This document discusses using context free grammars and XML to represent and manipulate symbols from data in order to generate fuzzed or corrupted inputs. It begins by introducing the concept of using the Sequitur algorithm to extract a hierarchical context free grammar from input data. This extracted grammar represents the patterns and symbols in the data. The document then discusses representing this grammar as XML for easier analysis and modification. It proposes using the symbol structure to guide a fuzzing technique called the CFG9000, which corrupts input data by shuffling, repeating, dropping or uniformly corrupting symbols. Examples of fuzzed output are shown for code and an XML document from Wireshark. The goal is to fuzz at the symbolic level rather than just corrup
2. Introduction
• Many physicists would agree that, had it not
been for congestion control, the evaluation of
web browsers might never have occurred. In
fact, few hackers worldwide would disagree with
the essential unification of voice-over-IP and
public private key pair. In order to solve this
riddle, we confirm that SMPs can be made
stochastic, cacheable, and interposable.
– Rooter: A Methodology for the Typical Unification of
Access Points and Redundancy
3. That was BS.
• That also got accepted into a con.
– Automatically generated from a context free grammar
– I’ve been working too hard all these years
– “Be quiet, or I will replace you with a very small shell
script”
• This talk is a bit of a remix
– Patterns and symbols are interesting me as of late
• Automatic determination of both is difficult, interesting, and
unsolved
– Integration into human symbolic systems promises
particularly interesting results
– So we’re going to explore a bit.
4. Language Is Cool
• Language: A protocol for the transmission of concepts and
intentions between humans
– Documentation is not available
– Documentation does not really work
– Learned through exposure and use
• Significant amount of internal structure, redundancy, and
consistency
• Who makes language?
– Kids.
• Adults coin words here and there, but when they’re forced
to invent a common language to get things done, it’s
called a Pidgin, and it’s terrible
• The kids hear it, and invent a Creole – a merged language
of significantly greater accuracy and depth
• Children make languages
• Adults make “working” languages
• Programmers make barely working languages
5. Programmers Talk Funny
• Fundamentally two languages that programmers must use
– Code to Human: “User Interface Design”
– Code to Code: “File and Network Protocol”
• UI is a protocol.
– This is obvious in retrospect.
• There are two things this talk hopes to do
– Correct some of the Code->Human protocols that are out
there
– Use human strategies to analyze Code to Code
communications
• Learning a protocol is learning a language.
Humans do not learn languages quickly, and thus
we’re resource bound on fuzzer development
• It’s 2007 – most parsers remain unfuzzed (and thus
just waiting to be exploited)
6. Weaponizing Noam?
• “An early inference procedure was described by
Chomsky and Miller (1957a), as reported in Solomonoff
(1959). Chomsky proposed a method for detecting loops
in finite state languages. The approach requires a set of
valid sentences, and an oracle that determines whether
a sentence is in the language.
The algorithm proceeds by deleting part of a valid
sentence and asking the oracle whether the sentence is
still valid. If it is, the deleted part is reinserted into the
sequence and repeated, so that it appears twice. If the
sentence is still in the language, a cycle has been
detected.”
– Inferring Sequential Structure, Craig Neville Manning, 1996
– This couldn’t POSSIBLY be useful for building a structure
for a dumb fuzzer to operate against.
• Instead of seeing if the parser crashes, just see if it considers
the input valid
7. Topics Of Discussion
• Further Explorations in Cryptomnemonics
– Using Names and Syllables for password
representation
• Sequitur-XML: Merging automated
structure discovery with the standard
architecture for structure representation
– …which turned out to be quite nice for
controlled structure destruction
• Exploring Dotplots
– Building a GUI
– Exploring other domains
8. Intro To Symbol Sets
• Machine Symbols
– Data (AA, BB, CC)
– Code (a(), b(), c())
– Formats (All, Bad, Code)
• Human Symbols
– Letters (A, B, C)
– Glyphs ()
– Syllables (Ah, Bee, See)
– Words (Amazing, Bear, Clear)
– Native Names (Alice, Bob, Charlie)
– Things (Axe, Bone, Chimpanzee)
– Actions (Ask, Buy, Compute)
– Colors (Aquamarine, Blue, Chartreuse)
• Machines can use formats, but their native format is raw bits
• Humans have no concept of “raw bits” – everything must be
contextual
– Long history in mnemonics of mapping arbitrary data to a
10. Cryptomnemonics
• Definition: The study of human memory, as it
applies to cryptographic systems
• Developing in response to this:
– $ ssh dan@blah
The authenticity of host 'blah
(1.2.3.4)' can't be established.
