Using Change Streams to Keep Up with Your Data

#MDBlocal
Using Change Streams to
Keep Up With Your Data
Asya Kamsky, Lead Product Manager
#MongoDB @MDBLocal @asya999 #askAsya

#MDBlocal
“TIME IS MONEY.”
B E N J A M I N F R A N K L I NW A R R E N B U F F E T

#MDBlocal
REAL-TIME IS AN EXPECTATION

#MDBlocal
MongoD
B
Action
Handler

#MDBlocal
const changeStream=
db.collection('temperature').watch();
c h a n g e S t r e a m . o n ( ' c h a n g e ' , f u n c t i o n ( c h a n g e ) {
c o n s o l e . l o g ( c h a n g e ) ;
} ) ;

#MDBlocal
CHANGE STREAM
CHARACTERISTICS

#MDBlocal
5 OPERATION TYPES
INSERT
DELETE
REPLACE
UPDATE
INVALIDATE

#MDBlocal
CHANGE STREAMS PRESENT A DEFINED
API

#MDBlocal
API, UTILIZE COLLECTION ACCESS
CONTROLS

#MDBlocal
CONTROLS, SHOW ONLY DURABLE
CHANGES

#MDBlocal
CONTROLS, SHOW ONLY DURABLE
CHANGES, AND ENABLE SCALING
ACROSS ALL YOUR NODES.

#MDBlocal
TOTAL ORDERING OF CHANGES
ACROSS SHARDS
mongos
3 1
2Shard
1
Shard
2
Shard
3

#MDBlocal
PS
CHANGES ARE DURABLE
P
S

#MDBlocal
SP
CHANGE STREAMS ARE RESUMABLE
P
S
{_id: <resumeToken>,
operationType: ‘update’,
ns: {db: ‘data’, coll: ‘temperature’},
documentKey: {_id: ‘room12345’},
updateDescription: {updatedFields: {temperature: 70},
removedFields: [‘humidity’]}
}
var newChangeStream = coll.watch({ resumeAfter: <cachedResumeToken> });

#MDBlocal
CHANGE STREAMS UTILIZE THE POWER
OF THE AGGREGATION FRAMEWORK
$match $project $addFields $replaceRoot $redact
var changeStream = coll.watch([{ $match: {$or: [{operationType: 'delete' }, {operationType:'replace'}]}}]);

#MDBlocal
1. DEFINED API
2. COLLECTION ACCESS CONTROLS
3. ENABLE SCALING
4. TOTAL ORDERING
5. DURABLE
6. RESUMABLE
7. POWER OF AGGREGATION

#MDBlocal
DELETEREPLACEUPDATEINVALIDATE5 OPERATION TYPES
{ _id: (resumeToken),
operationType: ‘insert’,
ns: {db: ‘test’, coll: ‘foo’},
documentKey: {userName: ‘alice123’,
_id: ObjectId("58a4eb4a30c75625e00d2820")
},
fullDocument: {_id: ObjectId("58a4eb4a30c75625e00d2820"),
userName: ‘alice123’,
name: ‘Alice’
}
}
INSERT
{_id: (resumeToken),
operationType: ‘delete’,
}
}
operationType: ‘replace’,
},
fullDocument: {_id: ObjectId("58a4eb4a30c75625e00d2820"),
name: ‘Alice’
}
}
},
updateDescription: {updatedFields: {email: ‘alice@10gen.com’},
removedFields: [‘phoneNumber’]}
}
operationType: ‘invalidate’,
ns: {db: ‘test’, coll: ‘foo’}}

#MDBlocal
_id: ObjectId("58a4eb4a30c75625e00d2820")},
removedFields: [‘phoneNumber’]}
}
UPDATE
var changeStream = coll.watch({ fullDocument: 'updateLookup' });
UPDATE fullDocument: updateLookup
_id: ObjectId("58a4eb4a30c75625e00d2820")},
removedFields: [‘phoneNumber’]},
fullDocument: { _id: ObjectId("58a4eb4a30c75625e00d2820"),
name: ‘Alice’,
email: ‘alice@10gen.com’,
team: ‘replication’}
}

