Steplead
Lead Your Steps to A More Successful Business!
FILLING MACHINE FOR
SMALL DRINK BOTTLE
Automatic Water Filling Machine
                                  For Small Beverage Drink Bottles, 3-in-1 Style
                                  Process: Bottle Rinsing + Filling +Capping




SLW machine combines full-automatic multiple-function washing, filling
and capping unit. It is used in washing. filling and sealing all kinds of non-
air drinks such as fruit juice, oil, vinegar, wine, fruit wine, mineral water
and pure water. The line has features of unique design, new style,
complete functions, multi-purpose, convenient in operation, beautiful
construction, high automaticity. It is the best filling equipment in China.


         Model                 SLW14125            SLW18186             SLW24248           SLW323210


 Number of Rising, Filling
                                 14, 12, 5           18, 18, 6            24, 24, 8          32, 32, 10
  and Capping Heads


 Production Capacity for
                                2,000-4,000         5,000-6,000         8,000-10,000       12,000-15,000
  500ml (Bottles/Hour)



  Suitable Bottles (MM)                             Φ500-100, H=150-320, 330-2000ML



    Rinsing Pressure
                                                                  2-3
         (KG/CM)



    Motor Power (KW)                1.5                 2.2                  3                   4



     Dimension (MM)          2,100×1,400×2,500   2,500×1,800×1,950   2,750×2,180×2,200   3,500×2,200×2,250



       Weight (KG)                 2,300               3,500               4,200               5,500
Automatic Carbonated Drink Filling Machine
                                          For Small Beverage Drink Bottles, 3-in-1 Style
                                          Process: Bottle Rinsing + Filling +Capping




        SLC series machine combines washing, filling and rotary capping functions
        in one unit, is a fully automatic and high efficiency liquid packing equipment.
        It is suitable for packing beverage containing gas. Its performance is as
        following: all parts, for instance, filling valve, which directly contact medium
        are made of stainless steel or harmless material.



                 Model                 SLC14125            SLC18186             SLC24248           SLC323210


         Number of Rising, Filling
                                         14, 12, 5           18, 18, 6            24, 24, 8          32, 32, 10
          and Capping Heads


         Production Capacity for
                                        2,000-4,000         5,000-6,000         8,000-10,000       12,000-15,000
          500ml (Bottles/Hour)



          Suitable Bottles (MM)                             Φ500-100, H=150-320, 330-2000ML



            Rinsing Pressure
                                                                          2-3
                 (KG/CM)



            Motor Power (KW)               2.07                 3.2                 3.92                7.5



             Dimension (MM)          2,300×1,600×2,500   2,460×1,860×2,650   3,100×2,100×2,650   4,350×2,880×3,200



               Weight (KG)                 2,800               3,650               4,800               6,000
Automatic Fruit Juice and Tea Filling Machine
                                           For Small Beverage Drink Bottles, 3-in-1 Style
                                           Process: Bottle Rinsing + Filling +Capping




         SLH fully automatic rinsing, filling and rotary capping combined machine,
         can be used to asepsis filling. It can apply to fill hot fruit juice. tea and
         other beverage into thermal proof PET bottle by changing few parts. The
         complete set of machine is more advanced in technique, smaller in space
         occupied, more compact in structure, it is suitable for normal temperature
         filling or hot filling PET bottled no gas contained beverages.


                  Model                 SLH14125            SLH18186             SLH24248           SLH323210


          Number of Rising, Filling
                                          14, 12, 5           18, 18, 6            24, 24, 8          32, 32, 10
           and Capping Heads


          Production Capacity for
                                         2,000-4,000         5,000-6,000         8,000-10,000       12,000-15,000
           500ml (Bottles/Hour)



           Suitable Bottles (MM)                             Φ500-100, H=150-320, 330-2000ML



             Rinsing Pressure
                                                                           2-3
                  (KG/CM)



             Motor Power (KW)               1.87                2.57                 3.7                 5.5



              Dimension (MM)          2,300×1,680×2,650   2,500×1,760×2,650   3,100×2,100×2,650   3,800×2,800×2,650



                Weight (KG)                 2,600               3,500               4,650               6,800
Supporting Equipment for Drink Bottle Filling




Label Sleeving, Shrinking Machine     Shrink Wrapping Machine        Warming / Cooling Machine       Code Inkjet Printer




  Auto Bottle Unscrambler           Self-adhesive Labeling Machine        Cap Elevator           Pallet Stretch Shrinking Machine
Supporting Equipment for Drink Bottle Filling




Sugar Melting Pot        Syrup Pump          Syrup Filter        Preparation Tank




 Syrup Cooler                   CO2 Filter    Beverage Mixer   Water Cooler
Turnkey Project Solution for Making Bottled Mineral Water, Pure Water.




1. Flowchart Process of Bottled Mineral Water




2. Flowchart Process of Bottled Pure Water
Turnkey Project Solution for Making Vegetable, Fruit Juice and Yogurt Drink .




3. Flowchart Process of Carbonated Drink




4. Flowchart Process of Vegetable and Fruit Juice Drink
FILLING MACHINE FOR
 3-5 GALLON BOTTLE
Automatic Water Filling Machine
                                           For 3 - 5 Gallon Bottles, 3-in-1 Style
                                           Process: Bottle Rinsing + Filling +Capping




                                                               Model: SL-600(600Bottles/Hour)
                                                               Power: AC 380V/50Hz
                                                               Input Watt: 19.0KW
                                                               Bottle Spec: Φ270x490xΦ56MM
                                                               DD            Φ230x460xΦ56MM
                                                               Bottle Volume: 3 or 5 gallons
                                                               Cap Spec.: Φ58x40MM
                                                               Air Pressure: P≥0.5MPa
                                                               Rinsing Capacity: 60 0Bottles/Hour
                                                               Filling Capacity: 60 0Bottles/Hour
                                                               Dimension: 3 , 60 0x 1 , 4 20x1, 65 0MM
                                                               Weight: 1 ,650 KGS




Model: SL-100(200Bottles/Hour)                                         Model: SL-300(300Bottles/Hour)
Power: AC 380V/50Hz                                                    Power: AC 380V/50Hz
Input Watt: 4.2KW                                                      Input Watt: 6.4KW
Bottle Spec: Φ270x490xΦ56MM                                            Bottle Spec: Φ270x490xΦ56MM
DD            Φ230x460xΦ56MM                                           DD            Φ230x460xΦ56MM
Bottle Volume: 3 or 5 gallons                                          Bottle Volume: 3 or 5 gallons
Cap Spec.: Φ58x40MM                                                    Cap Spec.: Φ58x40MM
Air Pressure: P≥0.5MPa                                                 Air Pressure: P≥0.5MPa
Rinsing Capacity: 20 0Bottles/Hour                                     Rinsing Capacity: 30 0Bottles/Hour
Filling Capacity: 20 0Bottles/Hour                                     Filling Capacity: 30 0Bottles/Hour
Dimension: 3 , 27 0x 1 , 2 00 x1, 85 0MM                               Dimension: 3 ,3 5 0x 98 0x1, 85 0MM
Weight: 320 KGS                                                        Weight: 400 KGS
Automatic Water Filling Machine
                                         For 3 - 5 Gallon Bottles, 3-in-1 Style
                                         Process: Bottle Rinsing + Filling +Capping




                                                             Model: SL-100(1200Bottles/Hour)
                                                             Power: AC 380V/50Hz
                                                             Input Watt: 46.6KW
                                                             Bottle Spec: Φ270x490xΦ56MM
                                                             DD            Φ230x460xΦ56MM
                                                             Bottle Volume: 3 or 5 gallons
                                                             Cap Spec.: Φ58x40MM
                                                             Air Pressure: P≥0. 8 MPa
                                                             Rinsing Capacity: 120 0Bottles/Hour
                                                             Filling Capacity: 120 0Bottles/Hour
                                                             Dimension: Filling Part 4 , 525 x 2,06 0x 2 , 3 00MM
                                                             Weight: 1,86 0KGS




Model: SL-100(600Bottles/Hour)                                      Model: SL-100(900Bottles/Hour)
Power: AC 380V/50Hz                                                 Power: AC 380V/50Hz
Input Watt: 12.8KW                                                  Input Watt: 38KW
Bottle Spec: Φ270x490xΦ56MM                                         Bottle Spec: Φ270x490xΦ56MM
DD             Φ230x460xΦ56MM                                       DD            Φ230x460xΦ56MM
Bottle Volume: 3 or 5 gallons                                       Bottle Volume: 3 or 5 gallons
Cap Spec.: Φ58x40MM                                                 Cap Spec.: Φ58x40MM
Air Pressure: P≥0. 8 MPa                                            Air Pressure: P≥0. 8 MPa
Rinsing Capacity:60 0 Bottles/Hour                                  Rinsing Capacity: 90 0Bottles/Hour
Filling Capacity: 60 0 Bottles/Hour                                 Filling Capacity: 90 0Bottles/Hour
Dimension: 3 , 275 x 1 ,50 0x1, 70 0MM                              Dimension: 3 , 725 x 2 , 06 0x 2 , 3 00MM
Weight: 1 ,23 0KGS                                                  Weight: 1,34 0KGS
Turnkey Project Solution for Making 3-5 Gallon Bottled Water .




