Escape from North America:Elastix localization for the world!
Agenda• What might we want to change?• Where can we change it?• How can we change it?• But first, a quick test...
A bit about me...• Chartered Engineer• Telecoms for the last 20+ years...• A firm belief that Telecoms is fun• Background ...
A bit about TeleSpeak...• Founded in 2006• Located close to Oxford, UK• Whole business is focussed around Asterisk  – Elas...
HOW TO LOCALISE YOUR  IMPLEMENTATIONS
What might we need          to change?• System prompts         • Telephony interfaces  – (language, accent)     – (physica...
Let’s start with tones
Let’s start with tones• Tones – IP devices (e.g. SIP)• Tones – analogue channels• Tones – internal calls
Where do we change         those tones?• Tones – IP channels (SIP phones, ATAs)  – On the device!!• Tones – analogue chann...
The Linux file system           /   bin        The /etc/asterisk directory is created               boot       when Asteri...
Time and date localisation• Actual time and date for the system is set  in Linux• Asterisk can be made aware of many time ...
Where can you change      times and dates?• When would you need to do this?• It mainly comes down to voicemail!!!  – Accor...
Where can you change         times and dates?/etc/asterisk/voicemail.conf[zonemessages]central=America/Chicago|vm-received...
Changing the language (or accent) of system prompts• By default Asterisk stores system prompts  (sound files) in /var/lib/...
Changing the language (or accent) of system prompts• E.g.  – /var/lib/asterisk/sounds/en/ for English  – /var/lib/asterisk...
So where do you specify       the language?• In the channel...• So for SIP, it would be in sip.conf (or  sip_xxxxxxx.conf•...
Specifying the language          in the Channel/etc/asterisk/sip.conf[general]language=escontext=custom-internaldeny=0.0.0...
Specifying the language          in the Dialplan/etc/asterisk/extensions_custom.conf (the dialplan)[custom-internal]exten ...
What about Caller ID?• Many different formats around the world• In the UK we use V23 (FSK)• Asterisk can be made to unders...
Setting the Caller ID format /etc/asterisk/chan_dahdi.conf or dahdi-channels.conf group=1 signalling=fxo_ks cidsignalling=...
Telephony Interfaces• Physical characteristics• Electrical characteristics  – UK uses 50V DC to power phones  – UK uses 75...
Basic telephonyFXS - Station                        FXO – Office
Physical characteristics             Hybrid Speaker                        Telephone Line                        with an i...
Digium Analog Interfaces
Basic rate interface (BRI)          B1   B2   D         B = Bearer         D = Data
Primary rate interfaces     (PRI) – North AmericaT1                  1 frame = 125 s x 24 time slots + 1 fb = 1.544 Mbps20...
Primary rate interfaces (PRI) – Everywhere else...E1                        1 frame = 125 s x 32 time slots = 2.048 Mbps31...
Observe the Protocol
Digium Digital Interfaces
PRI connectorisation• What is the impedance of the line?   – Europe 120 ohm, North America 100 ohm commonly       • Typica...
We all need approval• To connect equipment to the national PSTN, approval is often  required• Digium hardware is approved ...
Questions or comments?
Recap• What might we want to change?  – Language or accent of prompts, time zone  – Tones, telephony interfaces• Where can...
http://ofps.oreilly.com/titles/9780596517342/  Table 9.1. Internationalization cheat sheet                      What to ch...
May all your Elastixdeployments feel at home!
TeleSpeak        Trainingdavid.duffett@telespeak.co.uk      Thank you
Upcoming SlideShare
Loading in...5
×

Making asterisk feel like home outside north america

2,070

Published on

David Duffett
UK
TeleSpeak
8th Conference - ElastixWorld 2011
Making asterisk feel like home outside north america
Haciendo sentir a Asterisk como en casa fuera de Norte América

Published in: Technology
1 Comment
0 Likes
Statistics
Notes
  • David Duffett
    UK
    TeleSpeak
    8th Conference - ElastixWorld 2011
    Making asterisk feel like home outside north america
    Haciendo sentir a Asterisk como en casa fuera de Norte América
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
  • Be the first to like this

No Downloads
Views
Total Views
2,070
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
70
Comments
1
Likes
0
Embeds 0
No embeds

No notes for slide

Transcript of "Making asterisk feel like home outside north america"

