Java EE 6 & GlassFish 3
1. <Insert Picture Here>
Java EE 6 & GlassFish v3: Paving the path for the future
Arun Gupta, Java EE & GlassFish Guy
blogs.sun.com/arungupta, @arungupta
2. The following/preceding is intended to outline our
general product direction. It is intended for
information purposes only, and may not be
incorporated into any contract. It is not a
commitment to deliver any material, code, or
functionality, and should not be relied upon in
making purchasing decisions.
The development, release, and timing of any
features or functionality described for Oracle’s
products remains at the sole discretion of Oracle.
2
4. Java EE: Past & Present Flexible
Ease of
Development Java EE 6
Pruning
Java EE 5 Extensibility
Web Ease of
Services Prof les
i
Development
Annotations
Ease-of-dev
J2EE 1.4 EJB 3.0 EJB Lite
Web Services, Persistence API RESTful WS
Robustness Management, New and CDI
Enterprise Deployment, Updated
Java J2EE 1.3 Async. Web Services
Platform CMP, Connector
Connector
Architecture ` Java EE 6
J2EE 1.2
Servlet, JSP, Web Prof le
i
EJB, JMS
JPE RMI/IIOP
Project
Managed
Bean 1.0
May 1998 Dec 1999 Sep 2001 Nov 2003 May 2006 Dec 2009
10 specs 13 specs 20 specs 23 specs 28 specs
4
5. Compatible Java EE 5 Impl
http://java.sun.com/javaee/overview/compatibility-javaee5.jsp
5
7. Goals for the Java EE 6 Platform
• Flexible & Light-weight
• Extensible
• Embrace Open Source Frameworks
• Easier to use, develop on
• Continue on path set by Java EE 5
7
8. Java EE 6 is Flexible
• Decouple specs to allow more combinations
• Expands potential licensee ecosystem
• Profiles
• Targeted bundle of technologies
• Defined through the JCP
• Web Profile Defined
• Defined by the Java EE 6 Expert Group
8
9. Java EE 6 Web Profile 1.0
• Fully functional mid-sized profile
• Actively discussed in the Java EE 6 Expert
Group and outside it
• Technologies
• Servlets 3.0, JSP 2.2, EL 2.2, Debugging Support for
Other Languages 1.0, JSTL 1.2, JSF 2.0, Common
Annotations 1.1, EJB 3.1 Lite, JTA 1.1, JPA 2.0, Bean
Validation 1.0, Managed Beans 1.0, Interceptors 1.1,
Context & Dependency Injection 1.0, Dependency
Injection for Java 1.0
9
10. Java EE 6 is Lightweight
• Pruning
• Make some technologies optional
• Pruned today, means
• Optional in the next release
• Deleted in the subsequent releases
• Technologies marked in Javadocs
• JAX-RPC, EJB 2.x Entity Beans, JAXR, JSR 88
10
11. Java EE 6 - Done
09
• Specifications approved by the JCP
• Reference Implementation is GlassFish v3
20
• TCK
ec
D
11
12. Java EE 6 Specifications
• The Platform
• Java EE 6 Web Profile 1.0
• Managed Beans 1.0
12
13. Java EE 6 Specifications
New
• Contexts and Dependency Injection for
Java EE (JSR 299)
• Bean Validation 1.0 (JSR 303)
• Java API for RESTful Web Services (JSR 311)
• Dependency Injection for Java (JSR 330)
13
15. Java EE 6 Specifications
Updates
• Java API for XML-based Web Services 2.2 (JSR 224)
• Java API for XML Binding 2.2 (JSR 222)
• Web Services Metadata MR3 (JSR 181)
• JSP 2.2/EL 2.2 (JSR 245)
• Web Services for Java EE 1.3 (JSR 109)
• Common Annotations 1.1 (JSR 250)
• Java Authorization Contract for Containers 1.3 (JSR 115)
• Java Authentication Service Provider Interface for
Containers 1.0 (JSR 196)
15
16. Java EE 6 Specifications
As is
• JDBC 4.0 API
• Java Naming and Directory Interface 1.2
• Java Message Service 1.1
• Java Transaction API 1.1
• Java Transaction Service 1.0
• JavaMail API Specification 1.4
• JavaBeans Activation Framework 1.1