                                                                                         Lamp Check




De-capper           Leakage Checker     Inside/Outside Washer   Bottle         3-in-1       Steam Sealer      Bottle Lifter
                                                                Feeder         Filler




                                                                                                                    Ozone
            Water                                                                                     Water         Sterilizing
            Tank                                                                                      Tank




 Water                                                                                                            Treated Water
                             Sand     Carbon   Softener                  RO System      Ozoner
FILLING MACHINE FOR
 OTHER CONTAINERS
Filling Machine for Different Containers



                                                   Filling Machine for 3-7Liters Bottles
                                                   Suitable bottle: Polyester or PET or PE
                                                   Height of barrel: 150mm-300mm
                                                   Diameter of Barrel: Φ130-Φ230
                                                   Air source : 0.6-0.8 M Pa
                                                   Air consumption: 1M
                                                   Flushing pressure: 0.6 Mpa
                                                   Flushing Temperature: Normal
                                                   Power: 0.37 KW
                                                   Capacity: 1200 BPH




Big Sachet Water Filing Machine                  Filling Machine for Sachet/Plastic Bags
Model:SL- 7500                                   Model:SL-1000
The machine is for 12 . 5 L big sachet filing.   Sachet Size:500ML
This machine is an indispensable dedicated       Product Capacity:1500-2100
equipment of bagged water production line.       Filling Range:100-500ml
It is mainly composed of frame, mechanic         General Power:1.2kw/220v
drive system, film feeding system, traction      Size of Bag: L 30-120mm
mechanism, film cleaning and sterilization       d            W 120-160mm
device, ultraviolet radiation device, heat       Machine Size:850×800×1800mm
sealing and cutting device, and canning          Weight:370kg
device
Filling Machine for Different Containers



                   Carton Filling Machine for Different Liquid
                   Packing Size:250ML-1000ML
                   Filling Capacity:4000-5500BPH
                   Theoretical output:24KW
                   Machine Dimension:5980x2580x4318MM
                   Total Weight:2800KG
                   Heating Power:20KW
                   Motor Power:4KW
                   Pressure:4-6 M p a
                   A i r C o n s u m p t i o n : 0 . 3 m ³/Min
BOTTLE BLOW MOLDING MACHINE
PET Bottle Blow Molding Machine

                                                                                           Model: SLB-II
                                                                                           Blowing Capacity: 1500-180 0Bottles/Hour
                                                                                           for 500ml PET bottles
                                                                                           Bottle Volume: 50-2000ml PET bottles




                                                                                           Model: SL-C1
                                                                                           Blowing Capacity: 30 0Bottles/Hour
                                                                                           for 7000ml PET bottles
                                                                                           Bottle Volume: 3000-7000ml PET bottles




Model: SL-A6                                                                               Model: SL-Y
Full automatic blow molding machine is suitable for producing PET/PE and PP                Blowing Capacity: 70-85 Bottles/Hour
plastic containers and bottles in all kinds of shapes.It is widely used to produce         for 20L PET bottles
the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-         Bottle Volume: 8-20L PET bottles
mouth bottle and hot fill bottle etc.
* Reasonable design,full automatic control,save power and labor.Adopt high
quality components.
* Feeding system carries the pertoms by robot automatically.
* Infrared oven heater adopts the quartz lamp to heat the PET tube.
* Fully automatic process with low investment,high efficiency,quick and safe
operation,easy for trouble-shooting,maintenance and other benefits.
PC Bottle Blow Molding Machine




                                                                           Clamping system    Parison closing system




                                                                          Deflashing System      Control system




Model: SL - PC
* Made by German technology and quality parts
* Raw material: PC (polycarbonate) granules
* Bottle volume: 1-5 gallons (mainly for 5 gallons, 19 litters)
* Production capacity: 55 - 60 pcs/hour (5 gallons)
* Quality percentage: 95%
* Including:
1) Injection system; 2) Clamping system; 3) Energy supply;
4) Air source connection; 5) Water source connection;
                                                                             Die heads           Injection system
6) Electric control system; 7) Siemens PLC System.
INJECTION MOLDING MACHINE
Injection Molding Machine




                                                      Preform Injection Molding Machine




                                    Features:
                                    1) Twin pump system for higher flow rate and energy saving.
                                    2) High accuracy proportional pressure and valve with feedback
                                    3) Closed loop injection process control
                                    4) Closed loop metering control
                                    5) Closed loop back pressure control
                                    6) High pressure and suction filter come in standard
                                    7) Ten step injection and holding pressure control.
                                    8) Statistical process control for 8 parameters
                                    9) Direct screen dump and production data to printer
                                    10) Set curve and actual curve display for important parameters
    Cap Injection Molding Machine   11) Sophisticated built-in SPC and quality control system.
COMMERCIAL WATER TREATMENT
Commercial RO Water
Purification Systems                                                                  Model: RO-1000I (2000L/H)
                                                                                      Output: 2000L/H 25Deg.C
Process: Sand Filter + Carbon Filter + PP Sediment                                    Input Power: 6.3KW
                                                                                      Power: AC380V, 50Hz
Filter + RO Filter                                                                    RO Membrane: ESPA4040 10 PCS (2 stages)
                                                                                      Multi-stages Pump: CDL4-160/3KW 1 PC
Capacity: 300L-300000L/H
                                                                                      Pre-filter: Φ 750 x 1,550MM 2 PCS
                                                                                      Precise-filter: Φ 330 x 500MM 5 PCS
                                                                                      Pressure Added Pump: CHL8-30/1.1KW 1 PC
                                                                                      Quartz Sand: 800KGS
                                                                                      Active Carbon:300KGS
                                                                                      Dimensions: Main body 2,500x600x1,640MM




Model: RO-1000I (300L/H, 380V)             Model: RO-1000I (700L/H, 380V)               Model: RO-1000I (1000L/H)
Output: 300L/H 25Degrees.C                 Output: 700L/H 25Degrees.C                   Output:1000L/H 25Deg.C
Input Power: 2.75KW                        Input Power: 4.25KW                          Input Power: 5.25KW
Power: AC380V, 50Hz                        Power: AC380V, 50Hz                          Power: AC380V, 50Hz
RO Membrane: ESPA4040 2 PCS (2 stages)     RO Membrane: ESPA4040 4 PCS (2 stages)       RO Membrane: ESPA4040 6 PCS (2 stages)
Multi-stages Pump: CDL2-180/2.2KW 1 PC     Multi-stages Pump: CDL2-180/2.2KW 1 PC       Multi-stages Pump: CDL4-160/3.0KW 1 PC
Pre-filter: Φ 300 x 1,200MM 2 PCS          Pre-filter: Φ 300 x 1,200MM 2 PCS            Pre-filter: Φ500 x 1,200MM 2 PCS
Precise-filter: Φ 200 x 500MM 1 PC         Precise-filter: Φ 200 x 500MM 1 PC           Precise-filter: Φ 90 x 1,000 MM 5 PCS
Pressure Added Pump: BLC70/0.55KW 1 PC     Pressure Added Pump: BLC70/0.55KW 1 PC       Pressure Added Pump: BLC70/0.75KW 1 PC
Quartz Sand: 43KGS                         Quartz Sand: 43KGS                           Quartz Sand: 250KGS
Active Carbon: 90KGS                       Active Carbon: 90KGS                         Active Carbon: 125KGS
Dimensions: Main Body 1,500x560x1, 500MM   Dimensions: Main Body 1,660x600x1, 540MM     Dimensions: Main Body 1 , 7 00x700x1, 6 70MM
RO-1000I (1000L/H, 380V)
                                                                        Output: 1000L/H 25Deg. C
                                                                        Import Power: 5.5KW
                                                                        Power: AC380V, 12A, 50Hz
                                                                        RO Membrane: ESPA4040 6 PCS (2 stages)
                                                                        Multi-stages Pump: CDL4-160/3KW 1 PC
                                                                        CDL2-150/1.5KW 1 PC
                                                                        Pre-filter: (Diameter)450 x 1,650 2 PCS
                                                                        Precise-filter: (Diameter)90 x 1,000 5 PCS
                                                                        Pressure Added Pump: BLC70/0.75KW 1 PC
                                                                        Quartz Sand: 250KGS
                                                                        Active Carbon: 125KGS
                                                                        Dimensions: 3,200x700x1,970MM




