Effective Lessons for Building SOA from Amazon, Google and Lucidchart
- 1. Effective SOA Lessons from Amazon, Google, and Lucidchart By Derrick Isaacson
- 2. Can I get that without the bacon? Said no one ever http://www.food.com/photo-finder/all/bacon?photog=1072593
- 5. Simplicity of Single Component Services • I can’t remember if that getter function takes 100ns or 100ms. - Said no engineer ever • Should I try to model this server request as a “remote procedure call”? • 6 orders of magnitude difference! • My front-side bus fails for only 1 second every 17 minutes! - Said no engineer ever • 99.9% availability • Our internet only supports .NET. - Said no engineer ever • Do we need an SDK?
- 6. "A distributed system is at best a necessary evil, evil because of the extra complexity... An application is rarely, if ever, intrinsically distributed. Distribution is just the lesser of the many evils, or perhaps better put, a sensible engineering decision given the trade-offs involved." -David Cheriton, Distributed Systems Lecture Notes, ch. 1
- 7. Distributed System Architectures Does it have to be “Service-oriented”?
- 10. Distributed File System mount -t nfs -o proto=tcp,port=2049 nfs-server:/ /mnt
- 11. Distributed Data Stores • Replated MySQL • Mongo • S3 • RDS • BigTable • Cassandra …
- 12. P2P
- 13. Streaming Media
- 16. GET /profiles/123 GET /users/123 Calculate something GET /users/123/permissions If user can’t view profile send 403 POST /eventFeed {new profile view} GET /users/123/friends GET /bookmarks?userId=123 GET /catalog/books?ids=1,3,10 Calculate something else GET /bookmarks/trending Send response
- 17. Lucidchart.com by Status Code 96.5% 2xx or 3xx
- 19. What Happened?!? I though SOA was supposed to make my app better!
- 20. Simple SOA Availability <98.7% 99.5% 99.8% 99.6% .995 * .998 * .998 * .996 = 0.987
- 21. A distributed system is at best a necessary evil <98.7% 99.5% 99.8% 99.6%
- 24. The CAP Theorem1 • Safety – nothing bad ever happens • Liveness – good things happen • Unreliability – network dis-connectivity, crash failures, message loss, Byzantine failures, slowdown, etc. • Consistency – every response sent to a client is correct • Availability – every request gets a response • Partition tolerance – operating in the face of arbitrary failures
- 25. Consistency: Nothing Bad Happens
- 27. Assumption: Failures Happen Availability Consistency
- 28. ResponseHandler<User> handler = new ResponseHandler<User>() { public User handleResponse( final HttpResponse response) { int status = response.getStatusLine().getStatusCode(); if (status >= 200 && status < 300) { HttpEntity entity = response.getEntity(); return entity != null ? Parser.parse(entity) : null; } else { … } } }; HttpGet userGet = new HttpGet("http://example.com/users/123"); User user = httpclient.execute(userGet, handler); https://hc.apache.org/httpcomponents-client-4.3.x/examples.html Works great to calculate a user!
- 29. GET /profiles/123 GET /users/123 Calculate something GET /users/123/permissions If user can’t view profile send 403 POST /eventFeed {new profile view} GET /users/123/friends GET /bookmarks?userId=123 GET /catalog/books?ids=1,3,10 Calculate something else GET /bookmarks/trending Send response
- 30. Best Effort Availability - Euphemism for not always available
- 31. Best Effort Consistency - Euphemism for not always consistent
- 32. Google File System: relaxed consistency model Throughput Latency
- 35. “WOW I really regret sacrificing consistency for availability” -said no amazon ever That’s $74 Billion
- 36. Hang Consistency! Add • Caching • Timeouts • Retries • Guessing • Anything!
