Ada and Ada 2012 – Overview and rationale            Quentin Ochem            Technical Account ManagerCopyright © 2012 Ad...
Why Programming                           Languages Matter?Copyright © 2012 AdaCore                       Slide: 2
Presentation Scope             • In High-Reliable Software, the choice is usually               being made between        ...
Human Resources Criteria             • There are more people that know C++ than Ada             • There are more people th...
Human Resources Criteria                              Visual BasicCopyright © 2012 AdaCore                     Slide: 5
Is Programmers‟ Language Skill an Issue?             • Main software paradigms are key                      – Object orien...
Show-Stopper Criteria             •      Is the language supported by the industry?             •      Does the language h...
Other Criteria of Interest             •      What direction does the evolution of the language take?             •      W...
Goal: Reducing Costs (Finding Errors and Inconsistencies Earlier)                                                         ...
Goal: Finding Errors and Inconsistencies Earlier                                                      Problem Found       ...
Easing the Reaching Higher Levels of Reliability                                                                   Reliabi...
How do we get there?Copyright © 2012 AdaCore                          Slide: 12
The One-Line-Of-Code Hell             •      Is “tab” null? Can’t tell.             •      Is “tab” an array? Can’t tell. ...
The One-Line-Of-Code Hell             •      Is “tab” null? No, tab is an array.             •      Is “tab” an array?    ...
Driving Design Principles             •      Be explicit as much as possible                      –    Put as much (formal...
Driving Rationale             •      Ada eases manual and automatic analysis at various levels:                      –    ...
Strong Typing             •      A type is a semantic entity, independent from its implementation             •      Stron...
Strong typing (continued)             • Enumerations have a dedicated semantic   type Color is                            ...
Arrays             • Arrays can be indexed by any discrete types               (integers, enumeration)             • First...
Array Copy, Slicing and Sliding             •      Arrays provide a high-level copy sematic                              t...
Parameter Modes             •      Three parameter modes : in (input), out (output) and in-out                    (input/o...
Pre, Post Conditions and Invariants             • Generalized contracts are available through pre- and post-              ...
Package Architecture             •      All entities are subject to encapsulation                      –    Not only OOP c...
Privacy             •      A package contains well identified public and private parts             •      The user can con...
Private Types             •      A private type can be implemented by any data structure                           package...
Data Representation             •      Allows to optimize memory usage             •      Allows to precisely map data    ...
Genericity             •      Instanciation has to be explicit                     generic                           templ...
Object Orientation             •      Ada implements full OOP principles                      –    Encapsulation          ...
Object Orientation Example                           type Root is tagged record                              F1 : Integer;...
If pointers are needed…             •      Pointers are typed, associated with accessibility checks             •      Obj...
Concurrent Programing             •      Threads and semaphore are first class citizens                      task Some_Tas...
Why is all of this of any use?             • For readability                      – Specification contains formally expres...
Yes But…             •      It is possible to reach similar levels of safety with other                    technologies (M...
Key MessagesCopyright © 2012 AdaCore   Slide: 34
Ada Evolution                                                                     Ada 2012                                ...
In out parameters for functions             • Ada 83 to 2005 forbids the use of in out for function             • Since Ad...
Aliasing detection             • Ada 2012 detects “obvious” aliasing problems       function Change (X, Y : in out Integer...
Pre, Post conditions and Invariants             • The Ada 2012 standard normalizes pre-conditions, post-               con...
Conditional expressions             • It will be possible to write expressions with a result               depending on a ...
Iterators             • Given a container, it will be possible to write a simple loop               iterating over the ele...
Quantifier expressions             • Checks that a property is true on all components of a               collection (conta...
Generalized memberships tests             • Memberships operations are now available for all kind of               Boolean...
Expression functions             • Function implementation can be directly given at               specification time if it...
Containers             • Ada 2005 containers are unsuitable for HIE application                      – Rely a lot of the r...
Processor affinities             • Task can be assigned to specific processors             • Enhances control over program...
Ada 2012 safety improvements             • Improve readability                      – Specification contains formally expr...
