The DRAGONFLY is a hands-free internal glass cleaning system that allows cleaning windows from the ground using a telescopic pole. It has a pump and water reservoir in a backpack and cleans windows up to 10 meters high. It saves time over traditional cleaning methods by eliminating the need for ladders or scaffolding. It efficiently cleans windows, mirrors and other surfaces without chemicals through a microfiber pad attached to the end of an adjustable pole.

1. The STREAMLINE® DRAGONFLY® is the perfect answer
to internal glass cleaning where the use of a ladder
or other reach equipment is normally required, as
it allows you to clean windows at height with your
feet on the ground. With a simple pump system and
reservoir filled with de-ionised water or a glass cleaner
in a backpack and a microfibre pad on a swivel mop
plate attached to a telescopic pole the DRAGONFLY®
simplifies internal window cleaning forever.
Areas of use include car showrooms, stair wells and
atriums in office blocks, schools, colleges, hotels,
airports, shopping centres the opportunities are
endless! Saving time, saving money...
The DRAGONFLY®4 internal window and glass
cleaning kit brings you the latest innovation from
the STREAMLINE® range of high reach cleaning
equipment. It is the simplest, safest and most efficient
way to clean internal windows at height – reaching up
to heights beyond 10 meters!
The DRAGONFLY®4 does not rely on detergents or
chemicals and yet cleans a multitude of surfaces,
including windows, mirrors, cladding and stainless
steel surfaces to a sparkling and spot-free finish. With
a compact battery and pump combination mounted
in the comfortable backpack, controlled by a simple
switch on one of the lightweight XR™ poles the
DRAGONFLY®4 has proven to clean at height up to
three times faster than traditional methods … and
safely from the ground.
• Environmentally friendly – no chemicals required
• Rechargeable battery – ensures the task can be
completed without the worry of having to have
spare batteries
• Compatible with the XR™ telescopic poles – so
there are no modular pole sections lying around
• Can be fitted to any of the pole sizes from the XR™
range – reaching beyond 10 meters
Call +44 (0)1626 830830 Email sales@varitechsystems.co.uk www.varitechsystems.co.uk
NEWDESIGN
The DRAGONFLY® can be fitted to any
one of the STREAMLINE® telescopic
poles and extra pole kits can be
purchased to allow the DRAGONFLY® to
be connected to various pole sizes.
SPECIFICATION SHEET
DRAGONFLY4-001
DRAGONFLY ®
4

2. Varitech Systems Ltd Hamilton House, 8 Fairfax Road, Heathfield Industrial Estate, Newton Abbot, Devon, TQ12 6UD, UK
Call +44 (0)1626 830830 Email sales@varitechsystems.co.uk www.varitechsystems.co.uk
Dry Weight 2.5kg
Wet Weight 3.0kg
Battery Type NiMH 12V
Battery Life Time 20 Hours
Battery Charge Time 10 Hours with a 240V Charger
OPERATING SPECIFICATIONS
• 500ml reservoir in a backpack
• Secured battery and pump box, with an
illuminating on/off switch
• 240-volt battery charger
• Padded backpack to contain DRAGONFLY®
• Remote control ‘press-switch’ assembly
• Mop plate head assembly with fine spray tip
• 2x microfibre scrub pads
• 2x microfibre polishing pads
• An enclosure for safe storage of the backpack kit
when not in use.
WHAT DOES THE DRAGONFLY®4 INCLUDE?
DRAGONFLY®4 TELESCOPIC POLES
DRAGONFLY ®
4
DRAGON-XR70-405200 5.5mtr/20ft extended length 1.09kg
DRAGON-XR70-406000 6.4mtr/23ft extended length 1.22kg
DRAGON-XR70-507300 7.6mtr/27ft extended length 1.61kg
DRAGON-XR70-608500 8.5mtr/31ft extended length 2.03kg
DRAGON-XR70-709700 9.7mtr/35ft extended length 2.45kg
DRAGON-XR70-810800 10.8mtr/38ft extended length 2.62kg
DRAGON-XR70-713200 13.2mtr/46ft extended length 2.84kg
DRAGON-XR70-814800 14.8mtr/52ft extended length 3.32kg
DRAGON-XR70-816500 16.5mtr/57ft extended length 3.61kg
OPERATING SPECIFICATIONS
XR70™ Carbon Fibre Telescopic Pole complete with
internal coiling hose tubing*, non-drip spray nozzle, and
adjustable angle adapter. *please note, poles longer than 8.5mtr/31ft have external tubing
1 Litre
