This document provides specifications for various polyester printing mesh fabrics, including mesh count, thread diameter, mesh opening size, thickness, open area percentage, theoretical ink deposit volume, weight, and tension range. It contains technical data for over 50 mesh fabrics with counts ranging from 8-165 per inch and thread diameters ranging from 23-300 microns. The document is from a company called Share Group Limited that manufactures and sells polyester printing mesh and filtration products.

1. Polyester Printing Mesh Data
Share Group Limited
Pingqiao Industrial Park
Tiantai, Zhejiang 317203
Phone: 86-576-8950-8685 | Fax: 86-576-8950-8685
sales@sharefilters.com | http://www.sharefilters.com
Mesh count
(per inch/cm)
Type of weave
(tw or pw)
Thread diameter
(microns)
Mesh opening
(microns)
Overall fabric thickness
(microns)
% Open
area
Theoretical
ink deposit (cm3/m2)
Mesh Weight
(gsm)
8/20-300W
10/25-260W
12/30-140W
15/40-200W
18/45-180w
21/54-140W
24/60-120W
PW
PW
PW
PW
PW
PW
PW
300
260
140
200
180
140
120
950
739
688
465
375
333
294
560
498
256
353
330
250
210
57.8
54.6
68.2
48.6
45.5
49.0
49.7
323.5
272.0
174.7
171.5
145.5
122.5
104.3
169
158
55
141
128
96
81
Mesh count
(per inch/cm)
Type of weave
(tw or pw)
Thread diameter
(microns)
Mesh opening
(microns)
Overall fabric thickness
(microns)
% Open
area
Theoretical ink deposit
(cm3/m2)
Tension range
(N/cm)
27/70-120W
30/76-120W
32/83-70W
32/83-100W
36/92-90W
36/92-100W
PW
PW
PW
PW
PW
PW
120
120
70
100
90
100
249
211
240
209
183
174
210
212
117
166
147
162
45.3
40.2
58.7
44.5
43.3
39.1
95.0
82.4
68.7
72.1
64.9
62.6
91
101
37
75
68
84
Mesh count
(per inch/cm)
Type of weave
(tw or pw)
Thread diameter
(microns)
Mesh opening
(microns)
Overall fabric thickness
(microns)
% Open
area
Theoretical ink deposit
(cm3/m2)
Tension range
(N/cm)
40/103-80W
43/110-80W
45/115-80W
48/123-80W
48/123-55W
51/131-70W
54/137-64W
61/156-64W
68/175-55W
68/175-64W
71/180-55W
77/195-48W
PW
PW
PW
PW
PW
PW
PW
PW
PW
PW
PW
PW
80
80
80
80
55
70
64
64
55
64
55
48
166
149
138
122
151
121
115
90
85
78
79
77
133
130
130
130
90
114
103
101
87
98
90
80
44.1
40.8
38.7
34.5
52.8
38.1
38.7
30.1
33.5
28.2
31.5
35.0
58.6
53.0
50.3
44.8
47.5
43.5
39.8
30.4
28.4
27.6
28.4
28.0
60
64
67
72
34
58
51
58
48
65
51
42
Mesh count
(per inch)
Type of weave
(tw or pw)
Thread diameter
(microns)
Mesh opening
(microns)
Overall fabric thickness
(microns)
% Open
area
Theoretical ink deposit
(cm3/m2)
Tension range
(N/cm)
77/195-55W
82/206-48W
90/230-40W
90/230-48W
100/255-40W
PW
PW
PW
PW
PW
55
48
40
48
40
67
68
68
55
57
87
79
65
78
64
26.5
30.8
37.6
24.6
32.5
23.3
24.3
24.4
19.2
21.1
55
44
33
49
37
Thread diameter
(microns)
Mesh opening
(microns)
Overall fabric thickness
(microns)
% Open
area
Theoretical ink deposit
(cm3/m2)
Tension range
(N/cm)
34
40
34
40
34
34
34
34
54
47
45
37
40
31
23
23
55
65
55
64
55
55
55
62
35.2
26.6
29.6
20.1
26.9
19.4
12.1
13.9
19.3
17.3
16.3
13.0
14.3
10.6
6.6
8.6
31
40
34
44
37
39
42
46
Mesh count (per Type of weave (tw
inch)
or pw)
110/280-34W
110/280-40W
120/305-34W
120/305-40W
130/330-34W
140/355-34W
150/380-34W
165/380-34W
PW
PW
PW
PW
PW
PW
PW
PW
Fabric number
The fabric number is composed of:
Mesh-count n 110-80W PW
Thread ∅ dnom 110-80W PW
Fabric colour 110-80W PW
(White = W; yellow = Y)
Type of weave 110-80W PW (Plain Weave = PW)
