b FROM undirected_graph; 24

Common Table Expressions (CTE) -- VIEW CREATE VIEW undirected_graph (a, b) AS ( SELECT a, b FROM edges UNION ALL SELECT b, a FROM edges ); SELECT a, b FROM undirected_graph; -- CTE (dynamic VIEW) WITH undirected_graph (a, b) AS ( SELECT a, b FROM edges UNION ALL SELECT b, a FROM edges ) SELECT a, b FROM undirected_graph; 24

Recursive CTEs - Sequence WITH RECURSIVE seq (n) AS ( -- non recursive term SELECT 1 AS n UNION ALL -- recursive term SELECT n + 1 FROM seq WHERE n < 100 ) SELECT n FROM seq; 25

Recursive CTEs - Sequence WITH RECURSIVE seq (n) AS ( n -- non recursive term 1 SELECT 1 AS n 2 UNION ALL 3 4 -- recursive term SELECT n + 1 5 FROM seq ... WHERE n < 100 100 ) SELECT n FROM seq; 25

Recursive CTEs - Fibonacci Seq. WITH RECURSIVE fib (i, j) AS ( -- non recursive term SELECT 0, 1 UNION ALL -- recursive term SELECT GREATEST(i, j), (i + j) AS i FROM fib WHERE j < 1000 ) SELECT i FROM fib; 26

Recursive CTEs - Fibonacci Seq. WITH RECURSIVE fib (i, j) AS ( i -- non recursive term 0 SELECT 0, 1 1 1 UNION ALL 2 -- recursive term 5 SELECT GREATEST(i, j), 8 (i + j) AS i FROM fib 13 WHERE j < 1000 21 ) ... SELECT i FROM fib; 26

Recursive CTEs CREATE TABLE orgchart ( emp VARCHAR(10) PRIMARY KEY, boss VARCHAR(10) REFERENCES orgchart(emp), salary DECIMAL(10,2) ); INSERT INTO orgchart (emp, boss, salary) VALUES (‘A’, NULL, 1000.00), (‘B’, ‘A’, 900.00), (‘C’, ‘A’, 900.00), (‘D’, ‘C’, 800.00), A (‘E’, ‘C’, 700.00), (‘F’, ‘C’, 600.00), (‘G’, ‘B’, 800.00); B C G D E F 27

Recursive CTEs CREATE TABLE orgchart ( emp VARCHAR(10) PRIMARY KEY, boss VARCHAR(10) REFERENCES orgchart(emp), salary DECIMAL(10,2) emp boss salary ); A NULL 1000.00 INSERT INTO orgchart B A 900.00 (emp, boss, salary) VALUES C A 900.00 (‘A’, NULL, 1000.00), D C 800.00 (‘B’, ‘A’, 900.00), E C 700.00 (‘C’, ‘A’, 900.00), F C 600.00 (‘D’, ‘C’, 800.00), A G B 800.00 (‘E’, ‘C’, 700.00), (‘F’, ‘C’, 600.00), (‘G’, ‘B’, 800.00); B C G D E F 27

Recursive CTEs WITH RECURSIVE hierarchy AS ( -- non recursive term SELECT * FROM orgchart WHERE boss IS NULL UNION ALL -- recursive term SELECT E1.* FROM orgchart AS E1 JOIN hierarchy AS E2 ON E1.boss = E2.emp ) SELECT * FROM hierarchy ORDER BY emp; 28

Recursive CTEs WITH RECURSIVE hierarchy AS ( -- non recursive term SELECT * FROM orgchart emp boss salary WHERE boss IS NULL A NULL 1000.00 UNION ALL B A 900.00 -- recursive term C A 900.00 SELECT E1.* FROM orgchart AS E1 D C 800.00 JOIN hierarchy AS E2 E C 700.00 ON E1.boss = E2.emp F C 600.00 ) G B 800.00 SELECT * FROM hierarchy ORDER BY emp; 28

Recursive CTEs WITH RECURSIVE hierarchy AS ( SELECT *, 1 AS lvl, CAST(emp AS TEXT) AS tree, emp || ‘.’ AS path FROM orgchart WHERE boss IS NULL UNION ALL SELECT E1.*, E2.lvl + 1 AS lvl, LPAD(E1.emp, lvl * 2, ‘ ’) AS tree, E2.path || E1.emp || ‘.’ AS path FROM orgchart JOIN hierarchy AS E2 ON E1.boss = E2.emp ) SELECT * FROM hierarchy ORDER BY path; 29