Model: RO-1000I (20000L/H)             Model: RO-1000I (10000L/H)
Output: 20000L/H 25Deg. C              Output: 10000L/H 25Deg. C
Import Power: 22.5KW                   Import Power: 42KW
Power: AC380V, 45A, 50Hz               Power: AC380V, 45A, 50Hz
RO Membrane: CPA2-8040 20PCS           RO Membrane: BW30-400 20PCS
Multi-stages Pump: CR20-17 1 PC        Multi-stages Pump: CHL30-20-2 1PC
Pre-filter: Φ 1600 x 3000MM 2 PCS      D                     CR20-17 1 PC
Precise-filter: Φ 400 x 1,000MM 1 PC   Pre-filter: Φ 1400 x 2600MM 2 PCS
Pressure Added Pump: CR32-2 1 PC       Precise-filter: Φ 400 x 1,000MM 7 PC
Quartz Sand: 3500KGS                   Pressure Added Pump: CHL30-20-2 1 PC
Active Carbon: 1100KGS                 Quartz Sand: 3800KGS
Commercial Mineral Water
Purification Systems
Process: Sand Filter + Carbon Filter + PP Sediment
Filter + UF Filter
Capacity: 1000L-200000L/H




Model: UF-1000I (1000L/H, 380V)                 Model: UF-1000I (6000L/H, 380V)              Model: UF-1000 I (8000L/H)
Output: 1000L/H 25Degrees.C                     Output: 6000L/H 25Degrees.C                  Output:8000L/H 25Deg.C
Input Power: 550W                               Input Power: 3.12KW                          Input Power: 2.5KW
Power: AC380V, 50Hz                             Power: AC380V, 50Hz                          Power: AC380V, 50Hz
UF Membrane: Φ 95x1 , 000 MM 2 PCS (2 stages)   UF Membrane: 4040 12 PCS                     UF Membrane: 8040 2 PCS
Pre-filter: Φ 300 x 1,200MM 2 PCS               Pre-filter: Φ75 0 x 1, 5 00MM 2 PCS          Pre-filter: Φ900 x 2,600MM 2 PCS
Precise-filter: Φ330 x 500MM 2 PC               Precise-filter: Φ 330 x 500MM 8 PC           Precise-filter: Φ 90 x 1,000 MM 5 PCS
Quartz Sand: 90KGS                              Pressure Added Pump: CHL8-30 / 1.1 KW 1 PC   Pressure Added Pump: CDLF16-20 1 PC
Active Carbon: 43KGS                            Quartz Sand: 800KGS                          Quartz Sand: 1200KGS
UV Light: 40W 1PCS                              Active Carbon: 300KGS                        Active Carbon: 325KGS
Dimensions: Main Body 560x560x1, 500MM          UV Light: 40W 3PCS                           Dimensions: Main Body 1,600x750x1,700MM
                                                Dimensions: Main Body 2100x660x1, 600MM
Commercial Seawater Desalination
Purification Systems
Process: Sand Filter + Carbon Filter + PP Sediment
Filter + UF Filter
Capacity: 1000L-200000L/H




                     Multi-
                                                                          Function Discretion:
                                       Carbon                             ST series middle to large scale seawater desalination equipment is suitable for Sea
                     medium
                                       Filter                             Islands, troop stations and sea shore cities short of water. They can effectively
                     Filter                          Precise
                                                                          remove harmful elements such as inorganic salts, heavy metal ions, organic bacteria,
                                                     Filter
                                                                          pathogens, etc. and desalinate the seawater to good quality water complying with the
                                                                          National Drinking Water Quality Standard. In this series, the pre-treatment system
              Pump                                                        consists of a full-automatic multi-channel valve to perform automatic and large
                                                                          volume flush and back-flush processing. The shell and pipe are made of anti-
                                                                          corrosion materials, making for a complete system that is highly durable and long-
                                                                          lasting. The main RO system consists of the most advanced RO system elements,
  Sea Water                                                               and is designed with unique energy recovery technology to perform at the lowest
                          RO Unit                                         energy cost. The system is also equipped with an advanced monitoring system to
                                                                          assure its stability, quality of the product water (when the product water quality
                                                                          exceeds the alarm salinity value, the drain valve will open automatically to drain the
                 Dosing
                                                                          product into drainage) and provide accurate information on performance. There are
                 System
                                                                          advanced control instruments such as flow meters, pressure gauges, pressure relief,
                              Output            Energy         High       and drain pipes. These make the piping system more stable and safe so that the
                              Water             Recycle        Pressure   system is maintenance safe and reliable.
                                                               Pump
Supporting Equipment for Water Treatment




  UV Light       Ozone Water Generator   Ozone Blender     Water Softener




Water Tank1          Water Tank2         Vending Machine   Chemical Feeder
WATER DISPENSER
Bottled Type Water Dispenser
                                                                                                                         Floor Standing




Model: YLR2-5-X(28L-B/B)          Model: YLR2-5-X(168L)                               Model: YLR2-5-X(12L)
Hot and Cold, Floor Standing,     Hot and cold, Floor Standing, Expert                Hot and Cold, Floor Standing
Compressor Cooling, with 20L      Craft and Quality Components,                       ,Efficiency Compressor with CFC free,
Opaque-door Cooling Compartment   Universal Non-spill Water Guard                     Perfect Classic Shape Design,
                                  System. Stainless Steel Cold Reservoir.




                                                    Model                   28L-B/B      168L                 12L

                                                 HEATING WATT                500W         500W                500W

                                                 COOLING WATT                110W         110W                110W

                                                GROSS WEIGHT                 25.0KG       17KG               20.0KG


                                                  NET WEIGHT                 23.0KG       15KG               18.5KG

                                                  DIMENSIONS           34X35X100CM    40x37.5x110CM       39x40.5x106CM

                                                FCL(20FT/40FT)          168/336PCS     168/348 PCS         168/348 PCS
Bottled Type Water Dispenser




Model: YLR2-5-X(16L-B/C)        Model: YLR2-5-X(16L/E)
Hot and Cold, Floor Standing,   Hot and Cold, Floor Standing,
Compressor Cooling              Compressor Cooling




                                                                       Model: YLR2-5-X(20T-BN6)                   Model: YLR2-5-X(20L-BN6)
                                                                       Hot and Cold, Tabletop Standing,           Hot and Cold, Floor Standing,
                                                                       Microchip Controlled, VFD                  Microchip Controlled, VFD
                                                                       Display, Freely Setting                    Display, Freely Setting
                                                                       Heating/Cooling Temperature                Heating/Cooling Temperature
                                                                       Freely Setting On/Off Time,                Freely Setting On/Off Time,



                                                                    Model                16L-B/C             16L/E             20L-BN6

Model: YLR2-5-X(16L-B/C)        Model: YLR2-5-X(16T/E)           HEATING WATT              500W               500W               500W
Hot and Cold, Floor Standing,   Hot and Cold, Floor Standing,
                                                                 COOLING WATT              110W               110W               110W
Compressor Cooling              Compressor Cooling
                                                                 GROSS WEIGHT             21.5KG              17KG               23.0KG

                                                                  NET WEIGHT              20.0KG              15KG               21.0KG

                                                                  DIMENSIONS            31X31X96CM        40x37.5x110CM       36X31X95CM

                                                                 FCL(20FT/40FT)         180/372PCS         168/348 PCS         180/360PCS
Bottled Type Water Dispenser
                                                                                                                              Floor Standing




