Building your First App withMongoDBBlossom CoryatSolutions Architect, 10gen
Today‟s Talk• Introduction to MongoDB• Discuss data modeling, queries, indexes, updates and aggregation in MongoDB within ...
What is MongoDB?
MongoDB is a ___________database• Document Oriented• Open source• High performance• Highly Available• Horizontally scalabl...
Document Oriented• A document is essentially an associative array• Document == JSON object• Document == PHP Array• Documen...
Open Source• MongoDB is an open source project  – Started and maintained by 10gen• Licensed under the AGPL• Commercial lic...
High Performance• Written in C++• Runs nearly everywhere• Extensive use of memory-mapped files• Data serialized as BSON (f...
Full Featured• Ad Hoc queries• Real time aggregation• Rich query capabilities• Flexible schema• Geospatial features• Suppo...
MongoDB drivers• Official Support for 12 languages• Community drivers for tons more• Drivers connect to mongo servers• Dri...
Highly Available
Replica Sets• Redundancy and Failover• Multi-DC deployments• Zero downtime for upgrades and maintenance
Horizontally Scalable
Sharding• Partition your data• Auto-balancing• Scale write throughput• Increase capacity
Document Database
RDBMS                 MongoDBRow           ➜   DocumentTable, View   ➜   CollectionIndex         ➜   IndexJoin          ➜ ...
Typical (relational) ERD
MongoDB ERD
Example Document{        _id : ObjectId("4c4ba5c0672c685e5e8aabf3"),         author : "Blossom",         date : ISODate("2...
Building a check-in webapp
Requirements• Users should be able to check in to a location• Should be able to view check-ins by location• Ability to ass...
First step in any application isDetermine your entities
Check-in App Entities• People checking in• Places to check in to• Check-in events
In a relational based appWe would start by doingschema design
Relational schema design• Large entity relationship diagrams• Complex create table statements• Tables just to join tables ...
In a MongoDB based appWe start building ourand let the schema evolveapp
MongoDB collections• Users• Places• Check-ins  – Separate collection to manage discrete check-in events    and support hig...
We‟ll use the JS shell to getstarted
Start with an object(or array, hash, dict, etc)> user = {              firstname: fred,              lastname: jones,}
Insert the record> db.users.insert(user)                  No collection creation                  needed
Querying for the user> db.users.findOne(){    "_id" : ObjectId("50804d0bd94ccab2da652599"),    "firstname" : "fred",    "l...
_id• _id is the primary key in MongoDB• Automatically indexed• Automatically created as an ObjectId if not provided• Any u...
ObjectId• ObjectId is a special 12 byte value• Guaranteed to be unique across your cluster• ObjectId("50804d0bd94ccab2da65...
Places v1> db.places.insert({    name: “Exploratorium”,    address: “3601 Lyon St”    city: “San Francisco”,    postcode: ...
Places v1> db.places.insert({    name: “Exploratorium”,    address: “3601 Lyon St”    city: “San Francisco”,    postcode: ...
Places v2> db.places.insert({    name: “Exploratorium”,    address: “3601 Lyon St”    city: “San Francisco”,    postcode: ...
Places v2> db.places.insert({    name: “Exploratorium”,    address: “3601 Lyon St”    city: “San Francisco”,    postcode: ...
Places v3> db.places.insert({    name: “Exploratorium”,    address: “3601 Lyon St”    city: “San Francisco”,    postcode: ...
Indexes• Can be created on any field   – Including fields within sub-documents or embedded arrays• Support for compound in...
Indexes on Places// creating indexes> db.places.ensureIndex({name:1})> db.places.ensureIndex({categories:1})> db.places.en...
Updating Documents• MongoDB supports atomic, in-place document updates• $inc• $set, $unset• $push, $pushAll• $addToSet, $e...
Updating> db.checkins.insert({     place_id: pid,     user_id: uid,     datetime: new Date()})// update the “checkins” cou...
Simple Statistics// find the last 10 checkins for a place:> p = db.places.find({name:”Exploratorium”})> db.checkins.find({...
Aggregation Framework• Documents pass through a pipeline of operations• Mechanism to calculate aggregate values across you...
Aggregation FrameworkOperators• $project• $match• $limit• $skip• $unwind• $group• $sort
Advanced Statistics// checkins per place per day of the week> db.checkins.aggregate(    {$project: {          place_id:1, ...
Deployment
Deployment• Single server - need a strong backup plan                               P
Deployment• Single server - need a strong backup plan                                   P• Replica sets                 P ...
Deployment• Single server - need a strong backup plan                                   P• Replica sets                 P ...
Learn More:10gen.com/presentationseducation.10gen.com
Webinar: Building Your First Application with MongoDB
Webinar: Building Your First Application with MongoDB
Webinar: Building Your First Application with MongoDB
Upcoming SlideShare
Loading in …5
×

