Programming for High Performance Accelerated Systems
Overview of the development environment at SARA/NCF
Options for programming heterogeneous systems
Moving software development flows from multi-core to heterogeneous systems
Developing with OpenCL going forward
Petapath

Petapath Petapath/HP PRACE Prototype system at SARA/NCF

ClearSpeed Software Development environment at SARA/NCF
ClearSpeed SDK Version 3.1
Binary compatible across all ClearSpeed based products
C n Optimising Compiler
C with poly extensions for SIMD data types
Debugger – a port of gdb
Runs on hardware
Profiler – csprof
Allows system-wide visualization of an accelerated application’s performance while running on both a multi-core host and ClearSpeed accelerators
Libraries (BLAS, RNG and FFT) & High level APIs (CSPX)

Standard Eclipse graphical debug interface for CSX processors
CSX processors provide full hardware debugging of running application code
Provides seamless view of many processor cores in parallel with their associated state
Allows full symbolic debug of the C n language
Enhanced views for CSX specific information
ClearSpeed graphical debug interface for the heterogeneous systems Images used with permission of ClearSpeed Technology Plc

ClearSpeed profiler for heterogeneous and multi-processor systems Advance™ Accelerator Board CSX 600 Pipeline CSX 600 Pipeline Host CPU(s) Host CPU(s) Host CPU(s) Advance™ Accelerator Board Host Cores(s) CSX Pipeline HOST/BOARD INTERACTION View host/board interactions. Provides performance information for data transfer operations. Trace cluster node/board interaction. See overlap of host compute and board compute. CSX PIPELINE View detailed instruction issue information. Visualize overlap of executing instructions. Optimize code at the instruction level. View instruction level performance bottlenecks. Get accurate instruction timing. CSX SYSTEM View system level trace. Visually inspect the overlap of compute and I/O. Visualize cache utilization. View branch trace of code executing. Find and analyse performance bottlenecks. Get accurate event timing ClearSpeed Accelerated System CSX Pipeline HOST CODE PROFILING Visually inspect host code executing. Supports multiple threads and processes. Time specific code sections. See overlap of host threads executing. Platform and processor agnostic trace collection. PCIe

Petapath Programming for High Performance Accelerated Systems

Programming for High Performance Accelerated Systems Introduction
Heterogeneous systems are now increasingly common
They are being adopted at the top (Top500) and the bottom (technical workstation) of the HPC market
Acceleration can deliver significant performance and cost savings over traditional COTS HPC systems
However, there are real barriers to adoption:
Software support and programming models
Host system requirements

In order to take advantage of this new technology trend, what are the realistic options?
Some important things to consider:
Single or multi-use system?
Where do the majority of the cycles go?
ISV codes or Open Source/Custom Codes?
Sufficient development resources?

Starting with application source, what is the best way to target heterogeneous computing today?
Proprietary development environments and hardware:
Advance TM /C n (ClearSpeed)
Tesla TM /CUDA (NVIDIA)
Stream TM /Brook+ (AMD)
FPGA based solutions
Or via Third Party/Middleware:
RapidMind TM Platform
CAPS HMPP TM
PGI’s x64+GPU Accelerate Model
e.g. Mitrion Development Platform for FPGAs

These options can loosely be categorised into
Language
C n , CUDA, Brook+, Mitrion C, OpenCL
Directive based or hybrid approaches
PGI x86+GPU, CAPS HMPP, RapidMind
Allow re-targetable support
Can potentially support multiple vendor development environments

Library
All the languages have a library component
Manages hardware resources and runtime interaction
Can also provide higher level abstractions such as standard library support, e.g. BLAS or LAPACK
Some libraries are available from third parties that are designed to transparently interface ISV applications to accelerator hardware
Often the best implementations are available from the vendors themselves

Industry will inevitably move towards available open standards
We believe that the Khronos Group’s OpenCL TM (Open Computing Language) will be a key enabler in the wider adoption of heterogeneous systems
Petapath are members of the Khronos Group and participants on the OpenCL working group
What comes next?

OpenCL is the first open, royalty-free standard for general-purpose parallel programming of heterogeneous systems
OpenCL provides uniform programming environment for software developers
Can write efficient, portable code for a range of high-performance systems and a diverse mix of multi-core and parallel processors
OpenCL

OpenCL consists of:
An API for coordinating parallel computation
A programming language for describing those computations.
Specifically, the OpenCL standard defines:
Subset of the C99 language with extensions for parallelism
API for coordinating data and task-based parallel computations
Numerical requirements based on the IEEE 754 standard
Interoperability with other Khronos standards such as OpenGL
An abstraction layer for a diverse range of computational resources

OpenCL also specifies:
A rich set of built-in functions
Online or offline compilation and build of compute kernel executables
Platform Layer API
Query, select and initalize compute devices
Create compute contexts and work-queues
Runtime API
Execute compute kernels
Manage scheduling, compute and memory resources

Is OpenCL a golden bullet?
Possibly not but it’s an excellent place to start
It’s a well supported Open standard
OpenCL has complete cross vendor support
Most are motivated to increase their market share in the HPC and Technical computing market
Write once, work on many platforms is attractive for ISVs
The lack of an open standard has certainly slowed adoption of support for heterogeneous systems outside of the academic community for compute intensive applications

When will it be available?
Khronos TM Group ratified the OpenCL TM 1.0 specification at Siggraph Asia, December 9 th 2008
Conformant vendor implementations available in Q3 2009
One vendor already has a public beta program
Others will not be far behind
What are the principle reasons that make OpenCL attractive?
No reliance on proprietary programming languages
Cross vendor compatibility and interoperability
Cross platform support (Linux, Windows and OS X)

The incentive to support heterogeneous systems has to be a clear business win; so companies who differentiate on innovation are more likely to adopt early
Many large ISVs have long development cycles and if their licensing model is core or socket based they will have to revise their charging structures
Heterogeneous computing won’t really hit mainstream, multi-application HPC market without ISV support
Observations

Petapath Software development flows on multi-core and heterogeneous systems

Host Software Development Practice (Single Core)
Typical host development flow (Rinse, Profile, Repeat)
Use a naïve implementation (e.g. the infamous triple loop)
Compile (compiler choice can often be important)
Profile/Benchmark (use % of peak GFLOPS as a guide)
Throw some compiler switches
Repeat
Some developers don’t get very far into this optimisation process
Time vs Reward (Does it run fast enough yet?)