  1. 1. Escape from North America:Elastix localization for the world!
  2. 2. Agenda• What might we want to change?• Where can we change it?• How can we change it?• But first, a quick test...
  3. 3. A bit about me...• Chartered Engineer• Telecoms for the last 20+ years...• A firm belief that Telecoms is fun• Background in Civil Aviation air-ground comms, Wireless Local Loop, Computer Telephony• Qualified trainer• dCAP qualified Asterisk specialist• Contributed the ‗Internationalization‘ chapter (9) to Asterisk: The Definitive Guide
  4. 4. A bit about TeleSpeak...• Founded in 2006• Located close to Oxford, UK• Whole business is focussed around Asterisk – Elastix Training Partner – Digium Authorised Training Partner – Xorcom certified Distributor/Support Specialist • Permanent Asterisk Training Facility – Consultancy – Support
  5. 5. HOW TO LOCALISE YOUR IMPLEMENTATIONS
  6. 6. What might we need to change?• System prompts • Telephony interfaces – (language, accent) – (physical and• Caller ID electrical) – (reception and • Times and dates transmission) – (not only the actual• Tones time zone, but the way times and dates are – (generation and read out) recognition)
  7. 7. Let’s start with tones
  8. 8. Let’s start with tones• Tones – IP devices (e.g. SIP)• Tones – analogue channels• Tones – internal calls
  9. 9. Where do we change those tones?• Tones – IP channels (SIP phones, ATAs) – On the device!!• Tones – analogue channels – /etc/dahdi/system.conf • loadzone = uk • defaultzone = uk• Tones – internal calls – /etc/asterisk/indications.conf • country = uk
  10. 10. The Linux file system / bin The /etc/asterisk directory is created boot when Asterisk is installed dev etc asterisk home extensions.conf lib lost+found indications.conf media dahdi** sip.conf misc chan_dahdi.conf mntWhere net **system.conf lives in the /etc/dahdi directory as it is not part of Asterisk opt proc This is the home directory of the ‘root’exactly? user – if you are logged in as ‘root’ and root (~) start a terminal from the graphical selinux environement, you will start in this directory srv The /usr/src directory is where we put the sys LibPRI, Zaptel and Asterisk tarballs tmp usr var src asterisk-1.6.x.x.tar.gz asterisk-1.6.x.x dahdi-linux-2.x.x.tar.gz dahdi-linux-2.x.x dahdi-tools-2.x.x.tar.gz dahdi-tools... libpri-1.x.x, dahdi-xxxx-2.x.x and Asterisk-1.x.x subdirectories will be created in /usr/src when we ‘untar’ the tarballs
  11. 11. Time and date localisation• Actual time and date for the system is set in Linux• Asterisk can be made aware of many time zones – These zones can be used to change the way times and dates are presented, and even spoken
  12. 12. Where can you change times and dates?• When would you need to do this?• It mainly comes down to voicemail!!! – Accordingly, configuration occurs in /etc/asterisk/voicemail.conf – The [zonemessages] section is where the timezone, time and date presentation and pronounciation are set – The voicemail context (e.g. [default]) is where each mailbox is assigned a zone, if required
  13. 13. Where can you change times and dates?/etc/asterisk/voicemail.conf[zonemessages]central=America/Chicago|vm-received Q digits/at IMpUK=Europe/London|vm-received a b d digits/at HM[default]809=>1234,David Duffett,dd@xyz.com,,tz=UK810=>0000,Mark Spencer,markster@digium.com,,tz=central
  14. 14. Changing the language (or accent) of system prompts• By default Asterisk stores system prompts (sound files) in /var/lib/asterisk/sounds• Within this directory sub-directories are used for the storage of differing prompts
  15. 15. Changing the language (or accent) of system prompts• E.g. – /var/lib/asterisk/sounds/en/ for English – /var/lib/asterisk/sounds/es/ for Spanish• Filenames need to be known to Asterisk – E.g. hello.gsm would contain • ―hello‖ in /var/lib/asterisk/sounds/en/hello.gsm • ―hola‖ in /var/lib/asterisk/sounds/es/hello.gsm
  16. 16. So where do you specify the language?• In the channel...• So for SIP, it would be in sip.conf (or sip_xxxxxxx.conf• For IAX2, it would be in iax.conf• For analogue or digital channels (connected by a Digium card) it would be in chan_dahdi.conf or dahdi-channels.conf• Or in the dialplan
