The document tests and reviews the Skyworth HTA6 DVB-T2 receiver. It has the following key points:
1. The receiver has a simple minimalist design with rounded edges and includes connections like HDMI, audio/video ports, and a USB port.
2. It can receive both DVB-T and DVB-T2 signals and has a quick automatic channel scan.
3. The menu system is divided into submenus that allow customizing the channel list, picture settings, and other options. It supports resolutions up to 1080p.
The Topfield TF7700HSCI is an HDTV receiver that can process DVB-S2 QPSK and 8PSK signals. It has an eye-catching design and user-friendly interface. Testing showed it was able to receive HDTV channels without issues. However, its channel memory of 5000 channels is on the low side, and the included satellite list and remote control codes are not fully updated.
The Vantage VT-X111SCX is a new digital satellite receiver with an elegant design. It has a nicely equipped front panel and rear connections. It supports 121 satellites and has a channel memory of 4000. The menus are well organized and navigation is easy. However, it is missing support for DiSEqC 1.1 and the user manual could be improved. Overall, it is an easy to use receiver for the family.
The Jiuzhou DTS1601 is a small but capable digital satellite receiver. It has a clear display, robust construction, and convenient features like an SD card reader. The receiver produced a sharp picture and allowed quick channel changes. It also offers flexible scanning and satellite configuration options to make updating the channel list easy. Overall, the Jiuzhou DTS1601 proved to be a well-designed and solid performing receiver.
This document provides a review of the Arion AF-8000HDCI HDTV CI receiver. It summarizes the key features and test results.
The front panel has a large LCD display that shows channel numbers and text. It also has infrared, CI slots, buttons, and status LEDs.
Installation was smooth, with many language and satellite options. A network scan took 13 minutes and found HDTV channels from Hotbird.
The receiver had HDMI, analog, and audio outputs. Channel changing was fast at 2 seconds. Processing of MPEG-4 and DVB-S/S2 signals from tests worked well.
The Kathrein UFS 821 is an elegant satellite receiver packaged in a black or silver cabinet. It has a large multifunction control, VFD display, and is compatible with SatcoDX. The receiver comes preprogrammed with European satellites and has a channel memory of 4,000. Notable features include a 160GB hard drive for recording, compatibility with tvtv EPG data, USB connectivity, and DiSEqC support. The summary evaluates it as an ideal radio receiver but notes it could support more satellites and faster USB.
The document summarizes a test report of the Opensat X7000CI satellite receiver. Some key points:
- The receiver is easy to use, fast, and reliable for receiving free-to-air and encrypted satellite channels.
- It supports common connections like RF, SCART, and RCA inputs/outputs. Up to 4 satellites can be connected simultaneously.
- Channel scanning is quick, taking under 3 minutes to scan 79 transponders. The receiver also has an EPG and can schedule timer recordings up to a week in advance.
- In testing, the receiver performed well, with simple programming and navigation. However, it cannot decode HDTV or MPEG-4 signals
The TF6000PVR by Topfield is a digital satellite receiver with personal video recording (PVR) and wireless LAN (WLAN) functionality. It has a similar design to Topfield's popular TF5000 Masterpiece receiver. Key features include support for DiSEqC 1.0-1.3 protocols, automatic switching between PAL and NTSC, YUV and S-video outputs, and the ability to record two channels while viewing a third live or from the hard drive. Setup of the receiver and its WLAN connection is straightforward thanks to the detailed user manual.
The Arion AF9400PVR HDMI receiver includes a built-in scaler to increase the resolution of SD channels for viewing on HD TVs. It has dual satellite tuners, a built-in PVR with HDMI and other video/audio outputs. Special features include an integrated program guide and the ability to decrypt recorded content from encrypted channels.
The Topfield TF7700HSCI is an HDTV receiver that can process DVB-S2 QPSK and 8PSK signals. It has an eye-catching design and user-friendly interface. Testing showed it was able to receive HDTV channels without issues. However, its channel memory of 5000 channels is on the low side, and the included satellite list and remote control codes are not fully updated.
The Vantage VT-X111SCX is a new digital satellite receiver with an elegant design. It has a nicely equipped front panel and rear connections. It supports 121 satellites and has a channel memory of 4000. The menus are well organized and navigation is easy. However, it is missing support for DiSEqC 1.1 and the user manual could be improved. Overall, it is an easy to use receiver for the family.
The Jiuzhou DTS1601 is a small but capable digital satellite receiver. It has a clear display, robust construction, and convenient features like an SD card reader. The receiver produced a sharp picture and allowed quick channel changes. It also offers flexible scanning and satellite configuration options to make updating the channel list easy. Overall, the Jiuzhou DTS1601 proved to be a well-designed and solid performing receiver.
This document provides a review of the Arion AF-8000HDCI HDTV CI receiver. It summarizes the key features and test results.
The front panel has a large LCD display that shows channel numbers and text. It also has infrared, CI slots, buttons, and status LEDs.
Installation was smooth, with many language and satellite options. A network scan took 13 minutes and found HDTV channels from Hotbird.
The receiver had HDMI, analog, and audio outputs. Channel changing was fast at 2 seconds. Processing of MPEG-4 and DVB-S/S2 signals from tests worked well.
The Kathrein UFS 821 is an elegant satellite receiver packaged in a black or silver cabinet. It has a large multifunction control, VFD display, and is compatible with SatcoDX. The receiver comes preprogrammed with European satellites and has a channel memory of 4,000. Notable features include a 160GB hard drive for recording, compatibility with tvtv EPG data, USB connectivity, and DiSEqC support. The summary evaluates it as an ideal radio receiver but notes it could support more satellites and faster USB.
The document summarizes a test report of the Opensat X7000CI satellite receiver. Some key points:
- The receiver is easy to use, fast, and reliable for receiving free-to-air and encrypted satellite channels.
- It supports common connections like RF, SCART, and RCA inputs/outputs. Up to 4 satellites can be connected simultaneously.
- Channel scanning is quick, taking under 3 minutes to scan 79 transponders. The receiver also has an EPG and can schedule timer recordings up to a week in advance.
- In testing, the receiver performed well, with simple programming and navigation. However, it cannot decode HDTV or MPEG-4 signals
The TF6000PVR by Topfield is a digital satellite receiver with personal video recording (PVR) and wireless LAN (WLAN) functionality. It has a similar design to Topfield's popular TF5000 Masterpiece receiver. Key features include support for DiSEqC 1.0-1.3 protocols, automatic switching between PAL and NTSC, YUV and S-video outputs, and the ability to record two channels while viewing a third live or from the hard drive. Setup of the receiver and its WLAN connection is straightforward thanks to the detailed user manual.
The Arion AF9400PVR HDMI receiver includes a built-in scaler to increase the resolution of SD channels for viewing on HD TVs. It has dual satellite tuners, a built-in PVR with HDMI and other video/audio outputs. Special features include an integrated program guide and the ability to decrypt recorded content from encrypted channels.
