<Insert Picture Here>Oracle In-Database Hadoop:When MapReduce Meets RDBMSKuassi Mensah | db360.blogspot.com @kmensahDirector Product Management | kuassi.mensah@oracle.com

The following is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any material, code, or functionality, and should not be relied upon in making purchasing decisions. The development, release, and timing of any features or functionality described for Oracle s products remains at the sole discretion of Oracle.Hadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah 2 Copyright © 2012, Oracle and/or its affiliates. All rights reserved. Insert Information Protection Policy Classification from Slide 8

Oracle In-Database Hadoop Agenda •  In-Database MapReduce •  Why •  Previous Initiatives and Limitations •  Oracle In-Database Hadoop •  Integration with Oracle’s Big Data solution •  SummaryHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

In-Database MapReduceHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

MapReduce Paradigm You All Know This Stuff! Map: <K1,V1> → {<K2,V2>,…} Shuffle: {<K2,V2>, …} → {<K2,{V2,…,V2}>,…} Reduce: <K2,{V2,…,V2}> → {<K3,V3>,…} Hadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

In-Database MapReduce Why? •  Avoid shipping data residing in RDBMS to a separate infrastructure. •  Many initiatives •  Address top two issues preventing broader adoption of Hadoop in the enterprise •  Lack of development and/or administration skills •  Lack of enterprise-class securityHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

In-Database MapReduce Previous Efforts and Limitations •  SQL-MapReduce,HadoopDB (Hadapt), etc. •  PL/SQL User-defined pipelined table functions and aggregation objects •  Limitations •  Lack of compatibility with Hadoop •  Loose integration with Hadoop •  Dependency on Hadoop infrastructureHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database HadoopHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Hadoop is a prototype (not a feature of Oracle products), built on current Oracle products.Hadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Hadoop Goals •  Avoid shipping data residing in Oracle database to Hadoop clusters. •  Preserve Hadoop programming model •  Reduce dependency on Hadoop infrastructure •  Get enterprise developers up to speed with minimal training •  Get enterprise administrators (DBAs) up to speed with minimal training •  Reduce deployment time •  Bring enterprise class security to MapReduce •  Seamless integration with Oracle’s Big Data solutionHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Hadoop Compatibility & Minimal Dependency on Hadoop Infra Node 1 Node 2 Node 3 Pipelelined Table Function w Java impl. Mapping Process Mapping Process Mapping Process PARTITION by CLUSTER BY Clause Node 1 Node 2 Node 3 Pipelined Table Function w Java impl. Reducing Process Reducing Process Reducing ProcessHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Hadoop Preserve Hadoop Programming Model •  Source-compatibility •  Job configuration •  Invocation thru Java interface: job.run() •  Direct table access: TableReader and TableWriterHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Hadoop SQL and MapReduce Integration •  Mix SQL and MapReduce processing for flexibility and efficiency. •  MapReduce steps as pipelined table functions. INSERT INTO OutTable SELECT * FROM TABLE (Word_Count_Reduce(:ConfKey, CURSOR(SELECT * FROM TABLE (Word_Count_Map(:ConfKey, CURSOR(SELECT * FROM InTable)))))) Hadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Hadoop SQL and Java interfaces SELECT * FROM TABLE public class WordCount { (Reduce_VARCHAR2_NUMBER(:ConfKey, public static void main() throws Exception { /* Setup the parameters and run the job */ CURSOR(SELECT * FROM TABLE …… (Map_VARCHAR2_NUMBER(:ConfKey, job.init(); CURSOR(SELECT * from InTable)))))) job.run(); } Hadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Hadoop Leverage Enterprise Skills •  Get database developers up to speed, with minimal training, on developing MapReduce jobs by reusing Hadoop Mappers and Reducers •  Get DBAs up to speed on deploying and managing MapReduce jobs with minimal trainingHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle Database Security Bringing Enterprise Class Security to MapReduce •  Auditing and Monitoring •  Database Activity Auditing •  Database Firewall Monitoring •  Centralized Audit Data Warehouse •  Encryption and Masking •  Transparent Data Encryption •  Network Encryption/Strong Auth •  Data Masking for Non-Production •  Privileged User Access Control and Contextual Authorization •  Separation of Duties for DBAs •  Protection Realms & Rules •  Label Based Access ControlHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Seamless integration with Oracle’s Big Data SolutionHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle’s Big Data solution Endeca Information Discovery Oracle Big Data Oracle Appliance Exadata Oracle Exalytics InfiniBand InfiniBand Oracle Real-Time Decisions Acquire Organize & Discover Analyze DecideHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle Direct Connector for HDFS Direct Access from HDFS Oracle Database Oracle Database SQL Query SQL access to HDFS External Table External table view Data query or import DCH HDFS Infini Band DCH DCH ClientHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Analytics Oracle Advanced Analytics Statistical Data Mining Text Graph Spatial Semantic 2 milesHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

What Have We Done?Hadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Oracle In-Database Hadoop Summary A prototype: •  Apply MapReduce processing to data in Oracle RDBMS without the need of a separate infrastructure. •  Compatibility with Hadoop while minimizing dependency on the Apache Hadoop infrastructure. •  Reduce training and deployment time. •  Integration with Oracle SQL, allowing mixing MapReduce steps with sophisticated SQL queries. •  Bring Enterprise Class Security to Hadoop MapReduce •  Seamless integration with Oracle’s Big Data solutionHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

DemoHadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Hadoop Summit 2012, June 13-14, San Jose, California, USA Oracle In-Database Hadoop: When MapReduce Meets RDBMS. Kuassi Mensah

Thank You! Page 25