  17. 17. Specifying the language in the Channel/etc/asterisk/sip.conf[general]language=escontext=custom-internaldeny=0.0.0.0/0[dd-phone]type=friendlanguage=fr/etc/asterisk/extensions_custom.conf (the dialplan)[custom-internal]exten => _6001,1,Playback(hello)
  18. 18. Specifying the language in the Dialplan/etc/asterisk/extensions_custom.conf (the dialplan)[custom-internal]exten => _6001,1,Playback(hello)[language-menu]exten => s,1,Background(choose_language); 1 for French, 2 for German, 3 for Spanishexten => s,n,WaitExten(5)exten => 1,1,Set(CHANNEL(language)=fr)exten => 2,1,Set(CHANNEL(language)=de)exten => 3,1,Set(CHANNEL(language)=es)exten => _[1-3],n,Goto(custom-internal,6001,1)
  19. 19. What about Caller ID?• Many different formats around the world• In the UK we use V23 (FSK)• Asterisk can be made to understand different types of Caller ID signalling• ...and to send it to analogue phones too!
  20. 20. Setting the Caller ID format /etc/asterisk/chan_dahdi.conf or dahdi-channels.conf group=1 signalling=fxo_ks cidsignalling=v23 ;BT standard cidstart=polarity ;start indication sendcalleridafter=2 ;the number ; of rings before sending the data context=from-analogue channel => 1-4 group=2 signalling=fxs_ks callerid=asreceived context=from-outside channel => 5-8
  21. 21. Telephony Interfaces• Physical characteristics• Electrical characteristics – UK uses 50V DC to power phones – UK uses 75v ac @ 75Hz to ring phones
  22. 22. Basic telephonyFXS - Station FXO – Office
  23. 23. Physical characteristics Hybrid Speaker Telephone Line with an impedance = YMicrophone Impedance = Z
  24. 24. Digium Analog Interfaces
  25. 25. Basic rate interface (BRI) B1 B2 D B = Bearer D = Data
  26. 26. Primary rate interfaces (PRI) – North AmericaT1 1 frame = 125 s x 24 time slots + 1 fb = 1.544 Mbps20 21 22 23 24 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 1 2 3 4 5 1 framing bit (fb) ISDN – NI2, AT&TT1 1 frame = 125 s x 24 time slots + 1 fb = 1.544 Mbps20 21 22 23 24 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 1 2 3 4 5 1 framing bit CAS – T1 robbed bit
  27. 27. Primary rate interfaces (PRI) – Everywhere else...E1 1 frame = 125 s x 32 time slots = 2.048 Mbps31 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 0framing signalling octet octet ISDN – Euro ISDN, QSIG CAS – MFC R2, E1LS
  28. 28. Observe the Protocol
  29. 29. Digium Digital Interfaces
  30. 30. PRI connectorisation• What is the impedance of the line? – Europe 120 ohm, North America 100 ohm commonly • Typically RJ45 connectors – Might be 75 ohm • Typically BNC connectors
  31. 31. We all need approval• To connect equipment to the national PSTN, approval is often required• Digium hardware is approved in many countries• If connecting to a internal PABX, approval is not required
  32. 32. Questions or comments?
  33. 33. Recap• What might we want to change? – Language or accent of prompts, time zone – Tones, telephony interfaces• Where can we change it? – Asterisk, DAHDI, or individual devices• How can we change it? – Configuration files in Asterisk or DAHDI – Web interface (or provisioning) for IP phones and ATAs
  34. 34. http://ofps.oreilly.com/titles/9780596517342/ Table 9.1. Internationalization cheat sheet What to change Where to change it •IP phones—on the phone itself Call progress tones •ATAs—on the ATA itself •Analog phones—DAHDI (/etc/dahdi/system.conf) DAHDI—/etc/dahdi/system.conf and Type of PRI/BRI and protocol /etc/asterisk/chan_dahdi.conf •Balun if required for PRI Physical PSTN connections •Get the analog pair to middle 2 pins of the RJ11 connecting to the Digium card Caller ID on analog circuits Asterisk—/etc/asterisk/chan_dahdi.conf •Channel—/etc/asterisk/sip.conf, /etc/asterisk/iax.conf, Prompt language and/or accent /etc/asterisk/chan_dahdi.conf, etc. •Dialplan—CHANNEL(language) function Voicemail time/date stamps and pronunciation Asterisk—/etc/asterisk/voicemail.conf Asterisk—/etc/asterisk/indications.conf Tones delivered by Asterisk
  35. 35. May all your Elastixdeployments feel at home!
  36. 36. TeleSpeak Trainingdavid.duffett@telespeak.co.uk Thank you