The document provides a review of the Icecrypt S3500HDCCI miniature HDTV satellite receiver. It summarizes that the receiver:
1) Is extremely small but fully equipped with a Linux operating system and features like blindscan searching.
2) Offers fast channel zapping of less than one second and can find over 900 TV and radio channels through its various search modes.
3) Can be upgraded through additional applications since it is Linux-based, and connects to the internet for access to more plugins.
The Skyworth HT21 is an extremely small DVB-T receiver measuring just 10.5 x 6 x 1.5cm yet includes features of larger receivers. It has a sensitive DVB-T tuner, extensive programming options, USB recording capability, and a futuristic on-screen display. Despite its small size, the receiver produces surprisingly sharp pictures when connected to LCD or plasma TVs via its HDMI output. It offers an easy initial setup process and selection of reception locations. Overall, the engineering and design of the Skyworth HT21 was impressively executed in such a compact receiver.
The Nanoxx 9800HD receiver is a fully-featured HD receiver with an extensive number of connections and features. It has a slim design that fits on any TV stand. During testing, it was able to receive even very weak signals and perform well in channel scanning. The receiver has a user-friendly installation process and menu system. It offers multiple options for channel scanning and supports numerous languages. Overall, the Nanoxx 9800HD provides exceptional performance and value for users seeking an advanced yet easy to use satellite receiver.
The document provides a review of the Icecrypt S3000HDCCI HDTV satellite receiver. It summarizes the following key points:
- The receiver has a versatile feature set including a fast blind scan, support for various conditional access systems, and full DVR functionality via USB.
- Setup and navigation of the menus is straightforward, though some satellite experience is recommended. Language, audio preferences, and local time settings can be configured in the System Setup menu.
- The Installation menu allows the user to select fixed or motorized antenna options, identify satellites, and configure the reception system details like DiSEqC settings and frequencies.
- Overall the receiver performs well, with an elegant design
1. The Jiuzhou DTS6695 is a combo receiver capable of receiving DVB-S/S2 and DVB-T signals.
2. It has a variety of connection options, robust PVR functionality, and strong performance even on weak signals.
3. In addition to TV and radio reception, the receiver can play multimedia files, browse the internet, and access interactive services.
The PanSat 3500S is a versatile satellite receiver with many features, including an embedded Conax system, component video outputs, and servo motor control. It can store up to 5000 channels and has a built-in SD memory card slot for playing MP3 files or updating software. A full channel scan takes a few minutes, occasionally getting stuck on transponders for several minutes. The receiver requires passwords for some menu functions, which unfortunately cannot be turned off.
The document provides a review of the TechnoTrend Scart TV S100 miniature satellite receiver. It is a very small receiver measuring 55 x 22 x 100 mm that can be plugged directly into the scart port of a TV and receives signals from satellites. It has an integrated digital satellite receiver and supports common encryption systems. The receiver is easy to use with a simple installation process and includes features like an electronic program guide. While small in size, it packs in full digital satellite receiver functionality in a compact design suitable for invisible installation behind a TV.
This document provides a test report of the Icecrypt STC6000HD PVR HDTV combo receiver.
The summary is as follows:
1. The STC6000HD PVR is a well-designed receiver with an elegant appearance and intuitive on-screen interface. It has strong performance for both satellite and cable channels.
2. The receiver supports all relevant satellite protocols and has a large channel memory capacity. It was able to find over 1700 TV and 1300 radio channels during testing.
3. Testing showed the receiver has very fast channel scanning speeds and excellent signal reception for both strong and weak signals. The blind scan mode was also able to find more channels than other modes.
The Metabox HD Combo CI is an innovative HDTV receiver that can receive both satellite and terrestrial signals via DVB-S, DVB-S2, and DVB-T. It is the first receiver to combine these two reception modes into one box. The receiver has an easy-to-use interface and features multiple tuners, HDMI output, and the ability to store up to 10,000 channels. It also supports software updates and comes with a comprehensive EPG. The Metabox HD Combo CI provides a convenient solution for receiving both local terrestrial channels and satellite TV with one receiver.
The Star Sat SR-X2500CUCI receiver was found to have a compact design, numerous pay-TV options through its universal smart card slot, and fast channel searching though the network search mode found more channels than the automatic search. However, some transponders were still missing and the electronic program guide display could be improved.
The document summarizes a test report for the Jiuzhou DVS-2018BS professional satellite receiver. It describes the receiver's packaging, exterior, and various connection ports. Professional receivers are used in cable TV networks to receive signals from satellite transponders and output either analog or digital streams. They allow operators to receive multiple channels for distribution over a cable system. The receiver's menu system is simple due to its small display, but allows tuning and configuration of transponder and streaming parameters needed for integration into a cable TV headend.
1. The document tests and reviews the SPAUN VAM 420 NG PAL analogue modulator.
2. The modulator can generate two independent analogue TV signals from video and audio inputs, and features good technical specifications and simple programming.
3. Testing showed the modulator generated signals with excellent signal-to-noise ratios exceeding 50dB across the frequency band, even at minimum amplitude settings.
1. The document tests a Panodic M3601E DVB-T receiver that is extremely small, measuring just 11.5 x 7.5 x 2.5 cm and weighing 118g.
2. The receiver has an innovative user interface, supports SD and HD channels, and includes an integrated personal video recorder function.
3. Recordings can be edited on a connected PC, and the receiver supports playback of multimedia files from USB drives or memory cards.
The document provides a review of the Eycos S55.12 PVRH satellite receiver. Key features include an integrated scaler that improves picture quality of SDTV channels, recording 4 channels simultaneously using 2 tuners, and fast USB 2.0 port. The reviewer was impressed with picture quality, EPG functionality, and tuner performance but notes overscan output is not yet available. Overall, the receiver offers sound performance and useful features at a good value.
The Zimple Box 3 receiver is compact with a sensitive tuner and blind scan capabilities. It supports DiSEqC 1.0 and 1.2 to control up to four LNBs or a motorized dish. A blind scan found active transponders and downloaded channels in under 6 minutes. The receiver had fast channel switching and produced a sharp picture quality. However, it lacked an EPG and loop-through output.
The document provides a detailed review of the ABCom IPBOX 9000 HD Plus satellite receiver. Some key points:
- It has two DVB-S2 tuners that can each record a channel simultaneously. The tuners can be swapped out for other types like DVB-T.
- It has a large range of connection options, including HDMI, optical audio, USB, and Ethernet. Software updates can be done via the network.
- Setup involves running a channel scan to populate the 10,000 channel list. Many options are available to configure satellite, language, and time settings.
- The receiver has a 500GB hard drive with extensive PVR functions like an 8-hour
The document provides a review of the Sonicview SV-360 Elite PVR satellite receiver. It describes the receiver's external features like its black front panel with chrome stripe and buttons. The rear panel connections include dual satellite inputs and outputs, RCA, S-video, component video, digital audio, USB and serial ports. The included remote is silver with illuminated buttons and can control other devices. The review tests the receiver's set up process, menu system, channel scanning and recording functions. In summary, the Sonicview SV-360 Elite PVR is a full-featured satellite DVR receiver.
