Tatsumaki
non-blocking web framework built on Plack/AnyEvent

                Tatsuhiko Miyagawa
    Nov. 30th, 2009 / Shi...
PSGI
Perl Web Server
Gateway Interface
Python’s WSGI
 Ruby’s Rack
my $app = sub {
   my $env = shift;
   return [ $status, $headers, $body ];
};
Plain Old Perl
Servers
         CGI, FastCGI, mod_perl1&2
  Standalone, Prefork, AnyEvent, Coro, POE,
Danga::Socket, nginx, mod_psgi, evh...
Frameworks
Catalyst, Mason, Maypole, CGI::Application, Jifty
 Dancer, HTTP::Engine, Sqauatting, Continuity
  WebGUI, Movab...
Middleware
Static, ConditionalGET, AccessLog, Chunked, Deflater,
    NYTProf, FCGIDispatcher, JSONP, StackTrace,
      Auth...
Servers
         CGI, FastCGI, mod_perl1&2
  Standalone, Prefork, AnyEvent, Coro, POE,
Danga::Socket, nginx, mod_psgi, evh...
Non-blocking?
psgi.streaming
# delayed response
my $app = sub {
  my $env = shift;
  return sub {
   my $respond = shift;
   $respond->([ $status, $hea...
# streaming content
my $app = sub {
  my $env = shift;
  return sub {
   my $respond = shift;
   my $w = $respond->([ $sta...
WARNING
         psgi.streaming is an interface
Servers may not work if event loop is not shared
  (Recommended to use Any...
Frameworks?
Most frameworks do not
support non-blocking interface.
     (Mojo 0.99 has IOLoop and Client)
Let’s make one!
Tatsumaki

    http://www.flickr.com/photos/88699006@N00/679056142/
Port of Tornado
Plack and AnyEvent
   All the way from the bottom to the top
Handle thousands of connections with EV/epoll
Works with
AnyEvent, POE, Coro, Danga::Socket and perlbal
            Because it’s AnyEvent!
You can use
Any of AnyEvent::* libraries to do
asynchronous tasks (unlike Mojo)
The first and only framework
  that uses psgi.streaming
package MainHandler;
use base qw(Tatsumaki::Handler);

sub get {
  my $self = shift;
  $self->write(“Hello World”);
}

pac...
Tatsumaki::HTTPClient
        AnyEvent::HTTP wrapper
  non-blocking HTTP client for Tatsumaki
package HTTPClientHandler;
use base qw(Tatsumaki::Handler);
__PACKAGE__->asynchronous(1);

use Tatsumaki::HTTPClient;

sub...
Long-poll (comet)
package AsyncHandler;
use base qw(Tatsumaki::Handler);
__PACKAGE__->asynchronous(1);

sub get {
  my $self = shift;
  my $...
Tatsumaki::MessageQueue
    Pure perl MQ (in AnyEvent)
package LongPollHandler;
use base qw(Tatsumaki::Handler);
__PACKAGE__->asynchronous(1);

use Tatsumaki::MessageQueue;

sub...
package EventPostHandler;
use base qw(Tatsumaki::Handler);

sub post {
  my $self = shift;
  my $mq = Tatsumaki::MessageQu...
Multipart XHR
JavaScript hack to emulate server push
package MXHRPollHandler;
use base qw(Tatsumaki::Handler);
__PACKAGE__->asynchronous(1);

use Tatsumaki::MessageQueue;

sub...
JS Client libraries
       jquery.ev
      DUI.Stream
       raphaeljs
DEMO
http://192.168.100.50:5000/chat/demo
Other apps
            github.com/gugod/Social
        github.com/miyagawa/Subfeedr
         github.com/audreyt/socialcalc...
WHY
Web server resource
I/O bound
!CPU bound
I/O bound web apps
  HTTP API proxy (e.g. OpenSocial)
     Mash up (XML, REST API)
     Real-time Web (Comet)
CPU bound jobs
       Database Servers
 Job Workers (TheSchwartz etc.)
Tatsumaki for
I/O bound web
✓ Non-blocking HTTP client
 ✓ Pure perl Message Queue
 ✓ I/O libraries (AnyEvent::*)
✓ DB libraries (AnyEvent::DBI)
✓ Job ...
Status
 0.1.x on CPAN, considered beta
AnyEvent server has bugs on Linux
Plans
Tatsumaki::Service
Inspired by Google AppEngine Email/XMPP service
               Webhook pattern
XMPP/IRC
Write Jabber/IRC bot as a web application
# see Tatsumaki-Service-XMPP/eg/translate.psgi
package XMPPTranslateHandler;
use base qw(Tatsumaki::Handler::XMPP);

