Docker now provides several building blocks, combining engine, clustering, and componentization, while the new networking and service features enable many new usecases such as multi-tenancy. In this session, you will first discover the new experimental networking and service features expected soon, and then drift rapidly to software architecture, explaining how a complete Docker stack unleashes microservices paradigms. The first part of the talk will introduce what SDNs and service registries are to the audience and will cover corresponding network & service experimental features of docker accordingly, with a technical focus. For instance, it explains how to create an overlay network of top of a swarm cluster or how to publish services. The second part of the talk moves from infrastructure to application concerns, explaining that application architecture paradigms are shifting. In particular, we discuss the growing porosity of companies’s IS (especially due to massive use of cloud services) drifting security boundaries from the global IS perimeter, to the application shape. We also remind that traditional SOA patterns leveraging on buses (ie. ESBs & ETLs) are being replaced by microservices promoting more direct, full-mesh, interactions. To get the picture really complete, we’ll also rapidely remind other trends and shifts which are already covered by other docker components: scalability & resiliency to be supported by the apps themselves, fine-grained applications, or even infrastructure commoditization… Most of all, the last part depicts a concrete, state-of-the-art application, applying all the properties discussed previously, and leveraging on a multi-tenant docker full stack using new networking and services features, in addition to traditional swarm, compose, and engine components. And just because we say it doesn’t mean it’s true, we’ll be happy to demonstrate this live !

1. The missing piece: when Docker networking
unleashes software architecture 2.0
A. Blind
DevOps coach
Societe Generale
@adrienblind
L. Grangeau
Solutions architect
Finaxys
@laurentgrangeau

2. Agenda
2 - Starters
Docker networking
& volume features
discovered
4 - Dessert
Taste-an-app
1 - Apetizer
Back on current
Docker paradigms
3 - Main course
Application
architecture shifts

3. Back on current
docker paradigms

4. Back on Docker paradigms
‘’A universal, self-sufficient and standard artifact embedding an app
module, and its subsequent infrastructure configuration’’
Immutable
Versionned
Light
Portable
Disposable
Programatic
Social
Incremental
 It’s mainly focused on enclosing computing
capabilities: what about storage ? Network ?

5. Networking & volume
features discovered

6. Docker networking

7. Docker networking

8. Docker networking
The Container Network Model (CNM)
A docker container
Endpoint
A docker container
Endpoint
A docker container
EndpointEndpoint
Network sandbox Network sandbox Network sandbox
Front network Back network

9. Docker networking
$ docker network create mynetwork
5000dec7c180a63d87031de7e6bfcf2b25cf1e5daef6338f16fbd4
451210a938
$ docker network create –d overlay multihostnetwork
e6537b859359843bc02392245ab226070f79dbf87be2d492969c84
3f89fb6de6

10. Docker networking
$ docker network inspect mynetwork
[
{
"Name": "mynetwork",
"Id":
"5000dec7c180a63d87031de7e6bfcf2b25cf1e5daef6338f16fbd4451
210a938",
"Scope": "local",
"Driver": "bridge",
"IPAM": {
"Driver": "default",
"Config": [
{}
]
},
"Containers": {},
"Options": {}
}
]

11. Docker networking
Host Host Host Host
SDNs
SDN 1
SDN 2
SDN 3

12. Docker networking

13. Docker networking
Docker Compose evolved to embrace
new networking features
$ docker-compose --x-networking
--x-network-driver=overlay up
$ docker-compose up

14. Docker volumes

15. Docker volumes
Host file system Host file system
‘’Former data management locked in a host’’

16. Docker volumes
Host file system
Container
Volume
‘’Containers mount a volume which may be
backed externaly’’

17. Docker volumes
$ docker volume create –d volplugin --name pool/name
Cf872ca21d27843f6b6319ac1a34390dd38d94ed4649cd985456d5
23fb05d4cc
$ docker run –d –p 8080:8080 –v
pool/name:/var/jenkins_home jenkins
96aec6f4e45e050dfb4f75a1009e7f105bced5b406752e62d47061
5d07348b07

18. Docker volumes
$ docker volume ls
DRIVER VOLUME NAME
local cf872ca21d27843f6b6319ac1a34390…
local f19f50251f48c64a6b33a5c637c2330…
$ docker volume inspect
cf872ca21d27843f6b6319ac1a34390dd38d94…
[
{
"Name": "cf872ca21d27843f6b6319ac1a34390dd38d94…",
"Driver": "local",
"Mountpoint":
"/mnt/sda1/var/lib/docker/volumes/[…]/_data"
}
]

19. Take-away

20. Application
Compute
(Run containers)
Docker building blocks

21. Application
Compute
(Run containers)
Storage
(Volumes)
‘’Immutability of containers, resiliency & scalability
led to data externalization in separate objects’’

22. ‘’Fine-granularity of containers led to closely
interconnect them’’
Application
Compute
(Run containers)
Storage
(Volumes)
Transport
(Network)

23. ‘’The whole topology can now
be described’’
Application
Compute
(Run containers)
Storage
(Volumes)
Transport
(Network)
Topology
(Compose)

24. ‘’Docker finally shifted to
object-oriented infra. architecture’’
Application
Compute
(Run containers)
Storage
(Volumes)
Transport
(Network)
Topology
(Compose)
CaaS platform (Swarm, Machine...)

