WPF Fundamentals

Presenter Name Title Microsoft Corporation

Overview
Application Model
Property System
Events
Commands
Threading
Animation

Application Model
Application Class
Types of Application
Windows Application
XAML Browser Application

Application Class
Core of the WPF Application model
Serves as a container for WPF applications
Enables data to be shared
Provides Application Events
Provides Windows Message Dispatching
Supports Navigation Between Pages

Application Class WM_PAINT WM_MOUSEMOVE

Windows Application
Two types of Windows applications:
Window-derived
NavigationWindow-derived

WPF applications can be hosted within an internet browser
Internet Explorer 6.0 & 7.0(.NET 3.0/3.5)
Mozilla Firefox (.NET 3.5 only)
Unified programming model
Windowed apps and XBAPs are built using the same programming model
Graphics, Media, and Documents are all supported within this single model

Partial Trust
Available: Browser window, isolated storage, commands, 2-D and 3-D graphics, animation, media, audio, video, and more
Not available: Application-defined windows and dialog boxes, file system access, registry access, WinForms interop, and more
Deployment
ClickOnce, XCopy or MSI
Installed or live running

Trees
Element Trees
Logical Tree
Visual Tree

Element Tree Hierarchy
The composition of elements creates a couple of hierarchical trees
Logical Tree
Visual Tree
There is an additional tree in WPF called the automation tree, but we won’t cover that in this session

Logical Tree
The logical tree is composed of the elements that are explicitly listed in the XAML
The leaves of the logical tree may also be non-visual objects (CLR objects)
The content of a ContentControl
The items of an ItemsControl

Visual Tree
The visual tree is composed of the visuals used to represent the logical tree
This includes all inflated control and data templates for elements in the logical tree

Visual & Logical Tree

Tree Traversal
Logical Tree Traversal
The LogicalTreeHelper class provides several methods for traversing the logical tree
LogicalTreeHelper is not needed very often in practice because most controls have properties exposing their logical children

Tree Traversal, cont.
Visual Tree Traversal
The VisualTreeHelper class provides methods needed for traversing the visual tree
Although the Windows SDK indicates you won’t need to use VisualTreeHelper very often, in practice you will probably use it regularly

Resolving via trees
Resource resolution favors logical tree
Property Inheritance favors logical tree
Events route through the visual tree

Property System
Dependency Properties
Dependency Property Value Precedence
Creating Dependency Properties
Attached Properties
Dependency Property Metadata
Inherited Dependency Properties

The heart of the WPF property system
Enable most of the WPF features
Data Binding
Styling
Attached Properties
Animation
Property Invalidation
Property Inheritance
Default Values
Sparse Storage

Dependency Properties Exposes Dependency Properties Consumes Dependency Properties Does not have to derive from DependencyObject Derives from DependencyObject DependencyObject CustomClassA CustomClassB

Dependency Property Value Precedence
Validation
Property coercion
Animations
Local value
Style triggers
Template triggers
Style setters
Theme style triggers
Theme style setters
Property value inheritance
Default value

Creating Dependency Properties
Inherit from DependencyObject
Call DependencyObject.Register
Create standard .NET Framework property

Attached Properties
Inherit from DependencyObject
Call DependencyProperty.RegisterAttach
Create two static methods Get nnn /Set nnn

Dependency Property Metadata

The FrameworkPropertyMetadata class enables the setting of metadata for a property; an instance of this class should be passed when registering the property, be it attached or just a simple dependency property.