Webinar: Building Your First Application with MongoDB

9,018 views

Published on

This webinar will introduce the features of MongoDB by walking through how one can building a simple location-based checkin application using MongoDB. The talk will cover the basics of MongoDB's document model, query language, map-reduce framework and deployment architecture.

  • Be the first to comment

Webinar: Building Your First Application with MongoDB

  1. 1. Building your First App withMongoDBBlossom CoryatSolutions Architect, 10gen
  2. 2. Today‟s Talk• Introduction to MongoDB• Discuss data modeling, queries, indexes, updates and aggregation in MongoDB within the context of building a location-based app
  3. 3. What is MongoDB?
  4. 4. MongoDB is a ___________database• Document Oriented• Open source• High performance• Highly Available• Horizontally scalable• Full featured
  5. 5. Document Oriented• A document is essentially an associative array• Document == JSON object• Document == PHP Array• Document == Python Dict• Document == Ruby Hash• Etc.
  6. 6. Open Source• MongoDB is an open source project – Started and maintained by 10gen• Licensed under the AGPL• Commercial licenses available• On GitHub• Contributions welcome
  7. 7. High Performance• Written in C++• Runs nearly everywhere• Extensive use of memory-mapped files• Data serialized as BSON (fast parsing)• Full support for primary & secondary indexes• Document model = less work
  8. 8. Full Featured• Ad Hoc queries• Real time aggregation• Rich query capabilities• Flexible schema• Geospatial features• Support for most programming languages
  9. 9. MongoDB drivers• Official Support for 12 languages• Community drivers for tons more• Drivers connect to mongo servers• Drivers translate BSON into native types• Installed using typical means (npm, pecl, gem, pip)
  10. 10. Highly Available
  11. 11. Replica Sets• Redundancy and Failover• Multi-DC deployments• Zero downtime for upgrades and maintenance
  12. 12. Horizontally Scalable
  13. 13. Sharding• Partition your data• Auto-balancing• Scale write throughput• Increase capacity
  14. 14. Document Database
  15. 15. RDBMS MongoDBRow ➜ DocumentTable, View ➜ CollectionIndex ➜ IndexJoin ➜ Embedded DocumentForeign ➜ ReferenceKeyPartition ➜ ShardTerminology
  16. 16. Typical (relational) ERD
  17. 17. MongoDB ERD
  18. 18. Example Document{ _id : ObjectId("4c4ba5c0672c685e5e8aabf3"), author : "Blossom", date : ISODate("2012-11-02T11:52:27.442Z"), title: "Intro to MongoDB", tags : [ "tech", "databases”, ”documents" ], comments : [{ author : "Fred", date : ISODate("2012-11-03T17:22:21.124Z"), text : ”interesting article, lots of great nuggets of wisdom" }], comment_count : 1 }
  19. 19. Building a check-in webapp
  20. 20. Requirements• Users should be able to check in to a location• Should be able to view check-ins by location• Ability to assign categories to places• Find nearby places• Generate check-in statistics
  21. 21. First step in any application isDetermine your entities
  22. 22. Check-in App Entities• People checking in• Places to check in to• Check-in events
  23. 23. In a relational based appWe would start by doingschema design
  24. 24. Relational schema design• Large entity relationship diagrams• Complex create table statements• Tables just to join tables together• ORMs to map tables to objects• Lots of revisions until we get it just right
  25. 25. In a MongoDB based appWe start building ourand let the schema evolveapp
  26. 26. MongoDB collections• Users• Places• Check-ins – Separate collection to manage discrete check-in events and support high workload of writes
  27. 27. We‟ll use the JS shell to getstarted
  28. 28. Start with an object(or array, hash, dict, etc)> user = { firstname: fred, lastname: jones,}
  29. 29. Insert the record> db.users.insert(user) No collection creation needed