Recursive CTEs WITH RECURSIVE hierarchy AS ( SELECT *, emp boss lvl,salary 1 AS lvl tree path CAST(emp AS TEXT) AS tree, A NULL|| ‘.’ AS path 1 emp 1000.00 A A. FROM orgchart B A 900.00 WHERE boss IS NULL 2 B A.B. UNION ALL G B SELECT E1.*, 800.00 3 G A.B.G. E2.lvl + 1 AS lvl, C LPAD(E1.emp, lvl * 2, ‘ ’) AS tree, A 900.00 2 C A.C. E2.path || E1.emp || ‘.’ AS path D FROM orgchart 800.00 C 3 D A.C.D. JOIN hierarchy AS E2 E ON E1.boss =700.00 C E2.emp 3 E A.C.E. ) SELECT * F C 600.00 3 F A.C.F. FROM hierarchy ORDER BY path; 29

Recursive CTEs WITH RECURSIVE hierarchy AS ( SELECT *, 1 AS lvl, CAST(emp AS TEXT) AS tree FROM orgchart WHERE boss = ‘A’ UNION ALL SELECT E1.*, E2.lvl + 1 AS lvl, LPAD(E1.emp, depth * 2, ‘ ’) AS tree FROM orgchart JOIN hierarchy AS E2 ON E1.boss = E2.emp WHERE E2.lvl < 3 -- termination condition ) SELECT * FROM hierarchy ORDER BY path; 30

Transitive Closure 31

Transitive Closure 1 2 1 3 2 1 31

Transitive Closure with CTEs WITH RECURSIVE transitive_closure (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges UNION ALL SELECT tc.a, e.b, tc.distance + 1, tc.path_string || e.b || '.' AS path_string FROM edges AS e JOIN transitive_closure AS tc ON e.a = tc.b WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' ) SELECT * FROM transitive_closure ORDER BY a, b, distance; 32

Transitive Closure with CTEs WITHa RECURSIVE transitive_closure (a, path_string b distance b, distance, path_string) AS 1 3 1 ( SELECT a, b, 1 AS distance, .1.3. '.' || a || '.' || b || '.' AS path_string FROM edges 4 1 2 .1.3.4. UNION ALL 5 1 2 .1.3.5. 1 6 2 .1.3.6. SELECT tc.a, e.b, tc.distance + 1, tc.path_string || e.b || '.' AS path_string 1 6 FROM edges AS e 3 .1.3.5.6. JOIN transitive_closure AS tc 1 ON e.a = tc.b 7 3 .1.3.4.7. WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' ) 2 1 1 .2.1. SELECT * FROM transitive_closure ... BY a, b, distance; ... ORDER ... ... 32

Travel Planning: Possible Routes 33

Travel Planning: Possible Routes WITH RECURSIVE transitive_closure (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges WHERE a = 1 -- source UNION ALL SELECT tc.a, e.b, tc.distance + 1, tc.path_string || e.b || '.' AS path_string FROM edges AS e JOIN transitive_closure AS tc ON e.a = tc.b WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' ) SELECT * FROM transitive_closure WHERE b = 6 -- destination ORDER BY a, b, distance; 34

Travel Planning: Possible Routes WITH RECURSIVE transitive_closure (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges WHERE a = 1 -- source a UNION ALL b distance path_string SELECT tc.a, e.b, tc.distance + 1, 1 tc.path_string ||2e.b || '.' AS path_string 6 .1.3.6. FROM edges AS e JOIN transitive_closure 3 tc ON e.a = tc.b 1 6 AS .1.3.5.6. WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' ) SELECT * FROM transitive_closure WHERE b = 6 -- destination ORDER BY a, b, distance; 34

LinkedIN: Degrees of Separation 35

LinkedIN: Degrees of Separation WITH RECURSIVE transitive_closure (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges2 WHERE a = 1 UNION ALL SELECT tc.a, e.b, tc.distance + 1, tc.path_string || e.b || '.' AS path_string FROM edges2 AS e JOIN transitive_closure AS tc ON e.a = tc.b WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' ) SELECT a, b, MIN(distance) AS dist FROM transitive_closure --WHERE b = 6 (or where name matches pattern) GROUP BY a, b ORDER BY a, dist, b; 36

LinkedIN: Degrees of Separation WITH RECURSIVE transitive_closure (a, b, distance, path_string) AS a b ( SELECT a, b, 1 AS distance, dist '.' || a || '.' || b || '.' AS path_string 1 FROM edges2 2 1 WHERE a = 1 UNION 1ALL 3 1 SELECT1 tc.a, e.b, tc.distance + 1, 5 1 tc.path_string || e.b || '.' AS path_string 1 FROM edges2 AS e 6 1 JOIN transitive_closure AS tc ON e.a = tc.b WHERE tc.path_string NOT 4 1 2 LIKE '%.' || e.b || '.%' ) ... ... ... SELECT a, b, MIN(distance) AS dist FROM transitive_closure --WHERE b = 6 (or where name matches pattern) GROUP BY a, b ORDER BY a, dist, b; 36

