  • 1. X E N C LO U D P L AT FO R M Todd Deshane Technology Evangelist, Xen.org todd.deshane@xen.org
  • 2. X E N I N T H E C L O U D H I S TO R Y99XenoServers Project Global Public Computing(Cambridge University)"Xenoserver are machines that can “This dissertation proposes asafely and securely perform useful work new distributed computingon behalf of any user who is prepared to paradigm, termed global publicpay for the resources consumed" computing, which allows any user to run any code anywhere. SuchReed et al., 7th Workshop on Hot Topics platforms price computingin Operating Systems, 1999 resources, and ultimately charge users for resources consumed.“ Evangelos Kotsovinos, PhD dissertation, 2004
  • 3. X E N I N T H E C LO U D H I STO RY XCP 1.0 Kronos99 Nov ‘02 Oct ‘03 ‘06 ‘08 ‘09 ‘11 ‘12XenoServers Amazon Project EC2 Dom0 and in Linux Slicehost Xen launched Rackspace Repository Cloud Published Xen XCP Presented Announced XCP 1.5 at SOSP
  • 4. XEN WAS DESIGNED FOR THECLOUD AND THE CLOUDS AREBUILT ON XEN!
  • 5. BA S I C X E N CO N C E P T SControl domain One or more service VMn VM in Xen(Dom0) domains termionlogy VM1 is DomU VM0 Guest OS and Apps Dom0 Kernel Scheduler, MMU Xen Hypervisor Host HW I/O Memory CPUs
  • 6. X E N G U EST V I RT UA L I ZAT I O N T Y P ES • Paravirtualization (PV) o Guest kernel made Xen-aware (open source kernels) o Avoid or replace non-virtualizable operations o Very fast and legacy hardware is supported • Hardware-assisted virtualization (HVM) o Unmodified guest (full virtualization of proprietary OSes) o Requires Intel VT-x or AMD-V (virtualization in hardware) • PV on HVM o Emulate when necessary/beneficial (e.g. boot/BIOS) o Performs better or near PV for a variety of workloads
  • 7. XEN AND THE LINUX KERNEL Xen was initially a University research projectInvasive changes to the kernel to run Linux as a PV guest Even more changes to run Linux as dom0
  • 8. XEN AND THE LINUX KERNELDomU/Dom0 Xen guest support was not inupstream Linux kernelGreat maintenance effort on distributionsFedora/Ubuntu temporarily dropped Dom0 supportXen was harder to install
  • 9. XEN AND THE LINUX KERNEL PVOPS Project Xen DomU since Linux 2.6.23 Xen Dom0 since Linux 3.0 On-going work on feature set and performance optimization. Dom0 support in distros much better!
  • 10. X E N C LO U D P L AT FO R M ( XC P )
  • 11. XC P OV E RV I E W • Open source version of Citrix XenServer o wiki.xen.org/wiki/XCP/XenServer_Feature_Matrix • Enterprise-ready server virt. and cloud platform o Extends Xen beyond a single physical machine (host pools) o Built-in templates for Windows and Linux guests o Open vSwitch built-in and is default networking stack • Datacenter and cloud-ready management API o XenAPI (XAPI) is fully open source o CloudStack and OpenStack integration
  • 12. XC P TO O L S TA C K D I S T R O I N D E P E N D E N C E Extend the delivery model beyond XCP Appliance • apt-get install xcp-xapi or yum install xcp-xapi  Debian Wheezy, Ubuntu 12.04 LTS working (Project Kronos ) Fedora and CentOS in progress (Project Zeus) Volunteer to help and/or add support for your favorite distro
  • 13. X E N VS . XC P VS . P ROJ EC T K RO N O SXen XCP Project KronosHypervisor: latest stable via Debian/Ubuntu packageDom0 OS: CentOS, Debian, Fedora, NetBSD, CentOS 5.5 Debian and UbuntuOpenSuse, RHEL 5.x, Solaris 11, …Dom 0: 32 and 64 bits 64 bits 32 and 64 bitsLinux 3 Dom0: Yes As of XCP 1.5, not yet YesToolstack: Libxl or Libvirt stable XAPI latest XAPIAdvanced functionality: build it yourself Open vSwitch , storage build it yourself repositories, and signed PV drivers built-inConfigurations: everything directed by stable XAPI directed by latest XAPIUsage Model: distro support or do it yourself Shrink wrapped and tested distro support or do it yourselfDistribution: Source or via Linux/Unix ISO (source available) source or via Debian/Ubuntudistribution packages
  • 14. XC P/ X A P I F U T U R E • XCP & XAPI configuration of choice for clouds o Optimized for usage patterns in cloud orchestration (e.g. OpenStack, CloudStack OpenNebula) • Exploit advanced Xen security features o Driver domains, stub domains o Dom0 dissagregation • Xen on ARM (XAPI on ARM)
  • 15. XC P 1 . 5 • Architectural Improvements: Xen 4.1, GPT, smaller Dom0 • GPU pass through: for VMs serving high end graphics • Performance and Scalability: 1 TB mem/host 16 VCPUs/VM, 128 GB/VM. (Note: limits are due to XAPI restriction not Xen hypervisor) • Enhanced Guest OS Support: Support for Ubuntu 10.04 (32/64-bit). Updated support for Debian Squeeze 6.0 64-bit, Oracle Enterprise Linux 6.0 (32/64-bit) and SLES 10 SP4 (32/64-bit). Experimental VM templates for CentOS 6.0 (32/64-bit), Ubuntu 10.10 (32/64-bit) and Solaris 10.
