“Home ICT Services” with OSGi-HGW at NTT - Takefumi Yamazaki

3,442

Published on

NTT has expanded "Home ICT services" nationwide by adopting OSGi technology as software execution platform on NTT's resideintial and office gateways. We can take advantage of this technology to …

NTT has expanded "Home ICT services" nationwide by adopting OSGi technology as software execution platform on NTT's resideintial and office gateways. We can take advantage of this technology to provide not only "connected home services" but remote management services for cusotmers in a flexible way. In this talk we show our objectives and ideas about why we adopted OSGi as platform technology and describe our current usuages. In addition, we introduce our R&D activities regarding OSGi-HGW evaluations with Deutsche Telekom labs.

Published in: Technology, Business
0 Comments
2 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
3,442
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
229
Comments
0
Likes
2
Embeds 0
No embeds

Report content
Flagged as inappropriate Flag as inappropriate
Flag as inappropriate

Select your reason for flagging this presentation as inappropriate.

Cancel
No notes for slide

Transcript

  • 1. Home ICT Services with OSGi-HGW atNTTTakefumi YAMAZAKINTT/Cyber Solutions Laboratories20th September, 2011 OSGi Alliance Marketing © 2008-2010 . 1 PageCOPYRIGHT © 2008-2011 OSGi Alliance. All Rights Reserved All Rights Reserved
  • 2. Agenda(1) NTT’s view of Home ICT Services & Platform(2) Why has NTT adopted OSGi technology as a platform to provide Home ICT services?(3) Use cases with NTT’s Home ICT platform Page 2 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 3. (1)NTT’s view of Home ICT Services & Platform Page 3 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 4. NTT’s view on Home ICT Services “Home ICT services”are various types of connected home services realized with themanaged service gateway. One Stop Support Easy-to-use for anyone Easy-to-use operation interface Remote support for set-up Save energy Security/Disaster prevention Visualizing power usage Locks, keys, lights, sensor and and controlling energy consumption. home appliances can be controlled with mobile devices and Managed from remote places Service Gateway Entertainment Healthcare Daily health data can be Pictures/videos can be shared between auto-accumulated and graphed. home appliances and remote places Advice from experts can be given from remote places. 4
  • 5. NTT’s Home ICT platform  Key components:  Home gateway (HGW) installed with OSGi framework.  Center server that manages / delivers software modules (bundles).  Various kinds of services by 3rd parties can be provided flexibly on this platform.  The collaboration with 3rd parties is one of the essential keys to expand Home ICT services. Bundles developed by 3rd parties Home ICT PlatformFor Home appliances SOH devices Enter-For SOH devices tainment Home appliances NGNFor Entertainment PI OSGi Framework Home Security Tele- Center HGW communicationFor Security Services Server Page 5 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 6. (2)Why has NTT adopted OSGi technology as a platformto provide Home ICT services? Page 6 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 7. Expand service coverage with open, common APIs ◆ API (Application Programming interface) on HGW should be open, common, andstandardized to enable various service providers to use the platform easily.  OSGi technology meets these requirements. (Security) (Home appliance control) (Home contents) Open, common, & App by App by App by Standardized Provider A Provider B Provider C ・・・ API OSGi-PF OSGi-PF OSGi-PF HGW HGW HGW ・・・ User X User Y User Z Page 7 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 8. Reduce the cost for installation of services◆ The cost for installation of services will be reduced when a single shared servicegateway is used instead of separate multiple service control boxes. When providing various functionalities on the single gateway, software modularity is akey point on embedded devices because available resources are limited. OSGi is an excellent software module technology.User Improve convenience Control boxes can be eliminated by installing the (Reduce the number of control corresponding functional software into HGW. boxes at home)3rd Party Reduce service provision cost ×Teleco carrier App UTM-BOX Expand sale × opportunities OSGi-PF HGW HEMS-BOX × UTM:【Unified Threat Management】 HEMS:【Home Energy Management System】 Win&Win&Win Home appliance Page 8 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved Control BOX
