The document provides information about a software development demo. It discusses the steps involved in software development including gathering requirements, designing the process and modules, planning, development, testing, documentation, release, and maintenance. It gives examples and descriptions for many of the development steps.

1. Software Development Demo
A one of many ways to implement your project

2. About Gift
Gift Nnko
Systems Developer, HISP Tanzania
Technologies: ReactJS, Node, Typescript, Parse
Platform, Git,
Github: nnkogift

3. About HISP Tanzania
HISP Tanzania is an organization established to empower
governments, organizations and communities to
improve the quality and efficiency of services through
appropriate use of ICT for inclusive, technological and
social-economic development in Africa.
LinkedIn: hisptanzania
Twitter: hisptanzania
Facebook: HISP Tanzania
Github: hisptz

4. Development Vs Programming
What is the difference 🤔

5. Here’s The Major Difference
Programming
Programming is all about conceiving a network of logical
patterns that defines the behaviour of your application.
Coding
Coding involves implementing the set of instructions in a
form that a machine understands and in a way that is
optimal.
According to this well written article here…
Development
Development is about delivering a proper product and
maintaining it. Development encompasses the processes
of creating a complete package to the pleasure and
satisfaction of end users.

6. Development
Delivering a usable product that satisfies user’s need

7. Development…
Product
A complete & usable software system with minimal issues
User’s satisfaction
It does what the user wanted it to do…

8. Development Steps
- What should the software do (Gather requirements)
- How should it work (Design Process, Modules)
- Planning(Project Planning)
- Development
- Testing
- Documentation
- Release/Deployment
- Maintenance/Feedback
Note: Steps outlined above are based on personal experience and may differ from other standard practices

9. What should the software do (Gather requirements)
- Figure out what the user needs from your system
- Break it into individual user stories
- Write different scenarios (Acceptance criteria) of the user stories
- Use simple user story format:
As {user} I want to {need} so that {purpose}
- Create acceptance criteria based on the user
story:
Given {user} when I do a {need} then {purpose
should be fulfilled}
As a new user, I want to
register by creating a
username and password
so that the system can
remember me and my
data
Given that I am a new user,
when I go to the sign up page
and enter an username and
password and click on sign up,
then I am successfully
registered and able to log in
with my chosen credentials.
Visit here for more on user stories

10. How should it work (Process, Modules)
- Figure out what resources your app needs
Databases, 3rd Party Integrations, Analytics tools, e.t.c
- Choose your tools
Languages, Frameworks
- Modularization
Dividing your app into modules, designing connections between them
Not necessary for most simple projects
- App Process
Design process flow for all app entities, Design database model
Use a process flow diagram for simplicity
- UI/UX Design
Choose a consistent theme(colors, fonts,icon, shapes)
Use design system(recommended)
Consider basic UI/UX design guidelines
Create a mockup with apps like figma (takes time but recommended)
Visit here for more on user stories

11. Modularization example
Database
API Server
Web Interface
Mobile
Application
APIs
APIs
SQL
3rd Party Services
(Payment, google
sign in)
IoT systems
APIs
APIs

12. Planning(Project Planning)
- Create a plan for everything you have to do
- Plan feature wise, starting with independent/important features first
- Feel free to adjust your plan to accommodate changes
- Use a good project planning software
Jira, Open project, Trello, Todoist, GitHub(Recommended)

13. Development
Ahhh… yes, the fun stuff
- Structure your code well, not necessarily at the beginning
- Use frameworks to enforce good structure
- Consider good practices you know
SOLID, DRY, Don’t reinvent the wheel
- Tools are your friends, learn to use them
Es-lint, formatters, code completion, other useful plugins, IDEs or text
editors
- Use a version control system
Git, Apache Subversion, e.t.c

14. Testing
- Write unit test for complicated/sensitive functionalities
- Write automated e2e tests based on acceptance criteria
- Always modify your tests as you modify your code
- Use available tools
Cypress(Recommended)

15. Documentation
- Write a user guide (if your have a complex system)
- Write a brief technical documentation
Technologies used, File/Folder structure, Running/Deployment
Instructions

16. Release/Deployment
- Know the basics of deployment
- Prepare a good documentation on how to deploy your system
- Choose a good deployment environment based on your app
design
Containers(Docker), Nginx,Apache, Play store,

17. Maintenance/Feedback
- Keep In constant communication with your users
- Have a standard way of registering, prioritizing and fixing issues
Use an issue tracker, Jira, Github issues

18. ?
