1. ATT: Caring Circuit
From : **** Engineering
*****Company
Email:******
Phone:
Purchasing contact : ******
Technical contact : ******
Please quote for 10, 20, 50, 200 in standard and 5 day turn.
Part Number-----------------------: 110365
Revision--------------------------: 1.1
Board size------------------------: 4.5" x 5.00"
Board Thickness-------------------: 0.062"
Board type------------------------: TWO LAYER
P.C.B material--------------------: FR4
Finished Copper-------------------: 1 oz
Finish----------------------------: White Tin
Solder Mask on Bare Copper--------: Yes
Mask type-------------------------: LPI
Mask color------------------------: GREEN
Silk screen color-----------------: WHITE
Silk screen layers----------------: COMPONENT
Surface mount---------------------: Yes
Surface mount pads quantity-------: 789
Smallest trace size---------------: 0.008"
Smallest clearance between traces-: 0.008"
Routing---------------------------: Single boards
Gold Edge Connectors--------------: No
Internal slots/routes-------------: 2
Holes size qty.
T1 0.025" 338
T2 0.030" 6
T3 0.035" 6
T4 0.040" 115
T5 0.055" 34
T6 0.060" 2
T7 0.125" 3 ***** DO NOT PLATE *****
T8 0.150" 4 ***** DO NOT PLATE *****
T9 0.001" 2 SEE NOTES BELOW
Files to be found
110365.GBR COMPONENT SILK
110365.GBR COMPONENT MASK
110365.GBR COMPONENT COPPER
110365.GBR SOLDER COPPER
110365.GBR SOLDER MASK
www.caringcircuit.com care@caringcircuit.com PCB manufacturer in Shenzhen,China
1

2. 110365.NCD DRILL FILE
110365.FAB FAB DRAWING
Critical Tolerances: None
Special instructions:
T9 is a plated slot 0.125" x .060"
Manufacturing marks may be placed in solder side copper.
Thank you