RSA key fingerprint is
09:a9:b1:99:84:17:7d:ba:c6:55:46:5a:17:
f8:83:01.
Are you sure you want to continue
connecting (yes/no)?
• The machine is acting like its integrating with
another machine. It’s not, and that matters.
• Humans can handle hexadecimal characters –
but not that many.
11. Hex Confusion
• After somewhere between 2 and 5
characters, most of you will fail to see a
difference
– Positional Bias: Expect to see certain things
at the beginning or end
– Value Confusion: Letter vs. Number is
remembered before the actual value of letter
or number
• Glyph confusion
– “Despair” Effect
• Nobody could possibly detect a change, so it’s not
rational to even try
12. Classes of Memory
• There are three classes of memory, at least to
the degree as is useful in cryptography
– Rejection: “I’ve never seen that before”
– Recognition: “It’s that one, not that other one”
– Recollection: “Let me describe it to you.”
• SSH just requires rejection
– Hex is not rejectable
– Can we try another domain?
13. Exploring The Nymic Domain
• $ ssh dan@blah
Key Data:
julio and epifania dezzutti
luther and rolande doornbos
manual and twyla imbesi
dirk and cuc kolopajlo
omar and jeana hymel
The authenticity of host 'blah (1.2.3.4)' can't be
established.
Are you sure you want to continue connecting
(yes/no)?
– Alternate mapping for
09:a9:b1:99:84:17:7d:ba:c6:55:46:5a:17:f8:83:01.
– Proposed last year as a potential solution
• There is nothing more contextual than a story, and there is nothing
more stable in a story than the names of its participants
– Stories retold are stories remembered – we need to be exposed
to the above group time and time again to be able to reject any
deviation from it
14. How To Derive Names?
• Original Model
– Take US Census Data
– Remove any names that may be easily confused with
one another:
• Easy: Bob v. Bobby
• Hard: Bob v. Robert
• Celebrity Naming
– “Marge Godwin”
• Archaic Naming
– Use constructs from various ancient languages
• Mechanistic Constructs
– Bubble Babble: 64 bits = xegoz-tosys-vusik-masar
– Koremutake: 64 bits = darujifahe stygrifrejy
15. How Many Names?
• Unclear what the crossover point is between hard from more
names, and benefit from more entropy per name
– Present system is 512 male name, 512 female name, 1024
last names from US Census
– 256/256/256 would provide 24 bits per couple instead of
40, and the names would be more recognizable. Better?
How much better?
• The more names, the more a problem position
becomes
– We’re sensitive to names, but without a story
context, there’s no roles locking people to being the
first or the second or the third. So the more names,
the more bits we lose to reader confusion.
• How many bits are necessary? Depends on what for.
16. Flipping The Bits
• SSH Key Representation is not the only thing we can do with
this technique
– In fact, it’s not even the most pressing problem
• Passwords are in crisis right now
– PKI failed, deal with it
• There’s an entire alternate history where XSS enjoys
the benefits of your legal credentials being available
and shared
– People are being asked to generate, frequently, high
entropy non repeated passwords
• They’re repeating them
• They’ve exhausted personal entropy, and have moved
to geometric progressions to evade lameness checks
– &(*uoiJKL798
– Fixed prefix
17. A Fundamental Shift
• Generate passwords for your users.