sub p...
Standard Comet Interface
        a.k.a Stardust
Bayeux
HTTP push relay
“Real” PubSub interface
  for Tatsumaki::MQ
Pluggable MQ
using “real” MQ like ActiveMQ or RabbitMQ
DataStore interface
   using AnyEvent::DBI, Redis etc.
See Subfeedr
for Redis integration
  http://github.com/miyagawa/Subfeedr
cpan> install Tatsumaki
http://github.com/miyagawa/Tatsumaki
         irc://irc.perl.org/#plack
That’s it!
Questions?
Tatsumaki
Upcoming SlideShare
Loading in...5
×

Tatsumaki

13,970

Published on

Published in: Technology
1 Comment
17 Likes
Statistics
Notes
No Downloads
Views
Total Views
13,970
On Slideshare
0
From Embeds
0
Number of Embeds
3
Actions
Shares
0
Downloads
41
Comments
1
Likes
17
Embeds 0
No embeds

No notes for slide
  • Transcript of "Tatsumaki"

    1. 1. Tatsumaki non-blocking web framework built on Plack/AnyEvent Tatsuhiko Miyagawa Nov. 30th, 2009 / Shibuya.pm Tech Talks #12
    2. 2. PSGI
    3. 3. Perl Web Server Gateway Interface
    4. 4. Python’s WSGI Ruby’s Rack
    5. 5. my $app = sub { my $env = shift; return [ $status, $headers, $body ]; };
    6. 6. Plain Old Perl
    7. 7. Servers CGI, FastCGI, mod_perl1&2 Standalone, Prefork, AnyEvent, Coro, POE, Danga::Socket, nginx, mod_psgi, evhttpd, Perlbal
    8. 8. Frameworks Catalyst, Mason, Maypole, CGI::Application, Jifty Dancer, HTTP::Engine, Sqauatting, Continuity WebGUI, Movable Type, Ark, Angelos, Noe
    9. 9. Middleware Static, ConditionalGET, AccessLog, Chunked, Deflater, NYTProf, FCGIDispatcher, JSONP, StackTrace, Auth::Basic, XSendfile, Rewrite, JSConcat ...
    10. 10. Servers CGI, FastCGI, mod_perl1&2 Standalone, Prefork, AnyEvent, Coro, POE, Danga::Socket, nginx, mod_psgi, evhttpd, Perlbal
    11. 11. Non-blocking?
    12. 12. psgi.streaming
    13. 13. # delayed response my $app = sub { my $env = shift; return sub { my $respond = shift; $respond->([ $status, $headers, $body ]); };
    14. 14. # streaming content my $app = sub { my $env = shift; return sub { my $respond = shift; my $w = $respond->([ $status, $headers ]); some_event_loop(sub { $w->write($content); $w->close; }); };
    15. 15. WARNING psgi.streaming is an interface Servers may not work if event loop is not shared (Recommended to use AnyEvent in your app)
    16. 16. Frameworks?
    17. 17. Most frameworks do not support non-blocking interface. (Mojo 0.99 has IOLoop and Client)
    18. 18. Let’s make one!
    19. 19. Tatsumaki http://www.flickr.com/photos/88699006@N00/679056142/
    20. 20. Port of Tornado
    21. 21. Plack and AnyEvent All the way from the bottom to the top Handle thousands of connections with EV/epoll
    22. 22. Works with AnyEvent, POE, Coro, Danga::Socket and perlbal Because it’s AnyEvent!
    23. 23. You can use Any of AnyEvent::* libraries to do asynchronous tasks (unlike Mojo)
    24. 24. The first and only framework that uses psgi.streaming
    25. 25. package MainHandler; use base qw(Tatsumaki::Handler); sub get { my $self = shift; $self->write(“Hello World”); } package main; use Tatsumaki::Application; my $app = Tatsumaki::Application->new([ ‘/’ => ‘MainHandler’, ]);
    26. 26. Tatsumaki::HTTPClient AnyEvent::HTTP wrapper non-blocking HTTP client for Tatsumaki
    27. 27. package HTTPClientHandler; use base qw(Tatsumaki::Handler); __PACKAGE__->asynchronous(1); use Tatsumaki::HTTPClient; sub get { my $self = shift; my $client = Tatsumaki::HTTPClient->new; $client->get($api_url, sub { my $res = shift; my $body = $res->content; $self->write(...); $self->finish; }); }