Inherited Dependency Properties
Inherited by using the logical tree
Disabled by default (performance reasons)
Must be an AttachedDependencyProperty
Favors the logical tree
If an element does not have a logical parent, its properties will be inherited

Events
Direct Events
Tunneling Events
Bubbling Events
Routed Events
Raising and Handling Events
RoutedEventArgs

Direct Events
Direct events only go to the originating element
Direct events behave like standard CLR events
The difference is that you can trigger on direct events

Direct Events :ListBox Bd:Border :ScrollViewer :Grid :Rectangle :ScrollContentPresenter :ItemsPresenter :VirtualizingStackPanel :ListBoxItem :ListBoxItem :ListBoxItem : AdornerLayer : ScrollBar : ScrollBar

Tunneling Events
Tunneled events begin with the highest visual parent
Moves down through the visual tree
Tunneling events are, by convention, prefixed with the word “Preview”

Tunneling Events :ListBox Bd:Border :ScrollViewer :Grid :Rectangle :ScrollContentPresenter :ItemsPresenter :VirtualizingStackPanel :ListBoxItem :ListBoxItem :ListBoxItem :AdornerLayer :ScrollBar :ScrollBar

Bubbling Events
Bubbled events begin with the source visual element
Moves up through the visual tree

Bubbling Events :ListBox Bd:Border :ScrollViewer :Grid :Rectangle :ScrollContentPresenter :ItemsPresenter :VirtualizingStackPanel :ListBoxItem :ListBoxItem :ListBoxItem :AdornerLayer :ScrollBar :ScrollBar

RoutedEventArgs
Marking the event as “handled” will generally stop the routing of the event
Set the Handled property on RoutedEventArgs to true
If the event is a preview event, this will also prevent raising the corresponding bubbling event
Handlers can be registered to receive handled events also

RoutedEventArgs :ListBox Bd:Border :ScrollViewer :Grid :Rectangle :ScrollContentPresenter :ItemsPresenter :VirtualizingStackPanel :ListBoxItem :ListBoxItem :ListBoxItem :AdornerLayer :ScrollBar :ScrollBar

Raising and Handling Events
A routed event may be raised on any element within the visual tree
A handler for the event may be attached to any element higher in the visual tree
Attached Events
Neither the element on which it is raised nor the element on which it is handled "own" that event

XAML
The XAML language also defines a special type of event called an attached event. An attached event enables you to add a handler for a particular event to an arbitrary element. The element handling the event need not define or inherit the attached event, and neither the object potentially raising the event nor the destination handling instance must define or otherwise "own" that event as a class member.
The WPF input system uses attached events extensively. However, nearly all of these attached events are forwarded through base elements. The input events then appear as equivalent non-attached routed events that are members of the base element class. For instance, the underlying attached event Mouse..::.MouseDown can more easily be handled on any given UIElement by using MouseDown on that UIElement rather than dealing with attached event syntax either in XAML or code.

Raising and Handling Events :ListBox Bd:Border :ScrollViewer :Grid :Rectangle :ScrollContentPresenter :ItemsPresenter :VirtualizingStackPanel :ListBoxItem :ListBoxItem :ListBoxItem :AdornerLayer :ScrollBar :ScrollBar Event Handler

Attached Event Example <StackPanel Button.Click="CommonClickHandler" > <Button Name="YesButton">Yes</Button> <Button Name="NoButton" >No</Button> <Button Name="CancelButton">Cancel</Button> </StackPanel>

Commands
Commands Overview
RoutedCommand
Framework Commands
Control Support for Commands
Custom Commands

Commands Overview
Routed Commands
Encapsulate an action as an object
Separate the action from the handling of the action
Improved Designer/Developer workflow
When controls support commands it enables designers to very easily wire the invoking of those actions to whatever UI element they deem necessary

Commands
Commands in WPF are a more abstract and loosely-coupled version of routed events. The core concept of commanding in WPF is that the action is separate from both the source and the implementation of the command. An example would be the Cut, Copy, and Paste commands; these commands can be executed from many sources, such as a button, a menu item or a keyboard shortcut, but the implementation for each of the commands could be a single event handler.
By abstracting the action, or command, from the object that acts as the source and the implementation improves the designer and developer workflow, as the designer can simply say that they want a specific action to occur and leave it to the developer to actually implement command behaviour. Alternatively a developer can define a behaviour and have the designer easily wire that up in the UI with commands.