The Topfield TF6000PVRE is a PVR receiver with an Ethernet interface, allowing recordings to be accessed and managed remotely over a home network or internet connection. It has reliable hardware and a user-friendly interface carried over from previous Topfield models. A key innovative feature is its support for third-party applications through an open TAP interface. Testing found strong performance except for weaker signals below 2Mb/s. The Ethernet interface provides fast transfers of up to 1Mb/s for conveniently accessing recordings away from the receiver.
The document tests and reviews the Jiuzhou DTP8300 IPTV receiver. It summarizes the key differences between IPTV and traditional TV reception, noting that IPTV receivers do not process signals directly but instead act as web browsers to display streaming content from a middleware server. The review examines the DTP8300's design, connection and configuration options. It finds the receiver is easy to set up for either Ethernet or wireless network access and displays content smoothly from a test middleware installation.
The document provides an overview and test report of the Giga Blue HD Quad Plus 4-tuner HDTV receiver. It has 4 integrated tuners that allow recording of multiple channels simultaneously. Additional tuners can be added to support different reception types. The receiver has a variety of connection ports, robust build quality, and offers extensive customization options for its features and user interface.
The document describes a professional cable TV signal analyzer called the Rohde & Schwarz EFL210. Some key features include its specialized design for detecting leakage signals across a wide frequency spectrum, robust carrying case for field use, ergonomic shape for comfortable one-handed operation, and integrated high-resolution color screen. The analyzer performs a variety of cable TV measurements on analog and digital transmissions through an intuitive interface and menu structure.
Rod Hewitt is a software programmer from the United States known for developing the popular digital TV stream analysis program TSReader. He dropped out of school early but became self-taught in computer programming. He wrote TSReader to help technicians monitor digital TV streams for errors. TSReader identifies every element in a transmission stream including video, audio and data PIDs. Hewitt now works independently from his home in Annapolis, Maryland developing IPTV and digital video recording applications.
The document provides a review of the Icecrypt S3500HDCCI miniature HDTV satellite receiver. It summarizes that the receiver:
1) Is extremely small but fully equipped with a Linux operating system and features like blindscan searching.
2) Offers fast channel zapping of less than one second and can find over 900 TV and radio channels through its various search modes.
3) Can be upgraded through additional applications since it is Linux-based, and connects to the internet for access to more plugins.
The Skyworth HT21 is an extremely small DVB-T receiver measuring just 10.5 x 6 x 1.5cm yet includes features of larger receivers. It has a sensitive DVB-T tuner, extensive programming options, USB recording capability, and a futuristic on-screen display. Despite its small size, the receiver produces surprisingly sharp pictures when connected to LCD or plasma TVs via its HDMI output. It offers an easy initial setup process and selection of reception locations. Overall, the engineering and design of the Skyworth HT21 was impressively executed in such a compact receiver.
The Nanoxx 9800HD receiver is a fully-featured HD receiver with an extensive number of connections and features. It has a slim design that fits on any TV stand. During testing, it was able to receive even very weak signals and perform well in channel scanning. The receiver has a user-friendly installation process and menu system. It offers multiple options for channel scanning and supports numerous languages. Overall, the Nanoxx 9800HD provides exceptional performance and value for users seeking an advanced yet easy to use satellite receiver.
The document provides a review of the Icecrypt S3000HDCCI HDTV satellite receiver. It summarizes the following key points:
- The receiver has a versatile feature set including a fast blind scan, support for various conditional access systems, and full DVR functionality via USB.
- Setup and navigation of the menus is straightforward, though some satellite experience is recommended. Language, audio preferences, and local time settings can be configured in the System Setup menu.
- The Installation menu allows the user to select fixed or motorized antenna options, identify satellites, and configure the reception system details like DiSEqC settings and frequencies.
- Overall the receiver performs well, with an elegant design
1. The Jiuzhou DTS6695 is a combo receiver capable of receiving DVB-S/S2 and DVB-T signals.
2. It has a variety of connection options, robust PVR functionality, and strong performance even on weak signals.
3. In addition to TV and radio reception, the receiver can play multimedia files, browse the internet, and access interactive services.
The PanSat 3500S is a versatile satellite receiver with many features, including an embedded Conax system, component video outputs, and servo motor control. It can store up to 5000 channels and has a built-in SD memory card slot for playing MP3 files or updating software. A full channel scan takes a few minutes, occasionally getting stuck on transponders for several minutes. The receiver requires passwords for some menu functions, which unfortunately cannot be turned off.
The document provides a review of the TechnoTrend Scart TV S100 miniature satellite receiver. It is a very small receiver measuring 55 x 22 x 100 mm that can be plugged directly into the scart port of a TV and receives signals from satellites. It has an integrated digital satellite receiver and supports common encryption systems. The receiver is easy to use with a simple installation process and includes features like an electronic program guide. While small in size, it packs in full digital satellite receiver functionality in a compact design suitable for invisible installation behind a TV.
This document provides a test report of the Icecrypt STC6000HD PVR HDTV combo receiver.
The summary is as follows:
1. The STC6000HD PVR is a well-designed receiver with an elegant appearance and intuitive on-screen interface. It has strong performance for both satellite and cable channels.
2. The receiver supports all relevant satellite protocols and has a large channel memory capacity. It was able to find over 1700 TV and 1300 radio channels during testing.
3. Testing showed the receiver has very fast channel scanning speeds and excellent signal reception for both strong and weak signals. The blind scan mode was also able to find more channels than other modes.
The Metabox HD Combo CI is an innovative HDTV receiver that can receive both satellite and terrestrial signals via DVB-S, DVB-S2, and DVB-T. It is the first receiver to combine these two reception modes into one box. The receiver has an easy-to-use interface and features multiple tuners, HDMI output, and the ability to store up to 10,000 channels. It also supports software updates and comes with a comprehensive EPG. The Metabox HD Combo CI provides a convenient solution for receiving both local terrestrial channels and satellite TV with one receiver.
The Star Sat SR-X2500CUCI receiver was found to have a compact design, numerous pay-TV options through its universal smart card slot, and fast channel searching though the network search mode found more channels than the automatic search. However, some transponders were still missing and the electronic program guide display could be improved.
The document summarizes a test report for the Jiuzhou DVS-2018BS professional satellite receiver. It describes the receiver's packaging, exterior, and various connection ports. Professional receivers are used in cable TV networks to receive signals from satellite transponders and output either analog or digital streams. They allow operators to receive multiple channels for distribution over a cable system. The receiver's menu system is simple due to its small display, but allows tuning and configuration of transponder and streaming parameters needed for integration into a cable TV headend.
