Component Framework Primer for JSF Users

Component Framework Primer for JSF Users Andy Schwartz | Oracle Corporation

What?
What are we doing?
Comparing server-side component-centric frameworks
Understanding approaches to common problems
What is a server-side component-centric framework?
User interface component model defined on server
Components hold properties, children, fire events
Swing-like approach for web content
What frameworks?
JSF, Wicket and Tapestry
What else is there?
Client-side (jQuery, Dojo)
Hybrid (GWT)
MVC (Struts, RoR)

Why?
JSF has historically been a target of criticism
Often compared to related frameworks
Important to understand JSF’s limitations
JSF 2 addresses many of these issues
Still room for improvement
We can learn from other frameworks
We can continue to evolve/improve JSF

Why Wicket and Tapestry?
Similar in scope to JSF
Popular choices
Many areas of overlap
Different approaches
Interesting comparisons
Plenty of lessons to learn

Who?
User Interface Technology Architect, Oracle
Developing user interface frameworks since 1993
JSR-314/JSF 2.0 Expert Group Representative
Wicket/Tapestry Student
Biased, but honest :-)

Agenda
Hello, Frameworks!
Event Handling
Ajax
Navigation
Input Processing
Custom components
Wrap up

Hello, JSF!

JSF History
Originally standardized under JSR-127, 2004.
Standard piece of Java EE platform (Web Profile)
Sun serves as spec lead (Ed Burns, Roger Kitain)
JSR-252/JSF 1.2 enhancements, 2006
JSR-314/JSF 2.0 major release, 2009
Two widely used implementations
Mojarra (Reference Implementation)
MyFaces

JSF Vision
Swing-like component/event model
Declarative component tree specification
Integration with existing standards
Split logical (components) and physical (markup)
Tooling
Extensibility

What is a Page?
Legacy: Each page defined by a JSP (JSPX)
Now: Facelets standardized, preferred over JSP
Combines XHTML and component tags
Component tree definition specified via tags
Other view declaration languages (VDLs) available
JSF Templating, Gracelets

Saying Hello
(JSF)

Grunge: web.xml <servlet> <servlet-name>Faces Servlet</servlet-name> <servlet-class> javax.faces.webapp.FacesServlet </servlet-class> </servlet> <servlet-mapping> <servlet-name>Faces Servlet</servlet-name> <url-pattern>*.jsf</url-pattern> </servlet-mapping>

My First JSF Page <html xmlns="http://www.w3.org/1999/xhtml" xmlns:h="http://java.sun.com/jsf/html"> <head><title>My First JSF Page</title></head> <body>  Hello, <h:outputText value="World"/>! </body> </html>

JSF Rendering
Page definition drives component tree creation
Component tree contains UIComponent instances
UIComponents delegate to Renderers
Response produced by traversing component tree
UIComponents/Renderers generate markup
Markup written via ResponseWriter

What Happens After Rendering?
Component tree state saved via StateManager
State stored in session or client
Component tree restored on postback
JSF 2.0 optimization: partial state saving

Bindings
Component attributes can be bound
Allows components to access dynamic data
Specified via Unified Expression Language (EL)
Bindings used for both reading and writing

A Simple Binding <h:outputText value="#{sessionScope.user.firstName}"/>

Implicit Objects
Bindings have access implicit objects/scopes
Servlet-related scopes:
applicationScope
sessionScope
requestScope
JSF-specific scopes
viewScope
flash
component
Many more objects exposed

Managed Beans
POJOs
Named
Scoped
Container-managed

Managed Bean Registration <faces-config> <managed-bean> <managed-bean-name>user</managed-bean-name> <managed-bean-class>demo.User</managed-bean-class> <managed-bean-scope>session</managed-bean-scope> </managed-bean> </faces-config>

Managed Bean Registration @ManagedBean @SessionScoped public class User { public String getFirstName() { … } }

Managed Bean Reference  <h:outputText value="#{sessionScope.user.firstName}"/>  <h:outputText value="#{user.firstName}"/>

Hello, Wicket!