• Java API for XML Processing 1.3
• Java API for XML-based RPC 1.1
• SOAP with Attachments API for Java 1.3
• Java API for XML Registries 1.0
• Java EE Management Specification 1.1 (JSR 77)
• Java EE Deployment Specification 1.2 (JSR 88)
• Java Management Extensions 1.2
• Java Authentication and Authorization Service 1.0
• Debugging Support for Other Languages (JSR 45)
• Standard Tag Library for JSP 1.2 (JSR 52)
• Streaming API for XML 1.0 (JSR 173)
16
18. Managed Beans 1.0
• JavaBeans component model for Java EE
• Simple and Universally useful
• Advanced concepts in companion specs
• Basic Services
• Resource Injection
• Lifecycle Callbacks
• Interceptors
• Available as
• @Resource / @Inject
• java:app/<module-name>/<bean-name>
• java:module/<bean-name>
18
19. Managed Beans 1.0 - Sample
@javax.annotation.ManagedBean @Resource
public class MyManagedBean { MyManagedBean bean;
@PostConstruct
public void setupResources() {
// setup your resources
}
@Inject
@PreDestroy MyManagedBean bean;
public void cleanupResources() {
// collect them back here
}
public String sayHello(String name) {
return "Hello " + name;
}
}
http://blogs.sun.com/arungupta/entry/totd_129_managed_beans_1
19
20. Interceptors 1.1
• Interpose on invocations and lifecycle
events on a target class
• Defined
• Using annotations or DD
• On target class or an interceptor class
associated with the target class
• Default Interceptors (only in DD)
• Class & Method Interceptors
20
21. Interceptors 1.1 - Code
@InterceptorBinding
@Retention(RetentionPolicy.RUNTIME)
@Target({ElementType.METHOD, ElementType.TYPE})
public @interface MyInterceptorBinding {
}
@Interceptor
@MyInterceptorBinding
public class MyInterceptor {
. . .
}
21
22. Interceptors 1.1 – Sample Code
@Interceptors(MyInterceptor.class)
public class MyManagedBean {
. . .
}
@Inject / @Resource
MyManagedBean bean;
@Interceptors({MyInterceptor.class,
MyInterceptor2.class})
public class MyManagedBean {
. . .
}
http://blogs.sun.com/arungupta/entry/totd_134_interceptors_1_1
22
23. Java EE 6 & Ease-of-development
• Continue advancements of Java EE 5
• Primary focus: Web Tier
• General principles
• Annotation-based programming model
• Reduce or eliminate need for DD
• Traditional API for advanced users
23
24. Servlets in Java EE 5
At least 2 files
<!--Deployment descriptor /* Code in Java Class */
web.xml -->
<web-app> package com.sun;
<servlet> public class MyServlet extends
<servlet-name>MyServlet HttpServlet {
</servlet-name> public void
<servlet-class> doGet(HttpServletRequest
com.sun.MyServlet req,HttpServletResponse res)
</servlet-class> {
</servlet>
...
<servlet-mapping>
<servlet-name>MyServlet }
</servlet-name> ...
<url-pattern>/myApp/* }
</url-pattern>
</servlet-mapping>
...
</web-app>
24
30. Servlets 3.0
Extensibility
• Plugin libraries using web fragments
• Modular web.xml
• Bundled in framework JAR file in META-INF
directory
• Zero-configuration, drag-and-drop for web
frameworks
• Servlets, servlet filters, context listeners for a framework
get discovered and registered by the container
• Only JAR files in WEB-INF/lib are used
30
33. Servlets 3.0
Resource Sharing
• Static and JSP no longer confined to
document root of the web application
• May be placed in WEB-INF/lib/
[*.jar]/META-INF/resources
• Resources in document root take
precedence over those in bundled JAR
myapp.war
WEB-INF/lib/catalog.jar
/META-INF/resources/catalog/books.html
http://localhost:8080/myapp/catalog/books.html
33
34. Servlets 3.0
Much more ...