1. The document tests and reviews the SPAUN VAM 420 NG PAL analogue modulator.
2. The modulator can generate two independent analogue TV signals from video and audio inputs, and features good technical specifications and simple programming.
3. Testing showed the modulator generated signals with excellent signal-to-noise ratios exceeding 50dB across the frequency band, even at minimum amplitude settings.
1. The document tests a Panodic M3601E DVB-T receiver that is extremely small, measuring just 11.5 x 7.5 x 2.5 cm and weighing 118g.
2. The receiver has an innovative user interface, supports SD and HD channels, and includes an integrated personal video recorder function.
3. Recordings can be edited on a connected PC, and the receiver supports playback of multimedia files from USB drives or memory cards.
The document provides a review of the Eycos S55.12 PVRH satellite receiver. Key features include an integrated scaler that improves picture quality of SDTV channels, recording 4 channels simultaneously using 2 tuners, and fast USB 2.0 port. The reviewer was impressed with picture quality, EPG functionality, and tuner performance but notes overscan output is not yet available. Overall, the receiver offers sound performance and useful features at a good value.
The Zimple Box 3 receiver is compact with a sensitive tuner and blind scan capabilities. It supports DiSEqC 1.0 and 1.2 to control up to four LNBs or a motorized dish. A blind scan found active transponders and downloaded channels in under 6 minutes. The receiver had fast channel switching and produced a sharp picture quality. However, it lacked an EPG and loop-through output.
The document provides a detailed review of the ABCom IPBOX 9000 HD Plus satellite receiver. Some key points:
- It has two DVB-S2 tuners that can each record a channel simultaneously. The tuners can be swapped out for other types like DVB-T.
- It has a large range of connection options, including HDMI, optical audio, USB, and Ethernet. Software updates can be done via the network.
- Setup involves running a channel scan to populate the 10,000 channel list. Many options are available to configure satellite, language, and time settings.
- The receiver has a 500GB hard drive with extensive PVR functions like an 8-hour
The document provides a review of the Sonicview SV-360 Elite PVR satellite receiver. It describes the receiver's external features like its black front panel with chrome stripe and buttons. The rear panel connections include dual satellite inputs and outputs, RCA, S-video, component video, digital audio, USB and serial ports. The included remote is silver with illuminated buttons and can control other devices. The review tests the receiver's set up process, menu system, channel scanning and recording functions. In summary, the Sonicview SV-360 Elite PVR is a full-featured satellite DVR receiver.
The Topfield TF6000PVRE is a PVR receiver with an Ethernet interface, allowing recordings to be accessed and managed remotely over a home network or internet connection. It has reliable hardware and a user-friendly interface carried over from previous Topfield models. A key innovative feature is its support for third-party applications through an open TAP interface. Testing found strong performance except for weaker signals below 2Mb/s. The Ethernet interface provides fast transfers of up to 1Mb/s for conveniently accessing recordings away from the receiver.
The document tests and reviews the Jiuzhou DTP8300 IPTV receiver. It summarizes the key differences between IPTV and traditional TV reception, noting that IPTV receivers do not process signals directly but instead act as web browsers to display streaming content from a middleware server. The review examines the DTP8300's design, connection and configuration options. It finds the receiver is easy to set up for either Ethernet or wireless network access and displays content smoothly from a test middleware installation.
The document provides an overview and test report of the Giga Blue HD Quad Plus 4-tuner HDTV receiver. It has 4 integrated tuners that allow recording of multiple channels simultaneously. Additional tuners can be added to support different reception types. The receiver has a variety of connection ports, robust build quality, and offers extensive customization options for its features and user interface.
The document describes a professional cable TV signal analyzer called the Rohde & Schwarz EFL210. Some key features include its specialized design for detecting leakage signals across a wide frequency spectrum, robust carrying case for field use, ergonomic shape for comfortable one-handed operation, and integrated high-resolution color screen. The analyzer performs a variety of cable TV measurements on analog and digital transmissions through an intuitive interface and menu structure.
Rod Hewitt is a software programmer from the United States known for developing the popular digital TV stream analysis program TSReader. He dropped out of school early but became self-taught in computer programming. He wrote TSReader to help technicians monitor digital TV streams for errors. TSReader identifies every element in a transmission stream including video, audio and data PIDs. Hewitt now works independently from his home in Annapolis, Maryland developing IPTV and digital video recording applications.
1. Hwadar is a fiberglass dish manufacturer located in Dongguan, China that started in 1988 and has grown significantly using a "snowball effect" business approach of taking small, continuous steps towards expansion.
2. They produce a variety of fiberglass dishes and other products using SMC fiberglass from Chinese supplier Zhenshi Group, which provides high quality, durable materials.
3. Hwadar aims to produce high quality dishes and can accommodate small orders in addition to large wholesale customers as part of their snowball approach to sales.
The MX-OCS12 one cable LNB from Maxing receives signals from two Ku band sub bands and transmits them through a single cable. This allows multiple satellite receivers to be connected to the same cable running to the LNB, replacing the need for a multi-switch. The LNB performed well for the vertical sub band but showed slightly weaker performance for the horizontal sub band. While it simplifies the installation of satellite TV when replacing terrestrial TV with an existing cable system, it is limited to channels within the two Ku band sub bands it can receive.
The Jiuzhou Home Media Center is a wireless hub that distributes TV and media content throughout the home without cables. It uses WiFi and Bluetooth to wirelessly transmit signals to up to six TVs or monitors simultaneously. The central box connects to the home network via a cable connection but then streams content intra-network without additional wires. This allows for flexible TV placement and mobile viewing anywhere in the home.
The AntenasCastelo M-1038 antenna was tested against a simple metal rod antenna.
The M-1038 outperformed the rod antenna, providing 3dB stronger signals. When mounted outdoors, the M-1038's performance increased further, receiving digital channels the rod antenna could not.
Though a small indoor antenna cannot replace a large outdoor setup, the M-1038 was found to be a viable option for locations relatively close to transmitters, with its simple, discreet design suitable for indoor or outdoor use.
The document is a test report for a SVEC 1.2m VSAT dish. It discusses that the dish is perfectly made and easy to point to the desired satellite. It notes that receiving internet via satellite is not much different than receiving video transport streams, as bits and bytes are the same. The report also provides information on how to download the report in multiple languages and provides a link to more information on the SVEC company.
1. The document tests and reviews the AB IPBox 55HD, a Linux-based HDTV receiver.
2. It has a single tuner, no internal hard drive, but allows recording to an external hard drive. Software is customizable through Linux.
3. A dual boot feature will soon allow users to choose between two versions of the Enigma software, Enigma 1HD and Enigma 2HD, adding flexibility.
COMINTOUCH is a Dubai-based company that generates most of its revenue through distributing products made by the German manufacturer SPAUN. The two companies have an exclusive distribution agreement, with COMINTOUCH distributing SPAUN's multi-switch systems across the Middle East. COMINTOUCH was founded in 2001 and started working with SPAUN in 2004, experiencing rapid growth since then. SPAUN products now account for 80% of COMINTOUCH's turnover, with their multi-switches being top sellers.