Wicket Quick History
Founded by Johnathan Locke, 2005
Originally hosted at SourceForge
Moved to Apache, 2007
Graduated to top level project, June 2007
Current version: 1.4.3 (as of November 2009)

Wicket Vision
Complete separation of markup and logic
Web designers do HTML
Application developers do Java
Designers benefit from previewability
Developers benefit from type-safety
No special tooling required

What is a Page?
Markup lives in a .html file
Code/components live in a .java file
Properties/messages in a .properties file
All files live on the class path
All files for a page share a name
Components correlated across html/java by id

Saying Hello
(Wicket)

Grunge: web.xml <filter> <filter-name>wicket</filter-name> <filter-class> org.apache.wicket.protocol.http.WicketFilter </filter-class> <filter-mapping> <filter-name>wicket</filter-name> <url-pattern>/*</url-pattern> </filter-mapping> </filter>

Grunge: web.xml <init-param> <param-name> applicationClassName </param-name> <param-value> org.demo.wicket.HelloApplication </param-value> </init-param>

My First Wicket Application public class HelloApplication extends WebApplication { @Override public Class<Hello> getHomePage() { return Hello.class; } }

My First Wicket Page (HTML) <html xmlns:wicket="…"> <head><title>Hello, Wicket!</title></head> <body>  Hello, <span wicket:id="name" >Foo</span>! </body> </html>

My First Wicket Page (Java) public class Hello extends WebPage { public Hello() { // My first Wicket component (Java) add(new Label( "name" , "World")); } }

Wicket Rendering
Markup exposed via MarkupStream
MarkupElements: RawText, ComponentTag
ComponentTags correlated with Components
onRender() called for each component
onComponentTag(): modify/render start tag
onComponentBodyTag(): modify/render body
MarkupElements written to response.

Page state stored in page store
Pluggable page store behavior
DiskPageStore leverages file system for old pages
Page restored on postback

What is a Wicket Model?
Wicket models bind domain layer objects to components.
(Similar to EL ValueExpressions in JSF)

IModel Contract T getObject() void setObject(T object)

Components and Models
IModel<?> getDefaultModel()
Most components read from model.
Some components write to model.

Simple Model
Model class implements IModel
Stores model object locally
We have been using it already

Simple Model Sample // This: add(new Label("name", "World"); // Is shorthand for: add(new Label("name", new Model("World")));

Static Model
Simple Models are static.
// This is static: add(new Label("random", new Model<Double>(Math.random()) ));

Dynamic Model
Override getObject() for dynamic.
// This is dynamic: add(new Label("reallyRandom", new Model<Double>() { public Double getObject() { return Math.random(); } }));

Some More Models
PropertyModel
CompoundPropertyModel
LoadableDetachableModel
ResourceModel

Hello, Tapestry!

Tapestry Quick History
Founded by Howard Lewis Ship, 2000
Hosted at Apache
Graduated to top level project, June 2006
Current release: 5.1 (as of November 2009)

Tapestry Vision
Similar separation of markup/logic
Convention over Configuration
Inversion of Control
POJOs/annotations
Performance

What is a Page?
Markup lives in a .tml file
Code/components live in a .java file
Properties/messages in a .properties file
TML files live in web root
Other files on the class path
All files for a page share a name

Saying Hello
(Tapestry)

Grunge: web.xml <filter> <filter-name>tapestry</filter-name> <filter-class> org.apache.tapestry5.TapestryFilter </filter-class> </filter> <filter-mapping> <filter-name>tapestry</filter-name> <url-pattern>/*</url-pattern> </filter-mapping>

Grunge: web.xml <context-param> <param-name> tapestry.app-package </param-name> <param-value> org.example.tapestry </param-value> </context-param>

My First Tapestry Page (TML) <html xmlns:t="…"> <head><title>Hello, Tapestry!</title></head> <body>   Hello, <t:textoutput t:value="name"/>! </body> </html>

My First Tapestry Page (Java) public class Index { @Property private String name; }