Model: YLR2-5-X(28L-B)            Model: YLR2-5-X(50L-BC)                  Model: YLR2-5-X(16L-B)               Model: YLR2-5-X(280L)
Hot and Cold, Floor Standing,     Hot and Cold, Floor Standing,            Hot and Cold, Floor Standing,        Hot and Cold, Floor Standing,
Compressor Cooling, with 20L      Compressor Cooling, with 50L             Compressor Cooling, with 16L         Compressor Cooling
Opaque-door Cooling Compartment   Opaque-door Cooling Compartment          Opaque-door Cooling Compartment
                                                                ,




                                                             Model              28L-B              50L-BC         16L-B              280L

                                                          HEATING WATT            500W              500W           500W                 500W

                                                          COOLING WATT            110W              130W           110W                 110W

                                                          GROSS WEIGHT           25.0KG            30.0KG         21.5KG               25.0KG

                                                           NET WEIGHT            23.0KG            28.0KG         20.0KG               23.0KG

                                                           DIMENSIONS          34X35X100CM      44x40.2x106CM   38x39x100CM          34X35X100CM

                                                          FCL(20FT/40FT)       168/348PCS        120/240 PCS    180/384 PCS          168/348PCS
Supporting Equipment for Water Dispenser




Household RO Filter            Ozone Cleaner   Filter Bottle   Manual Pump




Water Bottles                Bottle Caps       Preforms        Cup Holder
Company Profile
Steplead, not only a leading veteran manufacturer in water product industry, but also a top professional one-stop-
service provider for water plant related equipments, from water treatment, bottle blow molding, bottle washing, filling,
capping, labeling, to wrap packing, etc. And our turn-key project service covers water plant layout design, machine
supply, assemble, installation and commissioning of a complete water plant, also covers excellent after service and
quality guarantee.


We also professional in producing reverse osmosis water purifiers, mineral water equipment, pure water filling
machines, mineral water filling machines, and related packing machineries. In addition, we also provide auxiliary
equipments for the water treatment processing. Due to our super craftsmanship, our products are selling well both at
home and abroad. If you are interested in any of our products or would like to discuss your OEM orders, please feel
free to visit our website for more details or contact us directly with your inquiries. We hope to have the chance of
working together with your company for mutual success.


                                                  Steplead, was founded in 1995, it is All about Drinking Water
                                                  Equipments. Our ISO 9001-certified factory covers an area of
                                                  5,800m2, equipped with 5 production lines. We provide one-stop
                                                  technical service, including design, installation, debugging and
                                                  maintenance. We can provide the technical training for clients. In
                                                  addition, we adopt the Italy and Germanic technique. When the
                                                  equipment gets something wrong, our technicians will provide
                                                  solutions within several hours. Besides, if necessary, we can
                                                  dispatch the technician to solve the problems on spot.
Our Value
Steplead and its employees acceptance for all that we do:

Customer Service: We are dedicated to the satisfaction and success of every customer.

Innovative Idea: Creating value for every customer, created and delivered with speed and efficiency.

Accuracy and truth-seeking: We carry out business and confirmation based on carefully understood facts and
detailed requirement from every customer.

Trustworthiness and integrity: Trust and personal responsibility in all relationship and course




Our Aqua Solution
Liquid package products markets are various; we are involved in
following 5 kinds according to the package features:

· Bottled water production line

· Fruit juice production line

· Carbonated drinks production line

· Tea production line

· 5 gallons rotating filling and packing line
Steplead International Co.,Ltd.
Address: Suite 302, Building NO. 40, Xinxing Village, Shang Mei Lin,
Futian District, Shenzhen, China.
Tel: (+86-755) 29210591
Fax: (+86-755) 83143479
Email: johnlauvip @ gmail .c om
Website: www.steplead.net ; www.steplead.com

More Related Content

Similar to Steplead

Laboratory glassware list
Laboratory glassware listLaboratory glassware list
Laboratory glassware listLabpro India

Blue Magic Catering Equipment 2014
Blue Magic Catering Equipment 2014Blue Magic Catering Equipment 2014
Blue Magic Catering Equipment 2014Cinzia Coppola

Silver Chef Certified Used Equipment NZ
Silver Chef Certified Used Equipment NZSilver Chef Certified Used Equipment NZ
Silver Chef Certified Used Equipment NZSilverChefNZ

4000 bph mineral water production line cbecl
4000 bph mineral water production line cbecl4000 bph mineral water production line cbecl
4000 bph mineral water production line cbeclCBECL BD

Arun Rega Bakery Machineries (Pvt) Limited, Coimbatore, Bakery Mixer, Ovens, ...
Arun Rega Bakery Machineries (Pvt) Limited, Coimbatore, Bakery Mixer, Ovens, ...Arun Rega Bakery Machineries (Pvt) Limited, Coimbatore, Bakery Mixer, Ovens, ...
Arun Rega Bakery Machineries (Pvt) Limited, Coimbatore, Bakery Mixer, Ovens, ...IndiaMART InterMESH Limited

KREA Swiss FOOD Equipment Portfolio
KREA Swiss FOOD Equipment PortfolioKREA Swiss FOOD Equipment Portfolio
KREA Swiss FOOD Equipment PortfolioTrevor Keegan

SaintyCo-Tablet&Capsule Counting Line
SaintyCo-Tablet&Capsule Counting LineSaintyCo-Tablet&Capsule Counting Line
SaintyCo-Tablet&Capsule Counting LineTony Zeng

Technical details of centrifuge tubes
Technical details of centrifuge tubesTechnical details of centrifuge tubes
Technical details of centrifuge tubesBioStar Lifetech


Similar to Steplead (20)

Laboratory glassware list
Laboratory glassware listLaboratory glassware list
Laboratory glassware list

Blue Magic Catering Equipment 2014
Blue Magic Catering Equipment 2014Blue Magic Catering Equipment 2014
Blue Magic Catering Equipment 2014

Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalog Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalog

13/10/2017 Sinergroup - Water softeners
13/10/2017 Sinergroup - Water softeners13/10/2017 Sinergroup - Water softeners
13/10/2017 Sinergroup - Water softeners

Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalogDrop In Housings Cartridges catalog
Drop In Housings Cartridges catalog

Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalog Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalog

Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalog Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalog

Silver Chef Certified Used Equipment NZ
Silver Chef Certified Used Equipment NZSilver Chef Certified Used Equipment NZ
Silver Chef Certified Used Equipment NZ

Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalog Drop In Housings Cartridges catalog
Drop In Housings Cartridges catalog

Water softeners catalogue
Water softeners catalogueWater softeners catalogue
Water softeners catalogue

Water softeners catalogue
Water softeners catalogueWater softeners catalogue
Water softeners catalogue

SVOD product line
SVOD product line SVOD product line
SVOD product line

Presentation of products 2019
Presentation of products 2019Presentation of products 2019
Presentation of products 2019

4000 bph mineral water production line cbecl
4000 bph mineral water production line cbecl4000 bph mineral water production line cbecl
4000 bph mineral water production line cbecl

Arun Rega Bakery Machineries (Pvt) Limited, Coimbatore, Bakery Mixer, Ovens, ...
Arun Rega Bakery Machineries (Pvt) Limited, Coimbatore, Bakery Mixer, Ovens, ...Arun Rega Bakery Machineries (Pvt) Limited, Coimbatore, Bakery Mixer, Ovens, ...
Arun Rega Bakery Machineries (Pvt) Limited, Coimbatore, Bakery Mixer, Ovens, ...