1. The document tests and reviews the Icecrypt S3000HDCCI HDTV satellite receiver.
2. It finds that the receiver has a versatile feature set for its price, with fast blind scanning, multi-satellite control, and full DVR functions.
3. Testing shows the blind scan can find all channels on a satellite system within minutes, which is an outstanding result and better than expected.
The document provides a review of the Topfield TF7700 HDPVR satellite receiver. Some key points:
1) It is a twin-tuner HDPVR receiver that can receive channels in DVB-S and DVB-S2 as well as record two channels simultaneously.
2) It has an extensive selection of connection ports and language options. An automatic channel scan found channels quickly.
3) In addition to recording functions, it has a robust EPG, robust network connectivity for software updates, and easy customization of the channel list.
4) Performance tests found the receiver had strong signal reception across formats with no issues. The review concludes it is a full-featured
The document provides a review of the Icecrypt S3500HDCCI miniature HDTV satellite receiver. It summarizes that the receiver:
1) Is extremely small but fully equipped with a Linux operating system and features like blindscan searching.
2) Offers fast channel zapping of less than one second and can find over 900 TV and radio channels through its various search modes.
3) Can be upgraded through additional applications since it is Linux-based, and connects to the internet for access to more plugins.
The Eycos S50.12 PVR satellite receiver:
1) Has a sleek design and many connection options including dual tuners, CI slots, and USB 2.0 port.
2) Has an easy to use menu system and supports numerous languages for the on-screen display.
3) Performed well in testing with fast channel changing and scanning, good picture and audio quality, and strong signal reception even for weak signals.
The Fortec Star FSIR-5400 NA receiver is easy to use right out of the box, with features like embedded Irdeto encryption, fast channel scanning and switching, and the ability to handle low symbol rates. It has a large channel memory and supports various satellite control protocols. Testing showed it could reliably receive a 1.279 Ms/sec signal. The receiver would be well-suited for family TV viewing or satellite TV hobby use.
The Pixx Event is a digital satellite receiver with twin tuners, 2 CI slots, and a blind scan feature. It has a 10000 channel memory and supports 54 pre-programmed satellites. Connections include 2 Scart ports, S-Video, digital audio output, and a USB port. The receiver found over 90 channels during a blind scan test and performed well, though channel switching time was a little slow. The remote control was deemed to have too many small buttons. Overall the Pixx Event provides a complete feature set for both hobbyists and family use.
The Technisat Digit 4S is a small but powerful satellite receiver. It has a compact size that allows it to fit on any living room shelf. Despite its small size, it has most important connectors and supports satellites including Astra, Hotbird, and Hispasat. It has a channel memory of 5,000 entries and automatic programming guide data loading. Testing found its tuner to be sensitive and able to receive signals down to 4-5 dB. The on-screen menus are nicely designed and intuitive to use.
The document describes a new DVB-T2 signal analyzer called the Horizon HD-T2. It is one of the first signal analyzers on the market that is compatible with DVB-T2. The HD-T2 has a compact design, LCD display, rechargeable battery, and ability to export measurement data. It also has features like a channel scan function and ability to identify 4G interference that make it suitable for professional and casual users.
1. The document provides a test report of the Panodic HDT-127A DVB-T mini receiver.
2. It is a small but fully-featured receiver with a built-in PVR, USB port, and support for HD resolutions.
3. The receiver had a smooth setup process, reliable channel tuning and recording, and high video and audio quality when playing HD and SD channels.
The document tests and reviews the MKTechHD Scart Stick satellite receiver. It found that the receiver has an extensive list of connections including HDMI, network port, USB and card reader. It has a powerful tuner, fast channel switching, supports various video formats and recording two channels simultaneously. The reviewer was impressed by its extensive channel scanning options, customization abilities, and additional multimedia and network features. It concluded that the HD Scart Stick demonstrates Scart receivers remain relevant with its strong performance and user-friendly design.
The Topfield TF5000CIP is a digital satellite receiver with a 5000 channel memory, support for DiSEqC 1.0, 1.1, 1.2 and USALS/DiSEqC 1.3 for motorized dish control. It has a logical and easy to use interface, fast channel scanning, and supports multiple video and audio outputs. The main limitations are a lack of a 12V switch output and a channel memory that may be too small for some multi-satellite setups. Overall, it provides everything most users need without any notable issues.
This document provides a review of the AB IPBox 9900HD Plus satellite and media receiver. It has the following key points:
1) The receiver has two DVB-S2 tuners and runs the open source Linux operating system Enigma2 HD, giving it advanced functionality and customization options.
2) It has an extensive list of connections for audio/video including HDMI, USB, and network connectivity.
3) The interface is customizable and provides advanced features like an extensive favorites function with customizable channel groups.
1. The document tests and reviews the Amiko HD 8840 HDTV and PVR receiver.
2. The receiver has two tuner slots that can each accept DVB-S/S2, DVB-T/T2, or DVB-C tuners, giving it flexibility in how it can receive digital television signals.
3. The review finds that the receiver offers good picture quality up to 1080p resolution, easy installation of tuners, a user-friendly interface, and the ability to record two channels simultaneously while watching a third live.
The T-Connect S-2400 USB is a small, lightweight satellite receiver that connects to a laptop or desktop via USB. It has a sensitive tuner, supports common FTA satellites, and offers features like an EPG, PVR recording, and teletext in a package that is well-suited for mobile use cases like camping. However, it only supports the older DiSEqC 1.0 standard and lacks more advanced protocols like DiSEqC 1.2 that support motorized dishes. Overall, testing found the receiver worked well without issues, offering full satellite TV functionality through the USB-connected computer.
The document tests and reviews the Skyworth HS1H014 satellite receiver. It found that the receiver has fast channel switching, can record two channels simultaneously, and has a full program guide. However, it also found that the software update failed and some integrated apps like YouTube did not work properly. Overall, it recommends the receiver for its dual-tuner DVR functions but notes some apps need improvement.
The document provides a review of the Topfield TF7700HSCI HDTV satellite receiver. It has a single tuner, supports DVB-S, DVB-S2, and has HDMI, SCART, and component video outputs. Notable features include an integrated USB port that allows recording to an external hard drive or USB stick, 5000 channel memory, a simple user interface, and automatic detection of HD and SD formats. In testing, the receiver quickly changed resolutions and switched channels, and worked well for recording programming to an external hard drive for playback on other devices.
The document tests and reviews the Amiko STHD-8820 CICXE PVR combo receiver. The receiver can receive both satellite (DVB-S/S2) and terrestrial (DVB-T) broadcasts. The receiver was well-packaged and built with high quality materials. It has a 400MHz CPU, 1024MB RAM, and connections for satellite cards, common interface modules, USB, and DVB-T antenna. The receiver provides a full-featured experience for viewing satellite and terrestrial television programming.
