The document describes an ore agitator and provides details about its features, specifications, and applications. It lists the agitator's advantages as long service life, high quality, energy efficiency, simple structure, and ability to mix materials well. Technical specifications are provided for different agitator types and sizes, including dimensions, power requirements, rotation speeds, and effective volumes. The agitator is suitable for mixing ores before processing in industries like mining and pharmaceuticals. Contact information is given for the manufacturer.

1. 2020/4/1 Ore Agitator
https://chinaminingproject.com/Ore-Agitator.html 1/4
sales
Features and advantages of Agitator
1. long service life
2. high quality and efficient
3. energy -saving
4.simple structure
5. mixing material well
6.OEM order accepted
Agitator technical data:
Ore Agitator
Ore Agitator
The agitator is suitab
the mixing before the
of pharmaceutical an
mixing of the other n
concentration canno
weight), and the part
than 1mm. The form
cycle with the spiral
chat online
Phone:0086 186371
Email: sales@hiima
China Mining Project About Us Projects Contact
Online
1

2. 2020/4/1 Ore Agitator
https://chinaminingproject.com/Ore-Agitator.html 2/4
Type Specification Inner dimensions of
chute
Effective
cubage
(m3)
Rotation speed
of main shaft
(r/min)
Power
(KW)
Dimensions
(L×W×H)
(mm)
Diameter
(mm)
Depth
(mm)
Mixing Berrel XB-10×10 1000 1000 0.58 390 1.5 1130×1130×1521
XB-12×12 1200 1200 1.18 390 2.2 1130×1330×1721
XB-15×15 1500 1500 2.2 280 3 1750×1640×2190
XB-20×20 2000 2000 5.6 210 5.5 2380×2160×2850
XB-25×25 2500 2500 11.2 190 7.5 2990×2720×3540
XB-30×30 3000 3000 19 140 18.5 4030×3270×3010
XB-35×35 3500 3500 29 230 30 3920×3740×4970
XB-40×40 4000 4000 45 210 37 4520×4320×5570
Lifting type XBT-10×15 1000 1500 1 510 2.2 1130×1130×2070
XBT-15×20 1500 2000 2.9 400 4 1636×1768×2785
XBT-20×20 2000 2000 5.6 312 11 2180×2220×3015
High
efficiency
leaching tank
XF-20×20 2000 2000 7.07 82.5 1.5 2032×2032×3595
XF-25×30 2500 3000 13.5 57.6 2.2 2532×2532×4152
XF-30×30 3000 3000 22.97 50 2.2 3180×3180×4673
XF-35×40 3500 4000 35.6 41 4 3685×3685×5314
XF-40×45 4000 4500 52.78 33.5 4 4185×4185×5814
XF-45×50 4500 5000 74.75 33.5 5.5 4685×4685×6466

3. 2020/4/1 Ore Agitator
https://chinaminingproject.com/Ore-Agitator.html 3/4
XF-50×56 5000 5600 102.1 30.6 5.5 5185×5185×6975
XF-55×60 5500 6000 135.4 24.4 7.5 5670×5670×7569