Tapestry Rendering
State machine/queue-based rendering
No recursive component tree traversal
Components hook into rendering phases
SetupRender, BeginRender, BeforeRenderBody, etc.
Specified via annotations or naming conventions
Hooks write response to MarkupWriter
Streaming API with access to DOM-like structure

Persistent properties are state saved
@Persist annotation identifes properties to persist
Page is cleaned up and returned to pool
On postback, page instance retrieved from pool
Persistent property values are restored
Pooling is for performance (smaller footprint)
Implies mostly static page structures

Take 2: t:id

Take 2: TML <html xmlns:t="…"> <head><title>Hello, Tapestry!</title></head> <body>  Hello, <span t:id="nameOutput" >Foo</span>! </body> </html>

Take 2: Java public class Index { @Property private String name; @Component( parameters={"value=name"}) private TextOutput nameOutput; }

Take 3: t:type

Take 3: TML <html xmlns:t="…"> <head><title>Hello, Tapestry!</title></head> <body> Hello, <span t:type="textoutput" t:value="name">Foo</span>! </body> </html>

Facelets Flashback  <span jsfc="h:outputText" value="#{name}">Foo</span>!

Tapestry Property Expressions
String notations for specifying object paths
Similar to EL
Supports referencing properties and methods
Used for parameters and template expansions
Compiled to Java classes (no reflection)

Property Expressions  <div><t:textoutput t:value="user.name"/></div>  <div>${user.name}</div>

Binding Expressions
Parameters can bind to other types of values
Prefix identifies binding type:
prop
literal
asset
context
component
message

Binding Expressions  Hello, <t:textoutput t:value="name"/>!  Hello, <t:textoutput t:value="literal:World"/>!

Some Initial Thoughts
Key difference: declarative vs programmatic component tree specification
JSF favors declarative approach
Wicket requires programmatic approach
Tapestry is somewhere in the middle
Component abstraction vs. direct access to HTML

Some More Thoughts
Implicit per-page Java object is convenient
Possible to simulate with JSF (viewScope bean)
Consider formalizing this in JSF?

Event Handling

JSF Event Handling
Inspired by Swing Event Model
Listeners registered on components
Components fire events
Declarative: listeners referenced via EL

JSF Event Handling <h:form> <h:commandButton value="Increment" actionListener="#{counter.increment}"/> <h:outputText value="#{counter.count}"/> </h:form>

JSF Event Handling @ManagedBean @SessionScoped public class Counter { public int getCount() { return count; } public void increment() { count++; } private int count; }

Wicket Event Handling
Components expose event-specific hooks
Subclasses override to receive notifications

Wicket Event Handling <form wicket:id="form"> <input type="submit" value="Increment" wicket:id="button"/> <span wicket:id="count">count</span> </form>

Wicket Event Handling public class EventsPage extends WebPage { public EventsPage() { Button button = new Button("button") { @Override public void onSubmit() { count++; } }; } private int count; }

Wicket Event Handling
onSubmit() exposed at both Button and Form level
Button onSubmit() called first
Link component provides form/POST-free events
onClick() vs. onSubmit()

Tapestry Event Handling
Naming Conventions
Annotations

Tapestry Event Handling <t:form t:id="form1"> <input type="submit" value="Increment" t:type="submit" t:id="button1"/> ${count} </t:form>

Tapestry Event Handling public class Events { @Persist @Property private int count; // Called when any form is submitted void onSubmit() { count++; } }

Tapestry Event Handling // All of these work too! // Called when form 1 is submitted void onSubmitFromForm1() { count++ } // Called when any button is selected void onSelected() { count++; } // Called when button1 is selected void onSelectedFromButton1() { count++; }

Tapestry Event Handling // And these too @OnEvent(value="selected", component="button1") void increment() { count++ } @OnEvent(value="submit", component="form") void foo() { count++ }

Tapestry Event Handling
Component-specific events before form
Global events before component-specific
ActionLink provides form/POST-free events

Event Handling Wrap Up
Three very different approaches
Managed bean annotations simplify JSF approach
Possible to add a Tapestry-like solution to JSF?
Possible to add Wicket-like solution to JSF?
Programmatic component creation cases, yes.
What about other cases?
Form-level submit hook is nice

