The Yamal-402 geostationary communications satellite was launched on December 8, 2012 by Gazprom Space Systems to provide Ku-band satellite communications services from 55°E orbital slot. It has 46 transponders across multiple beams with transmission power of 150W and accuracy of 0.1 degrees for station keeping and satellite orientation. The satellite provides coverage of Russia, Europe, and northern regions with various transponder bandwidths and polarization configurations.

1. YAMAL-402GEOSTATIONARY COMMUNICATIONS SATELLITE
The Satellite was Launched December 8, 2012
www.gazprom-spacesystems.ru
Orbital slot 55°E
Payload Power 10 800 W
Frequency Band Ku
Number of Transponders and Bandwidth
12x72 MHz,
16x54 MHz,
18x36 MHz
Transmitter Output Power 150 W
Polarization Linear
Station Keeping Accuracy 0.1°
Satellite Axes Orientation Accuracy 0.1°
55E

2. SOUTHERN BEAM
Ku-band
Linear Polarization
8 transponders х 54 МГц
RUSSIAN BEAM
Ku-band
Linear Polarization
18 transponders х 36 МГц
4 transponders х 54 МГц
Russia, 141112, Moscow region,
Schelkovo, Moscow street, bld. 77B
info@gazprom-spacesystems.ru
www.gazprom-spacesystems.ru
NORTHERN BEAM
Ku-band
Linear Polarization
9 transponders х 72 МГц
STEERABLE BEAM
Ku-band
Linear Polarization
3 transponders х 72 МГц
EIRP, dBW Dish size, m
53 0,9
52 0,9
51 0,9
EIRP, dBW Dish size, m
53 0,9
52 1,2
51 1,2
50 1,2
49 1,2
48 1,2
47 1,2
46 1,8
45 1,8
44 1,8
43 2,4
EIRP, dBW Dish size, m
51 0,6
50 0,75
49 0,8
48 0,9
47 1,0
46 1,2
45 1,2
Antenna diameters are indicated for receipt of a TV package in saturated transponders
Cross-connection possibility: Europeanbeam with Southern beam, Northern beam with Steerable beam.
EUROPEAN BEAM
Ku-band
Linear Polarization
4 transponders х 54 МГц
EIRP, dBW Dish size, m
54 0,9
53 0,9
52 1,2
51 1,2
50 1,2
49 1,2
47 1,2
45 1,8