LinkedIN: Shared Nodes 37

LinkedIN: Shared Nodes (1) SELECT b FROM ( [SELECT b FROM transitive_closure] WHERE a = 1 -- set the starting node (node1) ... WHERE distance = 0 -- limit the recursion to the first step UNION ALL [SELECT b FROM transitive_closure] WHERE a = 4 -- set the other starting node (node4) ... WHERE distance = 0 -- limit the recursion to the first step ) AS immediate_connections GROUP BY b HAVING COUNT(b) > 1; 38

LinkedIN: Shared Nodes (2) SELECT b FROM ( SELECT b FROM edges2 WHERE a = 1 -- set the starting node (node1) UNION ALL SELECT b FROM edges2 WHERE a = 4 -- set the other starting node (node4) ) AS immediate_connections GROUP BY b HAVING COUNT(b) > 1; 39

LinkedIN: Shared Nodes (3) SELECT e.b FROM edges2 AS e WHERE e.a = 1 -- node1 AND EXISTS ( SELECT * FROM edges2 AS e2 WHERE e2.a = 4 -- node4 AND e2.b = e.b ) 40

LinkedIN: Shared Nodes (4) A’s B’s connections connections 41

LinkedIN: Shared Nodes (4) A’s B’s connections connections shared connections 41

LinkedIN: Shared Nodes (4) SELECT b FROM edges2 WHERE a = 1 INTERSECT SELECT b FROM edges2 WHERE a = 4 A’s B’s connections connections shared connections 41

LinkedIN: How is connected to you 42

LinkedIN: How is connected to you you n2 43

LinkedIN: How is connected to you WITH RECURSIVE tc (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges2 WHERE a = 8 -- set the target node UNION ALL SELECT tc.a, e.b, tc.distance + 1, tc.path_string || e.b || '.' AS path_string FROM edges2 AS e JOIN tc ON e.a = tc.b WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' AND e.b <> 1 AND tc.distance < 5 ) SELECT b AS immediate_connection, MIN(distance) + 1 AS distance_via_node FROM tc WHERE EXISTS (SELECT * FROM edges2 WHERE a = 1 AND b = tc.b) GROUP BY b HAVING MIN(distance) > 1 ORDER BY b 44

LinkedIN: How is connected to you WITH RECURSIVE tc (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges2 WHERE a = 8 -- set the target node UNION ALL SELECT tc.a, e.b, tc.distance + 1, tc.path_string || e.b || '.' AS path_string FROM edges2 AS e JOIN tc ON e.a = tc.b WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' AND e.b <> 1 you AND tc.distance < 5 ) SELECT b AS immediate_connection, MIN(distance) + 1 AS distance_via_node FROM tc WHERE EXISTS (SELECT * FROM edges2 WHERE a = 1 AND b = tc.b) GROUP BY b HAVING MIN(distance) > 1 ORDER BY b 44

LinkedIN: How is connected to you WITH RECURSIVE tc (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges2 WHERE a = 8 -- set the target node UNION ALL SELECT tc.a, e.b, tc.distance + 1, tc.path_string || e.b || '.' AS path_string FROM edges2 AS e JOIN tc ON e.a = tc.b WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' AND e.b <> 1 AND tc.distance < 5 ) SELECT b AS immediate_connection, MIN(distance) + 1 AS distance_via_node FROM tc WHERE EXISTS (SELECT * FROM edges2 WHERE a = 1 AND b = tc.b) GROUP BY b you HAVING MIN(distance) > 1 ORDER BY b 44

LinkedIN: How is connected to you WITH RECURSIVE tc (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges2 immediate_connection distance_via_node WHERE a = 8 -- set the target node UNION ALL 2 SELECT tc.a, e.b, tc.distance + 1, 4 tc.path_string || e.b || '.' AS path_string FROM edges2 AS 3 4 you e JOIN tc ON e.a = tc.b n2 5 4 WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' AND e.b <> 1 ) 6 AND tc.distance < 5 3 SELECT b AS immediate_connection, MIN(distance) + 1 AS distance_via_node FROM tc WHERE EXISTS (SELECT * FROM edges2 WHERE a = 1 AND b = tc.b) GROUP BY b HAVING MIN(distance) > 1 ORDER BY b 44

