Clear sound reproducƟon is achieved with TOA high quality
conference and audio systems. BoasƟng compact size and simple
setup, they work in even the smallest of conference rooms.
TOA has conference and audio systems that will solve it!
CommunicaƟon Issues?Products
Speakers
Wide-dispersion Ceiling Speaker
F Series
Provides well-balanced audio without
treble aƩenuaƟon over an expanded
range. This makes it possible to uƟlize
fewer speakers to cover the desired
area.
Mixers
M-633D Digital Mixer
The M-633D focuses on ease-of-use. With one-touch
operaƟon, the M-633D’s built-in DSP measures the
acousƟcs of a meeƟng space and corrects the sound
field (ARC funcƟon). Instantly and automaƟcally
suppresses feedback that can interrupt the smooth
flow of a meeƟng.
M-9000M2 Digital Matrix Mixer
Modular digital matrix mixer with up to 8 input/8
outputs. Supports up to 32 preprogrammed Scenes.
Incorporates NOM funcƟon (auto-mixing) for smooth
operaƟon. Remote system control using various
opƟonal remote panels and through control inputs or
RS-232C serial port.
D-901 Digital Mixer
Modular digital mixer up to 12 inputs/8 outputs.
Incorporates feedback suppression and NOM funcƟon
(auto-mixing) for smooth operaƟon in a conferencing
seƫng. 16 preset memories for storage and recall of
different signal rouƟng and parameter configuraƟons.
Easy volume adjustment with opƟonal D-911 Fader
unit.
SR-H SR-S
Slim Line Array Speaker
Type H/Type S
Slim compact design visually blending
into demanding seƫngs. Disperses
sound uniformly at a level that resists
aƩenuaƟon with distance. Highly
controlled coverage yields improved
intelligibility.
Wired microphones ideal for
speech applicaƟons. Electret
condenser microphone element
with cardioid paƩern for focused
pickup. Wide frequency range for
well balanced sound with clarity
and a saƟsfying tonal response.
Condenser Microphones
EM-600/700/800
Stable operaƟon thanks to TOA's
proprietary diversity system.
Electret condenser microphones
available in handheld and lavalier
types. Long baƩery life: over 10
hours with single AA baƩery.
UHF Wireless Microphone
System 5000 Series
with cardioid paƩern for focused
pickup. Wide frequency range for
well balanced sound with clarity
and a saƟsfying tonal response.
available in handheld and lavalier
types. Long baƩery life: over 10
hours with single AA baƩery.
Wi d i h id l f
Condenser Microphones
EM-600/700/800
St bl Ɵ th k t TOA'
UHF Wireless Microphone
System 5000 Series
Microphones
EM-700
EM-600
EM-800
Conference
Systems
Conference System
TS-770 Series
Compact and easy-to-use conference system. Supports
system expansion of up to 210 Chairman/Delegate
units.Thesystemfeaturesremote conferencing, system
test funcƟon and all-mic-on funcƟon for recording.
Infrared Wireless Conference System
TS-800/900 Series
The wireless conference system provides flexible
adaptaƟon to diverse styles of conferences. Both are
highly secure systems that prevent eavesdropping and are
easy to set up. Expandable to up to 96 Chairman/Delegate
units(TS-800: up to 64 units). Includes voƟng funcƟon and
simultaneous translaƟon channel(TS-900 only).
Incorporates enhancing features for
confidenƟality and interference-free
communicaƟon. Stable transmission
thankstoawidevarietyofreceivers.8
hoursoperaƟonwithtwoAAbaƩeries.
Infrared Wireless
Microphone System
Amplifers
MulƟ-channel Power Amplifier
DA Series
This model can be neatly placed inside a controldesk
and offers high efficiency, high durability, and high
reliability.
DA-250F/FH
DA-250D/DH
DA-550F/DA-500FH