The document tests and reviews the Moi Plus streaming box by TBS, which acts as a central DVB receiver that can distribute TV and radio signals via a home network to multiple devices. Key features include its small size, ability to be located remotely from TVs, support for wireless and wired networking, and integration of tuners. It comes preinstalled with the Tvheadend software, which allows automatic channel scanning, creation of customized channel lists for each user, electronic program guide functionality, and recording of content to external USB drives connected to the Moi Plus box. The review concludes the Moi Plus and Tvheadend together provide a versatile whole-home digital TV solution.
The Tekniksat optical distribution system can deliver 4 satellite signals and 1 terrestrial signal to hundreds of receivers with equal signal quality at all outputs. It uses an optical transmitter to convert the signals to a single optical signal, an optical splitter to divide the signal, and an optical multiswitch to convert it back and distribute to subscribers. Testing showed the system maintained sufficient gain and only minimally impacted signal quality even when splitting the signal across 320 receivers. It is recommended for efficiently distributing signals to a large number of subscribers.
The document reviews the Satlink WS6979HD signal analyzer. It has a high-resolution screen, HDMI output, long battery life, and supports DVB-S2 and DVB-T2. The device has comprehensive measurement and analysis functions for satellite and terrestrial signals. It also functions much like a standard satellite receiver, with features like an editable channel list and electronic program guide. Overall, the Satlink WS6979HD is a fully-featured, high-quality signal meter suitable for both professional and amateur use.
The document summarizes a mobile app called Satbeams that helps users align satellite dishes. It allows users to check if a satellite is receivable at their location and see satellite footprints offline. The app displays satellites on a virtual sky and calculates azimuth and elevation. It relies on an extensive satellite database but lacks daily frequency lists. Overall, the app provides a valuable tool for easily determining satellite reception and positioning dishes.
The document discusses the Logitech Harmony Smart Control system, which allows a smartphone or tablet to replace all original remote controls. It utilizes a hub connected to devices via infrared and Bluetooth. The hub also connects to the local WiFi network to handle commands from the Harmony app. The app can control up to eight devices at once and remembers pre-programmed command sequences. Gestures on the app allow for easy control of functions like volume. The system was able to successfully control all devices tested, including receivers, Blu-Ray players, an Apple TV, and gaming consoles.
Jim Edstein operates a large satellite reception system from the remote mountains of Taiwan to provide streaming services around the world. He first set up systems for expats to watch channels from home, then began streaming channels over the Internet in 2006. With fast, unlimited fiber Internet access in his area, he is now able to stream over 1000 TB of data per month to 90 point-to-point customers and host equipment for 7 additional customers. Operating from a small town in Taiwan, he distributes international TV channels globally via Internet streaming.
TELE-audiovision is a digital TV industry publication established in 1981 that is headquartered in Munich, Germany. It is published by TELE-audiovision Magazine GmbH and edited by Alexander Wiese. The publication has a readership of over 350,000 digital TV professionals worldwide. The current issue discusses the shift from coaxial cable to fiber optic technology for satellite signal distribution. Fiber optic distribution eliminates limitations of cable length and number of distribution points. It also means each user has access to the full satellite bandwidth at all times. The editor notes that while coaxial cable faces issues like signal attenuation related to frequency, fiber optic technology is not impacted by these factors.
The document discusses a DekTec DTA-2115 PCI Express card that can generate test signals for terrestrial, cable, and satellite receivers using a single PC card. It has an extremely wide frequency range from 32 MHz to 2186 MHz and supports virtually all digital modulation standards. This makes it very useful for testing receivers and troubleshooting reception issues. The card's software allows the user to adjust various signal parameters like modulation, frequency, error injection and signal quality to simulate real-world conditions.
The document provides a review of the SATFINDER 5 HD Slim handheld satellite meter from Alpsat Elektronik. It is small, lightweight device that features a high-resolution color display, integrated battery, and ability to simultaneously measure up to four transponders. The meter has a comprehensive pre-programmed database of satellites, transponders and channels. It allows for fine-tuning of dish alignment through features like cross-polarization measurement and constellation diagrams. The review concludes the SATFINDER 5 HD Slim is an extremely responsive meter for evaluating satellite signals.
The document is the May-June 2015 issue of TELE-audiovision Magazine, the world's leading digital TV industry publication. The issue includes test reports on new satellite equipment from companies like TEKNIKSAT, SATLINK, TENOW, and SATBEAMS. It also features articles on the growing use of fibre-optic technology for signal distribution, a profile of a Taiwanese satellite enthusiast, an overview of notable satellite uplink stations, and the history of TELE-audiovision magazine.
The document describes the Spaun Sparos 711 professional meter for digital TV. It has a 10-inch touchscreen with high resolution and is optimized for antenna installers and technicians. The meter has a rugged metal case and offers simultaneous measurements of transponder signals. It can measure DVB formats along with ASI, HDMI and other connectivity. The large touchscreen and intuitive interface make it easy to use right out of the box. An included transport case presents a professional image for installers.
The document tests and reviews the MKTech CB200 HD dual tuner meter. It is a small, lightweight, and easy to use meter that allows installers to simultaneously monitor signals and parameters for two different inputs. It has a clear LCD screen, intuitive interface, built-in database of satellites and transponders, and features like automatic satellite detection that make it suitable for professional installation and troubleshooting tasks. The review finds that while small in size, the meter has strong performance and many useful features for installers.
1) Haenlein Software develops and sells PVR software that allows users to record and edit digital TV programs and easily transfer recordings between different receivers.
2) Started in 1999 as a side project, Haenlein Software is now the owner's full-time business, employing 3 people working from home.
3) Their software works with over 800 different receiver models, has been translated into many languages, and is sold internationally through distributors and partnerships with receiver manufacturers.
1. GlobalInvacom's FibreIRS family improves satellite signal distribution using fiber optic cables instead of coaxial cables, allowing signal splitting and longer cable runs with minimal loss.
2. The new FibreIRS O2E optical-to-electrical converter, combined with the FibreIRS ODU optical amplifier, can regenerate and amplify signals after splitting, improving signal quality beyond the original source.
3. In tests, the combination of FibreIRS O2E and ODU provided amplification to restore signal strength after splitting 32 ways, while further improving modulation error ratio, demonstrating its ability to multiply outputs from a single LNB while enhancing signal quality.
The Formuler F1 is a triple-tuner HD receiver that provides fast channel changing and search functions. It can be installed with various operating systems, including OpenPLI, OpenATV, and HDMU. The receiver features a versatile channel search, excellent electronic program guide, and the ability to record multiple channels simultaneously. Overall, the Formuler F1 delivers speed and a fun user experience, as its name and F1 designation would suggest.