• Programmatic authentication, login, logout
> HttpServletRequest.authenticate
> HttpServletRequest.login
> HttpServletRequest.logout
• File upload support
• Servlet Security <error-page>
<error-code>...</error-code>
> @ServletSecurity <exception-type>...</exception-type>
<location>/404.html</location>
• Default Error Page </error-page>
> Any HTTP status code
> http://blogs.sun.com/arungupta/entry/
totd_136_default_error_page
34
35. EJB 3.1 (JSR 318)
Package & Deploy in a WAR
Java EE 5 Java EE 6
foo.war
foo.ear
WEB-INF/classes
foo_web.war com.sun.FooServlet
com.sun.TickTock
WEB-INF/web.xml com.sun.FooBean
WEB-INF/classes com.sun.FooHelper
com.sun.FooServlet
com.sun.TickTock
foo_ejb.jar
com.sun.FooBean web.xml ?
com.sun.FooHelper
http://blogs.sun.com/arungupta/entry/totd_95_ejb_3_1
35
36. EJB 3.1
• No interface view – one source file per bean
• Only for Local and within WAR
• Required for Remote
• No location transparency
• Component initialization in @PostConstruct
• No assumptions on no-arg ctor
36
37. EJB 3.1
Portable Global JNDI Name Syntax
• Portable
• Global
• Application/Module-scoped
• Derived from metadata such as name,
component name etc.
37
38. EJB 3.1
Portable Global JNDI Name Syntax
Base name of ejb-jar/WAR
Only within EAR (or ejb-jar.xml/web.xml)
Base name of EAR
(or application.xml)
java:global[/<app-name>]/<module-name>/<bean-name>
[!<fully-qualified-interface-name>]
Unqualified name of the bean class
• Until now, only java:comp Annotation/name attribute
Or ejb-jar.xml
• Local & Remote business
• No-interface
• Also in java:app, java:module
38
39. EJB 3.1
Embeddable API – Simple Bean
@Stateless
public class App {
public String sayHello(String name) {
return "Hello " + name;
}
}
39
41. EJB 3.1
Singleton Beans
• One instance per app/VM, not pooled
• Useful for caching state
• CMT/BMT
• Access to container services for injection, resource
manager, timers, startup/shutdown callbacks, etc.
• Enable eager initialization using @Startup
• Always supports concurrent access
• Define initialization ordering using @Depends
@Singleton
public class MyEJB {
. . .
}
41
42. EJB 3.1
Asynchronous Session Beans
• Light-weight JMS
• Control returns to the client before the
container dispatches the invocation to a
bean instance
• @Asynchronous – method or class
• Return type – void or Future<V>
• Transaction context does not propagate
• REQUIRED → REQUIRED_NEW
• Security principal propagates
42
43. EJB 3.1
Asynchronous Session Beans – Code Sample
@Stateless
@Asynchronous
public class SimpleAsyncEJB {
public Future<Integer> addNumbers(int n1, int n2) {
Integer result;
result = n1 + n2;
try {
// simulate JPA queries + reading file system
Thread.currentThread().sleep(2000);
} catch (InterruptedException ex) {
ex.printStackTrace();
}
return new AsyncResult(result);
}
}
http://blogs.sun.com/arungupta/entry/totd_137_asynchronous_ejb_a
43
44. EJB 3.1
Timers
• Automatically created EJB Timers
• Calendar-based Timers – cron like semantics
• @Schedule(dayOfWeek=”Mon,Wed”)
• (hour=”14”, dayOfMonth=”Last Thu”,
month=”Nov”)
• (minute=”*/5”, hour=”*”)
• Automatically created EJB Timers
• Based upon @Schedule
• Non-persistent timer, e.g. Cache
44
45. EJB 3.1
EJB 3.1 Lite
A proper subset of the full EJB 3.1 API that
includes a small, powerful selection of EJB
features suitable for writing portable
transactional business logic
...
suitable for inclusion in a wider range
of Java products, many of which have much
smaller installation and runtime footprints
than a typical full Java EE implementation
45
47. Contexts & Dependency Injection
(JSR 299)
• Type-safe Dependency Injection
• Builds on @Inject API
• Context/Scope management
• Works with multiple bean types
• Includes ELResolver
47
48. CDI
Injection Points
• Field, Method, Constructor
• 0 or more qualifiers
Which one ?
• Type (Qualifier)
@Inject @LoggedIn User user
Request What ?