Commands Overview Cut Command Copy Command Paste Command

Commands
Commands in WPF are a more abstract and loosely-coupled version of routed events. The core concept of commanding in WPF is that the action is separate from both the source and the implementation of the command. An example would be the Cut, Copy, and Paste commands; these commands can be executed from many sources, such as a button, a menu item or a keyboard shortcut, but the implementation for each of the commands could be a single event handler.
By abstracting the action, or command, from the object that acts as the source and the implementation improves the designer and developer workflow, as the designer can simply say that they want a specific action to occur and leave it to the developer to actually implement command behaviour. Alternatively a developer can define a behaviour and have the designer easily wire that up in the UI with commands.

RoutedCommand
Command (ICommand)
action
Command Source (ICommandSource)
invoker of the action
Command Target
The object on which the command is executed
If unset, the command is raised on the element with keyboard focus
Command Binding (CommandBinding)
Maps the command logic to the command

RoutedCommand ICommand ICommandSource Command Target UI connected to a Command by Designers or Developers Cut Command

Framework Commands
MediaCommands
Play, Pause, Select, Stop, more...
ApplicationCommands
Cut, Copy, Paste, Find, Help, more...
NavigationCommands
BrowseBack, BrowseForward, Refresh, more...
ComponentCommands
MoveDown, MoveLeft, ScrollToEnd, more...
EditingCommands
AlignCenter, ApplyFontSize, MergeCells, more...

Framework Commands

Framework Commands
WPF defines a large number of commands built into five classes. This saves the developer effort as they do not have to write commands for Cut, Copy, and Paste for example. Each command is exposed as a static property on the five command classes.

Control Support for Commands
Several WPF classes support easy execution of routed commands:
MenuItem
Button (by way of ButtonBase)
Some WPF classes implement commands out of the box:
TextBox
RichTextBox
By using the Command property on MenuItem or any ButtonBase-derived class commands are automatically executed on the logical click of the element.
Some WPF controls ship with an implementation for some commands, for example the TextBox and RichTextBox controls both have implementations for the Cut, Copy, and Paste commands, by way of the ButtonBase class.

Input Bindings
An input binding binds an input gesture to a command
KeyGesture
MouseGesture

Applications and controls can implement their own custom routed commands by using the ICommand interface:
Or by using the RoutedCommand:
Custom Commands

Commanding
Commanding in WPF does not assume the use of a RoutedCommand or RoutedUICommand base class. Therefore, creating custom commands simply requires the implementation of the ICommand interface. Or they can simply expose a property of type RoutedCommand or RoutedUICommand.

Threading
Threading In WPF
Dispatcher
DispatcherObject
Invoke and BeginInvoke
Multiple UI Threads
Freezables

Threading In WPF
Multiple independent threads in WPF
The UI thread
The Render Thread
WPF UI is single threaded in the sense that most UI objects can only be associated with one thread
There are exceptions:
Static classes
Freezables

Dispatcher
The Dispatcher object is effectively the event loop for the UI thread
There is one Dispatcher instance per UI thread
Dispatcher.UnhandledException is great for catching data-binding/styling issues.

Dispatcher Each thread that creates UI objects needs and has affinity with a Dispatcher object. The Dispatcher owns the thread, the message loop and is responsible for dispatching to the appropriate handlers. Dispatcher Owns The Thread Owns the Message Loop Dispatches To Handlers

DispatcherObject
Most WPF objects derive from DispatcherObject
DispatcherObject Object Visual D ependencyObject

DispatcherObject
DispatcherObject associates an object with a Dispatcher and gives you methods to ensure that calling threads have access to the object.
CheckAccess method:
Returns a bool that indicates if access is allowed
VerifyAccess method:
Throws an exception if access is not allowed
Custom controls must use the VerifyAccess method in public members to ensure that only UI threads access it.
If you use dependency properties you don’t have to worry about doing this yourself in property setters (It is done within DependencyObject.SetValue

Invoke and BeginInvoke
Invoke and BeginInvoke are used to push events onto a Dispatcher’s queue
The Dispatcher’s event queue is “free-threaded” so any thread can call Invoke and BeginInvoke
These methods are typically used by background threads that need to communicate with the UI thread
These methods can also be used to queue work on the UI thread from the UI thread itself

