Discover TASTy Query
The library for Scala program analysis
Jamie Thompson

2. 2
● Not For Profit Organisation
● Located at EPFL, Switzerland
● Sponsored by donations
Scalafix
Metals
Scala Debug Adapter
BSP
scala3-migrate
Scala Native
Scala.js

3. ● Website: https://scala.epfl.ch/
● Twitter: @scala_lang
● Discord: https://discord.gg/scala
● Scala Contributors Forum: https://contributors.scala-lang.org/
● Scala Users Forum: https://users.scala-lang.org/
● LinkedIn: https://www.linkedin.com/company/scala-center
3
Find us online

4. What is it?
TASTy Query
4

5. TASTy Query Elevator Pitch
● Cross platform (JS, JVM)
● Reason about and analyse APIs defined in Scala 3, Java, and Scala 2.13
● Extract full information from TASTy files.
● Simple to use
● Independent of compiler
5

6. A general purpose IR for Scala
So… TASTy?
6

7. 7
Compiler Pipeline
Foo.scala
parser typer pickler
scalac
backend
➢ Typed AST
➢ Binary format
➢ Signatures for downstream libraries
➢ inline bodies
➢ Lossy
➢ Erased types
Foo.tasty
��
Foo.class
☕

8. TASTy Structure
8
0: PACKAGE(63)
2: TERMREFpkg 1 [<empty>]
4: TYPEDEF(59) 2 [Foo]
7: TEMPLATE(38)
9: PARAM(9) 3 [x]
12: TYPEREF 4 [String]
14: TERMREF 5 [Predef]
16: TERMREFpkg 6 [scala]
18: PRIVATE
19: LOCAL
20: APPLY(10)
22: SELECTin(8) 13 [<init>[Signed Signature(List(),java.lang.Object) @<init>]]
25: NEW
26: TYPEREF 11 [Object]
28: TERMREFpkg 10 [java[Qualified . lang]]
30: SHAREDtype 26
32: DEFDEF(13) 7 [<init>]
35: PARAM(5) 3 [x]
38: IDENTtpt 4 [String]
40: SHAREDtype 12
42: TYPEREF 14 [Unit]
44: SHAREDtype 16
46: STABLE
47: ANNOTATION(16)
49: TYPEREF 15 [SourceFile]
51: TERMREFpkg 19 [scala[Qualified . annotation][Qualified . internal]]
53: APPLY(10)
55: SELECTin(6) 22 [<init>[Signed Signature(List(java.lang.String),scala.annotation.internal.SourceFile) @<init>]]
58: NEW
59: SHAREDtype 49
61: SHAREDtype 49
63: STRINGconst 23 [Foo.scala]
class Foo(x: String)
package `<empty>`
@scala.annotation.internal.SourceFile(“Foo.scala”)
class Foo(private[this] val x: scala.Predef.String)
extends java.lang.Object()

9. 9
Why is TASTy useful as a format?
● Stores the whole program
● Stable with respect to dependencies
○ Method overloads are already resolved
○ Implicits are already resolved
Foo.tasty
��

10. Why do we need it?
TASTy Query
10

11. 11
Example Application
org::utils:1.0.0
my::app:2.7.2
foo::macros:3.3.
5

12. @main def app: Unit =
println(Macros.foo())
✅ my::app:2.7.2
12
object Utils:
def asList(xs: Seq[Int]): List[Int] = xs.toList org::utils:1.0.0
object Macros:
inline def foo(): String =
Utils.asList(Seq(1, 2, 3)).sum.toString
foo::macros:3.3.
5
Example Application: Code

13. 13
Example Application: Upgrade
org::utils:1.0.0
my::app:2.7.2
foo::macros:3.3.
5

14. 14
Example Application: Upgrade
org::utils:1.0.0
my::app:2.7.2
foo::macros:3.3.
5
org::utils:1.0.1 New patch release 🚀

15. 15
Example Application: Upgrade
org::utils:1.0.0
my::app:2.7.2
foo::macros:3.3.
5
org::utils:1.0.1
Patch release? Let’s upgrade!