The document provides a test report of the Fernsehfee 2.0, an intelligent TV receiver developed by TC Unterhaltungselektronik AG for German-speaking markets. Some key features of the Fernsehfee 2.0 include an ad blocker, optimized program guide for German channels, recording function, and built-in WiFi for connecting to networks. It also functions as a web TV box thanks to its Android operating system. The Fernsehfee 2.0 learns users' viewing preferences through an account system and recommends content it thinks they will enjoy based on ratings and past viewing behavior.
EICO is an antenna wholesaler and retailer located in Reykjavik, Iceland that has been in business since 1979. It sells over 400 satellite dishes per year, with 85cm dishes being the most popular for receiving signals from ASTRA. EICO also distributes signals using GlobalInvacom's fiber-optic system to over 100 apartments. While EICO previously installed MMDS systems, that technology is expected to be discontinued in Iceland. Overall, EICO remains at the forefront of technology for receiving TV signals in Iceland.
This document provides information about TELE-audiovision Magazine, a digital TV trade publication established in 1981. It is published by TELE-audiovision Magazine GmbH based in Munich, Germany. Alexander Wiese is the publisher and editor-in-chief. The magazine is published in both print and digital formats and covers topics related to digital TV technology and devices, with a focus on products that utilize multiple tuners in the latest issue.
This document is the March-April 2015 issue of TELE-audiovision, a digital TV trade magazine published since 1981. The issue includes test reports on new products such as a triple-tuner HD receiver, a dual tuner signal meter, and an amplifier that improves signal quality. It also has articles on a software developer in Germany and a satellite equipment wholesaler in Iceland, as well as information on the magazine's global readership and a history of TELE-audiovision.
The document tests and reviews the Titanium Satellite C1W-PLL LNBF. It was tested on an offset dish in southern France and found to have excellent reception quality, with a gain of up to 6.2 dBμV. The C1W-PLL uses PLL technology to provide a very stable signal lock, even for difficult signals like low symbol rates or high FEC carriers. It is recommended as a best bargain for C-band enthusiasts due to its high performance and low price.
1. TEST REPORT DVB-T2 Receiver
Skyworth
HTA6 • Simple Minimal Design
• Uses an external power supply
• Very stable software
• Exceptional EPG presentation
• Specialty is the ability to blend in
subtitles
32 TELE-audiovision International — The World‘s Largest Digital TV Trade Magazine — 01-02/2013 — www.TELE-audiovision.com www.TELE-audiovision.com — 01-02/2013 — TELE-audiovision International — 全球发行量最大的数字电视杂志 33
2. TEST REPORT DVB-T2 Receiver
DVB-T2 in an Elegant Package
The new HTA6 DVB-T re- essary connections. And of the HTA6 – typical from channel scan across the en-
ceiver from Skyworth can these include a tuner input Skyworth. tire frequency band. Here at
be found in a 19 x 11.5 x with looped-through output, The Skyworth HTA6 be- our test location in Vienna,
4cm sized chassis made out an HDMI jack, three RCA longs to that group of re- Austria, the HTA6 needed
of glossy black plastic with jacks for stereo audio and ceivers that come with a three minutes to complete
edges that are elegantly CVBS video as well as a port practical installation assis- this task and thereby man-
rounded off. On the front to plug in the external 12V tant; it’s just another plus aged to find every available
panel you’ll find a USB 2.0 power supply. point in our overall rating. channel in DVB-T as well as
interface, a slot for the in- Thanks to the fact that Before the user can put the test channel in DVB-T2.
tegrated card reader as well Skyworth chose to use an the receiver to work, se- And just like in any of our
as three buttons (On/Off, external power supply, the lections need to be made other tests, we couldn’t re-
Ch+ and Ch-). receiver itself is not only for OSD language, receiver sist taking a closer look at
And it’s precisely this sim- suitable for use while camp- location, picture display as the receiver’s main menu
ple design that that we liked ing or even in a car, its heat well as voltage selection for before going on to actual TV
so much; who really uses a output it very low allowing it the antenna. reception.
four-digit segmented dis- to be easily placed in any TV The submenu Picture Dis- The Main Menu is divided
play? Skyworth even came setup or in any living room play includes 4:3 and 16:9 into seven submenus start-
up with an interesting so- cabinet. formats although the reso- ing with ‘Program’. Here the
lution to display the opera- The remote control sup- lution of the video signal via user can set up the channel
tional state of the receiver: plied by the manufacturer HDMI cannot be changed list as desired; channels can
An LED positioned behind is nicely organized and easy from here. be deleted, moved, locked
the On/Off button shines to read. The pressure points To finish off the initial in- with a PIN code, renamed
green when the receiver is of the buttons are relatively stallation, the user is asked or skipped over. Channels
operational and red when comfortable; the buttons to perform an automatic can also be moved into one
it’s in standby. themselves are rather small
At first glance the rear but it won’t take long to
panel of the HTA6 appears get used to them. Overall,
somewhat limited yet it there’s nothing to complain 01-02/2013
does come with all the nec- about with the workmanship Skyworth HTA6
A solid receiver for HDTV
via a terrestrial
antenna
www.TELE-audiovision.com/13/01/skyworth
0.45
34 TELE-audiovision International — The World‘s Largest Digital TV Trade Magazine — 01-02/2013 — www.TELE-audiovision.com
3. 1 6 11
of four Favorites lists. Even receiver can also handle a
the automatic sorting of the manual scan using the chan-
channel list is possible here. nel number or channel fre-
If you go to the ‘Picture’ quency. Immediately after
submenu, that’s where entering in these values, the
you’ll find the ability to signal strength and qual-
change the resolution of the ity are shown on two large
HDMI video signal, some- bar graphs; this allows the
thing we couldn’t do earlier user to confirm even before
in the initial installation. The a channel scan that an ac-
2 7 12
available choices are 576i, tive frequency has been se-
576p, 720p, 1080i as well lected.
as 1080p 50/60 Hz. In other Regarding setting the
words, the receiver is best time, Skyworth came up
suited for use with HDTV with an interesting idea: in
reception and is also ready addition to the standard way
for the future thanks to its of selecting the local time
1080p full HD support. difference to GMT, the user
Although hardly ever used, can also simply select their
the picture standard can be location from a list and the
switched from PAL to NTSC receiver will then automati-
3 and back again if needed. cally adjust for that time 8 13
You can also adjust the OSD zone.
transparency to your needs. Skyworth also included an
Hidden behind the ‘Chan- on/off timer so that the re-
nel Search’ menu are all ceiver can be programmed
the channel scan options. to automatically turn on and
In addition to the automatic off at specified times.
channel scan across the en- On top of all the different
tire frequency range, the settings capabilities, Sky-
worth also included child
1. Installation assistant
protection through the age
2. Automatic channel scam – feature in the EPG, the abil-
4 thanks to DVB-T2 compatibility, ity to do a factory reset 9 14
HD channels in H.264/MPEG-4
can also be played back and also language selection
without any problems
for audio, subtitles and the
3. With the help of the colored
function buttons the channel OSD.
list can be customized to your
personal tastes OK, we spent enough time
4. Channels can be easily discussing all the different
renamed settings that the HTA6 has;
5. The exceptionally clear and
nicely designed EPG it’s time to let the receiver
6. Picture settings do what it was meant to do:
7. Manual channel scan – the and that is TV reception.
bar graphs at the bottom
instantly let the user know if As we would expect from
a valid frequency has been Skyworth, there were no is-
5 entered
sues and it provided excel-
10 15
8. Local time settings, and, if
needed, also with the help of lent picture and audio qual-
your location setting
9. Various language and audio ity. Even the roughly one
settings second channel switching
10. System settings
time from one frequency
11. USB settings
to another was nothing to
12. Music, pictures and videos
can be played back through the complain about and should
HTA6
even make a couch potato
13. Audio playback of an M4A
file happy.