Zeeheng pak
Zeeheng pakZeeheng pak
Zeeheng pak

KREA Swiss FOOD Equipment Portfolio
KREA Swiss FOOD Equipment PortfolioKREA Swiss FOOD Equipment Portfolio
KREA Swiss FOOD Equipment Portfolio

SaintyCo-Tablet&Capsule Counting Line
SaintyCo-Tablet&Capsule Counting LineSaintyCo-Tablet&Capsule Counting Line
SaintyCo-Tablet&Capsule Counting Line

Shaking Incubators - SSI2, SSI3
Shaking Incubators - SSI2, SSI3Shaking Incubators - SSI2, SSI3
Shaking Incubators - SSI2, SSI3

Technical details of centrifuge tubes
Technical details of centrifuge tubesTechnical details of centrifuge tubes
Technical details of centrifuge tubes


More from Lau John

Steps In Carbonated Drink Filling Machine Operation
Steps In Carbonated Drink Filling Machine OperationSteps In Carbonated Drink Filling Machine Operation
Steps In Carbonated Drink Filling Machine OperationLau John

Technology Of Bottled Water Filling Equipment
Technology Of Bottled Water Filling EquipmentTechnology Of Bottled Water Filling Equipment
Technology Of Bottled Water Filling EquipmentLau John

How To Install Water Bottling Machine Tips from iBottling
How To Install Water Bottling Machine Tips from iBottlingHow To Install Water Bottling Machine Tips from iBottling
How To Install Water Bottling Machine Tips from iBottlingLau John

Cola is angry again a 28 year siege
Cola is angry again  a 28 year siegeCola is angry again  a 28 year siege
Cola is angry again a 28 year siegeLau John

The ultimate guide of technical conditi...ing and capping machines google docs
The ultimate guide of technical conditi...ing and capping machines   google docsThe ultimate guide of technical conditi...ing and capping machines   google docs
The ultimate guide of technical conditi...ing and capping machines google docsLau John

Things you should know before buying liquid filling machine – national standa...
Things you should know before buying liquid filling machine – national standa...Things you should know before buying liquid filling machine – national standa...
Things you should know before buying liquid filling machine – national standa...Lau John

Canning and bottling beer,choose the best filling machine for your brewery
Canning and bottling beer,choose the best filling machine for your breweryCanning and bottling beer,choose the best filling machine for your brewery
Canning and bottling beer,choose the best filling machine for your breweryLau John

The 5 top reasons you should choose automatic filling machines
The 5 top reasons you should choose automatic filling machinesThe 5 top reasons you should choose automatic filling machines
The 5 top reasons you should choose automatic filling machinesLau John

The ultimate guide to buy a bottling line
The ultimate guide to buy a bottling lineThe ultimate guide to buy a bottling line
The ultimate guide to buy a bottling lineLau John

Ultimate guide of high speed rotary blow molding machine and critical issues
Ultimate guide of high speed rotary blow molding machine and critical issuesUltimate guide of high speed rotary blow molding machine and critical issues
Ultimate guide of high speed rotary blow molding machine and critical issuesLau John

What is the development status of bottle blowing machine
What is the development status of bottle blowing machineWhat is the development status of bottle blowing machine
What is the development status of bottle blowing machineLau John

How to choose the right filling machine type for your business
How to choose the right filling machine type for your businessHow to choose the right filling machine type for your business
How to choose the right filling machine type for your businessLau John

What is the development status of rotary pet bottle blowing machines in china
What is the development status of rotary pet bottle blowing machines in chinaWhat is the development status of rotary pet bottle blowing machines in china
What is the development status of rotary pet bottle blowing machines in chinaLau John

Why pet bottles the best choice for the beverage industry
Why pet bottles the best choice for the beverage industryWhy pet bottles the best choice for the beverage industry
Why pet bottles the best choice for the beverage industryLau John

What is-common-blow-molding-problems-and-solutions
What is-common-blow-molding-problems-and-solutionsWhat is-common-blow-molding-problems-and-solutions
What is-common-blow-molding-problems-and-solutionsLau John

How plastic bottles are made
How plastic bottles are madeHow plastic bottles are made
How plastic bottles are madeLau John

5 reasons to use an automatic glass bottle filling machine
5 reasons to use an automatic glass bottle filling machine5 reasons to use an automatic glass bottle filling machine
5 reasons to use an automatic glass bottle filling machineLau John

7 tips to master pet blow molding, without breaking a sweat
7 tips to master pet blow molding, without breaking a sweat7 tips to master pet blow molding, without breaking a sweat
7 tips to master pet blow molding, without breaking a sweatLau John

By 2030, the blow moulding machine market will be valued at us$65.1 billion
By 2030, the blow moulding machine market will be valued at us$65.1 billionBy 2030, the blow moulding machine market will be valued at us$65.1 billion
By 2030, the blow moulding machine market will be valued at us$65.1 billionLau John

17 incredibly useful tips for working principle of bottle blow moulder
17 incredibly useful tips for working principle of bottle blow moulder17 incredibly useful tips for working principle of bottle blow moulder
17 incredibly useful tips for working principle of bottle blow moulderLau John


More from Lau John (20)

Steps In Carbonated Drink Filling Machine Operation
Steps In Carbonated Drink Filling Machine OperationSteps In Carbonated Drink Filling Machine Operation
Steps In Carbonated Drink Filling Machine Operation

Technology Of Bottled Water Filling Equipment
Technology Of Bottled Water Filling EquipmentTechnology Of Bottled Water Filling Equipment
Technology Of Bottled Water Filling Equipment

How To Install Water Bottling Machine Tips from iBottling
How To Install Water Bottling Machine Tips from iBottlingHow To Install Water Bottling Machine Tips from iBottling
How To Install Water Bottling Machine Tips from iBottling

Cola is angry again a 28 year siege
Cola is angry again  a 28 year siegeCola is angry again  a 28 year siege
Cola is angry again a 28 year siege

The ultimate guide of technical conditi...ing and capping machines google docs
The ultimate guide of technical conditi...ing and capping machines   google docsThe ultimate guide of technical conditi...ing and capping machines   google docs
The ultimate guide of technical conditi...ing and capping machines google docs

Things you should know before buying liquid filling machine – national standa...
Things you should know before buying liquid filling machine – national standa...Things you should know before buying liquid filling machine – national standa...
Things you should know before buying liquid filling machine – national standa...

Canning and bottling beer,choose the best filling machine for your brewery
Canning and bottling beer,choose the best filling machine for your breweryCanning and bottling beer,choose the best filling machine for your brewery
Canning and bottling beer,choose the best filling machine for your brewery

The 5 top reasons you should choose automatic filling machines
The 5 top reasons you should choose automatic filling machinesThe 5 top reasons you should choose automatic filling machines
The 5 top reasons you should choose automatic filling machines

The ultimate guide to buy a bottling line
The ultimate guide to buy a bottling lineThe ultimate guide to buy a bottling line
The ultimate guide to buy a bottling line

Ultimate guide of high speed rotary blow molding machine and critical issues
Ultimate guide of high speed rotary blow molding machine and critical issuesUltimate guide of high speed rotary blow molding machine and critical issues
Ultimate guide of high speed rotary blow molding machine and critical issues

What is the development status of bottle blowing machine
What is the development status of bottle blowing machineWhat is the development status of bottle blowing machine
What is the development status of bottle blowing machine

How to choose the right filling machine type for your business
How to choose the right filling machine type for your businessHow to choose the right filling machine type for your business
How to choose the right filling machine type for your business

What is the development status of rotary pet bottle blowing machines in china
What is the development status of rotary pet bottle blowing machines in chinaWhat is the development status of rotary pet bottle blowing machines in china
What is the development status of rotary pet bottle blowing machines in china

Why pet bottles the best choice for the beverage industry
Why pet bottles the best choice for the beverage industryWhy pet bottles the best choice for the beverage industry
Why pet bottles the best choice for the beverage industry

What is-common-blow-molding-problems-and-solutions
What is-common-blow-molding-problems-and-solutionsWhat is-common-blow-molding-problems-and-solutions
What is-common-blow-molding-problems-and-solutions

How plastic bottles are made
How plastic bottles are madeHow plastic bottles are made
How plastic bottles are made

5 reasons to use an automatic glass bottle filling machine
5 reasons to use an automatic glass bottle filling machine5 reasons to use an automatic glass bottle filling machine
5 reasons to use an automatic glass bottle filling machine

7 tips to master pet blow molding, without breaking a sweat
7 tips to master pet blow molding, without breaking a sweat7 tips to master pet blow molding, without breaking a sweat
7 tips to master pet blow molding, without breaking a sweat

By 2030, the blow moulding machine market will be valued at us$65.1 billion
By 2030, the blow moulding machine market will be valued at us$65.1 billionBy 2030, the blow moulding machine market will be valued at us$65.1 billion
By 2030, the blow moulding machine market will be valued at us$65.1 billion

17 incredibly useful tips for working principle of bottle blow moulder
17 incredibly useful tips for working principle of bottle blow moulder17 incredibly useful tips for working principle of bottle blow moulder
17 incredibly useful tips for working principle of bottle blow moulder