Injection (Type)
48
49. CDI
Basics
• Separate from @Resource but can co-
exist
• @Resource for container managed DI
• @Inject for application managed DI
• Strong typing, loose coupling
• Clients only declare dependencies via injection
points
• Bean selection is done by CDI
49
50. CDI – Sample Client Code
Field and Method Injection
public class CheckoutHandler {
@Inject @LoggedIn User user;
@Inject PaymentProcessor processor;
@Inject void setShoppingCart(@Default Cart cart) {
…
}
}
50
51. CDI – Sample Client Code
Constructor Injection
public class CheckoutHandler {
@Inject
CheckoutHandler(@LoggedIn User user,
PaymentProcessor processor,
@Default Cart cart) {
...
}
}
51
52. CDI - Sample Client Code
Multiple Qualifiers and Qualifiers with Arguments
public class CheckoutHandler {
@Inject
CheckoutHandler(@LoggedIn User user,
@Reliable
@PayBy(CREDIT_CARD)
PaymentProcessor processor,
@Default Cart cart) {
...
}
}
52
53. CDI - How to configure ?
There is none!
• Discovers bean in all modules in which CDI
is enabled
• Beans are automatically selected for
injection
• Possible to enable groups of bean
selectively via a descriptor
53
54. CDI - Scopes
• Beans can be declared in a scope
• Everywhere: @ApplicationScoped,
@RequestScoped
• Web app: @SessionScoped
• JSF app: @ConversarionScoped
• Pseudo-scope (default): @Dependent
• CDI runtime will make sure the right
bean is created at the right time
• Client do NOT have to be scope-aware
54
55. CDI - Named Beans
Built-in support for the Unified EL
• Beans give themselves a name with
@Named(“cart”)
• Then refer to it from a JSF or JSP page
using the EL:
<h:commandButton
value=”Checkout”
action=“#{cart.checkout}”/>
55
56. CDI
Much more ...
• Producer methods and fields
• Bridging Java EE resources
• Alternatives
• Interceptors
• Decorators
• Stereotypes
56
57. Java Server Faces 2.0 (JSR 314)
• Facelets as “templating language” for the page
• Custom components much easier to develop
<html xmlns="http://www.w3.org/1999/xhtml"
xmlns:ui="http://java.sun.com/jsf/facelets"
xmlns:h="http://java.sun.com/jsf/html">
<h:head>
<title>Enter Name & Password</title>
</h:head>
<h:body>
<h1>Enter Name & Password</h1>
<h:form>
<h:panelGrid columns="2">
<h:outputText value="Name:"/>
<h:inputText value="#{simplebean.name}" title="name"
id="name" required="true"/>
<h:outputText value="Password:"/>
<h:inputText value="#{simplebean.password}" title="password"
id="password" required="true"/>
</h:panelGrid>
<h:commandButton action="show" value="submit"/>
</h:form>
</h:body>
</html>
57
59. JSF 2 Composite Components
<html xmlns="http://www.w3.org/1999/xhtml"
xmlns:ui="http://java.sun.com/jsf/facelets"
xmlns:h="http://java.sun.com/jsf/html"
xmlns:ez="http://java.sun.com/jsf/composite/ezcomp">
<h:head>
<title>Enter Name & Password</title>
</h:head>
<h:body>
<h1>Enter Name & Password</h1>
<h:form>
<ez:username-password/>
<h:commandButton action="show" value="submit"/>
</h:form>
. . .
</h:body>
WEB-INF
</html>
index.xhtml
resources/
ezcomp/
username-password.xhtml
http://blogs.sun.com/arungupta/entry/totd_135_jsf2_custom_components
59
60. Java Server Faces 2.0
Integrated Ajax Support
• f:ajax
<h:commandButton
actionListener="#{sakilabean.findActors}"
value="submit">
<f:ajax execute="length"
render="actorTable totalActors"/>
</h:commandButton>
http://blogs.sun.com/arungupta/entry/totd_123_f_ajax_bean
60
61. Java Server Faces 2.0
• “faces-config.xml” optional in common cases
• <managed-bean> → @ManagedBean or @Named
• Validator, Renderer, Listener, ...
• Default navigation rules – match a view on the disk
@Named(“simplebean”)
public class SimpleBean {
. . .
}
<h:commandButton action="show" value="submit"/>
61
62. Java Server Faces 2.0
Much more ...