  30. 30. Querying for the user> db.users.findOne(){ "_id" : ObjectId("50804d0bd94ccab2da652599"), "firstname" : "fred", "lastname" : "jones"}
  31. 31. _id• _id is the primary key in MongoDB• Automatically indexed• Automatically created as an ObjectId if not provided• Any unique immutable value could be used
  32. 32. ObjectId• ObjectId is a special 12 byte value• Guaranteed to be unique across your cluster• ObjectId("50804d0bd94ccab2da652599") |---------||-----||-----||--------| ts mac pid inc
  33. 33. Places v1> db.places.insert({ name: “Exploratorium”, address: “3601 Lyon St” city: “San Francisco”, postcode: 94123}
  34. 34. Places v1> db.places.insert({ name: “Exploratorium”, address: “3601 Lyon St” city: “San Francisco”, postcode: 94123}> db.places.find({name:”Exploratorium”})
  35. 35. Places v2> db.places.insert({ name: “Exploratorium”, address: “3601 Lyon St” city: “San Francisco”, postcode: 94123, categories: [“Social”, “Arts”, “Museums”]}
  36. 36. Places v2> db.places.insert({ name: “Exploratorium”, address: “3601 Lyon St” city: “San Francisco”, postcode: 94123, categories: [“Social”, “Arts”, “Museums”]}> db.places.ensureIndex({categories: 1})> db.places.find({categories: ”Social”})
  37. 37. Places v3> db.places.insert({ name: “Exploratorium”, address: “3601 Lyon St” city: “San Francisco”, postcode: 94123, categories: [“Social”, “Arts”, “Museums”], location: [37.803963,-122.448531]}> db.places.ensureIndex({location: “2d”})> db.places.find({location:{$near:[37.81,-122.45]}})
  38. 38. Indexes• Can be created on any field – Including fields within sub-documents or embedded arrays• Support for compound indexes on any combination of keys• Indexes should exist for primary, common, and user-facing queries
  39. 39. Indexes on Places// creating indexes> db.places.ensureIndex({name:1})> db.places.ensureIndex({categories:1})> db.places.ensureIndex({location:”2d”})// finding by regular expression> db.places.find({name:/^explor/i})// finding nearby> db.places.find({location:{$near:[37.81,-122.45]}})// finding by category> db.places.find({categories: ”Social”})
  40. 40. Updating Documents• MongoDB supports atomic, in-place document updates• $inc• $set, $unset• $push, $pushAll• $addToSet, $each• $pop, $pull, $pullAll• $rename• $bit
  41. 41. Updating> db.checkins.insert({ place_id: pid, user_id: uid, datetime: new Date()})// update the “checkins” count on place and user// “checkins” will be added if it doesn‟t exist> db.places.update({_id: pid}, {$inc: {checkins: 1}})> db.users.update({_id: uid}, {$inc: {checkins: 1}})
  42. 42. Simple Statistics// find the last 10 checkins for a place:> p = db.places.find({name:”Exploratorium”})> db.checkins.find({place_id:p[„_id‟]}) .sort({datetime:-1}).limit(10)// how many people checked in today> db.checkins.find({place_id:p[„_id‟], datetime: {$gt: midnight}}).count()
  43. 43. Aggregation Framework• Documents pass through a pipeline of operations• Mechanism to calculate aggregate values across your data• Similar functionality to GROUP BY and related SQL operators• Along with computation, data can be reshaped – Add computed fields – Create virtual sub-objects – Extract sub-fields
  44. 44. Aggregation FrameworkOperators• $project• $match• $limit• $skip• $unwind• $group• $sort
  45. 45. Advanced Statistics// checkins per place per day of the week> db.checkins.aggregate( {$project: { place_id:1, dotw: { $dayOfWeek: ”$datetime”} }}, {$group: { _id: {place_id: “$place_id”, dotw: “$dotw”}, count: {$sum: 1} }})
  46. 46. Deployment
  47. 47. Deployment• Single server - need a strong backup plan P
  48. 48. Deployment• Single server - need a strong backup plan P• Replica sets P S S - High availability - Automatic failover
  49. 49. Deployment• Single server - need a strong backup plan P• Replica sets P S S - High availability - Automatic failover P S S• Sharded - Horizontally scale - Auto balancing P S S
  50. 50. Learn More:10gen.com/presentationseducation.10gen.com

×