16. 16
Example Application: Upgrade
org::utils:1.0.0
my::app:2.7.3
foo::macros:3.3.
5
org::utils:1.0.1
🤔

17. 17
Example Application: Upgrade
org::utils:1.0.0
my::app:2.7.3
foo::macros:3.3.
5
org::utils:1.0.1
❌
😭

18. 18
Example Application: Upgrade
org::utils:1.0.0
my::app:2.7.3
foo::macros:3.3.
5
org::utils:1.0.1
❌
😭
MiMa ✅ (binary compatible)

19. 19
Example Application: Upgrade
org::utils:1.0.0
my::app:2.7.3
foo::macros:3.3.
5
org::utils:1.0.1
❌
😭
TASTy Compatibility ❌

20. 20
Before
object Macros:
inline def foo(): String =
Utils.asList(Seq(1, 2, 3)).sum.toString
@main def app: Unit =
println(Macros.foo())
object Utils:
def asList(xs: Seq[Int]): List[Int] = xs.toList org::utils:1.0.0
my::app:2.7.2
foo::macros:3.3.
5
🤔
Seq[Int]

21. org::utils:1.0.0
21
After
object Macros:
inline def foo(): String =
Utils.asList(Seq(1, 2, 3)).sum.toString
@main def app: Unit =
println(Macros.foo())
object Utils:
def asList(xs: Int*): List[Int] = xs.toList
🤯 org::utils:1.0.1
my::app:2.7.3
foo::macros:3.3.
5
❌😭
❌😭

22. 22
-- [E007] Type Mismatch Error: app.scala:2:20 ----------------------------------
2 | println(Macros.foo())
| ^^^^^^^^^^^^
| Found: Seq[Int]
| Required: Int
|-----------------------------------------------------------------------------
|Inline stack trace
|- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
|This location contains code that was inlined from Macros.scala:3
3 | Utils.asList(Seq(1, 2, 3)).sum.toString
| ^^^^^^^^^^^^
|-----------------------------------------------------------------------------
|
| longer explanation available when compiling with `-explain`
1 error found

23. 23
So, What’s Happening?
1. Recompile my::app:2.7.3 against new dependency org::utils:1.0.1 .
2. def app calls inline def Macros.foo from foo::macros:3.3.5 .
○ ⚠ foo::macros:3.3.5 still depends on older org::utils:1.0.0 .
3. Compiler substitutes Macros.foo call by its inline body from TASTy.
4. Macros.foo body calls Utils.asList , which resolves to newer org::utils:1.0.1 .
5. Seq(1, 2, 3) argument not passed as varargs and so no longer type-checks!
○ org::utils:1.0.0 and org::utils:1.0.1 are not TASTy compatible!

24. 24
TASTy Query Use Cases
● Validate API compatibility between releases ✅
● Metals Debugger ✅
● TASTy interpreter (for research) ✅
● Custom Analyses

25. Making a Query
TASTy Query
25

26. 26
Goal: Analyse Inheritance in scala-library .
class A extends B with C
class B
trait C
A
B C
AnyRef

27. 27
First Step: Building the Classpath
● Ordered sequence of entries ✅
● Each entry is a .jar file or directory ✅
● Inside each entry is .class/.tasty files, organised by package
✅
[0] my-library/target/scala-3.2.1/classes
[1]
maven2/org/scala-lang/scala3-library_3/3.2.1/scala3-library_3-3.2.1.jar
[2] maven2/org/scala-lang/scala-library/2.13.10/scala-library-2.13.10.jar
[3] jrt:/modules/java.base
import java.nio.file.*
val cpPaths = List(
Paths.get("my-library/target/scala-3.2.1/classes"),
Paths.get(".../scala3-library_3-3.2.1.jar"),
Paths.get(".../scala-library-2.13.10.jar"),
jrtFileSystem.getPath("modules/java.base")
)

28. 28
First Step: Read the Classpath
import tastyquery.jdk.ClasspathLoaders
import tastyquery.Classpaths.Classpath
val classpath: Classpath = ClasspathLoaders.read(cpPaths)
val lookup: Map[Path, Classpath.Entry] =
cpPaths.zip(classpath.entries).toMap
import java.nio.file.*
val cpPaths = List(...) // from previous slide

29. 29
First Step: Read the Classpath
● Pure, in-memory representation of classpath ✅
● Each Entry stores .class/.tasty files found in its source path ✅
● Platform agnostic (JS/JVM) ✅
Classpath.Entry
Classpath

30. 30
● A Context wraps a Classpath ✅
● Entry point to inspect definitions ✅
● Summon a Context with ctx ✅
Second Step: Context
import tastyquery.Contexts
import tastyquery.Contexts.*
Context
given Context = Contexts.init(classpath)

