Pregel: A System for Large-
                  Scale Graph Processing

                              Written by G. Malewicz...
Graphs are hard

                   • Poor locality of memory access
                   • Very little work per vertex
    ...
State of the Art Today
                   • Write your own infrastructure
                    • Substantial engineering ef...
State of the Art Today

                   • Use a single-computer graph library
                    • Not scalable ☹
    ...
Bulk Synchronous
                                    Parallel
                   • Series of iterations (supersteps)
     ...
Compute Model

                   • You give Pregel a directed graph
                   • It runs your computation at each...
Primitives

                   • Vertices - first class
                   • Edges - not
                   • Both can be d...
Vertex State Machine




                                8
Wednesday, October 13, 2010
C++ API

                   • Your code subclasses Vertex, writes a
                              Compute method
         ...
C++ API

                   • Message passing:
                   • No guaranteed message delivery order
                 ...
C++ API
                   • Combiners (off by default):
                   • User specifies a way to reduce many
         ...
C++ API

                   • Aggregators:
                   • User specifies a function
                   • Each vertex ...
C++ API
                   • Topology mutations:
                   • Vertices can create / destroy vertices at will
     ...
C++ API

                   • Input and output:
                    • Text file
                    • Vertices in a relatio...
Implementation

                   • Executable is copied to many machines
                   • One machine becomes the Ma...
Implementation
                   • Master partitions the graph
                   • Master partitions the input
         ...
Fault Tolerance
                   • At each superstep S:
                    • Workers checkpoint V, E, and Messages
    ...
The Worker

                   • Keeps graph in memory
                   • Message queues for supersteps S and S+1
      ...
The Master
                   • Master keeps track of which Workers own
                              each partition
     ...
Aggregators

                   • Worker passes values to its aggregator
                   • Aggregator uses tree structu...
PageRank in Pregel




                                      21
Wednesday, October 13, 2010
Shortest Path in Pregel




                              22
Wednesday, October 13, 2010
Evaluation
                   • 300 multicore commodity PCs used
                   • Only running time is counted
       ...
24
Wednesday, October 13, 2010
25
Wednesday, October 13, 2010
26
Wednesday, October 13, 2010
Current / Future Work

                   • Graph must fit in RAM - working on spilling
                              over ...
Conclusions
                   • Pregel is production-ready and in use
                   • Usable after a short learning ...
Related Work

                   • Hama - from the Apache Hadoop team
                   • BSP model but not vertex centri...
Related Work
                   • Phoebus, released last week on github
                   • Runs on Mac OS X
            ...
Thanks!

                   • To my advisor, Chandra Krintz
                   • To Google for this paper
                ...
Upcoming SlideShare
Loading in...5
×

Pregel: A System for Large-Scale Graph Processing

32,907

Published on

These are the slides for a presentation I recently gave at a seminar on Tools for High-Performance Computing with Big Graphs. It covers Google's Pregel system, in use for processing graph algorithms in a scalable manner.