– “But they’re hideous, nobody will remember
what we automatically generate”
• You’re theoretically forcing them to generate
those hideous passwords, off the top of their
head
• Use alternate symbolic domains to coat the
password entropy you require in a form users can
accept
– Why yes, this is exactly like a tunnel. We’re
tunneling entropy over a baby name book
18. Change Your Ways
• Modify your validation logic to accept long
passwords without weird character sets
– Punctuation and case sensitivity are
“weak symbols”
• It is easier to chain together common
symbols in a common way, than it is to
link together arbitrary bytes out of
context
– This is a fundamental difference between
human symbol manipulation and the
operations of computers
19. How Many Bits Do We Really
Need?
• Hash Validation: 80-100 bits
– We don’t have a birthday paradox problem with
hashes, since one of them is fixed.
– 2^80-2^100 work efforts are outside the range of
feasibility at this time
• Password Entry: 24 bits for low security, 36-48
bits for high security
– Need enough to make brute force enumeration
across all users infeasible
– For each username, try one possible password
– 48 bit is what we’re at with
punctuation/case/number/8 character.
20. Limits to alternate symbol domains
• We lose the ability to measure “nextness”
– 0x10 is one less than 0x11
– Bob is…how much less than Charlie?
• Data may become variable length – Bob is
three characters, Charlie is seven
– Harder to see patterns
• Has trouble scaling to any large number of
bits.
– We can’t analyze even mildly large systems
using this translation layer
22. N’est’ce pas Non Sequitur
• Sequitur: Linear Time Pattern Finder
– Creates hierarchal Context Free Grammars from arbitrary input
• Compression Algorithm in which you can “look under the
covers” to see what’s going on
• Created by Craig Neville-Manning as his PhD thesis a
decade ago
– He’s now Chief Research Scientist at Google
23. What’s New: Sequitur-XML
• echo ‘aabbabc’ |
./sequitur_simple.exe
• Why translate: Gives us
much easier to
manipulate output
– C is very good for
generating the tree
– Other languages are very
good for analyzing /
modifying the tree
• XML is a (shockingly)
good machine format for
representing structure
27. Browsing HOWTO
• For each entry in the root node,
– If it’s a literal, color it white
– If it’s part of a reference, color it red
– If it’s clicked, color it and every other instance
of that reference blue
• A little buggy
• Present implementation DOES NOT SCALE
• But effective!
28. Symbol Links: Where To Go From
Here
• Turns code on left into
symbolic set on right;
it’s easy then to link
the symbols together
as per the graph.
• This works for non-textual data
• Sequitur imputes meaningful
symbols from arbitrary input
data
29. Context Free Grammar Fuzzer:
THE CFG9000
• Reduce input data to a stream of symbols
• Fuzz data at the symbol level, rather than
at pure bytes
– Shuffle
– Drop
– Repeat
– Uniform Corrupt
• Consistently corrupt all instances of a given
symbol
• <HEAD> -> <FOOBAR>
• Partially ported to the new XML framework
33. Why We Moved To XML In The
First Place
• XML is a (potentially) validating format
– Has the concept of schemas
– NOT THAT THEY’RE ALWAYS OR EVEN OFTEN
CHECKED
• Schema validation is expensive
• We should be able to use XML Schemas to
guide fuzzers
– WS-Bang
• Excellent tool for bashing Web Services frameworks
• Given a WSDL file (Web Services Description Language),
fuzz it
– Untidy: Mostly just attacks XML parsers, doesn’t hit
the structure
34. Automatically Generating
Schemas?
• We can autogenerate Schemas from XML
(to some degree)
– Relaxer
– Trang
– Tends to capture structure better than content
• Doesn’t appear to automatically determine what
values are valid for each field
• Does provide framework for automatically
extracting all instances of what can go where
37. Could we automatically extract
structure from Sequitur-XML?
• “This sequence of bytes can be reconstructed
with these other sequences of bytes”
– No tree relationship – anything can link in
anything
– Need to have the content awareness
Relaxer lacks to get anything useful
– Where might we get this content
awareness?
38. What Might We Borrow From
Linguistics?
• Can we use linguistic approaches?
– Common Elements
• Humans: Subjects, Verbs, etc.
