2. Background
Normal bone growth and mineralization
require adequate availability of Ca and
phosphate.
Disease of growing bone that is unique
to children and adolescents
Due to failure of osteoid to calcify in a
growing person
Deficient bone mineralization can result
in rickets and/or osteomalacia
3. ..
Rickets: Changes caused by deficient
mineralization at the growth plate
Osteomalacia: Impaired mineralization of
the bone matrix
Usually occur together as long as the
growth plates are open
Only osteomalacia occurs after the
growth plates have fused
4. ..
Vit D deficiency – commonest cause
of rickets
Less commonly, a dietary deficiency of
Ca or phosphorus may also produce
rickets
Vit D-3 (cholecalciferol) is formed in the
skin from a derivative of cholesterol
under the stimulus of UV light
UV light or cod liver oil was the only
significant source of vit D until early in
the 20th C
5. ..
Natural nutritional sources of vit D are
limited primarily to fatty, ocean-going
fish
Human milk contains little vit D,
generally less than 20-40 IU/L
Breastfed infants at risk esp those who
receive no oral supplementation and
with darkly pigmented skin – melanin
blocks penetration of UV light
6. Requirements
Commonly measured in micrograms
(mcg)
International Units (IU) is the unit of
measurement that appears on food
labels
200 IU is equivalent to 5mcg (1mcg = 40
IU)
7. Epidemiology
In Africa, deficiency of Ca, phosphorus,
or both in the diet may lead to rickets,
especially in societies were corn is
predominant in the diet
Kenya:
-6.6% in preschoolers (1-4yrs)
-Risk factors:
1. Weaning under 1yr
2. Use of cereal-based, unfortified foods
3. Negligible cow or goat milk consumption
4. Being kept indoors when mothers were
working in the fields
Charlotte Grantz Neumann and Nimrod O Bwibo
8. ..
In the developed world, Vit D deficiency
rickets does not occur in formula-fed
infants because formula and milk sold
contain 400 IU of vit D/L
Nearly all cases occur in breastfed
infants with dark skin who receive no Vit
D supplementation
Patients with chronic malabsorption
syndromes
9. ..
Race: Individuals with dark skin are at
increased risk for vit D deficiency
rickets
Sex: No sexual predilection is noted
Age: By definition, rickets is observed
only in growing children, although the
effects may be observed later in life
10. Ossification
Process of bone formation, in which
connective tissues, such as cartilage are
turned to bone or bone-like tissue
Bone-forming cells(osteoblasts) deposit a
matrix of collagen
The tissue is invaginated with blood vessels -
bring minerals and deposit it in the ossifying
tissue
Ca, Mg and phosphate ions, chemically
combine and harden within the matrix into
hydroxyapatite
11. ..
The combination of hard mineral and
flexible collagen makes bone harder
than cartilage without being brittle
Bone formation is a dynamic process,
with osteoblasts depositing minerals,
and osteoclasts removing bone
This process, termed bone remodeling
continues throughout life
12. Etiology
VITAMIN D DISORDERS
◦ Nutritional deficiency
◦ Secondary deficiency
Malabsorption
◦ Vitamin D–dependent rickets type 1
◦ Vitamin D–dependent rickets type 2
◦ Chronic renal failure
14. ..
Anticonvulsant drugs (eg phenobarbital,
phenytoin) accelerate metabolism of
calcidiol, which may lead to insufficiency
and rickets, particularly in children who
are kept indoors in institutions
Aluminum-containing antacids interfere
with the absorption of phosphate
Transplacental transport of vit D, mostly
25-D, provides enough vitamin for the
1st 2mo of life unless there is severe
maternal def
15. Pathophysiology
Cutaneous synthesis - the most important
source of Vit D, depends on the conversion of 7-
dehydrochlesterol to cholecalciferol by UV
radiation from the sun
Undergoes a 2 step hydroxylation - 1st at position
25 in the liver → calcidiol (25-
hydroxycholecalciferol)
Circulates in the plasma as the most abundant of
the vit D metabolites - good indicator of overall vit
D status
2nd in the kidney at the 1 position → the active
metabolite calcitriol (1,25-
dihydroxycholecalciferol) – facilitated by PTH
16. ..