JSF Ajax
Before: Take your pick
ADF/Ice/Rich/Prime/Trinidad
Now: Standard Ajax APIs/implementation
Ajax behaviors attached to components
Primarily declarative solution
Programmatic APIs available too

JSF Ajax
<h:form>
<h:commandButton value="Increment"
actionListener="#{counter.increment}">
<f:ajax render="count"/>
</h:commandButton>
<h:outputText value="#{counter.count}"
id="count" />
</h:form>

JSF Ajax <f:ajax render="count"/> <h:commandButton value="Increment" actionListener="#{counter.increment}"> <h:commandButton value="Reset" actionListener="#{counter.reset}"> </f:ajax>

JSF Ajax
All standard components support behaviors
Attach points are component-specific
Action, valueChange, focus, blur, mouse over, etc…
Behavior mechanism is extensible
Not specific to Ajax

Wicket Ajax
Ajax Components
Behaviors

Wicket Ajax AjaxButton button = new AjaxButton("button") { @Override public void onSubmit( AjaxRequestTarget target , Form form) { count++; if (target != null) { target.addComponent(label); } }});

Wicket Ajax label = new Label("count", …); label. setOutputMarkupId(true);

Wicket Ajax
Many convenience components, behaviors
Fallback behavior: AjaxFallbackLink
setOutputMarkupPlaceholderTag()
Ajax debug window

Tapestry Ajax
Ajax Zones
Mixins

Tapestry Ajax <t:form t:id="form1" zone="countZone" > <input type="submit" value="Increment" t:type="submit" t:id="button1"/> <t:zone t:id="countZone"> Hello, ${count} </t:zone> </t:form>

Tapestry Ajax public class Ajax { @InjectComponent private Zone countZone; Object onSubmitFromForm1() { return countZone.getBody(); } }

Tapestry Ajax
Zone supported by Form, ActionLink, EventLink
MultiZoneUpdate
Mixins: autocomplete

Ajax Wrap Up
JSF 2.0 Ajax is competitive with other solutions
Wicket Ajax debug window is nice
JSF implementations could provide equivalent
Improve JSF's fallback story?
Resolve (or document) rendered toggling behavior

Navigation

JSF Navigation
Traditional: POST-based navigation
POST triggers action
Action determines outcome
Outcome mapped to target view

JSF Navigation <h:commandButton action="#{nav.goToPageB}"/> @ManagedBean(name="nav") @RequestScoped public class Navigation { public String goToPageB() { return "success"; } }

JSF Navigation <navigation-rule> <from-view-id>/pageA.xhtml</from-view-id> <navigation-case> <from-outcome>success</from-outcome> <to-view-id>/pageB.xhtml</to-view-id> <redirect/> </navigation-case> </navigation-rule>

JSF Implicit Navigation
Declarative navigation is good for many cases
Perhaps too verbose for simple cases
Implicit navigation simplifies simple cases
Outcome implicitly treated as view id
Bypasses faces-config.xml

JSF Implicit Navigation <h:commandButton action="#{nav.goToPageB}"/> @ManagedBean(name="nav") @RequestScoped public class Navigation { public String goToPageB() { // No faces-config entry required return "pageB" ; } }

JSF Pre-Emptive Navigation
Implict navigation simplifies, but still POST-only
Not GET/bookmark-friendly
Pre-emptive navigation: best of both worlds
Navigation rules aggressively evaluated
<h:link>/<h:button> produce GET requests

JSF Pre-Emptive Navigation  <h:button outcome="success"/>  <h:button outcome="pageB"/>

Wicket Navigation
Programmatic navigation: setResponsePage()
Class vs. instance

Wicket Navigation Button button1 = new Button("button1") { public void onSubmit() { setResponsePage(PageB.class); } };

Wicket Navigation Button button1 = new Button("button1") { public void onSubmit() { PageB pageB = new PageB(); // Configure PageB instance… setResponsePage(pageB); } }; Wicket Navigation