• Machines: Delimiters, Length Fields, ASCII/Unicode, x86,
Padding to Four Byte Boundries
– Symbol Interrelationships
• Humans: We take word boundries for granted
– Until we’re listening to a foreign language, and wonder
why there aren’t spaces between words
• Machines: File formats rarely make it easy to see where
one symbol starts and another begins
• Does one symbol always appear before another? Does
one symbol always found itself surrounded by two others?
39. How To Think Of Sequitur
• Any time you’re manipulating data as bytes,
think of manipulating it as symbols
– N-gram histograms on bytes -> N-gram histograms
on symbols
– Bayesian probabilities on characters -> Bayesian
probabilities on symbols
• Sequitur is not necessarily the best way to
determine a grammar
– Suffix Trees may be more accurate
– Keiffer-Yang (redundant symbol extraction) a very
good post-processing step to add
– Ray removes In-Memory Grammar Requirement
– Not all other solutions are linear time, though
• Kind of cool to have a grammar that covers a 750GB hard
drive undergoing forensics s
40. Fuzzy Wuzzy Wuz A Symbol
• Symbol analysis systems (language translators,
etc) have issues w/ TMTOWTDI (There’s More
Than One Way To Do It)
– Very similar messages can be encapsulated in very
different ways
– Very similar messages can be encapsulated in very
similar, but not identical ways
• Sequitur only handles exact matches – fuzzy
grammar imputation doesn’t appear to exist yet
– We must develop this fuzziness to create byte-
sourced XML schemas
• It is a pretty wild concept, so
– Are there any systems for analyzing complex, inequal
but somewhat related sets of symbols?
42. What Exactly Are We Doing
• Jonathan Helman’s
“DotPlot Patterns: A
Literal Look at Pattern
Languages” offers an
introduction
• Instead of “to, be, not” etc, we use chunks of
data from arbitrary files
– Instead of demanding perfect equality, we measure
how similar the chunks are
– If most of the bytes are in most of the same places,
it’s pretty similar, if most are different, pretty dissimilar
47. So How Might This Be Useful?
• A) Format Identification
– 1) Do different files appear different, and does the
appearance reflect the existence of internal structure?
– 2) Do different instances of the same file format
appear similar?
– 3) Does one format embedded in another make itself
apparent?
• B) Fuzzer Guidance
– 1) Can we locate the actual byte offsets where one
section ends and another begins?
– 2) Can we visualize and compare fuzzer operations
via Dotplots?
48. Format Identification
• 1) Do different files appear different,
and does the appearance reflect the
existence of internal structure?
• 2) Do different instances of the same file format appear
similar?
• 3) Does one format embedded in another make itself
apparent?
56. Format Identification
• 1) Do different files appear different, and
does the appearance reflect the existence
of internal structure?
– Answer: Yes. They do.
• 2) Do different instances of the same
file format appear similar?
• 3) Does one format embedded in another make itself
apparent?
57. Books from Project Gutenberg:
Consistent
Despite English’s low
information content,
lack of even mildly
related strings causes
little self-similarity
across symbol clusters
58. US Code:
Moderately Consistent
Legalese is a massively
structured dialect.
Symbols appear in very
distinct patterns that are
more reminiscent of
machine code than text.
60. Java Class Files (Compared):
Mildly Consistent
Binary code (be it bytecode
or x86) tends to be very
structured. Still, we are
dependent on both the
content and the compiler
to generate distinct
patterns.
61. x86:
Consistent (In Sections)
x86 tends not to be
handwritten; as such
complex instructions are
emitted in a highly
structured form.
62. Exception?
• 64 kilobyte graphical
demonstration
• Run through a packer
• Compression
removes patterns
64. Mario Games Look Rather
Different.
1) Output is highly
dependent on the
compiler
2) Output is highly
dependent upon the
actual content
File formats are merely
shells for actual
content. You are
analyzing the content;
the format is just
syntactic sugar.
65. Format Identification
• 1) Do different files appear different, and does the
appearance reflect the existence of internal structure?
– Answer: Yes. They do.
• 2) Do different instances of the same
file format appear similar?
– Answer: Somewhat. Similar content looks
like itself, but you’re measuring the
fundamental entropy of the underlying
content, not the format of the content
itself.
• 3) Does one format embedded in another make
itself apparent?
