Host
Natively, each container runs isolated from the outside world
A bridge network (an internal, virtual switch) is provided with Docker but
does not allow containerized processes to communicate together
without further config (see next slides)
Isolation by design
Container „app‟
Bridge docker0
Container „db‟
Tomcat
(port 8080)
MySQL
(port 3306)
5. 5
Exposing ports allows containers services to talk together through the
bridge network
Dockerfile: add line “EXPOSE <port>” (several ports can be appended)
Command line switch: “docker run ... –expose <port>”
Example for the „app‟ container: “docker run ... –expose 8080”
Exposing ports
Host
Container „app‟
Bridge docker0
Container „db‟
Tomcat
(port 8080)
MySQL
(port 3306)
TCP 3306
exposed
TCP 8080
exposed
« The app is able to talk to its database »
6. 6
Linking enables a client container to get information related to a
resource container (also known as the linked container)
Command line switch: “docker run -link <containername:alias>”
Example on „app‟ container: “docker –run … –link db:dbalias”
Linking containers
Host
Container „app‟
Bridge docker0
Container „db‟
Tomcat
(port 8080)
MySQL
(port 3306)
Env variables
DBALIAS_PORT_3306_TCP=tcp://1.2.3.4:33
06
DBALIAS_PORT_3306_TCP_PROTO=tcp
DBALIAS_PORT_3306_TCP_ADDR=1.2.3.4
DBALIAS_PORT_3306_TCP_PORT=3306
« The app knows where to join its database »
7. 7
Mapping ports enable to publish container‟s ports on “external
interfaces”. Ports may be translated.
Command line switch: “docker run -p <externalport:insideport>”
Example for „app‟ container: “docker –run … –p 80:8080”
Mapping ports
Host
Container „app‟
Bridge docker0
Container „db‟
Tomcat
(port 8080)
MySQL
(port 3306)
« The app is reachable from the external network at port 80 of the host,
while the database container only remains reachable to other containers »
IP_interface
TCP 80 map Tomcat‟s 8080 port
External network
8. 8
These characteristics enables containers:
To either remain fully isolated or talk to all other containers of the same
host having their services exposed
To map one-by-one services on the hosts interface
Hmm… What if I want to isolate groups of containers?
Conclusion
12. 12
SDNs proposes network solutions embracing cloud paradigms
Massively multi-tenant
Thousands tenants, massively scalable
Easy & fast (de)provisioning
Infra as code, API centric
Infrastructure agnostic
L3, does not stick with lower levels (physical designs, vlans & co)
Decouple infrastructure & tenants lifecycles
Cross technology, vendor agnostic
SDNs value proposal
13. 13
Enables to abstract
networking topologies &
services from wiring and
equipments
Centralize network
intelligence
Standardized management
APIs: ex. OpenFlow for both
physical & virtual network
equipments
SDNs overview
(Source Wikipedia)
14. 14
On hosts (hypervisors, Docker hosts…), SDNs mostly rely on:
Allocating network bridges (virtual and internal switches)
Setting ACLs to decide which flow to allow or deny
Connecting these bridges to external world through real host‟s
interfaces
Host perspective
15. 15
Network perspective – Low level isolation
Host #3
SDN
network #1
SDN
network #1
Host #1
SDN
network #1
SDN
network #1
Host #2
SDN
network #1
L2-Network focused
Keep traditional paradigms but use API/centralize intelligence
Requires VLANs, VPLS… to spread same virtual networks accross several hosts
Enforces low-level isolation
Consider API-based network configuration (ie. OpenFlow) to centralize and facilitates
network management, making it more dynamic
VPLS Router
Physical net.
VPLS network
The link tags both
virtual network trafics in
vlans
The VPLS ensure providing L2
networks at all ends – strong req.!
16. 16
Full-mesh, network agnostic and encapsulated approach
Relies on L3 networks and GRE, VXLAN… tunnels for inter-hosts communication (avoid using L2)
Network agnostic, til hosts can route trafic
SDN Routers must route traffic between an inner virtual net and the ext. world
Network perspective – Full mesh
Host #3
Host #1
Host #2
SDN
network #1
SDN
network #1
SDN
network #1
SDN
network #1
SDN
network #1
Router
Physical net.