  • 16. X A P I : W H AT I S I T ? • XAPI (or XenAPI) is the backbone of XCP o Provides the glue between all components • Its a XML-RPC style API, served via HTTPS o Provided by a service on every XCP Dom0 host o Designed to by highly programmable o API bindings for many languages: .NET, Java, C, Powershell, Python • XAPI is Extensible via plugins (e.g. used by OpenStack)
  • 17. X A P I F RO M 3 0 0 0 0 F E E T ( STO R AG E ) VM VM Virtual Block Device Virtual Block Device Virtual Block Device Virtual Disk Image Virtual Disk Image Storage Repository Physical Block Device(s) LVM, iSCSI, NFS. etc.
  • 18. X A P I F RO M 3 0 0 0 0 F E E T ( N E T WO R K ) VM VM Virtual Interface Virtual Interface Virtual Interface (VIF) (VIF) (VIF) Network Network Physical Interface(s) Physical Interface(s) Bridge, Open (PIF(s)) (PIF(s)) vSwitch, Bond, VLAN, etc.
  • 19. X A P I F RO M 3 0 0 0 0 ( M E T R I C S ) host_metrics VM_metrics PIF_metrics VBD_Metrics Host VM PIF VBD xen.org/files/XenCloud/ocamldoc/apidoc
  • 20. X A P I OV E RV I E W • VM lifecycle management: live snapshots, checkpoint, migration • Resource pools: live migration, auto configuration, disaster recovery • Flexible storage (NFS, iSCSI, LVM) and networking (Open vSwitch) • Event tracking: progress (VM status), notification (disk full) • Upgrade and patching capabilities (of XCP) • Real-time performance monitoring and alerting (metrics)
  • 21. O P E N VSW I TC H• Software switch, similar to: o VMware vNetwork Distributed Switch o Cisco Nexus 1000V• Distribution agnostic. Plugs right into Linux kernel.• Reuses existing Linux kernel networking subsystems.• Backwards-compatible with traditional userspace tools.
  • 22. W H Y U S E O P E N VSW I TC H W I T H C LO U D ? See also: XenServer Distributed Virtual Switch Controller• Automated control: OpenFlow• Multi-tenancy• Monitoring and QoS
  • 23. X A P I M A N AG E M E N T O P T I O N S • XAPI frontend command line tool: XE (tab-completable) • Desktop GUIs o Citrix XenCenter (Windows-only) o OpenXenManager (open source cross-platform XenCenter clone) • Web interfaces o Xen VNC Proxy (XVP)  lightweight VM console only  user access control to VMs (multi-tenancy) o XenWebManager (web-based clone of OpenXenManager) • XCP Ecosystem: ProjectPage, ProductsPage
  • 24. O P E N X E N M A N AG E R
  • 25. X E N V N C P ROX Y ( X V P )
  • 26. XC P A N D C LO U D O RC H EST R AT I O N STAC KS
  • 27. S EC U R I T Y A N D T H E N E X T WAV E O F X E N• Security is key requirement for Cloud• Security is the primary goal of client virtualization o Desktop, Laptops, Tablets & Smart Phones• Maintaining isolation between VMs is critical o Spatial and temporal isolation o Run multiple VMs with policy controlled information flow (e.g. Personal VM; Corporate VM; VM for web browsing; VM for banking)
  • 28. P L AC E M E N T O F C LO U D M A N AG E M E N T TO O LInstalled in a VM (DomU) Directly installed on Dom0 Pros  Pros  Isolation of cloud VM  Simple install  Security properties  Flexibility  Pre-packaged appliance  Cons Cons  Less isolation  More complex  Cloud service is potential entry  Less flexible point to compromise Dom0
  • 29. A RC H I T EC T U R E CO N S I D E R AT I O N SType 1: Bare metal Hypervisor Type 2: OS ‘Hosted’ User-level VMM VMn VMn VM1 User Device VM1 Apps Virtual VM Models VM Machine Guest OS Guest OS Control and Apps and Apps Host OS Scheduler Hypervisor Device Device Ring-0 VM Monitor Drivers/Models MMU Drivers “Kernel “I/O Memory CPUs Host HW Host HW I/ Memory CPU O s Provides partition isolation + Low cost, no additional drivers reliability,higher security Ease of use & installation