Calcitriol acts at 3 known sites to
tightly regulate Ca metabolism:
1. Promotes absorption of Ca and
phosphorus from the intestines
2. Increases reabsorption of phosphate in
the kidney
3. Acts on bone to release Ca and
phosphate
17. ..
These actions increase the
concentrations of Ca and phosphorus
in ECF
↓
Calcification of osteoid, primarily at the
metaphyseal growing ends of bones
but also throughout all osteoid in the
skeleton
In vit D deficiency → hypocalcaemia
→ excess PTH → renal phosphorus
loss → ↓deposition of Ca in the bone
18. ..
Early in the course of rickets, the Ca
concentration in the serum
decreases
After the parathyroid response, the
Ca concentration usually returns to
normal, though phosphorus levels
remain low
↑ALP- produced by overactive
osteoblasts
19. Clinical Features
General
Failure to thrive
Listlessness-spiritless mood
Protruding abdomen
Muscle weakness (especially proximal)
Fractures
Head
Craniotabes
Frontal bossing
Delayed fontanelle closure
Delayed dentition; caries
20. ..
Chest
Rachitic rosary
Harrison groove
Respiratory infections and atelectasis
Back
Scoliosis
Kyphosis
Lordosis
21. ..
Extremities
Enlargement of wrists and ankles
Valgus or varus deformities
Windswept deformity
Anterior bowing of the tibia and femur
Coxa vara
Leg pain
Hypocalcemic Symptoms
Tetany
Seizures
Stridor due to laryngeal spasm
22. ..
The site and type of deformity of the
extremities depend upon the age of the child
and the weight-bearing patterns in the limbs
Deformities of the forearms and posterior
bowing of the distal tibia more common in
infants
Exaggeration of the normal physiological
bowing of the legs (genu varum) is a
characteristic finding in the toddler who has
started to walk
In the older child, valgus deformities of the
legs or a windswept deformity may be
apparent
23. ..
Hypocalcemic rickets can affect the
musculoskeletal system with decreased
muscle tone, leading to delayed
achievement of motor milestones
Hypocalcemic seizures are a frequent
presenting sign in the first year of life
Children with hypocalcemic rickets also are
particularly prone to acquiring infectious
diseases
Increased sweating is a common finding
in young infants with hypocalcemic
rickets and may be caused by bone pain
31. Diagnosis
Based on the combination of:
1. History of poor Vit D intake and risk
factors for decreased cutaneous
synthesis
2. Consistent radiographic changes and
3. Typical laboratory findings
32. ..
Laboratory Studies
ALP markedly increased - Excellent
marker of activity of disease because it
participates in the mineralization of bone
and growth plate cartilage
↓ Ca early in the disease course; often
within the reference range at the time of
diagnosis as PTH levels increase
↓Calcidiol (25-hydroxy vit D) - levels
reflects the amount of vit D stores in the
body
33. ..
↑PTH
Calcitriol levels maybe normal or
elevated because of increased
parathyroid activity
The phosphorus level is invariably
low for age
34. ..
Radiographic findings
Changes best visualized at the growth plate
of rapidly growing bones - the distal ulna and
the metaphyses above and below the knee
joint
Decreased calcification leads to thickening of
the growth plate
The edge of the metaphysis loses its sharp
border – fraying
The metaphysis changes from a convex or
flat surface to a more concave surface –
cupping
35. ..
There is widening of the distal end of
the metaphysis, corresponding to the
clinical observation of thickened wrists
and ankles, as well as the rachitic
rosary
Other radiologic features include
coarse trabeculation of the diaphysis
and generalized
rarefaction(osteomalacia)
38. Treatment
Gradually over several months or in a
single-day dose
Single day dose: 15,000 mcg
(600,000 U)
divided into 4 or 6 oral doses, IM
injection available
Vit D is well stored in the body and is
gradually released over many weeks
39. ..