Wicket Navigation
Direct navigation also supported
BookmarkablePageLink
wicket:link

Wicket Navigation  <a wicket:id="bookmarkable" href="PageB.html">Navigate To Page B</a> // Java form.add( new BookmarkablePageLink("bookmarkable", PageB.class));

Wicket Navigation  <wicket:link> <ul> <li><a href="PageA.html">Page A</a></li> <li><a href="PageB.html">Page B</a></li> <li><a href="PageC.html">Page C</a></li> <li><a href="PageD.html">Page D</a></li> </ul> </wicket:link>

Tapestry Navigation
Programmatic navigation: onSubmit() return
Like Wicket, navigate to class or instance
Instance page injected

Tapestry Navigation public class PageA { Object onSubmitFromForm1() { return PageB.class; } }

Tapestry Navigation public class PageA { @InjectPage private PageB pageB; Object onSubmitFromForm1() { // Configure pageB instance... return pageB; } }

Tapestry Navigation
Direct navigation also supported
t:pageLink

Tapestry Navigation <t:pagelink t:page="PageB">Go</t:pagelink>

Navigation Wrap Up
JSF 2.0 enhancements simplify navigation
String outcomes vs. class/instance
Introduce class/instance support in JSF?
Redirect defaults

Input Processing

JSF Input Processing
EditableValueHolder lifecycle
Decode
Conversion
Validation
Update model
Value referenced via value expression

JSF Input Processing <h:inputText value="#{user.name}"/> @ManagedBean public class User { public String getName() { return name; } public void setName(String name) { this.name = name; } private String name; }

JSF Conversion
Converters control transformation to/from string
Attached to EditableValueHolder components
Default conversion for most types
Date/time and number converters for more control
Custom converters

JSF Conversion <h:inputText value="#{user.age}"> <f:convertNumber integerOnly="true"/> </h:inputText>

JSF Validation
Validators verify converted value
Attached to EditableValueHolder components
Various standard validators provided with JSF
Also possible to implement custom validators
JSF 2.0 also applies JSR-303 validation constraints

JSF Validation <h:inputText value="#{user.age}"> <f:validateLongRange minimum="18"/> </h:inputText>

More JSF Validation
Feedback
Typically displayed via <h:messages>/<h:message>
More interesting feedback possible
Multi-component validation
Historically very tricky
PostValidate system event makes this much easier
Client-side validation
No out-of-box support
3rd party solutions available (Trinidad/ADF Faces)
Ajax Validation
Facilitated by <f:ajax>

Wicket Input Processing
Similar lifecycle to JSF
Required field validation
Conversion
Validation
Push to model
onSubmit/onError
Value referenced via Model contract

Wicket Input Processing  <input type="text" wicket:id="firstName"/> // Java User user = getUser(); form.add(new TextField("firstName", new PropertyModel(user, "name")));

Wicket Conversion
IConverter contract, similar to JSF Converter
Converts to/from string
Default converters
Type derived or hinted
Custom converters
Override getConverter()

Wicket Validation
IValidator, similar to JSF Validator
Validators attached programmatically

Wicket Validation  <input type="text" wicket:id="age"/> // Java add(new TextField("age", new PropertyModel(getUser(), "age")) .add(NumberValidator.minimum(18)));

More Wicket Validation
Feedback
FeedbackPanel (like h:messages)
FormComponentFeedbackBorder
IFormValidator
No out-of-box support
Ajax validation preferred
Ajax Validation
AjaxFormValidatingBehavior

Tapestry Input Processing
Similar lifecycle to JSF, Wicket
Conversion
Validation
Push to model
onSuccess/onFailure
Value referenced via property expressions

Tapestry Input Processing  <input type="text" t:type="textfield" t:value="user.name"/> // Java public class Input { @Property private User user; }

Tapestry Conversion
FieldTranslator, similar to Converter/IConverter
Event-based conversion
toclient
parseclient

Tapestry Conversion Events public class Input { String onToClientFromAge() { // Return String representation of age } Object onParseClientFromAge(String input) { // Return converted representation of age } }