<navigation-case>
<from-outcome>success</from-outcome>
• Runs on Servlet 2.5+ <to-view-id>/page2.xhtml</to-view-id>
<!-- Only accept if the following condition
• Conditional navigation
is true -->
<if>#{foo.someCondition}</if>
</navigation-case>
• Project Stages
• Development, UnitTest, SystemTest, Production
• Custom Scopes for Managed Beans
• Bookmarkable URLs
• h:link, h:button <h:link outcome="viewEntry" value="Link">
<f:param name="entry" value="#{aBean.entry}"/>
</h:link>
<a href="http://localhost:8080/myapp/viewEntry.xhtml?
entry=entry1">Link</a>
62
63. Java Persistence API 2 (JSR 317)
Sophisticated mapping/modeling options
• Collection of basic types
@Entity
public class Person {
@Id protected String ssn;
protected String name;
protected Date birthDate;
. . .
@ElementCollection
@CollectionTable(name=”ALIAS”)
protected Set<String> nickNames;
}
63
64. Java Persistence API 2
Sophisticated mapping/modeling options
• Collection of embeddables
@Embeddable public class Address {
String street;
String city;
String state;
. . .
}
@Entity public class RichPerson extends Person {
. . .
@ElementCollection
protected Set<Address> vacationHomes;
. . .
}
64
65. Java Persistence API 2
Sophisticated mapping/modeling options
• Multiple levels of embedding
@Embeddable public class ContactInfo {
@Embedded Address address;
. . .
}
@Entity public class Employee {
@Id int empId;
String name;
ContactInfo contactInfo;
. . .
}
65
66. Java Persistence API 2
Sophisticated mapping/modeling options
• Improved Map support
@Entity public class VideoStore {
@Id Integer storeId;
Address location;
. . .
@ElementCollection
Map<Movie, Integer> inventory;
}
@Entity public class Movie {
@Id String title;
@String director;
. . .
}
66
67. Java Persistence API 2
Expanded JPQL
• Support for all new modeling/mapping
features
• Operators and functions in select list
• INDEX, KEY/VALUE ENTRY
// Inventory is Map<Movie, Integer>
SELECT v.location.street, KEY(i).title, VALUE(i),
FROM VideoStore v JOIN v.inventory i
WHERE KEY(i).director LIKE '%Hitchcock%'
AND VALUE(i) > 0
67
68. Java Persistence API 2
Expaded JPQL – CASE Expression
UPDATE Employee e
SET e.salary =
CASE e.rating
WHEN 1 THEN e.salary * 1.05
WHEN 2 THEN e.salary * 1.02
ELSE e.salary * 0.95
END
68
69. Java Persistence API 2
Type-safe Criteria API
EntityManager em = …;
CriteriaBuilder cb = em.getCriteriaBuilder();
CriteriaQuery<ResultType> cquery =
cb.createQuery(ResultType.class);
Root<MyEntity> e = cquery.from(MyEntity.class);
Join<MyEntity, RelatedEntity> j = e.join(…);
…
cquery.select(…)
.where(…)
.orderBy(…)
.groupBy(…);
TypedQuery<ResultType> tq = em.createQuery(cquery);
List<ResultType> result = tq.getResultList();
69
70. Java Persistence API 2
Much more ...
• 2nd-level Cache
• @Cacheable on entities
• contain, evict ...
• New locking modes
• PESSIMISTIC_READ – grab shared lock
• PESSIMISTIC_WRITE – grab exclusive lock
• PESSIMISTIC_FORCE_INCREMENT – update version
• Standard configuration options
• javax.persistence.jdbc.[driver | url | user | password]
70
71. Bean Validation (JSR 303)
• Tier-independent mechanism to define
constraints for data validation
• Represented by annotations
• javax.validation.* package
• Integrated with JSF and JPA
• JSF: f:validateRequired, f:validateRegexp
• JPA: pre-persist, pre-update, and pre-remove
• @NotNull(message=”...”), @Max, @Min,
@Size
• Fully Extensible
• @Email String recipient;
71
72. Bean Validation
Integration with JPA
• Managed classes may be configured
• Entities, Mapped superclasses, Embeddable classes
• Applied during pre-persist, pre-update, pre-
remove lifecycle events
• How to enable ?