Published in: Technology

Pregel: A System for Large-Scale Graph Processing

  1. 1. Pregel: A System for Large- Scale Graph Processing Written by G. Malewicz et al. at SIGMOD 2010 Presented by Chris Bunch Tuesday, October 12, 2010 1 Wednesday, October 13, 2010
  2. 2. Graphs are hard • Poor locality of memory access • Very little work per vertex • Changing degree of parallelism • Running over many machines makes the problem worse 2 Wednesday, October 13, 2010
  3. 3. State of the Art Today • Write your own infrastructure • Substantial engineering effort • Use MapReduce • Inefficient - must store graph state in each stage, too much communication between stages 3 Wednesday, October 13, 2010
  4. 4. State of the Art Today • Use a single-computer graph library • Not scalable ☹ • Use existing parallel graph systems • No fault tolerance ☹ 4 Wednesday, October 13, 2010
  5. 5. Bulk Synchronous Parallel • Series of iterations (supersteps) • Each vertex invokes a function in parallel • Can read messages sent in previous superstep • Can send messages, to be read at the next superstep • Can modify state of outgoing edges 5 Wednesday, October 13, 2010
  6. 6. Compute Model • You give Pregel a directed graph • It runs your computation at each vertex • Do this until every vertex votes to halt • Pregel gives you a directed graph back 6 Wednesday, October 13, 2010
  7. 7. Primitives • Vertices - first class • Edges - not • Both can be dynamically created and destroyed 7 Wednesday, October 13, 2010
  8. 8. Vertex State Machine 8 Wednesday, October 13, 2010
  9. 9. C++ API • Your code subclasses Vertex, writes a Compute method • Can get/set vertex value • Can get/set outgoing edges values • Can send/receive messages 9 Wednesday, October 13, 2010
  10. 10. C++ API • Message passing: • No guaranteed message delivery order • Messages are delivered exactly once • Can send messages to any node • If dest doesn’t exist, user’s function is called 10 Wednesday, October 13, 2010
  11. 11. C++ API • Combiners (off by default): • User specifies a way to reduce many messages into one value (ala Reduce in MR) • Must be commutative and associative • Exceedingly useful in certain contexts (e.g., 4x speedup on shortest-path compuation) 11 Wednesday, October 13, 2010
  12. 12. C++ API • Aggregators: • User specifies a function • Each vertex sends it a value • Each vertex receives aggregate(vals) • Can be used for statistics or coordination 12 Wednesday, October 13, 2010
  13. 13. C++ API • Topology mutations: • Vertices can create / destroy vertices at will • Resolving conflicting requests: • Partial ordering: E Remove,V Remove,V Add, E Add • User-defined handlers:You fix the conflicts on your own 13 Wednesday, October 13, 2010
  14. 14. C++ API • Input and output: • Text file • Vertices in a relational DB • Rows in BigTable • Custom - subclass Reader/Writer classes 14 Wednesday, October 13, 2010
  15. 15. Implementation • Executable is copied to many machines • One machine becomes the Master • Coordinates activities • Other machines become Workers • Performs computation 15 Wednesday, October 13, 2010
  16. 16. Implementation • Master partitions the graph • Master partitions the input • If a Worker receives input that is not for their vertices, they pass it along • Supersteps begin • Master can tell Workers to save graphs 16 Wednesday, October 13, 2010
  17. 17. Fault Tolerance • At each superstep S: • Workers checkpoint V, E, and Messages • Master checkpoints Aggregators • If a node fails, everyone starts over at S • Confined recovery is under development • what happens if the Master fails? 17 Wednesday, October 13, 2010
  18. 18. The Worker • Keeps graph in memory • Message queues for supersteps S and S+1 • Remote messages are buffered • Combiner is used when messages are sent or received (save network and disk) 18 Wednesday, October 13, 2010
  19. 19. The Master • Master keeps track of which Workers own each partition • Not who owns each Vertex • Coordinates all operations (via barriers) • Maintains statistics and runs a HTTP server for users to view info on 19 Wednesday, October 13, 2010
  20. 20. Aggregators • Worker passes values to its aggregator • Aggregator uses tree structure to reduce vals w/ other aggregators • Better parallelism than chain pipelining • Final value is sent to Master 20 Wednesday, October 13, 2010
  21. 21. PageRank in Pregel 21 Wednesday, October 13, 2010
  22. 22. Shortest Path in Pregel 22 Wednesday, October 13, 2010
  23. 23. Evaluation • 300 multicore commodity PCs used • Only running time is counted • Checkpointing disabled • Measures scalability of Worker tasks • Measures scalability w.r.t. # of Vertices • in binary trees and log-normal trees 23 Wednesday, October 13, 2010
  24. 24. 24 Wednesday, October 13, 2010
  25. 25. 25 Wednesday, October 13, 2010
  26. 26. 26 Wednesday, October 13, 2010
  27. 27. Current / Future Work • Graph must fit in RAM - working on spilling over to / from disk • Assigning vertices to machines to optimize traffic is an open problem • Want to investigate dynamic re- partitioning 27 Wednesday, October 13, 2010
  28. 28. Conclusions • Pregel is production-ready and in use • Usable after a short learning curve • Vertex centric is not always easy to do • Pregel works best on sparse graphs w / communication over edges • Can’t change the API - too many people using it! 28 Wednesday, October 13, 2010
  29. 29. Related Work • Hama - from the Apache Hadoop team • BSP model but not vertex centric ala Pregel • Appears not to be ready for real use: • 29 Wednesday, October 13, 2010
  30. 30. Related Work • Phoebus, released last week on github • Runs on Mac OS X • Cons (as of this writing): • Doesn’t work on Linux • Must write code in Erlang (since Phoebus is written in it) 30 Wednesday, October 13, 2010
  31. 31. Thanks! • To my advisor, Chandra Krintz • To Google for this paper • To all of you for coming! 31 Wednesday, October 13, 2010