#MDBlocal
1 . S H AR D K E Y I S U S E D ( B Y T H E M O N G O S ) T O R O U T E
O P E R AT I O N S
2 . _ I D I S U S E D T O U N I Q U E L Y I D E N T I F Y A D O C U M E N T
mongos
3 1
2Shard
1
Shard
2
Shard
3
DEFINING THE documentKey

#MDBlocal
BACK TO
THE USE CASE

#MDBlocal
operationType: 'insert',
ns: {db: 'data', coll: 'temperature'},
documentKey: {_id: 'orangeRoom123'},
fullDocument: {_id: 'orangeRoom123',
temperature: 76,
username: 'eliot_horowitz' }
}
operationType: 'update',
documentKey: {_id: 'greenRoom123'},
updateDescription: {updatedFields: {temperature: 68},
fullDocument: {_id: 'greenRoom123',
temperature: 68,
username: 'aly_cabral'}
}
temperature: 75,
}
Action Handler
var changeStream = coll.watch(
[{$match: {'fullDocument.temperature': {$gte : 70 }}}],
{fullDocument: 'updateLookup'});
temperature: 75
username: aly_cabral

#MDBlocal
IF YOUR APPLICATION REQUIRES STATE
ALWAYS MATCH ON UNCHANGING
FIELDS

#MDBlocal
operationType: 'replace',
documentKey: {_id: 'blueRoom123'},
fullDocument: {_id: 'blueRoom123',
temperature: 71,
username: 'asya_kamsky'}
}
fullDocument: {_id: 'blueRoom123',
temperature: 85,
}
Action Handler
var changeStream = coll.watch([{ $match: {'fullDocument.username': 'aly_cabral'}}],
temperature: 75
temperature: 85
operationType: 'delete',
documentKey: {_id: 'blueRoom123'}
}

#MDBlocal
IF YOUR APPLICATION NEEDS TO NOTIFY ON DELETED
DATA
ALWAYS HANDLE DELETES AND
REPLACES APPROPRIATELY

#MDBlocal
var changeStream = coll.watch([{ $match: {$or:
[ { 'fullDocument.username': 'aly_cabral' },
{ operationType: 'delete' },
{ operationType: 'replace' }
]}}],
Insert Update Delete
In the update notification fullDocument: null
updateLookup
operationType: 'update',
documentKey: {userName: 'greenRoom123'},
updateDescription: {updatedFields: {temperature: 78}},
fullDocument: null
}

#MDBlocal
IF YOU NEED TO SEE EVERY CHANGE (EVEN OUTDATED
CHANGES) TO A DOCUMENT
HAVE MATCHING FIELDS IN THE
DOCUMENT KEY

#MDBlocal
documentKey: {_id: 'blueRoom123',
username: 'aly_cabral'},
fullDocument: {_id: ‘blueRoom123’,
temperature: 85,
}
documentKey: {_id: 'blueRoom123',
username: 'aly_cabral'}}
documentKey: {_id: 'greenRoom123',
username: 'aly_cabral'},
temperature: 71,
username: “asya_kamsky”}
}
Action Handler
var changeStream = coll.watch([{ $match: {'documentKey.username': 'aly_cabral'}}],
temperature: 75
temperature: 85

#MDBlocal
temperature: 71,
username: “asya_kamsky”}
}
fullDocument: {_id: ‘blueRoom123’,
temperature: 85,
}
documentKey: {_id: 'blueRoom123'}
}
Action Handler
var changeStream = coll.watch([{ $match: {'documentKey._id':
{$in:['greenRoom123','blueRoom123']}
}}],
temperature: 75
temperature: 85

#MDBlocal
TO SEE EVERY CHANGE TO A DOCUMENT
CONSIDER ALL EDGE CASES

#MDBlocal
UNDERLYING
TECHNOLOGY

#MDBlocal
RESUMABLE
304 270 233 208 201 190
C AC H E D R E S U M E T O K E N : 2 0 8
N E W E S T O L D E S T
D E L E T E D

#MDBlocal
304 270 233 208 201 190
C AC H E D R E S U M E T O K E N : 1 9 0
N E W E S T O L D E S T
D E L E T E D
NON-RESUMABLE
