2. INTRODUCTION
TylerCo, Inc. is a lighting manufacturer that has developed
a totally new approach to lighting rather than just replacing
the light bulb. Through innovative design that uses LED
technology, TylerCo has developed and is currently delivering
a proprietary system that reduces KW energy consumption
by more than 80% over fluorescent lighting without sacrificing
illumination. Our product utilizes LED technology distinctively,
with enough versatility that broad areas of application are possible,
even in areas where lighting of any sort was impossible. It is a
virtually heatless low voltage system that can be used anywhere
lighting is used, or the effects of light are desired, but eliminates
the toxic waste associated with other types of lighting.
3. TylerCo, Inc. has, by proprietary means, encapsulated
the light guide allowing this light source to become
environmentally usable. It is now waterproof, dustproof,
and we found that because the LEDs generate so little
heat, the encapsulation absorbed the heat - so there is
virtually no heat coming from our light panels.
TYLERCO LIGHT SOURCE
FEATURES AND BENEFIT
·EVEN LIGHTING
·EASY INSTALLATION
·ENERGY SAVING
·EXTENDED LIFE
·HUMIDITY-MOISTURE RESISTANT
·MINIMAL HEAT DISCHARGE
·SHATTERPROOF DESIGN
·INSTANT START
·NO RF INTERFERENCE
·NO MERCURY
·EXTREME EFFICIENCY: OVER 80% MORE EFFICIENT
THAN TRADITIONAL FLUORESCENT
PRODUCT DESCRIPTION
4. TylerCo, Inc.
17831 Sky Park Circle
Suite A
Irvine, 92614CA
Tel: 877.723.2900
www.tylercoinc.com
Patent#
8,092,034 B2US
SignliteTM
Voltage: 12 VDC
Color: White
SIGNlite
Warranted for 20 years
Reduces energy by 91%
5. Inside menu board reduced from 352 watts to
28.6 watts of power, saving 323.3 watts.
Outside menu sign reduced from 440 watts
to 36.4 watts of power, saving 403.6 watts
Outside menu sign reduced
from 264 watts to
23.3 watts of power,
saving 240.7 watts
6. Paul Delaney
Senior Engineer
1515 Walnut Grove Avenue Rosemead, CA 91770
December 8, 2015
SUBJECT:
PURPOSE
BACKGROUND
Measure energy savings for Jack in the Box by retrofitting
menu board signs.
The purpose of this report is to collect the data on the total electricity demand savings by
retrofitting Jack in the Box menu board signs with TylerCo’s Signlite.
On November 12, 2015 TylerCo, Inc. retrofitted three menu boards at the Jack in the Box located
at 2291 W Esplanade Ave., San Jacinto, CA 92582. The total electricity demand savings for all
three back-lit signs is calculated = 968 watts or almost 1 kW. We will need annual operating hours
values for each sign to estimate the annual energy savings. The break down per sign is as
follows:
Inside Menu Sign
Present lighting
4 fluorescent T12 lamps at 80 watts each.
Sub-total: 320 watts + 32 watts (Ballast efficiency)
Total: 352 watts
Retrofit with SIGNlite
7 LED panels, 18” x 24”, at 3.72 watts each.
Sub-total: 26.04 watts + 2.6 watts (LED Driver efficiency)
Total: 28.64 watts
Total savings:
323.36 watts
91%
7. Paul Delaney
Senior Engineer
1515 Walnut Grove Avenue Rosemead, CA 91770
December 8, 2015
BACKGROUND
Outside Main Menu Sign
Present lighting
4 fluorescent T12 lamps at 100 watts each.
Sub-total: 400 watts + 40 watts (Ballast efficiency)
Total: 440 watts
Retrofit with SIGNlite
4 LED panels, 15” x 46”, at 7.32 watts each
1 LED panels, 18” x 22”, at 3.84 watts each
Sub-total: 33.12 watts + 3.3 watts (LED Driver efficiency)
Total: 36.43 watts
Total savings:
403.57 watts
91%
Outside Greeting Menu Sign
Present lighting
4 fluorescent T12 lamps at 60 watts each.
Sub-total: 240 watts + 24 watts (Ballast efficiency)
Total: 264 watts
Retrofit with SIGNlite
3 LED panels, 16” x 44”, at 7.08 watts each
Sub-total: 21.24 watts + 2.1 watts (LED Driver efficiency)
Total: 23.34 watts
Total savings:
240.66 watts
91%
Let me know if you have any questions.
