1. Novel Method for Rapid
Determination of Thermoformability
Dr. Amit Dharia
Transmit Technology Group, LLC, TX
Dr. Don Hylton
McConnell Co. Inc., GA
2. Outline
® Properties –Thermoforming Process
relationship
® Current test methods
® Description of new test apparatus
/operation/ data acquisition
® Application and data interpretation
® Future plans
® Conclusion
4. Structure - Properties -
Thermoformability
® Rate of change of strength with the
change in strain rate at forming
temperature
® % Crystallinity – Breadth of rubbery
Plateau
® Molecular weight, Molecular weight
distribution, molecular architecture
(branching, crosslinking) – MFR, Melt
Elasticity
5. Other parameters
® Density - % filler, type of fillers, degassing
® Geometry – Thickness, area, multi-layered
structures, adhesion between layers
® Residual stresses between and within in
extruded layer sheet stock
® Thermal diffusivity (Cp, K. Rho)
® Extrusion quality ( gels, unmelts,
thickness variation, grain patterns)
® Color (IR absorption)
6. Current tests
® Low shear melt viscosity (MFR, RMS)
® Hot tensile test (2 in gauge length, 0.2 to 20
ipm, or 0.002 to 0.33 1/s vs. 10/1s for TF
process)
® Melt Tension (Draw Force –Melt strength,
Break Velocity –Draw down)
® Sag Test (sag distance, sag time)
® Hot Creep Test
® DMA (Relaxation time)
7. Major disadvantages of current
methods
® Most tests are conducted in melt or near melt
phase – TF at Tg + 30-40 F
® Specimen do not reflect actual test geometry
(shape, size, thickness clamping mode)
® Do not account for orientation, thermal stresses,
thickness variations
® Isothermal environment, does not account for
transient nature during heating/ cooling steps
® Effects of secondary process parameters can not
be evaluated
® Results cannot be directly used.
8. What we want to know?
® Will this material thermoform?
® Will this new material process the same?
® Will this lot process the same as the last one?
® Why this lot does not process the same?
® How much time is needed to heat the sheet?
® How fast material will heat?
® What is the right forming temperature range?
® Will melt adhesion between layers survive
heating and stretching step?
® Will material discolor, fed or degrade during
heating?
9. What processors want to
know?
® What is the maximum draw down ratio?
® How fast part can be made?
® What is the MD and TD shrinkage?
® Will material tear?
® How much regrind can I use?
® Will grains retain shape and depth?
® Does extruded sheet have gels or
unmelts?
10. What Industry Needs?
® A standard test method which reflects all unit
steps – heating, 3D stretching, forming, and
cooling
® A test equipment which can be precisely
controlled, is rapid, easy to use, provides
repeatable and quantitative information, using the
lease amount of material.
® Easy to use “Thermoformability Index” standard
for comparing, contrasting effects of selected
process/ material variables
12. Typical Data input
® Mode of operation – Plug, vacuum, vacuum +plug
® The heating element distance from the sheet
surface
® The heating element temperature
® The sheet temperature
® Heat Soak time at given temperature
® Plug velocity (2 to 400 mm/second)
® Plug Delay Time
® Plug Temperature
® Cooling time
13. Typical user Input Screen
Sag Distance
Thinning
Strain
hardening
Forming Depth mm
Thermoformability Index=
slope
14. Typical Data Output
® Heating rate (Delta C/ time)
® Sag distance
® Forming force (Stress) vs. forming
distance (strain)
® Forming Force vs. time
® Yield force
® Forming force vs. actual temperature
® Shrinkage
15. Heating rates for various plastic materials
(Heater at 600 C, 3” from upper, 2” from lower)
30
80
130
180
230
0 20 40 60 80
t (seconds)
T(c)
PP
HDPE
HIPS
PVC
ABS
Acetal
PMMA
Nylon
24. Effect of % Regrind on formability TPO
20% regrind / Five Successive Extrusions
0
1
2
3
4
5
6
40 60 80 100 120
Forming Distance, mm
FormingForce,Lbf
1st
2nd
3rd
4th
5th
25. Comparison of Test Methods
Relaxation Time (s) Vs. Force @ 75 mm depth
R2
= 0.9968
0
2
4
6
8
10
12
0 2 4 6 8
Relaxation Time (sec)
FormignFroce(75mm)
PP, 165 C
HDPE,140C
HIPS,160 C
26. Future Plans
® Develop a standard “Thermoformability
Index” similar to Melt Flow Index; which
can be used by industry as specification
to describe thermoformability of material.
® Refine force-vs. displacement data into
stress vs. strain data for each plug
geometry
® Develop an integrated predictive modeling
system like “Moldflow”.
27. Conclusions
® A novel and simple test equipment is
developed which closely reflects all four
unit steps of the typical thermoforming
process and generates quantitative and
repeatable information.
® The test data can be used in raw form to
compare or contrast various materials and
process parameters input or can be
further modeled as a design or predictive
tool.