Steplead

  • 1. Steplead Lead Your Steps to A More Successful Business!
  • 2.
  • 4. Automatic Water Filling Machine For Small Beverage Drink Bottles, 3-in-1 Style Process: Bottle Rinsing + Filling +Capping SLW machine combines full-automatic multiple-function washing, filling and capping unit. It is used in washing. filling and sealing all kinds of non- air drinks such as fruit juice, oil, vinegar, wine, fruit wine, mineral water and pure water. The line has features of unique design, new style, complete functions, multi-purpose, convenient in operation, beautiful construction, high automaticity. It is the best filling equipment in China. Model SLW14125 SLW18186 SLW24248 SLW323210 Number of Rising, Filling 14, 12, 5 18, 18, 6 24, 24, 8 32, 32, 10 and Capping Heads Production Capacity for 2,000-4,000 5,000-6,000 8,000-10,000 12,000-15,000 500ml (Bottles/Hour) Suitable Bottles (MM) Φ500-100, H=150-320, 330-2000ML Rinsing Pressure 2-3 (KG/CM) Motor Power (KW) 1.5 2.2 3 4 Dimension (MM) 2,100×1,400×2,500 2,500×1,800×1,950 2,750×2,180×2,200 3,500×2,200×2,250 Weight (KG) 2,300 3,500 4,200 5,500
  • 5. Automatic Carbonated Drink Filling Machine For Small Beverage Drink Bottles, 3-in-1 Style Process: Bottle Rinsing + Filling +Capping SLC series machine combines washing, filling and rotary capping functions in one unit, is a fully automatic and high efficiency liquid packing equipment. It is suitable for packing beverage containing gas. Its performance is as following: all parts, for instance, filling valve, which directly contact medium are made of stainless steel or harmless material. Model SLC14125 SLC18186 SLC24248 SLC323210 Number of Rising, Filling 14, 12, 5 18, 18, 6 24, 24, 8 32, 32, 10 and Capping Heads Production Capacity for 2,000-4,000 5,000-6,000 8,000-10,000 12,000-15,000 500ml (Bottles/Hour) Suitable Bottles (MM) Φ500-100, H=150-320, 330-2000ML Rinsing Pressure 2-3 (KG/CM) Motor Power (KW) 2.07 3.2 3.92 7.5 Dimension (MM) 2,300×1,600×2,500 2,460×1,860×2,650 3,100×2,100×2,650 4,350×2,880×3,200 Weight (KG) 2,800 3,650 4,800 6,000
  • 6. Automatic Fruit Juice and Tea Filling Machine For Small Beverage Drink Bottles, 3-in-1 Style Process: Bottle Rinsing + Filling +Capping SLH fully automatic rinsing, filling and rotary capping combined machine, can be used to asepsis filling. It can apply to fill hot fruit juice. tea and other beverage into thermal proof PET bottle by changing few parts. The complete set of machine is more advanced in technique, smaller in space occupied, more compact in structure, it is suitable for normal temperature filling or hot filling PET bottled no gas contained beverages. Model SLH14125 SLH18186 SLH24248 SLH323210 Number of Rising, Filling 14, 12, 5 18, 18, 6 24, 24, 8 32, 32, 10 and Capping Heads Production Capacity for 2,000-4,000 5,000-6,000 8,000-10,000 12,000-15,000 500ml (Bottles/Hour) Suitable Bottles (MM) Φ500-100, H=150-320, 330-2000ML Rinsing Pressure 2-3 (KG/CM) Motor Power (KW) 1.87 2.57 3.7 5.5 Dimension (MM) 2,300×1,680×2,650 2,500×1,760×2,650 3,100×2,100×2,650 3,800×2,800×2,650 Weight (KG) 2,600 3,500 4,650 6,800
  • 7. Supporting Equipment for Drink Bottle Filling Label Sleeving, Shrinking Machine Shrink Wrapping Machine Warming / Cooling Machine Code Inkjet Printer Auto Bottle Unscrambler Self-adhesive Labeling Machine Cap Elevator Pallet Stretch Shrinking Machine
  • 8. Supporting Equipment for Drink Bottle Filling Sugar Melting Pot Syrup Pump Syrup Filter Preparation Tank Syrup Cooler CO2 Filter Beverage Mixer Water Cooler
  • 9. Turnkey Project Solution for Making Bottled Mineral Water, Pure Water. 1. Flowchart Process of Bottled Mineral Water 2. Flowchart Process of Bottled Pure Water
  • 10. Turnkey Project Solution for Making Vegetable, Fruit Juice and Yogurt Drink . 3. Flowchart Process of Carbonated Drink 4. Flowchart Process of Vegetable and Fruit Juice Drink
  • 11. FILLING MACHINE FOR 3-5 GALLON BOTTLE
  • 12. Automatic Water Filling Machine For 3 - 5 Gallon Bottles, 3-in-1 Style Process: Bottle Rinsing + Filling +Capping Model: SL-600(600Bottles/Hour) Power: AC 380V/50Hz Input Watt: 19.0KW Bottle Spec: Φ270x490xΦ56MM DD Φ230x460xΦ56MM Bottle Volume: 3 or 5 gallons Cap Spec.: Φ58x40MM Air Pressure: P≥0.5MPa Rinsing Capacity: 60 0Bottles/Hour Filling Capacity: 60 0Bottles/Hour Dimension: 3 , 60 0x 1 , 4 20x1, 65 0MM Weight: 1 ,650 KGS Model: SL-100(200Bottles/Hour) Model: SL-300(300Bottles/Hour) Power: AC 380V/50Hz Power: AC 380V/50Hz Input Watt: 4.2KW Input Watt: 6.4KW Bottle Spec: Φ270x490xΦ56MM Bottle Spec: Φ270x490xΦ56MM DD Φ230x460xΦ56MM DD Φ230x460xΦ56MM Bottle Volume: 3 or 5 gallons Bottle Volume: 3 or 5 gallons Cap Spec.: Φ58x40MM Cap Spec.: Φ58x40MM Air Pressure: P≥0.5MPa Air Pressure: P≥0.5MPa Rinsing Capacity: 20 0Bottles/Hour Rinsing Capacity: 30 0Bottles/Hour Filling Capacity: 20 0Bottles/Hour Filling Capacity: 30 0Bottles/Hour Dimension: 3 , 27 0x 1 , 2 00 x1, 85 0MM Dimension: 3 ,3 5 0x 98 0x1, 85 0MM Weight: 320 KGS Weight: 400 KGS
  • 13. Automatic Water Filling Machine For 3 - 5 Gallon Bottles, 3-in-1 Style Process: Bottle Rinsing + Filling +Capping Model: SL-100(1200Bottles/Hour) Power: AC 380V/50Hz Input Watt: 46.6KW Bottle Spec: Φ270x490xΦ56MM DD Φ230x460xΦ56MM Bottle Volume: 3 or 5 gallons Cap Spec.: Φ58x40MM Air Pressure: P≥0. 8 MPa Rinsing Capacity: 120 0Bottles/Hour Filling Capacity: 120 0Bottles/Hour Dimension: Filling Part 4 , 525 x 2,06 0x 2 , 3 00MM Weight: 1,86 0KGS Model: SL-100(600Bottles/Hour) Model: SL-100(900Bottles/Hour) Power: AC 380V/50Hz Power: AC 380V/50Hz Input Watt: 12.8KW Input Watt: 38KW Bottle Spec: Φ270x490xΦ56MM Bottle Spec: Φ270x490xΦ56MM DD Φ230x460xΦ56MM DD Φ230x460xΦ56MM Bottle Volume: 3 or 5 gallons Bottle Volume: 3 or 5 gallons Cap Spec.: Φ58x40MM Cap Spec.: Φ58x40MM Air Pressure: P≥0. 8 MPa Air Pressure: P≥0. 8 MPa Rinsing Capacity:60 0 Bottles/Hour Rinsing Capacity: 90 0Bottles/Hour Filling Capacity: 60 0 Bottles/Hour Filling Capacity: 90 0Bottles/Hour Dimension: 3 , 275 x 1 ,50 0x1, 70 0MM Dimension: 3 , 725 x 2 , 06 0x 2 , 3 00MM Weight: 1 ,23 0KGS Weight: 1,34 0KGS
  • 14. Turnkey Project Solution for Making 3-5 Gallon Bottled Water . Lamp Check De-capper Leakage Checker Inside/Outside Washer Bottle 3-in-1 Steam Sealer Bottle Lifter Feeder Filler Ozone Water Water Sterilizing Tank Tank Water Treated Water Sand Carbon Softener RO System Ozoner
  • 15. FILLING MACHINE FOR OTHER CONTAINERS
  • 16. Filling Machine for Different Containers Filling Machine for 3-7Liters Bottles Suitable bottle: Polyester or PET or PE Height of barrel: 150mm-300mm Diameter of Barrel: Φ130-Φ230 Air source : 0.6-0.8 M Pa Air consumption: 1M Flushing pressure: 0.6 Mpa Flushing Temperature: Normal Power: 0.37 KW Capacity: 1200 BPH Big Sachet Water Filing Machine Filling Machine for Sachet/Plastic Bags Model:SL- 7500 Model:SL-1000 The machine is for 12 . 5 L big sachet filing. Sachet Size:500ML This machine is an indispensable dedicated Product Capacity:1500-2100 equipment of bagged water production line. Filling Range:100-500ml It is mainly composed of frame, mechanic General Power:1.2kw/220v drive system, film feeding system, traction Size of Bag: L 30-120mm mechanism, film cleaning and sterilization d W 120-160mm device, ultraviolet radiation device, heat Machine Size:850×800×1800mm sealing and cutting device, and canning Weight:370kg device
