This document provides an agenda and details for a meeting to review door, window, and cabinet hardware for a project. The agenda includes reviewing door types and functions, window hardware, cabinet hardware, and miscellaneous hardware. It defines common door functions and finishes. It also lists additional resources for different types of hardware and provides a hardware schedule with locations, sizes, materials, finishes, and product details.

1. Project Name
PROJECT ADDRESS
STREET
CITY, STATE, ZIP
projectwebsiteportal.com LOGO
Hardware + Fittings

2. LOGO
Agenda
MEETING DATE
1.0 Door Types, Function, + Hardware Review
Sliding, swinging, pocket, concealed. We’ll be reviewing: hinges, handles, functions, locks, finishes and more than you ever wanted to know
about door hardware!
2.0 Window Hardware
Operators, locks, finishes.
3.0 Cabinetry Hardware
Pulls, slides, specialty hardware.
4.0 Miscellaneous Hardware
Kitchen accessories and anything else that doesn’t neatly fit into the above.

3. LOGO
DOOR HARDWARE
A few terms you’ll see listed on the hardware schedule, defined for you.
Door Functions
Passage Latchbolt is retracted by knob/lever from either side at all times. Inside room is always free for immediate egress.
Privacy Latchbolt retracted by knob/lever from either side unless outside is locked by inside thumbturn. Turning inside knob/lever unlocks outside
knob/lever. To unlock from outside engage emergency unlock feature (button or access hole. Inside room is always free for immediate egress.
Typically used: baths or bedrooms where privacy is desired.
Entry Latchbolt retracted by knob/lever from either side unless outside is made inoperative by key outside or by turning inside thumbturn. When outside
is locked, latchbolt is retracted by key outside or by knob/lever inside. Outside knob/lever remains locked until thumbturn is returned to vertical or
unlocked by key. Auxillary latch deadlocks latchbolt when door is closed. Inside lever is always free for immediate egress.
Dummy Full dummy - full-size door knobs or handlesets that have no mechanical latch mechanism. They are flush mounted and require no mortise, or
hole, through the face of the door. Full dummy sets are used in certain decorative applications such as double doors, closet, pantry and utility
space doors. Half dummy - same as the above, without any handles on the inside face of the door.
Storage Latchbolt retracted by key outside or by knob/lever inside. Outside knob/lever is always inoperative. Auxiliary latch deadlocks latchbolt when door
is closed. Inside lever is always free for immediate egress. Single key deadlock is a variant of this: no operation inside, deadbolt by key outside.

4. LOGO
Concept
Describe the idea or list keywords informing the design +/or
hardware selected. Completely optional.
OVERVIEW

5. LOGO
Finishes
Here’s a good place to discuss the reasoning behind the
finishes you’ve selected (brushed, oil-rubbed, how it will
weather, any cost implications, etc.)
DETAILS

6. LOGO
Additional Resources
Kitchen Fittings HAFELE.COM Description as necessary.
Door Hardware FSB.COM Description as necessary.
Window Hardware MARVINWINDOWS.COM Description as necessary.
Cabinetry Hardware HARDWAREHUT.COM Description as necessary.
RESEARCH

7. LOGO
LOCATION:
SIZE:
MATERIAL:
FINISH.:
TYPE
HANDLE + ROSE
ALL SWINGING
5 3/16”
304 S/STL.
SATIN
1173-6204
FSB N.A.
H1

8. LOGO
LOCATION:
SIZE:
MATERIAL:
FINISH.:
TYPE
SLIDING DOOR PULL
HALLWAYS
4 11/16” X 2 3/16”
S/STL. 304
BRUSHED
DSI-4251-38
SUGATSUNE
B1
