This presentation vividly describes what is going on in the IT industry with the advent of cloud technology, focusing in Google App Engine. Then reviews competitors’ moves both in terms of background technology and the service capitalization.
It was revealed that major Japanese companies such as Fujitsu and NTT Data are introducing Microsoft Azure in their data centers, but Oracle and IBM are the technically strong chasers. So far there are very few moves
for Japanese IT companies to implement their own cloud products.
IBM's zEnterprise product line has potential to replace and wipe out container-based data centers, but their pricing policy unknown. Oracle's next hardware strategy unknown.
In Japan, tailoring open-source softwares auch as Cassandra and Hadoop found at newly rising companies, IIJ, and Rakuten.
22. 22
共通仕様
Bluetooth Core Specification Supplement (CSS) v5 に準拠
https://www.bluetooth.org/ja-jp/specification/adopted-specifications
下記のPDU(Protocol Data Unit)データタイプが必須
・The Complete List of 16-bit Service UUIDs
Eddystone Service UUID = 0xFEAA
「iOSのバックグラウンドスキャンを許可するために含める」との記述あり
・The Service Data
上記UUIDに続く各種データフレーム
23. 23
実例
① 02 01 06
② 03 03 AAFE
③ 13 16 AAFE10D802676F6F2E676C2F52304B533731
0201060303AAFE1316AAFE10D802676F6F2E676C2F52304B533731…
データタイプごとに分解すると
データバイト長
データタイプ
あるEddystone-URLのデータ(Hex)
データタイプの定義
01:Flags
03:Complete List of 16-bit Service Class UUIDs
16:Service Data
EddystoneのService UUID
各フレームフォーマットに則ったデータ
24. 24
iBeaconの場合
① 02 01 06
② 1A FF 4C000215
B9407F30F5F8466EAFF925556B57FE6D
FBA9
08F9
B6
0201061AFF4C000215B9407F30F5F8466EAFF925556B57FE6DFBA9
08F9B6…
あるiBeaconのデータ(Hex)
データタイプの定義
01:Flags
FF:Manufacturer Specific Data
Appleの独自仕様による
iBeaconのデータフレーム
25. 25
Eddystone-UID
Byte offset Field Description
0 Frame Type Value = 0x00
1 Ranging Data Calibrated Tx power at 0 m
2 - 11 NID[0] - [9] 10-byte Namespace
12 - 17 BID[0] - [5] 6-byte Instance
18 RFU Reserved for future use, must be0x00
19 RFU Reserved for future use, must be0x00
データフレーム
Tx power:0m時の送信出力( iBeaconのRSSI)
Namespace:名前空間、集合体のID( iBeaconのUUID)
Instance:実体のID( iBeaconのMajor, Minor)
26. 26
Eddystone-URL
Byte offset Field Description
0 Frame Type Value = 0x10
1 TX Power Calibrated Tx power at 0 m
2 URL Scheme Encoded Scheme Prefix
3+ Encoded URL Length 0-17
データフレーム
Decimal Hex Expansion
0 0x00 http://www.
1 0x01 https://www.
2 0x02 http://
3 0x03 https://
URL Scheme
URLがフレーム長に納まらない場合、
goo.gl等の短縮URLサービスを使用する
27. 27
Eddystone-TLM
データフレーム
Byte offset Field Description
0 Frame Type Value = 0x20
1 Version TLM version, value = 0x00
2 - 3 VBATT[0] - [1] Battery voltage, 1 mV/bit
4 - 5 TEMP[0] - [1] Beacon temperature
6 - 9 ADV_CNT[0] - [3] Advertising PDU count
10 - 13 SEC_CNT[0] - [3] Time since power-on or reboot
このフレームのみ、Versionが存在する
改変の可能性が高い?
42. 42
Proximity Beacon API
・REST APIで提供
API例:
・登録できるビーコンのタイプは3種
Eddystone, iBeacon, AltBeacon
※ただし、Nearbyで取得できるのはEddystoneのみ
・APIの認証(Google Developerアカウント)に
紐付いてビーコンが登録される
GET https://proximitybeacon.googleapis.com/v1beta1/beacons
43. 43
Proximity Beacon API
・登録情報(ビーコンリソース定義)
Field name Description
beaconName ビーコンの名称
advertisedId ビーコンタイプ(Eddystone, iBeacon,..) & ID
status 有効、無効、廃止
placeId Google Places API の Place ID
latLng 緯度経度
indoorLevel Google Maps API 建物の階
expectedStability 固定、稀に移動、頻繁に移動、常に移動
description 最大140文字のフリーテキスト
properties ビーコンデバイスの情報(key-value)