  • 9. Reduce the cost for application development Service providers have to create different application software for the differentvendors’ HGWs unless a common application platform is available.  Common application platform is effective to reduce the cost. Java virtual machine is suitable for this platform since it can conceal the differencesin operating systems. OSGi platform provides modularity for Java. 【Without a common AP-PF】 【With a common AP-PF (OSGi-PF)】 Service Provider Service Provider Common app Common app Common appApp soft App soft OSGi-PF OSGi-PF OSGi-PF App soft HGW HGW HGW HGW HGW HGWApp softVendor A Vendor B Vendor C Vendor A Vendor B Vendor C Page 9 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 10. (3)Use cases with NTT’s Home ICT platform Page 10 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 11. Platform service for service providers: “FLETS Joint” NTT started the platform service for service providers in August 2011. Service providers can use NTT’s Home ICT facilities to provide their own services. NTT charges service providers according to the file size of theirapplication software modules. Customers Home Gateway [Indoors] [Outdoors] Software Modules Mobile Customer devices phone (home appliances, etc.) Apply for service Payment Remote operation Invoice NTT East/West Service provider Home ICT Platform Deliver, control Inter Provide services NGN net Center Application server SNI Request software delivery server Invoice Page 11 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved Payment
  • 12. A service example on “FLETS Joint” :Picture sharing service for pet lovers(NEC BIGLOBE, Ltd.)NEC BIGLOBE Ltd. , a major Internet provider in Japan, started the service on“FLET’S Joint” in August 2011.Pet lovers can watch their pets anytime from remote places and can share theirfavorite pictures with their families and friends. Check their pets from remote places Upload pictures bundle WWW. WWW. server Internet HGW Sharing pictures with families and friends Page 12 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 13. Home security & home appliances controlHome security service and home appliance control services can be provided with bundleson HGW instead of using the home equipment network panel that is needed on theconventional service. Trial service is being provided as an alliance service with an electronic manufacturer. Home Equipment Network Panel ■ Security(break-in info) warning service Break-in warning bundle WWW. ■ Home device remote control Service Internet Air-cond’ /lights HGW ON/OFF Page 13 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 14. Health care■ Measurement is aggregated via HGW into the application server. ・ Application bundles collect data with Continua Guideline v.1.0 and control HGWbased on data received and transmits data to the server.The service is being provided as an alliance service with a healthcare device manufacturer. Customer bundle WWW. Internat Application Healthcare USB HGW server devices receiver Page 14 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 15. Energy visualization Visualization service of the entire electric supply data and consumption is provided with an NTT tablet terminal. Future option: visualize energy data including solar energy generation and control home appliances intelligently with the Home ICT platform.Trial service started in July 2011.Visualizes energy supply&consumption(from July 2011) Utilize more ICT at home (planned for 2012) Energy Center Energy visualization Upload functions & Control server Server Power supply server transmit to servers status Visualizes the status of Internet NGN home power demand &Power NGN supply including solarcompany power generation Uploads Sends real-time info home energy consumption of power supply status/home power 1℃ UP consumption Sends bundles Power distribution measer bundle Consumption power measure “NTT’s tablet terminal” Wireless adapter 。すまい てし費消 く多 。すまし奨 w 0 6りよ日昨 推を作操 Power tap 更変 の下以 ) w 0 8▲ (PU ℃ 1 更変 ン コ ア エ● ) w 0 7▲ (中 ⇒ 強 更変 庫蔵冷● )w 0 5 1▲ (す消を① ビレテ● (for each home appliance USB bundle 昨日より60w多く消費しています。 Controls home appliances Collects 以下の操作を推奨します。 Connected to the network measureme ●エアコン 1℃ UP(▲80w) 変更 based on home energy ●冷蔵庫 強 ⇒ 中(▲10w) nt info 変更 ●テレビ①を消す(▲150w) 変更 consumption info Page 15 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
  • 16. Summary• NTT has adopted OSGi technology to provide Home ICT services by considering merits for both the users and service providers.• NTT has conducted some trial services on the platform and started the platform service for home ICT service providers called“FLET’S Joint” in August 2011.• We will take advantage of this platform to expand NTT’s Home ICT services. Page 16 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

×