14. Playback of a DivX HD Video A push of the OK button
15. Playback of a Flash Video
displays the channel list.
36 TELE-audiovision International — The World‘s Largest Digital TV Trade Magazine — 01-02/2013 — www.TELE-audiovision.com www.TELE-audiovision.com — 01-02/2013 — TELE-audiovision International — 全球发行量最大的数字电视杂志 37
4. 16
Here the user can easily side you’ll find the associ-
switch between TV and ra- ated detailed information.
dio reception using the left/ With the help of the color-
right arrow buttons on the ed function buttons on the
remote control. The FAV remote control you can eas-
button opens up a list con- ily page through all of the
taining the channels that content. Timer entries can
were previously marked as also be set up in the EPG so
Favorites while the red func- that you won’t have to worry
tion button lets you search about missing your favorite
17
for specific channels. program; they can be stored
In our tests the HTA6 was on an external storage de-
easily able to handle any vice connected via the USB
of the received streams in 2.0 port.
either DVB-T or DVB-T2. It With the help of dedicated
was also quite happy with buttons on the remote con-
the H.264/MPEG-4 format trol for audio language and
for optimal use of bandwidth subtitles, the associated
in DVB-T2. settings can be adjusted
As long as the program- while the receiver is in op-
ming provider supplies EPG eration. There’s also an in-
18 data, it is shown by the tegrated teletext decoder
HTA6 in a clear and easy to and although the technol-
understand Info bar for the ogy is rather old, its pages
current and upcoming pro- are still a popular source of
grams with every channel information.
change. If more detailed in- Did you ever get annoyed
formation is needed, simply at the occasional small size
press the ‘i’ button on the of the subtitle text? Well,
remote control to access the Skyworth even thought of
expanded EPG. this problem: the HTA6 has
We also liked a particu- the ability to change the
lar feature of the Info bar text size, text color and
19 in which a row of dots indi- background color of the
cates graphically to the user subtitles. We found that to
how long a program has be extraordinary!
already run and how much There are hardly any digi-
time is left for that program. tal receivers out there today
Even the Electronic Pro- that don’t come with multi-
gram Guide (EPG) is a high- media features and the Sky-
light from Skyworth in that worth HTA6 with its USB 2.0
it is presented in a clear interface is no exception.
and organized fashion. It We appreciated all the dif-
is always displayed for one ferent audio and video for-
channel and divided into two mats that the HTA6 can han-
20
sections. On the left side are dle, specifically, AAC, M4A,
the individual programming MP3 and WMA for audio as
entries while on the right well as AVCHD, DivX SD/HD,
Flash, MOV, MP4 SD/HD,
16. Playback of an MOV Video MPEG and TS for video.
17. Playback of an MP4 Video in This receiver not only lets
HD quality
18. Playback of a TS video you enjoy music, but you
stream can also view the latest In-
19. Picture viewer
ternet videos in full-screen
20. Thanks to the grid view,
multiple photos can be shown mode on your TV. At the
side-by-side same time, a picture viewer
38 TELE-audiovision International — The World‘s Largest Digital TV Trade Magazine — 01-02/2013 — www.TELE-audiovision.com
5. 21
6 25 29 30
22 26 21. The display time and the switchover mode can be individually
set for a slideshow Expert Opinion
22. Subtitles can be displayed in three different font sizes and in
user-selectable colors An elegant housing, a clear OSD as well as
23. Channel list simple and logical operation highlight this
24. The red function button can be used to search for a specific receiver. Its menu operation should not be a
channel problem for anyone. The software proved to
be stable during our tests and didn’t present
25. A push of the ‘i’ button on the remote control displays
expanded information on the current channel + any problems. The video and audio output via Thomas Haring
TELE-audiovision
26. Info bar with the EPG data from the current and upcoming HDMI is very good and thanks to the external Test Center
program 12V power supply, the receiver would be per- Austria
27. Teletext fect for use in your back yard or while cam-
28. Selection of the desired audio track ping.
29. Favorites list
30. Selection of the desired subtitles The remote control is somewhat small but you’d eventually get
23 27
– used to it.
has become standard and and family conveniently and
Skyworth also included this comfortably from your living
function in the HTA6. room couch on your TV. TECHNICAL
DATA
Pictures stored on a USB The HTA6 from Skyworth Manufacturer Shenzhen Skyworth Digital Technology CO., LTD.
storage device can be dis- is a solid receiver that has Email sales miaodan@skyworth.com
played one-at-a-time, in no problems handling DVB- Internet www.skyworthdigital.com
slideshow format with ad- T and DVB-T2 signals. It Model HTA6
justable display time, at therefore lets you enjoy Function DVB-T/DVB-T2 Receiver
random or in a grid format. high-resolution TV from a Input frequency VHF (177.5-226.5 MHz) UHF (474-858 MHz)
Skyworth even thought terrestrial antenna. EPG yes
Supported standards DVB-T, DVB-T2
about a zoom function and The OSD is clear and easy-
Video resolution 576i, 576p, 720p, 1080i, 1080p 50/60 Hz
24 28 maintaining the aspect ra- to-follow, the operation of
RS232 no
tion. Regardless if it’s pic- the receiver is intuitive and
Ethernet no
tures from your most recent the housing was very taste-
USB 2.0 yes
vacation, a kid’s birthday fully designed. We here at HDTV yes
party or some other event, TELE-audiovision like this MPEG4/H.264 yes
the HTA6 will let you show box and feel it is worthy of a Internal Smarrcard Reader yes
them off to your friends recommendation. Power supply 12V DC
More about this company ENERGY
www.TELE-audiovision.com/11/03/skyworth
DIAGRAM
Mode Apparent Active Factor
Active 11 W 5 W 0.45
StandBy 3.5 W 0.5 W 0.14
Apparent Power
Active Power
The first 15 minutes active operation with channel surfing and
multimedia playback; the second 15 minutes Standby
40 TELE-audiovision International — The World‘s Largest Digital TV Trade Magazine — 01-02/2013 — www.TELE-audiovision.com www.TELE-audiovision.com — 01-02/2013 — TELE-audiovision International — 全球发行量最大的数字电视杂志 41
