Managing Security At 1M Events a Second using Elasticsearch

1. 0

2. Joe Alex, Senior Big Data Engineer, Verizon
10/06/2015
1
Managing Security @1M Events/Sec

3. Introduction
• Senior Big Data Engineer, Tech. Lead @ Verizon
 Managed Security Services
• Using Elasticsearch since ver 0.19
• Aspiring Data Scientist - Who is not ?
• Loves to work with data at scale
2

4. What we do - Manage Security for our Customers
• Collect Security Logs
• Correlate
• Store
• Index
• Analyze
• Monitor
• Escalate
3

5. Before Elasticsearch
4

6. Before Elasticsearch
• Traditional RDBMS won’t scale for
the billions of logs
 filtered logs > events > incidents >
tickets
• All raw Logs were on disks
• Requests from customers took
days, weeks
• No way to search through billions
of Logs
• Advanced analytics not possible
5
http://www.liftoffit.com

7. After Elasticsearch
• Customers
 have access to all their logs near real-time 
 can search and download their logs through the Portal
 visualize/analyze using Kibana
• Operations
 No more grep through disks 
• Opens up the data for all kind of Analytics and Monitoring
 Anomaly detection
 Real-time alerting
 Advanced monitoring
6

8. How we do it
7

9. What we use and some numbers
• Multiple Elasticsearch Clusters
 Search, Data Visualization, Analytics, Forensics
• Largest cluster has 128 Nodes
 Current load about 20 billion docs per day
 Has around 800 billion docs
• Index heavy use case (vs. search heavy)
• Hadoop for long term storage and analytics
• Spark for real-time analytics and monitoring
• Kafka for Queue
• Flume for collectors
8

10. How we progressed
• Earlier
 Co-located with 28 Hadoop Data nodes
 12 Core, 128GB RAM, 12 X 3TB Disks
 Elasticsearch 0.19
• Later
 Ran 2 Elasticsearch Nodes co-located with Hadoop data nodes
 Effectively 56 Elasticsearch Nodes
• Now
 128 dedicated bare metal boxes for Elasticsearch
 8 core, 64GB RAM, 6 X 1TB Disks
 Elasticsearch 1.5.2 (soon to ver 1.7)
9

11. Know your environment and data
• ENV
 CPU
 Memory
 I/O
 Network
• Elasticsearch typically runs in to Memory issues before CPU
 Get the CPU – RAM – Disk ratios correct for your env.
 Too much disk storage – ES may not utilize
• For data nodes prefer physical boxes
• For disks – SSD, RAID0, JBOD
10

12. Know your environment and data
• Data
 Data ingestion rates
 Type of data
o Our docs were mostly 1.5k – 2k, rarely 5k
o 10% of the customers produced 80% of data
o Variety of data
 Volume
11

13. Storage requirements
• Depends on
 volume
 retention period
 replication factor
 _all
 _source
 analyzed
 doc_values
 _timestamp
12

14. Things you should change
• change default location of data and logs
• change cluster.name
• avoid multicast use unicast
• discover timeouts adjust per your network
• use mapping/templates
 plan your field types number, date, ipv4
• adjust gateway, discovery, threadpool, recovery settings
• adjust throttling settings
• evaluate breakers
• to analyze or not to
13

15. Things you should change
14
• JVM Heap set to 50% of available memory
 Leave 50% for OS, page caching
 Elasticsearch/Java tends to have issues after 31GB heap
• Disable _all, _timestamp, _source if you don't need it
• No swap - mlockall: true, vm.swappiness = 0 or 1
• Tune kernel parameters
 file, network, user, process
 vm.max_map_count = 262144
 /sys/kernel/mm/transparent_hugepage/defrag = never
 10G network tweaks

16. Dedicated Master, Client, Data Nodes
• Master
 Only cluster management (don’t send search or indexing requests)
 3 masters minimum
 Avoid split-brain
• Client
 Coordinators, Aggregation (send all search requests here, will co-ordinate)
 Load balance behind Apache, Nginx, F5 …
• Data nodes
 Indexing, Searches (send all indexing requests direct to data nodes)
• Use Tribe node to search across multiple clusters
15

17. Effects of shards, replication, indexes on Cluster
• Replication factor
 More replicas – searches faster, but more memory pressure
 We had factor 2 initially, later changed to 1
• Shards
 More shards - better indexing rates, but more memory pressure
 We had 2 per index initially, later as per customer 2 – 35 shards
• Index/Shard sizes
• Number of indexes (one big one, monthly, weekly, daily, hourly …)
• Index naming – performance, access control, data retention, shard size
• Know your data and plan shards and replicas
16

18. Field data cache
17
• When you do - sorting, facets/aggregation with high cardinality fields
 All unique values are loaded to memory and held on to
 never goes away
• Risks running out of memory
 indices.breaker.fielddata.limit
 indices.fielddata.cache.size
• Use doc_values - writes to a columnar store side of the inverted index
 lives on disk instead of in heap memory (storage, indexing small effect)
 for not_analyzed fields
 default in Elasticsearch 2.0

19. Indexing
• Use Bulk Indexing
 We use mapreduce, about 60 - 100 reducers do the indexing
 flush size, find your sweet spot (ours is 5000)
 index.refresh_interval: -1
 Transport client - tcp vs http client, tcp slightly faster
 Increase thread pool for bulk and adjust merge speed
• More shards better indexing, but watch cluster
• Watch out for Bulk Rejections and Hotspots
• Index direct to data nodes
• Now es-hadoop available
18

20. Key items for extremely large clusters
19
• Manage shard sizes and counts (including replicas)
• Hotspots - adjust shards per node
• Some Nodes/disks getting full
 adjust disk.watermark low/high settings
• Disk failures (especially when you have multiple disks, striping)
 remove disk from config and restart Node
• Set replication to 0 and adjust throttling for initial Bulk inserts
• Disable allocation for faster restarts
• Adjust throttling settings for recovery and indexing
• Elasticsearch shard is a Lucene index, max docs 2.1 billion

21. Watch out for
20
• Use Aliases from Day 1
• _type
 use generic - minimize dynamic updating of mappings
• Template dir., all files will be picked up
• Scripting and Updates a bit slow, use carefully
• Node failures
• Disk failures
• Bulk Rejections
• Network timeouts
• ttl performance issues

22. Monitor and Stats
21
• Cluster and Node health/stats
• Heap
• Stats: clear view on what is going on in your cluster
 intake volumes, when received at edge, when indexed, index rate
• Lots of APIs available for cluster/node health, stats
• Watch for hotspots – nodes, disks
• Watch for safety trips (from ES 1.4 onwards)
• Nagios, Zabbix, custom
• Housekeeping - Use curator or custom
• Use Marvel, Watcher

23. Get ready for production
• Difficult to recreate production volumes in Dev/QA
• Plan a buffering or queuing mechanism
• Be ready to Re-index
 We had data in HDFS for a year and in ES for 6 months
• Monitor and Alert
 With hundreds of machines/disks, something is bound to fail
• Stats
 Find bottle necks, Project storage/processing needs
• Sharing a single config for same Node type helps
• Use automation as much as possible – Puppet, Ansible
22

24. Security & Access control
• Plan index per customer
• Use Aliases
• Control access via APIs
• Use a reverse proxy Apache, Nginx
 Authentication/Authorization
 Client nodes behind proxy
• Now Shield available
23

25. Tips on Searches
24
• Use Filters, they are cached
• Use match query instead of query_string
• term is not analyzed, match is analyzed
• For large search results – Use Scan search type and Scroll API

26. Thank You
Questions / Comments
@joealex
25