  • 17. Filling Machine for Different Containers Carton Filling Machine for Different Liquid Packing Size:250ML-1000ML Filling Capacity:4000-5500BPH Theoretical output:24KW Machine Dimension:5980x2580x4318MM Total Weight:2800KG Heating Power:20KW Motor Power:4KW Pressure:4-6 M p a A i r C o n s u m p t i o n : 0 . 3 m ³/Min
  • 19. PET Bottle Blow Molding Machine Model: SLB-II Blowing Capacity: 1500-180 0Bottles/Hour for 500ml PET bottles Bottle Volume: 50-2000ml PET bottles Model: SL-C1 Blowing Capacity: 30 0Bottles/Hour for 7000ml PET bottles Bottle Volume: 3000-7000ml PET bottles Model: SL-A6 Model: SL-Y Full automatic blow molding machine is suitable for producing PET/PE and PP Blowing Capacity: 70-85 Bottles/Hour plastic containers and bottles in all kinds of shapes.It is widely used to produce for 20L PET bottles the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide- Bottle Volume: 8-20L PET bottles mouth bottle and hot fill bottle etc. * Reasonable design,full automatic control,save power and labor.Adopt high quality components. * Feeding system carries the pertoms by robot automatically. * Infrared oven heater adopts the quartz lamp to heat the PET tube. * Fully automatic process with low investment,high efficiency,quick and safe operation,easy for trouble-shooting,maintenance and other benefits.
  • 20. PC Bottle Blow Molding Machine Clamping system Parison closing system Deflashing System Control system Model: SL - PC * Made by German technology and quality parts * Raw material: PC (polycarbonate) granules * Bottle volume: 1-5 gallons (mainly for 5 gallons, 19 litters) * Production capacity: 55 - 60 pcs/hour (5 gallons) * Quality percentage: 95% * Including: 1) Injection system; 2) Clamping system; 3) Energy supply; 4) Air source connection; 5) Water source connection; Die heads Injection system 6) Electric control system; 7) Siemens PLC System.
  • 22. Injection Molding Machine Preform Injection Molding Machine Features: 1) Twin pump system for higher flow rate and energy saving. 2) High accuracy proportional pressure and valve with feedback 3) Closed loop injection process control 4) Closed loop metering control 5) Closed loop back pressure control 6) High pressure and suction filter come in standard 7) Ten step injection and holding pressure control. 8) Statistical process control for 8 parameters 9) Direct screen dump and production data to printer 10) Set curve and actual curve display for important parameters Cap Injection Molding Machine 11) Sophisticated built-in SPC and quality control system.
  • 24. Commercial RO Water Purification Systems Model: RO-1000I (2000L/H) Output: 2000L/H 25Deg.C Process: Sand Filter + Carbon Filter + PP Sediment Input Power: 6.3KW Power: AC380V, 50Hz Filter + RO Filter RO Membrane: ESPA4040 10 PCS (2 stages) Multi-stages Pump: CDL4-160/3KW 1 PC Capacity: 300L-300000L/H Pre-filter: Φ 750 x 1,550MM 2 PCS Precise-filter: Φ 330 x 500MM 5 PCS Pressure Added Pump: CHL8-30/1.1KW 1 PC Quartz Sand: 800KGS Active Carbon:300KGS Dimensions: Main body 2,500x600x1,640MM Model: RO-1000I (300L/H, 380V) Model: RO-1000I (700L/H, 380V) Model: RO-1000I (1000L/H) Output: 300L/H 25Degrees.C Output: 700L/H 25Degrees.C Output:1000L/H 25Deg.C Input Power: 2.75KW Input Power: 4.25KW Input Power: 5.25KW Power: AC380V, 50Hz Power: AC380V, 50Hz Power: AC380V, 50Hz RO Membrane: ESPA4040 2 PCS (2 stages) RO Membrane: ESPA4040 4 PCS (2 stages) RO Membrane: ESPA4040 6 PCS (2 stages) Multi-stages Pump: CDL2-180/2.2KW 1 PC Multi-stages Pump: CDL2-180/2.2KW 1 PC Multi-stages Pump: CDL4-160/3.0KW 1 PC Pre-filter: Φ 300 x 1,200MM 2 PCS Pre-filter: Φ 300 x 1,200MM 2 PCS Pre-filter: Φ500 x 1,200MM 2 PCS Precise-filter: Φ 200 x 500MM 1 PC Precise-filter: Φ 200 x 500MM 1 PC Precise-filter: Φ 90 x 1,000 MM 5 PCS Pressure Added Pump: BLC70/0.55KW 1 PC Pressure Added Pump: BLC70/0.55KW 1 PC Pressure Added Pump: BLC70/0.75KW 1 PC Quartz Sand: 43KGS Quartz Sand: 43KGS Quartz Sand: 250KGS Active Carbon: 90KGS Active Carbon: 90KGS Active Carbon: 125KGS Dimensions: Main Body 1,500x560x1, 500MM Dimensions: Main Body 1,660x600x1, 540MM Dimensions: Main Body 1 , 7 00x700x1, 6 70MM
  • 25. RO-1000I (1000L/H, 380V) Output: 1000L/H 25Deg. C Import Power: 5.5KW Power: AC380V, 12A, 50Hz RO Membrane: ESPA4040 6 PCS (2 stages) Multi-stages Pump: CDL4-160/3KW 1 PC CDL2-150/1.5KW 1 PC Pre-filter: (Diameter)450 x 1,650 2 PCS Precise-filter: (Diameter)90 x 1,000 5 PCS Pressure Added Pump: BLC70/0.75KW 1 PC Quartz Sand: 250KGS Active Carbon: 125KGS Dimensions: 3,200x700x1,970MM Model: RO-1000I (20000L/H) Model: RO-1000I (10000L/H) Output: 20000L/H 25Deg. C Output: 10000L/H 25Deg. C Import Power: 22.5KW Import Power: 42KW Power: AC380V, 45A, 50Hz Power: AC380V, 45A, 50Hz RO Membrane: CPA2-8040 20PCS RO Membrane: BW30-400 20PCS Multi-stages Pump: CR20-17 1 PC Multi-stages Pump: CHL30-20-2 1PC Pre-filter: Φ 1600 x 3000MM 2 PCS D CR20-17 1 PC Precise-filter: Φ 400 x 1,000MM 1 PC Pre-filter: Φ 1400 x 2600MM 2 PCS Pressure Added Pump: CR32-2 1 PC Precise-filter: Φ 400 x 1,000MM 7 PC Quartz Sand: 3500KGS Pressure Added Pump: CHL30-20-2 1 PC Active Carbon: 1100KGS Quartz Sand: 3800KGS
  • 26. Commercial Mineral Water Purification Systems Process: Sand Filter + Carbon Filter + PP Sediment Filter + UF Filter Capacity: 1000L-200000L/H Model: UF-1000I (1000L/H, 380V) Model: UF-1000I (6000L/H, 380V) Model: UF-1000 I (8000L/H) Output: 1000L/H 25Degrees.C Output: 6000L/H 25Degrees.C Output:8000L/H 25Deg.C Input Power: 550W Input Power: 3.12KW Input Power: 2.5KW Power: AC380V, 50Hz Power: AC380V, 50Hz Power: AC380V, 50Hz UF Membrane: Φ 95x1 , 000 MM 2 PCS (2 stages) UF Membrane: 4040 12 PCS UF Membrane: 8040 2 PCS Pre-filter: Φ 300 x 1,200MM 2 PCS Pre-filter: Φ75 0 x 1, 5 00MM 2 PCS Pre-filter: Φ900 x 2,600MM 2 PCS Precise-filter: Φ330 x 500MM 2 PC Precise-filter: Φ 330 x 500MM 8 PC Precise-filter: Φ 90 x 1,000 MM 5 PCS Quartz Sand: 90KGS Pressure Added Pump: CHL8-30 / 1.1 KW 1 PC Pressure Added Pump: CDLF16-20 1 PC Active Carbon: 43KGS Quartz Sand: 800KGS Quartz Sand: 1200KGS UV Light: 40W 1PCS Active Carbon: 300KGS Active Carbon: 325KGS Dimensions: Main Body 560x560x1, 500MM UV Light: 40W 3PCS Dimensions: Main Body 1,600x750x1,700MM Dimensions: Main Body 2100x660x1, 600MM