Flow encapsulation
L3 network
18. 18
How to support several containers related to a same tenant, accross multiple hosts
(or even multiple datacenters or providers), and avoid them to talk to other containers
in the same time ?
Answer to this question enables several usecases
Isolate containers of a same app without having to face limits of a single Docker host
Resilience (ex. spread an app server farm over multiple hosts)
Multi providers (ex. spread containers over several clouds/hosters, overflow mgmt…)
…
Usecases – Back to Docker
Internet
LAN
DMZ
DMZ
DMZ 1
DMZ 2
LAN
Container
Tenant #1
Tenant #3
Tenant #2
19. 19
Host #1 Host #3Host #2
0. From where we start
Container „app‟
Container „db‟
Bridgedocker0
Container „app‟
Container „db‟
Bridgedocker0
Container „app‟
Container „db‟
Container „app‟
Bridgedocker0
Container „app‟
TCP ports of
services running
in containers are
mapped
Get rid of actual Docker bridges implementation !
If not, all containers will talk together across a same host
20. 20
Use OpenVSwitch to create bridges on each host, for each tenant‟s subnet. For
instance, on host #1:
» ovs-vsctl add-br tech-br
» ovs-vsctl add-port tech-br tep0 -- set interface tep0 type=internal
» ifconfig tep0 192.168.1.1 netmask 255.255.255.0
» ovs-vsctl add-br sdn-br0
» ovs-vsctl set bridge sdn-br0 stp_enable=true
1. Create SDN compliant bridges
Host #1
sdn-br0
Host #3
sdn-br0
sdn-br1
Host #2
sdn-br0
sdn-br1
Simplified view. Detailed insight exposed in later slides
Once per host: common plumbing
(detailed slide 24)
For each bridge: create and protect
against ethernet loops using
Spanning Tree Protocol (beware, in
complex/large deployments, it may
consumes a lot of CPU!)
21. 21
2. Link SDN bridges
Host #1
sdn-br0
Host #3
sdn-br0
sdn-br1
Host #2
sdn-br0
sdn-br1
Use OpenVSwitch to link corresponding bridges accross hosts
In this example, we decided to use the full-mesh approach. On host #1:
ovs-vsctl add-port sdn-br0 gre0 --set interface gre0 type=gre options:remote_ip:1.2.3.2
ovs-vsctl add-port sdn-br0 gre1 --set interface gre1 type=gre options:remote_ip:1.2.3.3
1.2.3.1 1.2.3.2 1.2.3.3
Simplified view. Detailed insight exposed in later slides
22. 22
U
3. Instanciate VMs and map them to the bridges
Host #1
sdn-br0
Host #3
sdn-br0
sdn-br1
Host #2
sdn-br0
sdn-br1
Container „app‟
Container „db‟
Container „app‟
Container „db‟
Container „app‟
Container „app‟
Container „db‟
Container „app‟
Container „db‟
Instanciate containers without pre-built interfaces to avoid
plugging containers to native docker0 bridge
Use “docker run … -n=false” switch in “docker run” calls
23. 23
U
4. Connect containers to the appropriate bridge
Host #1
sdn-br0
Host #3
sdn-br0
sdn-br1
Host #2
sdn-br0
sdn-br1
Container „app‟
Container „db‟
Container „app‟
Container „db‟
Container „app‟
Container „app‟
Container „db‟
Container „app‟
Container „db‟
Use pipework.sh from J. Petazzoni to easily plug containers to a chosen bridge
https://github.com/jpetazzo/pipework
Creates network adapter in each containers, allocate them an IP (manually/static vs DHCP), and
plug it to the bridge.
