The SWORD Course<br />Module3<br />HowSWORD<br />works<br />
Module objectives<br />By the end of this module you will:<br />Know how SWORD works<br />Understand service documents<br ...
How does SWORD work?<br />A quick re-cap:<br />SWORD is a web service that allows deposits to take place into a repository...
HTTP basics<br />There are different methods / verbs that we use when interacting with the web:<br />GET<br />Requests a r...
HTTP basics<br />Whenever a web request is made, the server responds with a code:<br />200 OK<br />201 CREATED<br />400 BA...
SWORD foundations<br />SWORD is a profile of an existing standard<br />Atom Publishing Protocol (AtomPub)<br />AtomPub is ...
SWORD foundations<br />SWORD is a profile of an existing standard<br />Atom Publishing Protocol (AtomPub)<br />What does t...
Two step process<br />Ask the repository’s SWORD interface to describe itself<br />Use that information to prepare and mak...
Introducing the service document<br />Ask the repository’s SWORD interface to describe itself<br />This is done using a Se...
Who can request a Service Document?<br />A repository typically protects its service documents using HTTP BASIC Authentica...
How to request a Service Document<br />Request a service document from the repository<br />GET a service document<br />In ...
An example service document<br />           <?xml version="1.0" encoding="utf-16"?><app:servicexmlns:atom="http://www.w3.o...
An example service document<br />           <?xml version="1.0" encoding="utf-16"?><app:servicexmlns:atom="http://www.w3.o...
An example service document<br />           <?xml version="1.0" encoding="utf-16"?><app:servicexmlns:atom="http://www.w3.o...
An example service document<br />           <?xml version="1.0" encoding="utf-16"?><app:servicexmlns:atom="http://www.w3.o...
An example service document<br />           <?xml version="1.0" encoding="utf-16"?><app:servicexmlns:atom="http://www.w3.o...
An example service document<br />           <?xml version="1.0" encoding="utf-16"?><app:servicexmlns:atom="http://www.w3.o...
An example service document<br />           <?xml version="1.0" encoding="utf-16"?><app:servicexmlns:atom="http://www.w3.o...
Common Service Document locations<br />DSpace:<br />http://dspace.example.com/sword/servicedocument<br />EPrints:<br />htt...
The second step<br />We have retrieved the Service Document<br />We know where we can deposit<br />We know whatwe can depo...
Let’s talk about packaging<br />What is a package?<br />Like a birthday present!<br />It has some content in the middle<br...
Let’s talk about packaging<br />Examples of packaging formats<br />IMSCP<br />JAR files<br />.docx files<br />Typically zi...
Let’s talk about packaging<br />What packaging format does my repository use?<br />No de-facto packaging format in the rep...
Let’s talk about packaging<br />METS/SWAP<br />Zip file<br />mets.xml manifest<br />Metadata described in SWAP<br />Dublin...
The second step<br />We have retrieved the Service Document<br />We know where we can deposit<br />We know whatwe can depo...
Performing a deposit<br />To perform a deposit:<br />POST a file to the deposit URL<br />POST /geography-collection HTTP/1...
Performing a deposit<br />HTTP/1.1 201 Created<br />Date: Mon, 18 August 2008 14:27:11 GMT<br />Content-Length: nnn<br />C...
A failed deposit<br />Receive an error document<br />Is also an Atom document<br />HTTP 1.1 400 Bad Request<br /><?xml ver...
SWORD vsAtomPub<br />AcceptPackaging<br />What packaging formats are accepted<br /><sword:acceptPackagingq="1.0">http://pu...
SWORD vsAtomPub<br />Mediated Deposit<br />Deposit ‘on-behalf-of’<br />In service document:<br /><sword:mediation>true</sw...
SWORD vsAtomPub<br />Developer features<br />NoOp deposit (don’t actually make the deposit):<br />X-No-Op: true<br />Verbo...
SWORD vsAtomPub<br />Nested Service Documents<br />Stops a service document getting too large when representing the struct...
Questions?<br />SWORD email list:<br />sword-app-tech@lists.sourceforge.net<br />https://lists.sourceforge.net/lists/listi...
Want to learn more?<br />If SWORD is the answer, what is the question? Use of the Simple Web service Offering Repository D...
Credits<br />This course has been produced by:<br />Stuart Lewis<br />The SWORD project<br />http://swordapp.org/<br />Fun...
Photo Credits<br />Lecture hall: http://www.flickr.com/photos/iamthebestartist/2008790/<br />