Facebook: You might also know 45

Facebook: You might also know you 45

Facebook: You might also know (1) WITH RECURSIVE transitive_closure (a, b, distance, path_string) AS ( SELECT a, b, 1 AS distance, '.' || a || '.' || b || '.' AS path_string FROM edges2 WHERE a = 1 -- set the starting node UNION ALL SELECT tc.a, e.b, tc.distance + 1, tc.path_string || e.b || '.' AS path_string FROM edges2 AS e JOIN transitive_closure AS tc ON e.a = tc.b WHERE tc.path_string NOT LIKE '%.' || e.b || '.%' AND tc.distance < 2 ) SELECT a, b FROM transitive_closure GROUP BY a, b HAVING MIN(distance) = 2 -- select nodes 2 steps away 46

Facebook: You might also know (2) SELECT a AS you, b AS might_know, CASE WHEN n1.feat1 = n2.feat1 THEN 'feat1' WHEN n1.feat2 = n2.feat2 THEN 'feat2' ELSE 'nothing' END AS common_feature FROM ( CTE for nodes 2 steps away (previous slide) ) AS youmightknow LEFT JOIN nodes AS n1 ON youmightknow.a = n1.id LEFT JOIN nodes AS n2 ON youmightknow.b = n2.id WHERE n1.feat1 = n2.feat1 OR n1.feat2 = n2.feat2; 47

Facebook: You might also know (2) SELECT a AS you, b AS might_know, CASE WHEN n1.feat1 = n2.feat1 THEN 'feat1' WHEN n1.feat2 = n2.feat2 THEN 'feat2' ELSE 'nothing' END AS common_feature FROM ( you might_know common_feature 1 7 feat1 CTE for nodes 2 steps away (previous slide) 1 13 ) AS youmightknow feat2 LEFT JOIN nodes AS n1 ON youmightknow.a = n1.id LEFT JOIN nodes AS n2 ON youmightknow.b = n2.id WHERE n1.feat1 = n2.feat1 OR n1.feat2 = n2.feat2; 47

Window Functions 48

Sample Table company id emp dept salary 1 Robert Management 2500 2 Jane Sales 1800 3 Dave Sales 1700 4 Clare Development 1900 5 Richard Development 1500 6 Simon Development 1850 7 Elizabeth Tech Support 1350 8 Dylan Tech Support 1450 ... ... ... ... 49

Aggregates SELECT dept, AVG(salary) FROM company GROUP BY dept dept AVG(salary) Management 2500 Sales 1750 Development 1750 Tech Support 1400 50

Window Functions (SQL-2003) SELECT id, emp, dept, salary, SUM(salary) OVER (PARTITION BY dept) FROM company id emp dept salary SUM(salary) 1 Robert Management 2500 2500 2 Jane Sales 1800 3500 3 Dave Sales 1700 3500 4 Clare Development 1900 5250 5 Richard Development 1500 5250 6 Simon Development 1850 5250 7 Elizabeth Tech Support 1350 2800 8 Dylan Tech Support 1450 2800 51

Window Functions (SQL-2003) SELECT id, emp, dept, salary, ROUND(salary - AVG(salary) OVER (PARTITION BY dept), 0) AS diff_avg_dept FROM company id emp dept salary diff_avg_dept 1 Robert Management 2500 0 2 Jane Sales 1800 50 3 Dave Sales 1700 -50 4 Clare Development 1900 150 5 Richard Development 1500 -250 6 Simon Development 1850 100 7 Elizabeth Tech Support 1350 -50 8 Dylan Tech Support 1450 50 52

Window Functions (SQL-2003) row_number() avg() rank() corr() dense_rank() first() percent_rank() max() cume_dist() min() ntile() last() lag() sum() lead() stddev() first_value() variance() last_value() ... nth_value() 53

Window Functions Syntax function (args) OVER ( [partition clause] [order by clause] [frame clause] ) 54

Window Functions Syntax function (args) OVER ( [partition clause] [order by clause] [frame clause] ) PARTITION BY expr, ... (if empty, over the entire result set) 54

Window Functions Syntax function (args) OVER ( [partition clause] [order by clause] [frame clause] ) ORDER BY expr [ASC|DESC] [NULLS FIRST|LAST], ... (useful for order and ranking functions) 54

Window Functions Syntax function (args) OVER ( [partition clause] [order by clause] [frame clause] ) (ROWS|RANGE) [BETWEEN (UNBOUNDED|expr) (PRECEDING|FOLLOWING) AND] CURRENT ROW 54

Window Functions Syntax function (args) OVER ( [partition clause] [order by clause] [frame clause] ) 54