Per container: “pipework bridge_name $container_id container_ip/24”
24. 24
Switch
Insight - Detailed view between two hosts
Previous drawings were simplified to ease overall understanding
Following schema details more deeply what happened inside a single host
Host #1
sdn-br0
Container
Host #2
Container
gre
0
tech-br
tep0
eth0
sdn-br0
Container Container
gre
0
tech-br
tep0
eth0
Switch
ovs-vsctl add-br tech-br
ovs-vsctl add-port tech-br tep0 --
set interface tep0 type=internal
ovs-vsctl add-port sdn-br0 gre0 --set
interface gre0 type=gre
options:remote_ip:1.1.1.1
GRE tunnel in which the traffic really flows
Ethernet link between an adapter and a switch
L2 switch
Network adapter
pipework sdn-br0
$container_id
192.168.0.3/24
eth1 eth1ovs-vsctl add-br sdn-br0eth1 eth1
1.1.1.1/24 2.2.2.2/24
192.168.1.2/24
192.168.0.3/24192.168.0.2/24192.168.0.1/24 192.168.0.4/24
4
7
6
1
2
ifconfig tep0 192.168.1.1 netmask
255.255.255.0
3
L3 routed
network
Docker container
Docker host
pipework sdn-br0
$container_id
192.168.0.4/24
8
192.168.1.1/24
Repeat step #6 to create additional tunnels in order to reach other hosts
ovs-vsctl set bridge sdn-br0
stp_enable=true
5Virtual, direct link established
through the GRE tunnel
25. 25
Bonus: Alternate design - OpenStack Neutron paradigms
Alternate design, based on OpenStack Neutron paradigms – notice that use of VLAN limits to 2048 tenant networks on each hosts
All VMs/containers of a same tenant network are segregated inside a dedicated, local VLAN of a shared unique bridge
Full-mesh of GRE tunnels between all hosts
On each host, local mapping between a local tenant network VLAN and its GRE identifier shared across all hosts
Full story from VM A to B (tenant #1): traffic outgoing A is tagged with VLAN 20 entering br-int, flows to br-tun, is untagged entering GRE tunnel while the
GRE identifier 11111 is set on transmitted packets. At the other end of the GRE tunnel, the traffic having the GRE id 11111 is assigned to VLAN 40, then
flow outside br-tun, to br-int, and is finally untagged before entering B.
Full story from A to C (tenant #1): traffic is tagged with VLAN 20 entering br-int, then flows to br-eth1 which finally untag inbound trafic (or assign a different
VLAN corresponding to the external world)
Switch
Host #1
br-int
br-eth0
eth0
Switch
GRE tunnel in which the traffic really flows
Ethernet link between an adapter and a switch
L2 switch
Network adapter
L3 routed
network
VM or container
Host/server
br-eth1
eth1
br-tun
Tenant #2
Local VLAN 30
Tenant #1
Local VLAN 20
A single bridge is used for all
VMs/containers ; VMs of different
tenants isolated using local VLANs
(not exposed externally !)
A single bridge is used as end-points
for all GRE tunnels used for full-
mesh
One bridge is
created for each
physical interface
Host #2
br-int
br-eth0
eth0
br-tun
Tenant #2
Local VLAN 50
Tenant #1
Local VLAN 40
Switch or VLAN
(not related to
internal VLANs)
gre
0
gre
0
veth
A B
Server
C
Flow rules:
Tenant #1: VLAN 20 GRE ID 11111
Tenant #2: VLAN 30 GRE ID 11112
Single patch link between the two
bridges supporting all traffic from/to full-
mesh
Flow rules:
Tenant #1: VLAN 40 GRE ID 11111
Tenant #2: VLAN 50 GRE ID 11112
27. 27
Use Docker for containers hosting, externalize SDN management
Disable bridges management features in Docker, use OpenVSwitch
Abstract from low level network considerations whenever possible, between
hosts (L2 VLANs for instances): consider tunneling
Get further
Use OpenStack Neutron to centralize & automatize the whole network conf.
You definitively use VLANs ? Consider encapsulating several VLANs in your own
tenant network
Other (dirty) options:
Docker in VMs nesting
Multiple Docker instances on the same host
ebtables/iptables/openvswitch acls on flat network
Take away