66. File Formats Contain Multiple Subformats
Another Look At Kernel32.DLL
These are all different
parts of Kernel32.
67. Quickly Browsing Large Files:
Tilt-Shift View
• Instead of measuring
absolute Y against
absolute X, make X
relative
– Advance through the
file going down, look
back a number of
bytes going right
69. Format Identification
• 1) Do different files appear different, and does the
appearance reflect the existence of internal structure?
– Answer: Yes. They do.
• 2) Do different instances of the same file format appear
similar?
– Answer: Somewhat. Similar content looks like itself,
but you’re measuring the fundamental entropy of the
underlying content, not the format of the content itself.
• 3) Does one format embedded in another
make itself apparent?
– Answer: Yes. Multiple, distinct sections
are clearly visible in a way that hex cannot
show.
70. Fuzzer Guidance
• 1) Can we locate the actual byte offsets
where one section ends and another begins?
– Why would we want to?
• Fuzzers break parsers.
• Many subformats to a format, many subparsers to a parser
• To a rough level of approximation, fuzzing a single subformat
lets you stress a single subparser
• So once we split a file up, we can selectively attack one
subparser at a time.
• 2) Can we visualize and compare fuzzer operations via
Dotplots?
71. Simple Math
We select an interesting blob
from kernel32.dll. The blob is
at pixel offset 507x507, and
is a square around 570 pixels
wide.
Window size on viz was 32.
507*32 = The interesting
section starts 16224 bytes
into the file.
570*32 = The interesting
section is 18240 bytes long.
72. Whats The Actual Data?
dd if=kernel32.dll bs=1 skip=16100
| hexdump - | more
73. Using Hardcorr as a “first knife” to
locate interesting-to-fuzz regions
74. Fuzzer Guidance
• 1) Can we locate the actual byte offsets where
one section ends and another begins?
– Answer: Yes. We can quickly route from the image
to the byte offset, through basic arithmetic.
• 2) Can we visualize and compare
fuzzer operations via Dotplots?
75. Differentials
• Major use of dotplots in bioinformatics is to
compare one genome against another
– Autocorrelation: Compare A to A
– Cross-Correlation: Compare A to B
• Most files are sufficiently dissimilar that
not very interesting structure shows up
– Notable exception: Different versions of
the same binary
79. Fuzzer Guidance
• 1) Can we locate the actual byte offsets where one
section ends and another begins?
– Answer: Yes. We can quickly route from the image
to the byte offset, through basic arithmetic.
• 2) Can we visualize and compare
fuzzer operations via Dotplots?
–Answer: Yes – visual diffing effectively
shows differences between files,
including differences introduced by
various flavors of fuzzers.
80. Conclusions…
• Lots of interesting work left to do
– Unification of local presence of symbols, and global
view of file format
• Possible to do dotplots themselves in the symbolic domain
– Use of dotplots to segment formats, which thus
provides the tree we want for an XML schema
• <format>
– <blob1 />
– <blob2 />
– <blob3 />
• </format>
– More colorful pretty pictures!
81. The Ancient Tongue:
TCP/IP
• Can’t all be about pretty pictures
• A new problem has popped up: Network
oligopolies are threatening to install
firewalls that limit or eliminate bandwidth
on a per-company basis
– Their own media services might be fast,
others will be slow
– Their own VPN services might be fast, others
will be slow
• Question: Is it possible to detect and
locate devices violating network
82. What’s The Closest Tool We Have?
• Firewalk
– Mike Schiffman’s Firewall Analysis Tool
– Packets elicit a ICMP Time Exceeded error if
they reach a router with TTL=0
• TTL decremented by one for each hop, so you
start low, you can trace the route to a host
– A firewalled packet won’t live long enough to
reach TTL=0
– So you can locate the firewall, and divine
things about its ruleset, based on when your
packets stop getting ICMP Time Exceeded
83. Limitations of Firewalking
• But Firewalk tells us what, not who is
blocked…and it tells us nothing about who
is allowed to go fast, and who is made to
go slow
– Suddenly, we devolve to a much older
question: Is it possible to find out that a target
firewall is, or is not, blocking against or
accepting traffic from an arbitrary IP address?
