1. POTENTIOMETER KNOBS
Uses, Types, And Working Principles

2. STYLES OF POTENTIOMETER KNOBS
 Potentiometer knobs come in two
basic styles, with the most common
being a smooth shaft and a knurled
shaft.
 The latter type is suitable for fitting
knobs with a 6.0 mm potentiometer.
 The latter type does not have many
features but has a cutout and
resembles a "D" shape when viewed
from above.

3. MOST COMMON
POTENTIOMETERS
 One of the most common
potentiometers is the RD901F series.
 Its T18 knurled shaft is the most
commonly used for DIY synthesizers.
 This type has a high resistance of 5V
and is ideal for most applications.
 They are widely used in many
electronic circuits, including MIDI and
Eurorack systems.

4. MAKE YOUR OWN POTENTIOMETER
KNOBS
 If you are planning to make your own
potentiometer knobs, you should know
how they work.
 The knobs are designed to change the
resistance of electrical devices.
 The knobs of a potentiometer come
with three terminals.
 The third terminal is connected to the
knob and can be used to control the
voltage flowing through the
potentiometer.

5. POTENTIOMETER IS A THREE-TERMINAL
RESISTOR
 A potentiometer is a three-terminal
resistor with a sliding or rotating
contact.
 Its main function is to adjust the level
of analog signals.
 Its application in audio equipment
includes volume and color response.
 Its properties can help in the frequency
modulation of waves.

6. FINAL WORDS
 A potentiometer's resistive element is
usually made of graphite.
 Some potentiometers are made of
carbon-based materials, while others
have a resistive element made of
graphite.
 In addition to their haptic properties,
potentiometers can also be used as
voltage dividers.
 They can be used with a fixed input
voltage and produce a manually
adjustable output voltage.

7. WHERE TO BUY
 You Can Buy This Product Online In UK.
 Enrgtech have potentiometer knobs.
 you can order here the product
 https://www.enrgtech.co.uk/category/passive-components/variable-resistors/potentiometer-
knobs