Dispatcher Operation
BeginInvoke returns a DispatcherOperation object which can be used to interact with the delegate when the delegate is in the event queue
The DispatcherOperation object can be used in several ways to interact with the specified delegate, such as:
Changing the DispatcherPriority of the delegate as it is pending execution in the event queue
Removing the delegate from the event queue
Waiting for the delegate to return
Obtaining the value that the delegate returns after it is executed

Dispatching Priorities
The Dispatcher maintains a prioritized queue of work items for a specific thread
Priority Processed Send Before other asynchronous operations. This is the highest priority Normal Normal priority. This is the typical application priority DataBind At the same priority as data binding Render At the same priority as rendering Loaded When layout and render has finished but just before items at input priority are serviced. Specifically this is used when raising the Loaded event Input Processed at the same priority as input Background After all other non-idle operations are completed Context Idle After background operations are completed ApplicationIdle Application is idle SystemIdle Processed when the system is idle Inactive Not processed

Multiple UI Threads
In some scenarios it makes sense to have multiple UI threads in an application
For example an MDI application where each document or window gets its own thread
Each UI thread gets its own Dispatcher in this case

Coding UI Threads
To create another UI thread, call the Dispatcher.Run static method on a new thread.
using System;
using System.Threading;
using System.Windows;
using System.Windows.Threading;
namespace MuiltpleUIThreads
{
public partial class MainWindow : Window
{
public MainWindow()
{
InitializeComponent();
this.Title = this.Dispatcher.GetHashCode().ToString();
}
private void Button_Click(object sender, RoutedEventArgs e)
{
Thread t = new Thread(new ThreadStart(NewUIThread));
t.SetApartmentState(ApartmentState.STA); // All UI element must be on a STA thread.
t.Start();
}
private void NewUIThread()
{
MainWindow win = new MainWindow();
win.Show();
Dispatcher.Run(); // Start a new UI Thread.
}
}
}

Freezables
Objects with two states:
Frozen – shared across threads, no change notification, immutable
Unfrozen
Inherits from Freezable
Includes Brush, KeyFrame, Transform, Pen, Geometry,Drawing, ImageSource ….

Freezables
Freezable defines an object that has a modifiable state and a read-only (frozen) state. Classes that derive from Freezable provide detailed change notification, can be made immutable, and can clone themselves.
The Freezable class makes it easier to use certain graphics system objects and can help improve application performance. Examples of types that inherit from Freezable include the Brush, Transform, and Geometry classes; as they contain unmanaged resources, WPF must monitor these objects for modifications, and then update their corresponding unmanaged resources when there is a change. Even if the object is not actually modified, the system must still spend some of its resources monitoring the object, in case it does get changed it. Freezing an object tells WPF to stop monitoring the object for changes, and therefore provides a potential performance boost and removes the thread affinity for the object, so it can be used safely on many threads.
If the object subsequently needs to be modified it is possible to then clone the object into a new instance, which will be unfrozen.

Triggers
There are three types of Triggers in WPF
Property Triggers
Data Triggers
Event Triggers
Triggers are implemented by using the Style.Triggers property

Property Triggers
Used to monitor a DependencyProperty's value
This code demonstrates the changing of the FontWeight property by using a Trigger:

Data Triggers
Data triggers are executed when the value of any property changes using data binding
This code shows a DataTrigger:

Event Triggers
Event triggers are executed when a routed event occurs
The following code example shows an EventTrigger:

Presenter Name Title Microsoft Corporation

http://www.uxmagic.com	172
http://www.slideshare.net	27
http://www.e-presentations.us	3
http://uxmagic.com	2
http://blog.donburnett.com	1
http://wpfdesign.blogspot.com	1

WPF Fundamentals

by www.donburnett.com

Accessibility

Categories

Upload Details

Usage Rights

6 Embeds 206

Statistics

WPF Fundamentals Presentation Transcript
