1. Toolbox Meeting
Venue
Bilfinger Tebodin
Online – Microsoft Teams | 18 June 2020

2. HYDROGEN
page 2
2H2 +O2 2H2O + Energy
LHV of H2 = 120 MJ/kg
LHV of CH4 = 50 MJ/kg
 Hydrogen is Zero Emission Fuel
H2
CH4
LEL
4%
5%
HEL
75%
17%

3. PARIS AGREEMENT & WIND ENERGY
page 3
• Limit the increase of global average temperature to <2°C above pre-industrial
levels and to pursue 1.5°C
• No country is on target to achieve this goal
• Wind & Solar energy play a major role
• Current offshore wind power capacity ~24GW
• Wind Power generation rapidly growing
• Wind Energy to power conversion is challenging due to variability of wind
• Grid cannot cope at high wind conditions

4. • Steel plant need gas, not electricity
• Hydrogen mixed with gas reduces carbon foot print
• High concentration of hydrogen in gas leads to high NOx levels
• Electrolysis to convert purified sea water to H2
• Generated Hydrogen can be stored or injected into existing gas infrastructure
• H2 can be stored in depleted gas fields through wells
• North Sea will be a major activity center with many offshore well platforms that will be
decommissioned
WIND ENERGY TO HYDROGEN
page 4

5. GREEN, BLUE & GREY HYDROGEN
page 5
• Green Hydrogen produced from renewable energy like wind
• Blue hydrogen produced from non – renewable energy source. Can be from
natural gas provided CO2 is captured & stored.
• Grey hydrogen is present day hydrogen production from natural gas using SMR
process. No CO2 capture.
• Electrolysis Technology carbon footprint  0.01 kg CO2/MJ hydrogen
• SMR without CCS carbon footprint 0.09 kg CO2/MJ hydrogen
• Hydrogen mixing in natural gas  15% - 40%
• Electrolysis using electricity from grid has higher carbon foot-print.

6. page 6
Comparison of Electrolysis technologies

7. QUESTIONS
page 7
• How do we sell concept of Hydrogen production from Solar PVs?
• Power is continuous or Hydrogen production is continuous?
• Hydrogen storage in underground caverns? What is the potential?

8. LOHC
page 8
• Overall Effciency is 69% if the surplus energy during dehydrogenation step is not
recovered. If it is recovered somehow, the efficiency will be 88%.
Of course the above assessment does not take into consideration the aspects of the
carrier chemical production.
Efficiency of 69% compares OK with respect to Liquid hydrogen which has 72%
efficiency.

9. Questions
page 9