- 38. Tip 2: HTTP Caching as Fallback
- 39. Tip 3: Retries • Exponential backoffs & max retries
- 40. Tip 3: HTTP Caching Technologies • Apache HttpComponents – HttpClient Cache • Ehcache • Redis • Memcached • CloudFront • Akamai • Berkeley DB • AWS SNS (for notifying caches components of changes)
- 41. Segmenting Consistency and Availability 1. Data Partitioning Shopping Cart Warehouse Inventory DB
- 43. Segmenting 3. Functional partitioning User Service, Document Snapshots Document Service
- 45. http://www.slashgear.com/google-data-center-hd-photos-hit-where-the-internet-lives-gallery-17252451/
- 46. Timeouts
- 47. Stop Guessing and Just Calculate It • Max I/O wait time = # of threads * (CONNECT_TIMEOUT + READ_TIMEOUT) • 9 front end servers received 1900 requests in 60 seconds and 300 for Flickr resources (16%). • 35 requests per server per minute • Max 100 threads, => 6,000 thread seconds in one minute • Goal: ensure < 10% of thread seconds spent blocked on Flickr I/O • 600 < 35 requests * (CONNECT_TIMEOUT + READ_TIMEOUT) • CONNECT_TIMEOUT + READ_TIMEOUT < 17 seconds TCP Connect Send Request Block on socket read Read response CONNECT_TIMEOU T READ_TIMEOUT
- 48. Best Effort Consistency System 99.9% 99.5% 99.8% 99.6%
- 49. Wow, my pizza has too much cheese and toppings Said no one ever http://upload.wikimedia.org/wikipedia/commons/6/60/Pizza_Hut_Meat_Lover's_pizza_3.JPG
- 50. “WOW My system has too much caching, timeouts, and availability.” -said no one ever
- 52. References 1. Perspectives on the CAP Theorem 2. Bacon Ipsum 3. Brewer’s Conjecture and the Feasibility of Consistent, Available, Partition-Tolerant Web 4. The Google File System 5. Big Table 6. Amazon Architecture References 7. Apache HttpComponents 8. Apache HttpClient Cache 9. Ehcache
Editor's Notes
- Effective SOA: Lessons from Amazon, Google, and LucidchartIt has been observed that "A distributed system is at best a necessary evil, evil because of the extra complexity." Multiple nodes computing on inconsistent state with regular communication failures present entirely different challenges than those computer science students face in the classroom writing DFS algorithms. The past 30 years have seen some interesting theories and architectures to deal with these complexities in what we now call "cloud computing". Some researchers worked on "distributed memory" and others built "remote procedure calls". More commercially successful architectures of late have popularized ideas like the CAP theorem, distributed caches, and REST.Using examples from companies like Amazon and Google this presentation walks through some practical tips to evolve your service-oriented architecture. Google's Chubby service demonstrates how you can take advantage of CAP's "best effort availability" options and Amazon's "best effort consistency" services show the other end of the spectrum. Practical lessons learned from Lucidchart's forays into SOA share insight through quantitative analyses on how to make your system highly available.Bio:Derrick Isaacson is the Director of Engineering for Lucid Software Inc (lucidchart.com). He has a BS in EE from BYU and an MS in CS from Stanford. He's developed big services at Amazon, web platforms for Microsoft, and graphical apps at Lucidchart. Derrick has two patent applications at Microsoft and Domo. For fun he cycles, backpacks, and takes his son out in their truck.
- Multiple nodes computing on inconsistent state with regular communication failures present entirely different challenges than those computer science students face in the classroom writing DFS algorithms.
- Idea:Nothing’s more familiar to programmers than reading from and writing to memory? We access variables all day long. Why not make distributed state access look like simple memory access? We can use modern operating systems’ support for virtual memory to “swap in” memory that is located on another machine.Problem:How often do you go to access a variable and can’t because a section of memory is “down”?How do you provide a mutex to parallel threads of execution?How can the distributed memory layer be efficient when it has no knowledge of the application?
- Idea: Next to memory access, nothing’s more familiar to programmers than functional calls. Can we make distributed state transfer look like a simple procedure call? SOAP!Problems:How often do you retry a method call because the JVM failed to invoke it the first time?Why does incrementing a value take 100 milliseconds?Why does your internet only support .NET and PHP (stub compiler/SDK)?
- Idea:Easy network file sharing.NFS, AFS, GFSWorks great for files.