    28. 28. Long-poll (comet)
    29. 29. package AsyncHandler; use base qw(Tatsumaki::Handler); __PACKAGE__->asynchronous(1); sub get { my $self = shift; my $t; $t = AE::timer 3, 0, sub { undef $t; $self->write(“Hello World”); $self->finish; }); } package main; use Tatsumaki::Application; my $app = Tatsumaki::Application->new([ ‘/’ => ‘AsyncHandler’, ]);
    30. 30. Tatsumaki::MessageQueue Pure perl MQ (in AnyEvent)
    31. 31. package LongPollHandler; use base qw(Tatsumaki::Handler); __PACKAGE__->asynchronous(1); use Tatsumaki::MessageQueue; sub get { my $self = shift; my $mq = Tatsumaki::MessageQueue- >instance(‘ch-name’); $mq->poll_once($client_id, sub { my @events = @_; $self->write(@events); $self->finish; }); }
    32. 32. package EventPostHandler; use base qw(Tatsumaki::Handler); sub post { my $self = shift; my $mq = Tatsumaki::MessageQueue- >instance(‘ch-name’); $mq->publish({ name => “NewComment”, ... }); $self->write({ success => 1 }); }
    33. 33. Multipart XHR JavaScript hack to emulate server push
    34. 34. package MXHRPollHandler; use base qw(Tatsumaki::Handler); __PACKAGE__->asynchronous(1); use Tatsumaki::MessageQueue; sub get { my $self = shift; $self->multipart_xhr_push(1); my $mq = Tatsumaki::MessageQueue- >instance(‘ch-name’); $mq->poll($client_id, sub { my @events = @_; $self->stream_write(@events); }); }
    35. 35. JS Client libraries jquery.ev DUI.Stream raphaeljs
    36. 36. DEMO
    37. 37. http://192.168.100.50:5000/chat/demo
    38. 38. Other apps github.com/gugod/Social github.com/miyagawa/Subfeedr github.com/audreyt/socialcalc github.com/clkao/Finance-GeniusTrader-Chart github.com/lestrrat/Hamaki github.com/yusukebe/Nagare
    39. 39. WHY
    40. 40. Web server resource
    41. 41. I/O bound !CPU bound
    42. 42. I/O bound web apps HTTP API proxy (e.g. OpenSocial) Mash up (XML, REST API) Real-time Web (Comet)
    43. 43. CPU bound jobs Database Servers Job Workers (TheSchwartz etc.)
    44. 44. Tatsumaki for I/O bound web
    45. 45. ✓ Non-blocking HTTP client ✓ Pure perl Message Queue ✓ I/O libraries (AnyEvent::*) ✓ DB libraries (AnyEvent::DBI) ✓ Job dispatcher (AE::Gearman)
    46. 46. Status 0.1.x on CPAN, considered beta AnyEvent server has bugs on Linux
    47. 47. Plans
    48. 48. Tatsumaki::Service Inspired by Google AppEngine Email/XMPP service Webhook pattern
    49. 49. XMPP/IRC Write Jabber/IRC bot as a web application
    50. 50. # see Tatsumaki-Service-XMPP/eg/translate.psgi package XMPPTranslateHandler; use base qw(Tatsumaki::Handler::XMPP); sub post { my $self = shift; my $msg = $self->xmpp_message; my $uri = “http://ajax.googleapis.com/...”; my $client = Tatsumaki::HTTPClient->new; $client->get($uri, $self->async_cb(sub { my $res = shift; my $r = JSON::decode_json($res->content); $msg->reply($r->{translatedText}); $self->finish; })); }
    51. 51. Standard Comet Interface a.k.a Stardust
    52. 52. Bayeux HTTP push relay
    53. 53. “Real” PubSub interface for Tatsumaki::MQ
    54. 54. Pluggable MQ using “real” MQ like ActiveMQ or RabbitMQ
    55. 55. DataStore interface using AnyEvent::DBI, Redis etc.
    56. 56. See Subfeedr for Redis integration http://github.com/miyagawa/Subfeedr
    57. 57. cpan> install Tatsumaki http://github.com/miyagawa/Tatsumaki irc://irc.perl.org/#plack
    58. 58. That’s it! Questions?