• “validation-mode” in persistence.xml
• “javax.persistence.validation.mode” key in
Persistence.createEntityManagerFactory
• Specific set of classes can be targeted
• javax.persistence.validation.group.pre-[persist|update|
remove]
72
73. Bean Validation
Integration with JSF
• Individual validators not required
• Integration with EL
• f:validateBean, f:validateRequired
<h:form>
<f:validateBean>
<h:inputText value=”#{model.property}” />
<h:selectOneRadio value=”#{model.radioProperty}” > …
</h:selectOneRadio>
<!-- other input components here -->
</f:validateBean>
</h:form>
73
74. JAX-RS 1.1
• Java API for building RESTful Web Services
• POJO based
• Annotation-driven
• Server-side API
• HTTP-centric
74
75. JAX-RS 1.1
Code Sample - Simple
@Path("helloworld")
public class HelloWorldResource {
@Context UriInfo ui;
@GET
@Produces("text/plain")
public String sayHello() {
return "Hello World";
}
@Path("morning")
public String morning() {
return “Good Morning!”;
}
}
75
76. JAX-RS 1.1
Code Sample – Specifying Output MIME type
@Path("/helloworld")
@Produces("text/plain")
public class HelloWorldResource {
@GET
public String doGetAsPlainText() {
. . .
}
@GET
@Produces("text/html")
public String doGetAsHtml() {
. . .
} @GET
} @Produces({
"application/xml",
"application/json"})
public String doGetAsXmlOrJson() {
. . .
}
76
78. JAX-RS 1.1
Code Sample
import javax.inject.Inject;
import javax.enterprise.context.RequestScoped;
@RequestScoped
public class ActorResource {
@Inject DatbaseBean db;
public Actor getActor(int id) {
return db.findActorById(id);
}
}
78
79. JAX-RS 1.1
Code Sample
import javax.ws.rs.GET;
import javax.ws.rs.Path;
import javax.ws.rs.Produces;
import javax.ws.rs.PathParam;
import javax.inject.Inject;
import javax.enterprise.context.RequestScoped;
@Path("/actor/{id}")
@RequestScoped
public class ActorResource {
@Inject DatbaseBean db;
@GET
@Produces("application/json")
public Actor getActor(@PathParam("id") int id) {
return db.findActorById(id);
}
} http://blogs.sun.com/arungupta/entry/totd_124_using_cdi_jpa
79
80. JAX-RS 1.1
More Code Samples
• Processing POSTed HTML Form
@POST
@Consumes("application/x-www-form-urlencoded")
public void post(@FormParam("name") String name) {
// Store the message
}
• Sub-Resources
@Singleton
@Path("/printers")
public class PrintersResource {
@GET @Path("/list")
@Produces({"application/json", "application/xml"})
public WebResourceList getListOfPrinters() { ... }
@GET @Path("/ids/{printerid}")
@Produces({"application/json", "application/xml"})
public Printer getPrinter(@PathParam("printerid") String printerId) { ... }
80
81. JAX-RS 1.1
Integration with Java EE 6 – Servlets 3.0
• No or Portable “web.xml”
<web-app> @ApplicationPath(“resources”)
<servlet>
<servlet-name>Jersey Web Application</servlet-name>public class MyApplication {
<servlet-class> @Override
com.sun.jersey.spi.container.servlet.ServletContainer
</servlet-class>
public Set<Class<?>> getClasses() {
<init-param> return new HashSet<Class<?>(
<param-name>javax.ws.rs.Application</param-name>
Arrays.asList(
<param-value>com.foo.MyApplication</param-value>
</init-param> AResource.class,
</servlet>
AnotherResource.class));
<servlet-mapping>
<servlet-name>Jersey Web Application</servlet-name> }
<url-pattern>/resources/*</url-pattern>
}
</servlet-mapping>
</web-app>
81
82. JAX-RS 1.1
Integration with Java EE 6 – EJB 3.1
• Use stateless or singleton EJBs in the
WAR as resource and provider classes
@Path(“stateless”)
@Stateless @Singleton
public class MyStatelessRootResource { public class MyStatelessResource {
@Context UriInfo ui; @Context UriInfo ui;
@GET …
public String get() { return “GET”; } }
@EJB MyStatelessResource subResource;
@Path(“sub-resource”)
public MyStatelessResource sub() {
return subResource;
}
}
82
83. JAX-RS 1.1
Jersey Client-side API
• Consume HTTP-based RESTful Services
• Easy-to-use
• Better than HttpURLConnection!