25. Application
architecture shifts

26. Security paradigms shifts

27. Security paradigms shifts
Your IT opens up
• Externalization (housing, hosting)
• Cloud (IaaS/PaaS/SaaS)
Open up your IS
• B2B, services exposition
• Multi tenancy
More & more breaches appears in your Great Wall of China!

28. Security paradigms shifts
The necessary porosity of your IS requires to stick
security closer to each application: sandbox your apps
and expose protected interfaces!
Network is part of application topology
Security is an app topic, not just infra. concern
Onboard security in feature teamSecDevOps

29. Network paradigms shifts
VM
VM
VM
VM
VM
VM
VM
VM
VM
Internet
Internet
DMZ
Physical overview
Logical overview
Tenant
#1
Tenant
#2
LAN
LAN
DMZ1
DMZ2
Traditional networks
relies a lot on low layers
(L2, etc.)
Application topologies
are quite different from
physical ones

30. Network paradigms shifts
SDNs propose network solutions embracing
cloud paradigms
Massively multi-tenant
Thousands tenants, massively scalable
Easy & fast (de)provisioning
Infra as code, API centric
Infrastructure agnostic
L3, does not stick with lower levels (physical designs, vlans & co)
Decouple infrastructure & tenants lifecycles
Cross technology, vendor agnostic

31. From Enterprise Services buses
to full-mesh topologies
ESB
Service Service Service
Service Service
>
ServiceService
Service
Service
Service
Micro services

32. Fine-grained, highly decoupled and
atomic purpose centric services
Designed
for failure
Multi-versioned
Scalable
Micro services
Stateless
Share-nothing
Immutable
Continuously
delivered
Distributed

33. Service
consumer
Service
provider
Registry
2. Find 1. Publish
3. Bind
Leverage on a Service registry to discover
where are services located
Micro services

34. Resilience & scalability: apps problem now!
Vertical > horizontal
Apps designed for failure & scalability
Data to be externalized
Dumber infrastructure
 Structured: MongoDB, Hadoop, Cassandra, Elastic Search...
 Binaries: object storage with Ceph, OpenStack Swift...
 Helpful patterns: stateless, multi-versioning, loose coupling...
 Infrastructure rationalization
 Low-cost, poor-SLA commodity

35. « Organizations which design systems... are constrained to
produce designs which are copies of the communication structures
of these organizations ». - M. Conway, 1968
Consider shifting your organization if you
wish to shift your architecture
Forget about the central architects myth of
organizing, integrating everything
Consider changing your organization to expect
changing the architecture!  promote feature teams
Organization

36. Docker suits perfectly new applications
challenges
Create docker networks to isolate applications
Docker container properties fits micro-services challenges
Resilience & scalability is mostly about multiplying containers
Expect to discuss roles shift in organization

37. Taste-an-app

38. Execution platform
Registry
Docker-machine
Docker-swarm
The registrator
discovers new
containers and
feeds the registry

39. Application design
Provider micro serviceConsumers
The python app module exposes a REST service searching
information in the MongoDB
The NGINX reverse proxy forward app. requests on one of the
python instance registered in Consul
Find

40. Application topology & runtime
The whole application topology is stored as:
docker-compose yaml file
docker-compose args (aka --x-networking & --x-network-driver)
You can scale up or down the python instances of the micro-
service using traditionnal docker-compose scale command

41. Network view
Only the load balancer VIP is exposed externally
A WAF instance could secure this entrypoint
SDN « dockerconeu15 »
Host network
Provider micro serviceConsumers

42. Network view - advanced
Provider micro service
Consumers
SDN « front »
SDN « back »
Host network
Back
Middle
Front
‘’To enhance security
you may decouple
each application tier’’

43. Zoom on the registry usages
Between micro-services, consumers asks the
registry where a desired micro-service is located
Inside a micro-service, NGINX is made aware of
the backend API instances available, via the registry
At container level, the registrator enable to registers
any container instances, grouped per type
At infrastructure level, the registry is used by swarm
(internally) to be aware of the cluster’s participants
Noticed the different usages of a registry ?
You may consider using different registries for each usage : for example an
internal registry for the micro service internal topology

44. Conclusions

45. Docker shifted from universal containers to
object-oriented infrastructure
Security is an app concern
Software is eating the world: application
architecture is the key, infrastructure is commodity

46. Thank you!