84. TCP Does Speed Measurement
• TCP speed analysis done blindly
– Endpoints do not negotiate with one another
– Everyone sends their packets, routers route
what they will. Endpoints need to adjust to
what the routers are willing to pass.
• Routers communicate with endpoints by dropping
their packets
• Can we combine this router backchannel
w/ Firewalk?
85. In From The Side
• What causes packets to drop?
– Too many packets
• What are we going to do?
– Send too many packets
• Two channels are set up
– A primary channel, which drops packets at some
known rate
– A secondary channel, whose purpose it is to interfere
(or not) with the primary channel
• When the secondary interferes with the primary,
we get feedback via the primary channel
– The traffic composing the secondary channel can
come from anywhere, be composed of anything, and
can be TTL’d just like in a normal firewalk.
86. The TTL Channel
• Normally, you don’t know which router
along a path is dropping your packets
• If you are the source of the drop-inducing
packets, you can control how far your
noise goes out – thus, you can discover
which router is hitting its limit / censoring
your net connection
87. Scorchmarking
• Why Scorchmarking?
– Routers are burning packets…those that get through
might have a scorch mark or two
• Basic Model
– Client downloads a file from a site, at some given
speed negotiated via TCP.
– At the same time, traffic is injected from different IP
addresses. This should cause drops.
• If it doesn’t, the network is either penalizing the primary
channel (easy to drop against) or rewarding the secondary
channel (resilient to drops)
88. Advanced Scorchmarking [0]
• Having to depend on a client is lame
– Wouldn’t it be nice if we could scan the
Internet for these servers?
• What fundamental service is a receiving
client providing?
– It is acknowledging our traffic – letting us
know how much it received, and how many
milliseconds it took to receive it
• Aren’t there other ways we could extract
the same data from hosts?
89. Advanced Scorchmarking [1]
• What else will acknowledge receiving traffic from
us?
– TCP Servers
• Sting, from Stefan Savage, used this to great effect
– DNS Servers
– Routers.
• Supposedly, routers won’t send more than a certain number
of ICMP Time Exceeded packets per second
• In reality, they seem to ICMP Time Exceeded ACK however
much you throw at them
• Even if they didn’t, you could use the difference in ICMP
Time Exceeded rates between Primary and Secondary
channel, to determine whether interference was showing up.
• Everyone’s got a NAT – so you can query everyone for
whether certain sorts of traffic are being blocked to them
90. Advanced Scorchmarking [2]
• So, yes.
– You can scan for violations of Network Neutrality
– You can find networks that are blocking or passing
particular IP ranges
• It’s not exactly efficient though
• Neutrality violations are easier to find than the
standard FW case
– Firewalls are normally between the WAN and the LAN
(Slow Net -> FW -> Fast Net)
– Neutrality violators are mid-WAN (Slow Net -> Fw ->
Slow Net -> Fast Net)
– Easier to overload the slow net after the firewall
• Boxes with max TTL rates override this
91. Speed Limits
• Fundamental Problem: Have to max out
bandwidth on the link to trigger the backchannel
– No packets dropping, no data
– Means you have to DoS a link – not scalable/legal
• Potential Solution: Find capped acknowledgers
– The mythical ICMP Time Exceeded rate limit works
well
• Primary and Secondary channel both eliciting ITE’s
• When secondary channel gets a packet through, it takes up a
slot on the primary channel’s
• ITE is perfect, since you can TTL limit any packet
• Depends on the firewall passing the primary’s ITE’s
• Maybe Linux / NATs actually implement rate limits?
– Another option: What if we have code on the client?
92. Windows Media Player:
More Than Just DRM. Really!
• Bulk Transfer: RTP
– Runs over Unicast UDP
– Yes, the same Unicast UDP that penetrates NAT so
well!
• Flow Control / Quality Monitoring: RTCP
• No technical reason RTCP needs to go back to
the same address that RTP stream is coming
from
– So: We pretend to provide media streams from all
sorts of sites, and use WMP to collect traffic stats for
us
• It might work…
