The document contains a G-code program for milling several pockets of increasing depth into a material using an end mill cutter in a repeating pattern across an area. The program runs the cutter at varying feed rates and depths in a zigzag pattern to cut successive layers at depths of 0.25mm, 0.5mm, 0.75mm, 1mm, 1.25mm, 1.5mm, and 1.75mm.
CNC milling is developed a new technology for the mechanical engineers with the highly accuracy.The maximum accuracy of this CNC machine is up to 0.01 mm or 10 microns.
The fanuc system is very easy as compare to other controls but i can say that if you will learn the fanuc system,it helps you to very easy as compare to other systems.
In this ppt. all the operations and programmings of CnC milling are available.
Some programming are very important just like how to make :
1. PcD
2. Ellipse
3.Origin at angle
4.Shift the origin
5.Facing,peck drilling,boring,threading etc.