In nutritional rickets, the phosphorous
level rises in 96 hrs and radiographic
healing is visible in 6-7 days with
single day dose
Gradual approach: 125-250 mcg (5000-
10,000 U) daily for 2-3mo until healing is
well established and the ALP
concentration is approaching the
reference range - success depends on
compliance
If severe deformities have occurred,
orthopedic correction may be required,
most of the deformities correct with
40. Prevention
Adequate UV light for at least 20 min/d to the
face of a light-skinned baby - longer for darker
children
10 mcg (400 IU) PO daily and an adequate
dietary supply of calcium and phosphorus
Human milk contains little vit D and too little
phosphorus for babies who weigh <1500g – need
special supplementation if breast milk is their
primary dietary source
Vit D supplement from the 1st week of life for
susceptible infants who are breastfed is safe
and effective
41. RICKETS OF PREMATURITY
80% of the transfer of Ca and phosphorus from
mother to fetus occurs during the 3rd trimester
Most cases in infants with a birthweight <1,000 g.
Presents 1–4 mo after birth
Breast milk and standard infant formula do not
contain enough Ca and phosphorus for the needs
of a premature infant
Nontraumatic fractures, esp of the legs, arms, and
ribs; most fractures are not suspected clinically
Fractures and softening of the ribs lead to
decreased chest compliance → respiratory distress
42. ..
Poor linear growth
Frontal bossing, rachitic rosary, craniotabes, and
widened wrists and ankles
Most infants have no clinical manifestations, with
the diagnosis based on radiographic and laboratory
findings
Provision of adequate amounts of Ca, phosphorus,
and vit D significantly decreases the risk of rickets
of prematurity
Increased mineral feedings should continue until
the infant weighs 3–3.5 kg
400 IU/day of vit D via formula and vitamin
supplements
43. CONGENITAL VITAMIN D DEFICIENCY
Rare
Due to severe maternal vit D deficiency
during pregnancy
Risk factors: poor dietary intake, lack of
adequate sun exposure, and closely
spaced pregnancies
Newborns may have symptomatic
hypocalcaemia, IUGR, decreased bone
ossification, along with classic rachitic
changes
44. VITAMIN D–DEPENDENT RICKETS, TYPE 1
Autosomal recessive
Mutations in the gene encoding renal 1α-
hydroxylase, preventing conversion of 25-D
into 1,25-D
Normally presents during the 1st 2 yr of life
with any of the classic features of rickets
Normal levels of 25-D, but low levels of 1,25-
D
Responds to long-term treatment with 1,25-D
(calcitriol) 0.25–2 μg/day
45. VITAMIN D–DEPENDENT RICKETS, TYPE 2
Autosomal recessive
Mutations in the gene encoding the vit D receptor,
preventing a normal physiologic response to 1,25-D
Levels of 1,25-D are extremely elevated
Most patients present during infancy
50–70% of children have associated alopecia;
epidermal cysts are a less common manifestation
May respond to extremely high doses of vit D2, 25-D, or
1,25-D. Treatment of patients who do not respond is
difficult
46. CHRONIC RENAL FAILURE
↓ activity of 1α-hydroxylase in the kidney →
diminished production of 1,25-D
Hyperphosphatemia as a result of decreased renal
excretion
The rickets is worsened by the metabolic acidosis
of CRF
Therapy by calcitriol (does not require 1-
hydroxylation by the kidney)
Because hyperphosphatemia stimulates PTH
secretion, dietary phosphorus restriction and oral
phosphate binders always required
Editor's Notes
PTH-Parathyroid hormone
PTH-Parathyroid hormone
Craniotabes-ping poss ball sensation of skull bones esp parietal and occipital bones
Harrison groove/sulcus-horizontal depression on lower chest. Softened lower rib cage at the site of attachment of the diaphragm.
Coxa vara- deformity of the hip whereby the angle btw the head and the shaft of femur is reduced to less than 120 degrees. This results in the leg being shortened.