  • 27. Commercial Seawater Desalination Purification Systems Process: Sand Filter + Carbon Filter + PP Sediment Filter + UF Filter Capacity: 1000L-200000L/H Multi- Function Discretion: Carbon ST series middle to large scale seawater desalination equipment is suitable for Sea medium Filter Islands, troop stations and sea shore cities short of water. They can effectively Filter Precise remove harmful elements such as inorganic salts, heavy metal ions, organic bacteria, Filter pathogens, etc. and desalinate the seawater to good quality water complying with the National Drinking Water Quality Standard. In this series, the pre-treatment system Pump consists of a full-automatic multi-channel valve to perform automatic and large volume flush and back-flush processing. The shell and pipe are made of anti- corrosion materials, making for a complete system that is highly durable and long- lasting. The main RO system consists of the most advanced RO system elements, Sea Water and is designed with unique energy recovery technology to perform at the lowest RO Unit energy cost. The system is also equipped with an advanced monitoring system to assure its stability, quality of the product water (when the product water quality exceeds the alarm salinity value, the drain valve will open automatically to drain the Dosing product into drainage) and provide accurate information on performance. There are System advanced control instruments such as flow meters, pressure gauges, pressure relief, Output Energy High and drain pipes. These make the piping system more stable and safe so that the Water Recycle Pressure system is maintenance safe and reliable. Pump
  • 28. Supporting Equipment for Water Treatment UV Light Ozone Water Generator Ozone Blender Water Softener Water Tank1 Water Tank2 Vending Machine Chemical Feeder
  • 30. Bottled Type Water Dispenser Floor Standing Model: YLR2-5-X(28L-B/B) Model: YLR2-5-X(168L) Model: YLR2-5-X(12L) Hot and Cold, Floor Standing, Hot and cold, Floor Standing, Expert Hot and Cold, Floor Standing Compressor Cooling, with 20L Craft and Quality Components, ,Efficiency Compressor with CFC free, Opaque-door Cooling Compartment Universal Non-spill Water Guard Perfect Classic Shape Design, System. Stainless Steel Cold Reservoir. Model 28L-B/B 168L 12L HEATING WATT 500W 500W 500W COOLING WATT 110W 110W 110W GROSS WEIGHT 25.0KG 17KG 20.0KG NET WEIGHT 23.0KG 15KG 18.5KG DIMENSIONS 34X35X100CM 40x37.5x110CM 39x40.5x106CM FCL(20FT/40FT) 168/336PCS 168/348 PCS 168/348 PCS
  • 31. Bottled Type Water Dispenser Model: YLR2-5-X(16L-B/C) Model: YLR2-5-X(16L/E) Hot and Cold, Floor Standing, Hot and Cold, Floor Standing, Compressor Cooling Compressor Cooling Model: YLR2-5-X(20T-BN6) Model: YLR2-5-X(20L-BN6) Hot and Cold, Tabletop Standing, Hot and Cold, Floor Standing, Microchip Controlled, VFD Microchip Controlled, VFD Display, Freely Setting Display, Freely Setting Heating/Cooling Temperature Heating/Cooling Temperature Freely Setting On/Off Time, Freely Setting On/Off Time, Model 16L-B/C 16L/E 20L-BN6 Model: YLR2-5-X(16L-B/C) Model: YLR2-5-X(16T/E) HEATING WATT 500W 500W 500W Hot and Cold, Floor Standing, Hot and Cold, Floor Standing, COOLING WATT 110W 110W 110W Compressor Cooling Compressor Cooling GROSS WEIGHT 21.5KG 17KG 23.0KG NET WEIGHT 20.0KG 15KG 21.0KG DIMENSIONS 31X31X96CM 40x37.5x110CM 36X31X95CM FCL(20FT/40FT) 180/372PCS 168/348 PCS 180/360PCS
  • 32. Bottled Type Water Dispenser Floor Standing Model: YLR2-5-X(28L-B) Model: YLR2-5-X(50L-BC) Model: YLR2-5-X(16L-B) Model: YLR2-5-X(280L) Hot and Cold, Floor Standing, Hot and Cold, Floor Standing, Hot and Cold, Floor Standing, Hot and Cold, Floor Standing, Compressor Cooling, with 20L Compressor Cooling, with 50L Compressor Cooling, with 16L Compressor Cooling Opaque-door Cooling Compartment Opaque-door Cooling Compartment Opaque-door Cooling Compartment , Model 28L-B 50L-BC 16L-B 280L HEATING WATT 500W 500W 500W 500W COOLING WATT 110W 130W 110W 110W GROSS WEIGHT 25.0KG 30.0KG 21.5KG 25.0KG NET WEIGHT 23.0KG 28.0KG 20.0KG 23.0KG DIMENSIONS 34X35X100CM 44x40.2x106CM 38x39x100CM 34X35X100CM FCL(20FT/40FT) 168/348PCS 120/240 PCS 180/384 PCS 168/348PCS
  • 33. Supporting Equipment for Water Dispenser Household RO Filter Ozone Cleaner Filter Bottle Manual Pump Water Bottles Bottle Caps Preforms Cup Holder
  • 34. Company Profile Steplead, not only a leading veteran manufacturer in water product industry, but also a top professional one-stop- service provider for water plant related equipments, from water treatment, bottle blow molding, bottle washing, filling, capping, labeling, to wrap packing, etc. And our turn-key project service covers water plant layout design, machine supply, assemble, installation and commissioning of a complete water plant, also covers excellent after service and quality guarantee. We also professional in producing reverse osmosis water purifiers, mineral water equipment, pure water filling machines, mineral water filling machines, and related packing machineries. In addition, we also provide auxiliary equipments for the water treatment processing. Due to our super craftsmanship, our products are selling well both at home and abroad. If you are interested in any of our products or would like to discuss your OEM orders, please feel free to visit our website for more details or contact us directly with your inquiries. We hope to have the chance of working together with your company for mutual success. Steplead, was founded in 1995, it is All about Drinking Water Equipments. Our ISO 9001-certified factory covers an area of 5,800m2, equipped with 5 production lines. We provide one-stop technical service, including design, installation, debugging and maintenance. We can provide the technical training for clients. In addition, we adopt the Italy and Germanic technique. When the equipment gets something wrong, our technicians will provide solutions within several hours. Besides, if necessary, we can dispatch the technician to solve the problems on spot.
  • 35. Our Value Steplead and its employees acceptance for all that we do: Customer Service: We are dedicated to the satisfaction and success of every customer. Innovative Idea: Creating value for every customer, created and delivered with speed and efficiency. Accuracy and truth-seeking: We carry out business and confirmation based on carefully understood facts and detailed requirement from every customer. Trustworthiness and integrity: Trust and personal responsibility in all relationship and course Our Aqua Solution Liquid package products markets are various; we are involved in following 5 kinds according to the package features: · Bottled water production line · Fruit juice production line · Carbonated drinks production line · Tea production line · 5 gallons rotating filling and packing line
  • 36. Steplead International Co.,Ltd. Address: Suite 302, Building NO. 40, Xinxing Village, Shang Mei Lin, Futian District, Shenzhen, China. Tel: (+86-755) 29210591 Fax: (+86-755) 83143479 Email: johnlauvip @ gmail .c om Website: www.steplead.net ; www.steplead.com
