Rails for mobile devicesAlberto Perdomo                  Conferencia Rails 2011
Mobile devices
BlackberryNokiaPalmKindleWindows Phone
Issues
User Interface
ScreenDifferent sizes and resolutionsDifferent orientations: portrait vs. landscapeZooming
Touch interfaces
Touch interfacesSmall font size, little space between linksNo hoverGestures events vs. mouse events
The network
Heavy websites
Unsused assets
1 big asset vs. several smaller ones
Solutions
User Interface
Width
<!DOCTYPE html><html><head>    <title>Hello world!</title></head><body><p>Hello world!</p></body>
Viewport meta tag<meta name="viewport"      content="width=device-width, initial-scale=1">         Separated by commas, no...
Responsive Web Designs     http://mediaqueri.es/
Fluid layouts and stylesdepending on width & device         capabilities
Simon Collison: http://colly.com/
Andersson-Wise Architects: http://www.anderssonwise.com/
Conferencia Rails by @mamuso: http://conferenciarails.org/
Media Queries     W3C Candidate Recommendation http://www.w3.org/TR/css3-mediaqueries/
Examplesblock for > 900px@media screen and (min-width: 900px) {  // styles for bigger displays}or separate CSS file<link r...
Frameworks
http://www.sencha.com/products/touch/   open source + commercial licenses
demos.Forms = new Ext.TabPanel({    items: [{        title: Basic,        xtype: form,        id: basicform,        scroll...
Javascript        DOMUnified User Interface
Clean semantic markup          +      JavascriptUnified User Interface
FeaturesjQuery                    Progressive                          enhancementCross-platform                          ...
Crossbrowser Experience
<!DOCTYPE html><html>  <head>  <title>Page Title</title>  <link rel="stylesheet" href="http://code.jquery.com/mobile/1.0b1...
Anatomy of a page<div data-role="page">  <div data-role="header">...</div>  <div data-role="content">...</div>  <div data-...
Example: Single Page<body><div data-role="page">  <div data-role="header">    <h1>Page Title</h1>  </div><!-- /header --> ...
Example: local linked pages <div data-role="page" id="foo" >   <div data-role="header">     <h1>Foo</h1>   </div><!-- /hea...
Other stuffComponents: Lists, Buttons, Dialogs, Grid, ...Hijax / AjaxPage transitions / AnimationsThemingDual license: MIT...
The Network
Pa! I:   "e manifest
At its simplest, an offline web application is alist of URLs — HTML, CSS, JavaScript, images,           or any other kind o...
SupportIE   Firefox   Safari   Chrome   Opera   iPhone   Android-     3.5+     4.0+      5.0+    10.6+    2.1+     2.0+
Basic example/index.html<!DOCTYPE HTML><html manifest="/offline.appcache" ><body>.../offline.appcache         Content type...
Anatomy of a manifest  <name>.appcache   CACHE MANIFEST   CACHE   /css/screen.css   /css/offline.css                      ...
Cache what?                           Place        All pages must be included Read         Browse                         ...
A more complex example                 All pages    CACHE MANIFEST                             Fallback for offline    FALL...
Manifest: Status status (returns boolean) navigator.onLine callbacks ononline onoffline
Manifest: DOM & Eventsobject                        eventswindow.applicationCache       checking                          ...
Manifest: DOM & Events                                                          manifest                                  ...
Rack Offline              by          Yehuda Katzhttps://github.com/wycats/rack-offline
AutomatedMobile::Application.routes.draw do  match "/application.manifest" => Rails::OfflineAutomatically caches all JS, C...
Custom manifestMobile::Application.routes.draw do  offline = Rack::Offline.configure do    cache [ "http://code.jquery.com...
Debugging
Part II: Storage
Local StorageImplemented natively in the browsersKey/Value storePersistenceNever sent to server (unlike cookies)Supported ...
Details5MB by defaultacessible through localStorage objectkey: String, value: Any JS supported typeUse parseInt, parseFloa...
ExamplesRead/Writevar foo = localStorage["bar"];localStorage["bar"] = foo;Clear keylocalStorage.removeItem("bar");Empty st...
Competitors: WebSQLSQL database in the browserSQLiteImplemented by some browsers: Safari, Chrome, WebkitAsynchronous APIRe...
Competitors: IndexedDB   No standard Query Language   Access through API functions   Very early stage, not yet usable
Toolbox
Detect requests from mobile devices in your Rails app      https://github.com/brendanlim/mobile-fu    https://github.com/s...
Rails helpers for jQuery Mobilehttps://github.com/Consoci8/jqmobile_helpershttps://github.com/wakeless/rails-jquery-mobile
Manifesthttps://github.com/wycats/rack-offline
Modernizrhttp://modernizr.com/
Examples
Googlehttp://mail.google.com
Wanderlust Stories  http://wanderluststories.com/
Testflighthttps://testflightapp.com/
PieGuyhttp://mrgan.com/pieguy
Movie Timeshttp://andrew.harrison.org/movies/
Harmonioushttp://harmoniousapp.com/app/
Conclusions
Native apps vs. Web apps
Benefits of Native AppsPerformanceUser ExperienceInstallationMonetization optionsDistribution & Market visibility
Benefits of Web AppsInteroperability & cross platformInstallation & deployment optionsURLsShorter Time to MarketDeploy inst...
Resources
Dive Into HTML5            by       Mark Pilgrim  http://diveintohtml5.org
Introducing HTML5              by Bruce Lawson and Remy Sharp  http://introducinghtml5.com/
HTML5 Demos               by           Remy Sharp      http://html5demos.comhttps://github.com/remy/html5demos
Mobilizer               from            SpringBoxhttp://www.springbox.com/mobilizer/
Thanks.@albertoperdomoalberto.perdomo @aentos.com
Questions.
Creative Commons                                     Title                                                  Author        ...
