16. Generalized SIZE definition
G.SIZE Qualifier(at least)
xlarge 960dp x 720dp
large 640dp x 480dp
normal 470dp x 320dp
small 426dp x 320dp
} Android does not currently support screens smaller than
small screens.
18. Some model
device SIZE G.SIZE DPI G.DPI RES. px RES. dp
HTC wildfire 2.8 in small 140dpi ldpi 240*320 320*428dp
HTC hero 3.2 in normal 180dpi mdpi 320*480 320*480dp
HTC desire 3.7 in normal 252dpi hdpi 480*800 320*533dp
Dell Streak 5.0 in large 186dp mdpi 480*800 480*800dp
HTC sensation 4.3 in normal 256dpi hdpi 540*960 360*640dp
Galaxy note 5.3 in normal 280dpi xhdpi 800*1280 400*640dp
HTC Flyer 7.0 in large 170dpi mdpi 600*1024 600*1024dp
Galaxy tab 7.0 in normal 170dpi hdpi 600*1024 400*682dp
Xoom 10.1 in xlarge 150dpi mdpi 800*1280 800*1280dp
22. Effect of G.DPI
} Developers do not need to care about real density.
} RES.(px). are aggregated to RES.(dp).
} RES.(dp) has a much smaller range.
device G.SIZE G.DPI RES. px RES. dp
HTC wildfire small ldpi 240*320 320*428dp
HTC hero normal mdpi 320*480 320*480dp
HTC desire normal hdpi 480*800 320*533dp
HTC sensation normal hdpi 540*960 360*640dp
Galaxy note normal xhdpi 800*1280 400*640dp
Galaxy tab normal hdpi 600*1024 400*682dp
23. Density independence
} 根据G.DPI,系统将dp units和drawables换算调整为适
配设备的大小(px).
} A Button (100*100dp) and a icon (48px*48px in mdpi)
} Go back to see first demo.
25. Handset features
} Small and Normal devices take over 90%.
} These devices are nearly all handsets.
26. Handset qualifier
} G.SIZE: small/normal
} Default Orientation: portrait
} RES.(dp): 426dp x 320dp - 640dp x 480dp.
27. How to support?
} Develop a scalable app.
} Use wrap_content, fill_parent.
} Use dp not px.
} Use LinearLayout/RelativeLayout, not AbsoluteLayout.
} Provide different drawables for different dpi.
} Use more 9-patch drawable.
} …
30. The first guideline
} Develop one app for all devices.
} Tablets和Handsets没有明显的界限。
} 为不同的设备、分辨率开发不同的app耗费巨大且效果不佳。
} Anti-example:
31. Official Guidelines
} Build your activity designs based on fragments
} Use the action bar
} Implement flexible layouts
32. Implement flexible layouts
} How to implement flexible layouts in one app?
} Official answer: Think like a web designer.
33. Responsive web design
} Build something that works on any possible width or
device instead of something that works on all current
widths and devices.
} 与其为当前所有设备、大小做支持,不如去支持所有可能
出现的情况。
} Use css3 media queries.
} Usually combine with fluid web design.
34. Media queries
} Sample:
} <link media="screen and (max-device-width: 800px)"
href=“common.css" />
} Media queries contain two components:
} A media type. (screen, print)
} A media feature(max-device-width) and query value(800px).
} Use media queries to filter css depend on device info.
36. Responsive mobile design
} Same content, same logical, but different representation.
} 同样的内容,同样的逻辑,不同的展示方式。
} Use configuration qualifiers to provide different layout for
different devices.
38. New screen size qualifiers
} Smallest Width
} sw600dp
} Available Width
} w600dp
} Available height
} h600dp
39. Web design vs Android design
} CSS vs Layout
} CSS pixel vs Dip
} Ems vs Sp
} CSS3 media query vs Configuration qualifiers
} Fluid web design vs Scalable design
} Responsive web design vs Responsive mobile design
40. App demos
} IOSched2011
} IOSched2012
} Google Play
52. Android UI design patterns
} Design pattern
} 对于⼀一些普遍出现的问题的通用解决方法。
} 成熟的UI patterns能在不同的设备环境下自我调节。
} Here we introduce some useful patterns.
} Action Bar
} Workspace
} Dashboard
} Slide navigation
53. Action Bar
} Replace the old TitleBar.
} Many functions:
} Menu
} Search
} Navigation
} Tab
} Spinner
} Up
} Action Mode
} Split Action Bar
