    Stovesevolutionreddygeover3 Stovesevolutionreddygeover3 Presentation Transcript

    • EVOLUTION OF
      GOOD STOVE
      DESIGNS
      VER. 3
      OPEN KNOWLEDGE
      [OK]
      Dr. N. Sai Bhaskar Reddy, CEO, GEO
      saibhaskarnakka@gmail.com
      http://www.e-geo.org
      http://www.goodstove.com
      Ver. 1 | 22 designs
      Ver. 2 | 24 designs
    • THREE STONE STOVE
      BRICKS
      STONES
      FUEL
      FUEL
      AIR FROM ALL SIDES
    • ANNULAR STOVE - OPEN
      METAL STOVE
      CEMENT STOVE
      FUEL
      SIDE AIR
    • ANNULAR STOVE – WITH POT - OPEN
      CLAY AND BRICKS
      FUEL
      SIDE AIR
    • ANNULAR STOVE
      CLAY AND BRICKS
      METAL
      FUEL
      SIDE AIR
    • ANNULAR STOVE – WITH POT
      A. CLAY AND BRICKS
      FUEL
      SIDE AIR
    • ANNULAR STOVE – TALL WITH CHIMNEY EFFECT
      A. BOMBAY STOVE
      SIDE AIR
    • ANNULAR STOVE – TALL WITH CHIMNEY EFFECT
      BANGLADESH STOVE 1
      BANGLADESH STOVE 2
      BANGLADESH STOVES 3
      FUEL
      FUEL FEED
      & SECONDARY AIR
      PIT FOR ASH COLLECTION
      PRIMARY AIR
      (WITH OR WITHOUT)
    • ANNULAR STOVE – WITH CHIMNEY
      DRAFT AIR
      SIDE AIR
    • ANNULAR STOVE – WITH CHIMNEY & GRATE
      GOOD STOVE (TWO POT)
      GOODSTOVE DESIGN
      DRAFT AIR
      FUEL
      SIDE AIR
      GRATE
      PRIMARY AIR
    • ANNULAR STOVE – RAISED FOR CHIMNEY EFFECT & GRATE
      GOOD STOVE PORTABLE
      GOODSTOVE (SINGLE POT)
      DRAFT AIR
      FUEL
      SIDE AIR
      GRATE
      PRIMARY AIR
    • HYBRID STOVE – ALL TYPES OF FUELS - SAFEST
      MY HOME GOOD STOVE
      SECONDARY AIR
      STEEL MESH
      FUEL
      DRAFT AIR
      SIDE AIR
      GRATE
      PRIMARY AIR
    • CAMP FIRE / STOVE
      FUEL FEED
      FUEL FEED
      & SECONDARY AIR
      GEO CAMP FIRE STOVE
      DRAFT AIR
      PRIMARY AIR
    • ANNULAR STOVE – RAISED FOR CHIMNEY EFFECT & GRATE
      DRAFT AIR
      SIDE AIR
      FUEL
      GRATE
      PRIMARY AIR
      GOOD STOVE (TWO POT)
    • NATURAL DRAFT TLUD GASIFIER STOVE
      A. LOW-COST WOODGAS STOVE
      FUEL
      SECONDARY AIR
      DRAFT AIR
      GRATE
      PRIMARY AIR
    • NATURAL DRAFT TLUD GASIFIER STOVE
      DRAFT AIR
      SECONDARY AIR
      FUEL
      GRATE
      PRIMARY AIR
    • FORCED AIR TLUD GASIFIER STOVE
      A. Magh-1
      B. Magh-3
      C. Magh-1b
      D. Magh-1 Cyclone
      SECONDARY AIR
      FUEL
      DRAFT AIR
      GRATE
      FORCED AIR (FAN)
      PRIMARY AIR
    • FORCED AIR TLUD GASIFIER STOVE / LIGHT
      A. Magh-4 Lamp stove
      SECONDARY AIR
      FUEL
      DRAFT AIR
      GRATE
      FORCED AIR (FAN)
      PRIMARY AIR
    • FORCED AIR TLUD GASIFIER STOVE
      SECONDARY AIR
      FUEL
      FUEL
      DRAFT AIR
      DRAFT AIR
      GRATE
      GRATE
      FORCED AIR (FAN)
      PRIMARY AIR
      A. Magh-2
      B. Magh Open stove
    • DOWN DRAFT GASIFIER STOVE
      BIOMASS FEED
      FUEL
      BURNER
      SECONDARY AIR
      PRIMARY AIR
      GRATE
    • FORCED AIR TLUD GASIFIER STOVE
      A MAGH CM
      FORCED AIR (FAN)
      FUEL
      SECONDARY AIR
      DRAFT AIR
      GRATE
      PRIMARY AIR &
      FACILITY FOR
      BIOCHAR / ASH REMOVAL
    • FORCED AIR TLUD GASIFIER STOVE
      A. MAGH OPEN STOVE
      FORCED AIR (FAN)
      FUEL
      FUEL
      FUEL
      SECONDARY AIR
      GRATE
      PRIMARY AIR &
      FACILITY FOR
      BIOCHAR / ASH REMOVAL
    • NATURAL DRAFT TLUD HYBRID STOVE
      A. MAGH CM LAXMI
      NATURAL DRAFT
      SECONDARY AIR
      DRAFT AIR
      GRATE
      PRIMARY AIR &
      FACILITY FOR
      BIOCHAR / ASH REMOVAL
    • HYBRID STOVE – SIDE FEED FOR ALL TYPES OF FUELS
      A. AVAN STOVE
      BIOMASS FEED
      DRAFT AIR
      SECONDARY AIR
      FUEL
      GRATE
      PRIMARY AIR &
      FACILITY FOR
      BIOCHAR / ASH REMOVAL
    • HYBRID TLUD STOVE / CHARCOAL RETORT
      MAGH BURNER SERIES
      MAGH CM II
      NATURAL DRAFT
      SECONDARY AIR
      FUEL
      GRATE
      PRIMARY AIR &
      FACILITY FOR
      BIOCHAR / ASH REMOVAL
    • NATURAL DRAFT TLUD GASIFIER STOVE
      FUEL
      A. TWISTER STOVE
      GRATE
      NATURAL DRAFT
      SECONDARY AIR
      PRIMARY AIR &
      FACILITY FOR
      BIOCHAR / ASH REMOVAL
    • HYBRID STOVE – TLUD / ALL TYPES OF FUELS
      A. MAGH 3G
      SECONDARY AIR
      FUEL
      SIDE AIR
      CONTROL
      SIDE AIR
      GRATE
      PRIMARY AIR &
      FACILITY FOR
      BIOCHAR / ASH REMOVAL
    • INSTITUTIONAL STOVE
    • THE GASES FLOW UP OR DOWN BASED ON THE DRAFT, MINIMUM GASES FLOW OUT AS SOME GAS REACHES THE COMBUSTION CHAMBER
      UP / DOWN DRAFT STOVE
      CHANNEL FOR DRAFT
      STOVE
      POT
      RAISED PLATFORM
      FEED
      Satara sugarcane juice boiling stove
      2
      GROUND
      AIR