Tapestry Validation
FieldValidator, similar to Validator/Ivalidator
Constraints attached via component parameters
Event and annotation-based validation

Parameter-Based Validation <input type="text" t:type="textfield" t:value="user.age" t:validate="required,min=18"/>

Event-Based Validation void onValidateFromAge(Integer value) throws ValidationException { if (value < 18) throw new ValidationException("Too young!"); }

Anntation-Based Validation public class Input { @Property @Validate("required,min=18") private int age; }

More Tapestry Validation
Feedback
Border highlight, hover text
<t:errors>
onValidateForm()
Provided automatically for standard validators
Ajax Validation
Client-side validation preferred

Input Processing Wrap Up
Similar input processing across frameworks
Surprise?
Pull client-side validation into JSF?
Improve feedback reporting
Encourage use of PostValidate system event for multi-component validation

Custom Components

JSF: Old School (Java)
Java class (extends UIComponent)
Renderer class
Tag class
faces-config.xml
tld

JSF: New School (Java)
Annotations replace faces-cofig.xml
Default Facelets handlers replace Tag class
taglib.xml replaces tld

JSF: New School (Composite)
Single Facelets file defines composite component
Installed in resources directory
Component namespace/name derived
No external configuration
Optional Java component class
Optional properties file

resources/demo/titleBorder.xhtml <html ... ><body> <composite:implementation> <div class="tb-root"> <div class="tb-title"> #{cc.attrs.title} </div> <div class="tb-body"> <composite:insertChildren/> </div> </div> </composite:implementation> </body></html>

Composite Interface <composite:interface> <composite:attribute name="title" required="true"/> </composite:interface>

Component Usage <html … xmlns:demo= "http://java.sun.com/jsf/composite/demo"> <body> <demo:titleBorder title="My Favorite Greeting"> Hello, World! </demo:titleBorder> </body> </html>

Wicket Custom Components
We have already seen several custom components
Think event handling
Can also define components with custom markup
Very similar to page
HTML/Java split
Java extends Panel or Border (not WebPage)

TitleBorder.html <html ... ><body> <wicket:border> <div class="tb-root"> <div class="tb-title" wicket:id="titleLabel">Title</div> <div class="tb-body"> <wicket:body/> </div> </div> </wicket:border> </body></html>

TitleBorder.java public class TitleBorder extends Border { public TitleBorder(String id) { super(id); add(new Label("titleLabel", new PropertyModel(this, "title"))); } // Accessors private String title; }

Component Usage  <div wicket:id="titleBorder"> Hello, World! </div> // Java add(new TitleBorder("titleBorder"));

Tapestry Custom Components
Again, similar to page
TML/Java split
Java component is a POJO
Located in app-package/components directory

TitleBorder.tml <div class="tb-root" ... > <div class="tb-title"> ${title} </div> <div class="tb-body"> <t:body/> </div> </div>

TitleBorder.java public class TitleBorder { @Property @Parameter(required=true, defaultPrefix=BindingConstants.LITERAL) private String title; }

Component Usage <t:titleborder t:title="My Favorite Greeting"> Hello, World! </t:titleborder>

Custom Component Wrap Up
JSF custom component development became much, much simpler in 2.0
Composite components provide ease of use previously only available in other frameworks
Further simplifications possible?
Composite components
Java-based components

Wrap Up

So Much To Do, So Little Time
Many other possible points of comparison
Performance
Tooling
Testing
I18N
Persistence
REST
Extensions
Community
Other interesting frameworks too!
Presentation 2.0 :-)

Conclusion
Some differences are fundamental
Interesting to see many similarities too
Looking outward: good exercise
Good to see historical areas of difficulty addressed by JSF 2.0.
JSF2.next: Keep the progress coming!

Component Framework Primer for JSF Users

by Andy Schwartz

Accessibility

Categories

Upload Details

Usage Rights

2 Embeds 22

Statistics

Component Framework Primer for JSF Users Presentation Transcript

http://www.slideshare.net	21
http://webcache.googleusercontent.com	1
