by the #s with @raffi
Giv ing a @twitter t alk at ColumbiaUni versity talking a bout Twitter’sNumbers!22 Feb via Twitter for iPhone             ...
http://twitter.com/#!/toptweets/status/12483108178
http://twitter.com/#!/Emergency_In_SF/status/29440739442
http://twitter.com/#!/i80chains/status/9726084734
http://twitter.com/#!/remedyoakland/status/29002198672
http://twitter.com/#!/AlbionsOven/status/10015063036
What’s a Tweet?It’s a short message thats sent through                                           140 characters
How many are there?
How many are there?                      110M!
110M tweets       1200 tweets    per day   ≈   per second
How big are they?      1 tweet text   =   140 characters                     ≈   200 bytes
1200 tweets per                      ≈     230 KB/sec        second                      ≈     14 MB/min                  ...
MySQL         Can’t generate IDs fast enoughCentralized and a single point of failure                                    s...
ampura                                         mons from ch                  used under Creative Com          Photo1 TB ge...
10 TBper day in total                                                                         ≈   120 MB per sec          ...
Where do they go?               Followed by   Following                             Asymmetric Digraph
1                   Digraph                           2            Need to represent this                                 ...
200M registered users       2006    2008     2010   2011
Photo used under Creative Commons from jurvetson          Distributed graph databaseflockdb   High rate of CRUD operations...
@ladygagamother mons†er8.3 million followers@justinbieberJustin Bieber7.5 million followers@BarakObama44th President of th...
How do they get out?    10B API calls       100,000 calls         per day    ≈   per second
REST API         XML/JSON API over HTTPPoll-based system / pseudo real-time                               hosebird        ...
Latency200ms100ms 0ms
752%in 2008
1358% in 2009
Where do we want to be?          Today - 200M people generate ~1200 TPSTomorrow - we want to support half the world and al...
Real challenges in front of us               Real time     Indexing, search, and analytics           Relevance systems    ...
Follow me atQuestions?   twitter.com/raffi
Twitter by the Numbers (Columbia University)
Twitter by the Numbers (Columbia University)
Twitter by the Numbers (Columbia University)
Twitter by the Numbers (Columbia University)
Twitter by the Numbers (Columbia University)
Twitter by the Numbers (Columbia University)
Twitter by the Numbers (Columbia University)
Twitter by the Numbers (Columbia University)
Upcoming SlideShare
Loading in...5
×

Twitter by the Numbers (Columbia University)

17,645

Published on

The version of "Twitter by the Numbers" that I delivered at Columbia University for @TwitterU. 22 Feb 2011.

Published in: Technology
2 Comments
24 Likes
Statistics
Notes
  • Wow! These are mind boggling (and awesome to work with technology that supports this). Thanks for sharing this!
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
  • about twitter up
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
No Downloads
Views
Total Views
17,645
On Slideshare
0
From Embeds
0
Number of Embeds
14
Actions
Shares
0
Downloads
0
Comments
2
Likes
24
Embeds 0
No embeds

No notes for slide

Transcript of "Twitter by the Numbers (Columbia University)"

  1. 1. by the #s with @raffi
  2. 2. Giv ing a @twitter t alk at ColumbiaUni versity talking a bout Twitter’sNumbers!22 Feb via Twitter for iPhone ty from Mudd Building at Columbia Universi 500 West 120th Street New York, New York View Tweets at this place
  3. 3. http://twitter.com/#!/toptweets/status/12483108178
  4. 4. http://twitter.com/#!/Emergency_In_SF/status/29440739442
  5. 5. http://twitter.com/#!/i80chains/status/9726084734
  6. 6. http://twitter.com/#!/remedyoakland/status/29002198672
  7. 7. http://twitter.com/#!/AlbionsOven/status/10015063036
  8. 8. What’s a Tweet?It’s a short message thats sent through 140 characters
  9. 9. How many are there?
  10. 10. How many are there? 110M!
  11. 11. 110M tweets 1200 tweets per day ≈ per second
  12. 12. How big are they? 1 tweet text = 140 characters ≈ 200 bytes
  13. 13. 1200 tweets per ≈ 230 KB/sec second ≈ 14 MB/min ≈ 19 GB/day Just tweet text!
  14. 14. MySQL Can’t generate IDs fast enoughCentralized and a single point of failure snowflake Highly available and uncoordinated (10kqps) Compatible with the ecosystem http://github.com/twitter/snowflake
  15. 15. ampura mons from ch used under Creative Com Photo1 TB generated 10 TB generated per day per day
  16. 16. 10 TBper day in total ≈ 120 MB per sec 80 MB = per sec Photo used u n der Creative C ommons from Mac Users G uide
  17. 17. Where do they go? Followed by Following Asymmetric Digraph
  18. 18. 1 Digraph 2 Need to represent this 4 1 2 3 4 31 Matrix2 Naïve implementation is not scalable34
  19. 19. 200M registered users 2006 2008 2010 2011
  20. 20. Photo used under Creative Commons from jurvetson Distributed graph databaseflockdb High rate of CRUD operations Complex set arithmetic queries http://github.com/twitter/flockdb
  21. 21. @ladygagamother mons†er8.3 million followers@justinbieberJustin Bieber7.5 million followers@BarakObama44th President of the United States6.7 million followers@raffime!0.007 million followers
  22. 22. How do they get out? 10B API calls 100,000 calls per day ≈ per second
  23. 23. REST API XML/JSON API over HTTPPoll-based system / pseudo real-time hosebird Streaming API Long poll HTTP Near real-time delivery of Tweets
  24. 24. Latency200ms100ms 0ms
  25. 25. 752%in 2008
  26. 26. 1358% in 2009
  27. 27. Where do we want to be? Today - 200M people generate ~1200 TPSTomorrow - we want to support half the world and all its devices (5B phones and 6B people)
  28. 28. Real challenges in front of us Real time Indexing, search, and analytics Relevance systems Graph databases Storage Scalability and efficiency
  29. 29. Follow me atQuestions? twitter.com/raffi

×