- Idea:Easy network file sharing.NFS, AFS, GFSWorks great for files.
- Idea:How could you steal bandwidth from universities and avoid infringement lawsuits at the same time?Problems:Mooching resources is a great business model but a terrible architecture if that’s not what you’re going for.
- Idea:I have so much state I don’t want to transfer it all in a single response.
- What’s the availability of the overall system if a single response for service A is calculated by making 4 total requests to services B, C, and D?If the average availabilities of those 3 components are as given, and the random values are modeled as IID, what is the maximum percentage of requests is service A able to calculate correctly?.995 * .998 * .998 * .996 = 0.987IID is a bad assumption for nearly any distributed system, but it illustrates the effective of naively distributing computation.When crash failures originating at service A are included, the total availability is < 98.7%!That’s an average of 19 minutes of downtime per day!
- What’s the availability of the overall system if a single response for service A is calculated by making 4 total requests to services B, C, and D?If the average availabilities of those 3 components are as given, and the random values are modeled as IID, what is the maximum percentage of requests is service A able to calculate correctly?.995 * .998 * .998 * .996 = 0.987IID is a bad assumption for nearly any distributed system, but it illustrates the effective of naively distributing computation.When crash failures originating at service A are included, the total availability is < 98.7%!That’s an average of 19 minutes of downtime per day!
- Conjecture made by UC Berkely computer scientist in 2000Gilbert & Lynch published a formal proof
- Conjecture made by UC Berkely computer scientist in 2000Gilbert & Lynch published a formal proof
- We want the user to 1) get a response (available) and 2) have it be consistent with the view of other nodes.From that end user definition, a slow, error status, or non-existent response are all “incorrect”.
- “In order to model partition tolerance, the networkwill be allowed to lose arbitrarily many messages sent from one node toanother.” – Gilbert & Lynchhttp://lpd.epfl.ch/sgilbert/pubs/BrewersConjecture-SigAct.pdfIt becomes a fundamental tradeoff between availability and consistency.
- It drops below the SLA for a consistent, available response perhaps 10 of every 1000 requests.
- It turns out the usual approach to implementing a computation like this errs on the side of consistency. If a single service request fails, this calculation hangs or returns an error to the user.
- Web crawler, Big Table“our access patterns are highly stylized”“GFS has a relaxed consistency model that supports our highly distributed applications well but remains relatively simple and efficient to implement.”“Record append’s append-at-least-once semantics preserves each writer’s output. Readers deal with the occasional padding and duplicates as follows. Each record prepared by the writer contains extra information like checksums so that its validity can be verified. A reader can identify and discard extra padding and record fragments using the checksums. If it cannot tolerate the occasional duplicates (e.g., if they would trigger non-idempotent operations), it can filter them out using unique identifiers in the records, which are often needed anyway to name corresponding application entities such as web documents.”
- “For the checkout process you always want to honor requests to add items to a shopping cart because it's revenue producing. In this case you choose high availability. Errors are hidden from the customer and sorted out later.”
- Wow, that guy must be an engineer – said no one ever
- The Amazon Dynamo and Yahoo PNUTS data stores support high read availability while limiting write availability in the face of partitions. For example, Dynamo has a configurable number of replicas on which the data must be stored before a write is confirmed to the client.
- Network partitions are less frequent at the leaves of a geographically hierarchical system.
- The CAP theorem appears to have implications for scalability.“Intuitively, we think of a system a scalable if it can grow efficiently, using new resources efficiently to handle more load. In order to efficiently use new resources, there must be coordination among those resources;” – Gilbert & Lynch
- What’s the availability of the overall system if a single response for service A is calculated by making 4 total requests to services B, C, and D?If the average availabilities of those 3 components are as given, and the random values are modeled as IID, what is the maximum percentage of requests is service A able to calculate correctly?.995 * .998 * .998 * .996 = 0.987IID is a bad assumption for nearly any distributed system, but it illustrates the effective of naively distributing computation.When crash failures originating at service A are included, the total availability is < 98.7%!That’s an average of 19 minutes of downtime per day!