Host Software Development Practice (Multi-core)
Look for more scalable implementations
In the multi-core era look for algorithmically scalable solutions
This usually means looking to leverage architectural features
e.g. Make sure you are cache friendly and take advantage of Vector/SIMD support
Compile, Profile/Benchmark (use % of peak GFLOPS as a guide)
Throw compiler switches but also use compiler directives e.g. OpenMP which can require some changes to code
The parameter space for these optimisations can be large
Challenging even for the experienced

Host Software Development Practice (Pitfalls)
The ‘memory wall’ is probably the biggest hurdle
With more cores sharing an already scarce resource in main memory bandwidth, cache hygiene is very important!
Once you fall out of cache then it is sometimes possible that adding more cores can actually slow down your application
Effective programming is about optimising bandwidth
Tools such as Acumem’s SlowSpotter TM are particularly useful!
Deliberately skipping multi-node development as it’s a whole other subject and deserves it’s own track

Heterogeneous Systems Software Development Practice
An implementation tuned for multi-core is a good starting point for porting to an accelerated system
This is because available concurrency (via multi-threading and asynchronous operations) and data parallel operations will likely have been explicitly exposed
In all but the most compute bound applications, effective implementations of data parallel problems are usually tuned to maximise cache bandwidth
And to allow effective loop blocking and strip-mining transformations
This set of optimisations provide a good template for developing an algorithm on an accelerated system

First ascertain at what limiting factors on the host are:
Bandwidth
Is your application bandwidth limited on the host?
In its most cache/memory friendly implementation does it scale and exhibit good cache behaviour?
GPU based accelerators have several times the BW to their local memories of even the latest servers
However accelerators typically have less local memory than the host so large working sets will have to be streamed from the host
Any significant and repeated data movement to and from the accelerator can often be a gating factor for overall application acceleration

Compute
Is you application compute limited?
Is it single precision?
Single precision is still the clear advantage for GPU based accelerators
Does your application require double precision?
GPU based accelerators have less of a delta over x86 hosts in terms of pure DP performance
Lower GFLOP/$ and GFLOP/W vs Implementation Complexity
ClearSpeed has significant advantages in terms of GFLOP/W for applications needing double precision

As for optimal multi-core development
Make sure you are making the most of the architectural features
Occupancy vs. Latency hiding
Shared or local memory accesses
Consider using other memories (constant, texture etc.)
Make sure you are maximising external memory bandwidth
Correct alignment and granularity vital
Must used coalesced memory accesses
General comments on using accelerators

Accelerator Software Development Pitfalls
Pay attention to Amdahl’s Law
Simply put it describes the limit of potential acceleration of an application due to parallelisation
Applies equally to many multi-core implementations
As you process the data parallel kernels faster, the data movement and other serial portions of the application start to dominate the actual runtime
At this point the host interface to the accelerator can now be a bottleneck

Petapath The future - Developing with OpenCL

OpenCL in use
The Khronos Group’s conformance requirements for OpenCL will endeavour to ensure correctness of implementation between vendors
A real challenge for those using OpenCL could well be managing varying performance characteristics of different OpenCL capable platforms
Even different products by the same vendor may vary
What works well on a multi-core CPU and efficiently on a massively parallel accelerator will likely vary

How similar is the heterogeneous development environment to traditional host development?
What tools are there to help the development process?
Do they all support a similar debug interface?
Do they all have similar profiling capabilities?
Will development methods and tools converge?

Debug
Hardware gdb support?
ClearSpeed supports source level debug of C n
NVIDIA in CUDA 2.1, CELL
Debug for Brook+ & pre-CUDA 2.1 was via host versions of kernels
Profiling
gprof (supported by ClearSpeed in C n )
Host API only support for gprof with NVIDIA
Hardware profiling?
ClearSpeed has a very sophisticated profiling and debugging environment
Other profilers currently report a more limited set of information for kernels running on HW

Will these debug and profile tools support OpenCL out of the gate?
With an open development environment now available, it makes sense to develop cross-platform tools that support OpenCL natively and more importantly across multiple vendors and operating systems
Not having to use vendor specific tools will increase the likelihood that developers will not spend too much time tuning for each platform
What will OpenCL have initially?

ClearSpeed CSX700 All Image Rights reserved by original copyright holders Architectures targeted by OpenCL are similar, but different …

NVIDIA GT200 Image Rights reserved by original copyright holders

AMD RV770 Image Rights reserved by original copyright holders

INTEL LARRABEE Image Rights reserved by original copyright holders

Additional utilities and development tools available to the host based developer:
Intel ® Compilers, MKL, IPP, VTune, Thread Building Blocks, Thread Checker (and soon Parallel Studio)
AMD Partner Compilers, CodeAnalyst, ACML
Acumem SlowSpotter
Allinea Tools
And a myriad of other third party tools …
Can we look forward to …