Named Windows and Ranking SELECT emp, dept, salary, row_number() OVER w, rank() OVER w, dense_rank() OVER w FROM company WINDOW w AS (ORDER BY salary DESC) ORDER BY salary DESC emp dept salary row_number rank dense_rank Robert Management 2500 1 1 1 Clare Development 1900 2 2 2 Simon Development 1800 3 3 3 Jane Sales 1800 4 3 3 Dave Sales 1700 5 5 4 Richard Development 1500 6 6 5 Dylan Tech Support 1450 7 7 6 Elizabeth Tech Support 1350 8 8 7 55

Cumulative Sum SELECT id, customer, article, price, SUM(price) OVER (PARTITION BY customer ORDER BY purchase_date ROWS BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW) AS cumulative, SUM(price) OVER (PARTITION BY customer) AS tot_price FROM orders ORDER BY customer 56

Cumulative Sum id customer article price cumulative tot_price 1 1 hat 15.50 15.50 42.25 2 1 gloves 10.75 26.25 42.25 3 1 scarf 16.00 42.25 42.25 4 2 skirt 39.90 39.90 86.00 5 2 white shirt 22.65 62.55 86.00 6 2 undies 23.45 86.00 86.00 7 3 trousers 33.85 33.85 140.83 8 3 black socks 5.99 39.84 140.83 9 3 belt 14.99 54.83 140.83 10 3 shoes 86.00 140.83 140.83 57

Multiple Partitions SELECT id, customer, article, price, SUM(price) OVER (PARTITION BY customer ORDER BY purchase_date ROWS BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW) AS cumulative, SUM(price) OVER (PARTITION BY customer) AS tot_price SUM(price) OVER (PARTITION BY article) AS tot_price_by_article FROM orders ORDER BY customer 58

Address Book 59

Address Book SELECT MIN(firstname) || ' - ' || MAX(firstname) AS name_range, TRUNC(rn / 250) + 1 AS chunk, COUNT(*) AS chunk_size, tot FROM ( SELECT firstname, row_number() OVER (ORDER BY firstname) - 1 rn, COUNT(*) OVER () AS tot FROM my_contacts ) AS f_names GROUP BY chunk, tot ORDER BY name_range 60

Address Book name_range chunk chunk_size tot Aaron - Anisha 1 250 5494 Anissa - Bethany 2 250 5494 Bethel - Caryn 3 250 5494 Casandra - Colene 4 250 5494 Coletta - Delois 5 250 5494 Deloise - Eleanore 6 250 5494 Elease - Felix 7 250 5494 ... ... ... ... Verdell - Zulma 22 244 5494 61

Address Book SELECT UPPER(SUBSTR(MIN(firstname), 1, 2)) || ' - ' || UPPER(SUBSTR(MAX(firstname), 1, 2)) AS name_range, ... name_range chunk chunk_size tot AA - AN 1 250 5494 AN - BE 2 250 5494 BE - CA 3 250 5494 ... ... ... ... VE - ZU 22 244 5494 62

Parting Thoughts... 63

Why Not To Do Stuff In The DB 64

Why To Do Stuff In The DB 65

Links & sources http://www.alberton.info/talks http://wiki.postgresql.org/wiki/CTEReadme http://msdn.microsoft.com/en-us/magazine/cc163346.aspx http://msdn.microsoft.com/en-us/library/ms190766.aspx http://en.wikipedia.org/wiki/Transitive_closure http://asktom.oracle.com/pls/asktom/f? p=100:11:0::::P11_QUESTION_ID:656006300346204826 http://www.sybase.it/detail?id=1037447 http://www.lorentzcenter.nl/awcourse/oracle/server.920/ a96540/functions2a.htm#81409 http://www.depesz.com/index.php/2009/01/21/waiting- for-84-window-functions/ http://www.pgexperts.com/document.html?id=23 [PDF] http://www.java2s.com/Tutorial/Oracle/0320__Analytical- Functions/Movingaverage.htm 66

Image credits http://en.wikipedia.org/wiki/Hall–Janko_graph http://www.flickr.com/photos/bounder/315179191/ http://www.flickr.com/photos/piet_musterd/394001824/ http://www.flickr.com/photos/eyefruit/179553810/ http://www.flickr.com/photos/roach-family/182395939/ http://www.flickr.com/photos/nathangibbs/98592171/ http://www.flickr.com/photos/jefthomas/1265577154/ http://icanhascheezburger.com/2009/01/20/funny-pictures- teh-internets/ 67

Questions ? 68

Thank you! Contact details: lorenzo@ibuildings.com http://www.alberton.info/talks http://joind.in/1451