• Reuses JAX-RS API
• Resources and URI are first-class citizens
• Not part of JAX-RS yet
• com.sun.jersey.api.client
83
84. JAX-RS 1.1
Jersey Client API – Code Sample
Client client = Client.create();
WebResource resource = client.resource(“...”);
//curl http://example.com/base
String s = resource.get(String.class);
//curl -HAccept:text/plain http://example.com/base
String s = resource.
accept(“text/plain”).
get(String.class);
http://blogs.sun.com/enterprisetechtips/entry/consuming_restful_web_services_with
84
87. JAX-RS 1.1
Much more ...
• Jersey is the Reference Implementation,
included in GlassFish
• RESTEasy, Restlet, CXF, Wink
• Hypermedia support (only in Jersey)
• Integration with Spring, Guice, Atom, …
• WADL representation
• Complete, Per resource
• Jersey 1.2 modules are OSGi compliant
87
91. What is GlassFish ?
• A community
• Users, Partners, Testers, Developers, ...
• Started in 2005 on java.net
• Application Server
• Open Source (CDDL & GPL v2)
• Java EE Reference Implementation
91
92. GlassFish Distributions
Distribution License Features
GlassFish Open Source CDDL & • Java EE 6 Compatibility
Edition 3.0 GPLv2 • No Clustering
• Clustering planned in 3.1
• mod_jk for load balancing
GlassFish Open Source CDDL & • Java EE 5 Compatibility
Edition 2.1.1 GPLv2 • In memory replication
• mod_loadbalancer
Oracle GlassFish Server 3.0 Commercial • GlassFish Open Source Edition 3.0
• GlassFish Server Control Clustering
• Clustering planned in 3.1 Coming
Soon!
Oracle GlassFish Server Commercial • GlassFish Open Source Edition
2.1.1 2.1.1
• Enterprise Manager
• HADB
92
93. GlassFish 3
• Modular
• Maven 2 – Build & Module description
• Felix – OSGi runtime (200+ bundles)
• Allow any type of Container to be plugged
• Start Container and Services on demand
• Embeddable: runs in-VM
• Extensible
• Rails, Grails, Django, ...
• Administration, Monitoring, Logging, Deployment, ...
http://blogs.sun.com/dochez/entry/glassfish_v3_extensions_part_5
93
94. GlassFish 3 & OSGi
• No OSGi APIs are used in GlassFish
• HK2 provides abstraction layer
• All GlassFish modules are OSGi bundles
• Felix is default, also runs on Knopflerfish & Equinox
• Can run in an existing shell
http://blogs.sun.com/arungupta/entry/totd_103_glassfish_v3_with
94
99. Light Weight & On-demand Monitoring
• Event-driven light-weight and non-intrusive
monitoring
• Modules provide domain specific probes
(monitoring events)
• EJB, Web, Connector, JPA, Jersey, Orb, Ruby
• End-to-end monitoring on Solaris using
DTrace
• 3rd party scripting clients
• JavaScript to begin with
99
108. GlassFish 3.1
• Main Features
• Clustering and Centralized Administration
• High Availability
• Other ...
• Application Versioning
• Embedded (extensive)
• Admin Console based on RESTful API
108
109. GlassFish Roadmap
• Oracle committed to GlassFish community
• No changes to the operation of GlassFish OSS
• Remains transparent and participatory
• GlassFish strengthened by Oracle stewardship
• Oracle wants to grow the community
• Customer and community driven roadmap
http://glassfish.org/roadmap
109
111. Fusion Middleware Integration Strategy
• Commercial version will have
integrations with Fusion Middleware
• Certification on JRockit
• Integration with Coherence and TopLink
• Fusion Middleware and Fusion
Applications currently not planned to be
certified on GlassFish
• Initial integrations will be interoperability
• Web services, Web services policy, Identity
Management (OAM)
111
113. <Insert Picture Here>
Java EE 6 & GlassFish v3: Paving the path for the future
Arun Gupta, Java EE & GlassFish Guy
blogs.sun.com/arungupta, @arungupta