31. 31
Third Step: Query
🤔 how to find only the classes from scala-library ?
val scalaLib: Classpath.Entry =
lookup.filterKeys(_.toString.contains("scala-library")).values.head
val scalaLibRoots: Iterable[Symbol] =
ctx.findSymbolsByClasspathEntry(scalaLib) // top-level classes
val lookup: Map[Path, Classpath.Entry] = … // from earlier slide
import tastyquery.Symbols.*

32. 32
Core Concepts: Data
Symbols
● Unique identity for a definition ✅
● Store all information about the definition ✅
● Specialised for each kind of definition ✅
import tastyquery.Symbols.*

33. DeclaringSymbol
33
Core Concepts: Data
Symbols
Symbol
ClassSymbol TypeParamSymbol
TypeMemberSymbol
PackageSymbol TermSymbol
TypeSymbol
import tastyquery.Symbols.*

34. 34
ClassSymbol Methods
cls.parentClasses List[ClassSymbol] of the parents of the class.
cls.fullName FullyQualifiedName of the class.
cls.owner What symbol was cls declared in?
cls.getDecls(name) Find all overloads in cls matching a Name .
cls.declarations Find all symbols declared in cls .
ClassSymbol

35. 35
Comparison to the Compiler API
● Inspired by compiler ✅
● Single “temporal” view ✅
● Favor specialisation over abstraction ✅
TermSymbol
declaredType
Type
TypeMemberSymbol
bounds
TypeBounds
ClassSymbol
parents
List[Type]
typeParams
List[CTPSymbol]

36. 36
Comparison to the Compiler API
dotty.tools.dotc API
Symbol
info
Type | TypeBounds | ClassInfo
❌
● Inspired by compiler ✅
● Single “temporal” view ✅
● Favor specialisation over abstraction ✅

37. 37
Third Step: Query
🤔 how to find only the classes in scala.collection.mutable ?
val mutablePackage = ctx.findPackage("scala.collection.mutable")
val mutableClasses: Iterable[ClassSymbol] =
scalaLibRoots.collect {
case cls: ClassSymbol if cls.owner == mutablePackage => cls
}
val scalaLibRoots: Iterable[Symbol] = … // from earlier slide

38. Algorithm
Inheritance Graph
38

39. 39
Computing inheritance graph of class A
1. Links := []; explore := {class A}
2. While explore is non-empty:
a. remove class A from explore
b. For each parent class P of A:
i. add a link class A -> class P
ii. add class P to explore
3. Return Links

40. Demo
Inheritance Graph
40

41. API Overview
TASTy Query
41

42. Symbols Names
42
Core Concepts: Data
import tastyquery.Names.*
import tastyquery.Symbols.*
import tastyquery.Types.*
import tastyquery.Trees.*
Trees
Types

43. Names
43
Core Concepts: Data
Name
TermName ...
TypeName SignedName
Trees
Types
sym.name

44. Names
44
Core Concepts: Data
SignedName
foo [
Signed @bar (1,java.lang.Object):java.lang.Object
]
@targetName("bar") def foo[T](t: T): T
def foo(x: Int, y: String): Int
Trees
Types
sym.signedName

45. Types
45
Core Concepts: Data Trees
Type
TermRef ...
TypeRef
TypeBounds
sym.declaredType

46. 46
Core Concepts: Data
TypeTree Tree
Trees
Ident ...
Select
sym.tree

47. Cheatsheet
TASTy Query
47

48. 48
Types
tp1.isSubType(tp2) Boolean is tp1 <:< tp2 by Scala’s type rules
tp1.isSameType(tp2) Boolean is tp1 =:= tp2 by Scala’s type rules
tp1.member(name) Find a (possibly inherited) member of tp1 called name .
tp1.isRef(sym) Does tp1 reduce to a reference of sym ?
val tp1: Type
val tp2: Type
val name: Name
val sym: Symbol

49. 49
Overrides
f.overridenSymbol(cls) Which term/type in cls is overridden by f ?
f.overridingSymbol(cls) Which term/type in cls overrides f ?
f.allOverriddenSymbols
Find all the terms/types overridden by f in parent
classes.
f.nextOverriddenSymbol
Find the first term/type overridden by f in parent
classes.
val f: TermOrTypeSymbol
val cls: ClassSymbol

50. Do They Exist?
Alternatives
50

51. 51
Why Not Use…
● Scala 3 compiler’s tasty-inspector library?
● Scalameta?

52. Summary
52

53. Summary
● TASTy Query will be critical for Scala ecosystem’s infrastructure
● Simple API to inspect definitions from all the classpath
● Cross platform
● Accessible for many kinds of user.
53

54. Community sponsors
Thank you!
Any questions?
