7. Columbia University GSAPP
Danil Nagy
The design space
x
parameter
y
parameter
zparameter
Design 1
x = 9.3
y = 7.9
z = 7.5
Design 2
x = 3.9
y = 6.8
z = 7.5
Design 3
x = 3.9
y = 1.4
z = 0.7
8. Columbia University GSAPP
Danil Nagy
Performance
y parameter
x
parameter
performance
Design 1
x = 9.3
y = 7.9
z = 7.5
volume = 551.0
Design 3
x = 3.9
y = 1.4
z = 0.7
volume = 3.8
11. Columbia University GSAPP
Danil Nagy
Complexity and continuity
Too simple “Just right”
complex yet continuous
Too discontinuous (random)<-------- -------->
14. Columbia University GSAPP
Danil Nagy
Generative geometry types
1) Morphological
AdvantageDisavantage
2) Data-oriented 3) Rule-based 4) Behavioral
• good top-down control over
design
• can create discontinous
design spaces
• control over individual
elemens
• L-system, shape grammers,
1d CA (single-state)
• object-oriented, agent-based
behavior models (dynamic)
• parametric models, GH • scripting, state-change
• reduced number of inputs
(abstraction of inputs into
rule sets)
• can create complexity
• reduced number of inputs
(abstraction of inputs into
agent behaviors)
• can lead to emergence
• only top-down control
• can’t control individual
behavior
• can’t create emergence
• potentially redundant or
incomplete design space
• little intuitive control over
macro design
• potentially redundant or
incomplete design space
• can generate only simple and
design spaces
• many inputs (each element
needs to be controlled
seperately
15. Columbia University GSAPP
Danil Nagy
Generative geometry examples: (3) rule-based systems
Prusinkiewicz, P. and Lindenmayer A., The Algorithmic Beauty of Plants
(1990)
Aristid Lindenmayer, Mathematical models for cellular interaction in
development (1968)
16. Columbia University GSAPP
Danil Nagy
George Stiny and James Gips, Shape Grammars and the Generative Specification of Painting and Sculpture (1971)
Generative geometry examples: (3) rule-based systems
17. Columbia University GSAPP
Danil Nagy
Weisstein, Eric W. “Elementary Cellular Automaton.” From MathWorld--A Wolfram Web Resource.
http://mathworld.wolfram.com/ElementaryCellularAutomaton.html
Generative geometry examples: (3) rule-based systems
18. Columbia University GSAPP
Danil Nagy
Explanation of Koch Curve. From Daniel Shiffman, The Nature Of Code (2012)
Generative geometry examples: (3) rule-based systems
19. Columbia University GSAPP
Danil Nagy
Benoit B. Mandelbrot, The Fractal Geometry of Nature (1977)
Generative geometry examples: (3) rule-based systems
20. Columbia University GSAPP
Danil Nagy
J. Tarbell, Substrate Algorithm (2003)
Generative geometry examples: (3) rule-based systems
21. Columbia University GSAPP
Danil Nagy
Generative geometry examples: (4) behavioral systems
Abstract agent-based modeling system
22. Columbia University GSAPP
Danil Nagy
Generative geometry examples: (4) behavioral systems
Description of flocking algorithm. From Daniel Shiffman, The Nature Of Code (2012)
30. Columbia University GSAPP
Danil Nagy
Demo: tower panalization
?
LEFT CORNER
RULE 1
RULE 2
RULE 3
RULE 4
type 2 type 4
RIGHT CORNER
type 1 type 4
(3) Rule-based system
31. Columbia University GSAPP
Danil Nagy
Demo: tower panalization
neighbor agerage = SUM(neighbor states) / 4
FACTOR = own state - neighbor average + 3
FACTOR range: [0 - 6]
FACTOR 0 = RULE 1
FACTOR 1 = RULE 2
FACTOR 2 = RULE 3
FACTOR 3 = RULE 4
FACTOR 4 = RULE 5
FACTOR 5 = RULE 6
FACTOR 6 = RULE 7
# OF ITERATIONS
neighbor state
own state
0-3
0-3
0-3
0-30-3
(4) Behavioral system
35. Columbia University GSAPP
Danil Nagy
Analysis types: (2) graph-based analysis
The Living, Computational analysis of office circulation based on visibility graphs (2016)
36. Columbia University GSAPP
Danil Nagy
Analysis types: (3) finite element analysis (FEA) - node and beam [1d]
Model setup (nodes and beam centerlines)
Beam Element (2D Line)
Beam elements are long and slender, have three
nodes, and can be oriented anywhere in 3D
space
Beam corss section definition Load application and deflection
37. Columbia University GSAPP
Danil Nagy
Analysis types: (3) finite element analysis (FEA) - mesh [2d/3d]
Surface Mesh Solid (Volumetric) Mesh
Membrane Element (2D Planar)
Membrane Elements are 3 or 4 node 2D
elements that can be oriented anywhere in 3D
space.
3D Tetrahedra Element (3D Solid)
Tetrahedra elements are normally used to
model solid objects for which plate elements
are not appropriate
38. Columbia University GSAPP
Danil Nagy
Wind tunnel Air movement/heat dissipation Fluid analysis
Analysis types: (3) finite element analysis (FEA) / computational fluid dynamics (CFD)
39. Columbia University GSAPP
Danil Nagy
Analysis types: (4) physics simulation
Antoino Guadi, hanging model for the
Colònia Güell
Frei Otto, soap bubble minimal surface
model
Daniel Piker, Kangaroo plugin for
Rhinoceros Grasshopper
40. Columbia University GSAPP
Danil Nagy
MOS, Installation No. 9 (Rainbow Vomit) MOS, Software No. 3 (Stack)
Analysis types: (4) physics simulation