  • 30. X E N : T Y P E 1 W I T H A T W I ST • Thin hypervisorControl domain(dom0) o Key functionality moved to Dom0 Device Models VMn • Using Linux PVOPS VM1 o Take advantage of PV Drivers VM0 Guest OS o PV on HVMLinux, BSD, etc. and Apps o No additional device Sched MMU XSM Hypervisor drivers (Linux 3.x dom0) • uler Host HW In other wordsI/O Memory CPUs o Low cost (drivers) o Isolation & security
  • 31. X E N S EC U R I T Y A DVA N TAG ES• Even without advanced security features o Well-defined trusted computing base o (much cleaner than a type-2 hypervisor) o No extra services in hypervisor layer• More Robustness: Mature, tried & tested architecture• Xen Security Modules (or XSM) o Developed and contributed to Xen by NSA o Generalized security framework for Xen o The Xen equivalent of SELinux
  • 32. X E N D O M 0 D I SAG G R EG AT I O N• Split control domain (Dom0) into driver, stub and service domains o Each contains a specific set of control logic o See: ”Breaking up is hard to do” @ Xen Papers• Unique benefit of the Xen architecture o Security: minimum privilege; narrow interfaces o Performance: lightweight, e.g. Mini-OS service domains o Robustness: ability to safely restart parts of the system o Scalability: more distributed system (less reliant on single control domain)
  • 33. Q U B ES O S / X E N C L I E N T X T • First products configured to take advantage of the security benefits of Xen’s architecture • Isolated driver domains • Virtual hardware emulation domains • Service VMs (global and per-guest) • Xen Security Modules (XSM)
  • 34. X E N C L I E N T A RC H I T EC T U R E Per host/device Per guest Service VMs Service VMs Managemen User VM Emulation User VM Isolation Emulate t Domain Isolation Isolation Device Network Domain Control Device VPN VPN Policy Granularity Policy Granularity Xen Hypervisor Xen Security Modules VT-d TXT Intel vPro Hardware AES- VT-x NI
  • 35. X E N S EC U R I T Y I N T H E C LO U D • Xen-based server products (such as XCP) will start making use of advanced security features o Driver domains, stub domains, service domains o Xen Security Modules (XSM) o Dom0 Disaggregation • Driver domains, stub domains, services domains, and XSM already in upstream Xen • Dom0 disaggregation code coming to xen-unstable
  • 36. S U M M A RY: W H Y X E N ?• Designed for the Cloud : many advantages for cloud use! o Resilience, robustness & scalability o Security and architecture: small, clean attack surface, isolation properties, and advanced security features• Widely used in production by public cloud providers• XCP & XAPI o Ready for use with cloud orchestration stacks o XCP and Project Kronos: flexibility and choice o Lots of additional improvements for cloud still to come• Flexibility and choice of usage models• Open Source with a large community and eco-system
  • 37. THANK YOU!
  • 38. X E N R ES O U RC ES• IRC: ##xen @ FREENODE• Mailing List: xen-users & xen-api• Wiki: wiki.xen.org o Beginners & User Categories • Excellent XCP Tutorials o A day worth of material @xen.org/community/xenday11
  • 39. R E F E R E N C ES Xen and the Art of Repeated Research, Clarkson University  www.clarkson.edu/class/cs644/xen/files/repeatedxen- usenix04.pdf XenAPI (XAPI) Classes  xen.org/files/XenCloud/ocamldoc/apidoc
  • 40. H OW TO CO N T R I B U T E• Same process as for Linux Kernel o Same license: GPLv2 o Same roles: Developers, Maintainers, Committers o Contributions by patches + sign-off (Developer Certificate of Origin) o Details @ xen.org/projects/governance.html
  • 41. CO M M U N I T Y & ECO SYST E M M A P xen.org/community/projects Resear A Hostin ch Xen g D Vendor Project s s D XCP XCP Produc # Project s ts s Xen Consul Produc ting ts Consul People ting Firms
