1. NCC Group Plc, Manchester Technology Centre, Oxford Road, Manchester M1 7EF www.nccgroup.com
ssh for pen-testers
By: Ed Williams

2. ssh for pen-testers
“I use ssh, I must be safe!”

3. Internet Facing ssh attacks (July – August, 2010)
http://isc.sans.edu/port.html

4. safe.....not in the matrix!!

5. And in the real world......
 Web directory traversal

6. And in the real world......
 Extract valid users
 Brute –force.....well sort of!
 *And yes......i did priv esc to root 

7. ssh for pen-testers
 ssh
 putty
 scp / pscp
 ssh authentication
 hardening the ssh daemon
 ssh & MiTM
 Tunnelling
 X11 Tunnelling
 ssh-agent
 Only dealing with ssh, appreciate that iptables, tcpwrappers (hosts.allow /
hosts.deny), fail2bin and even port-knocking can and “should” be used!

8. ssh – secure shell
 We all use ssh / putty?
 We all know why we use ssh / putty?
Telnet - rubbish ssh – much better

9. putty
 PuTTY is a free and open source terminal emulator application which can act as a
client for ssh…and a hell of a lot more too!
 PuTTY – the ssh client;
 PSCP - an scp client, i.e. command-line secure file copy;
 PSFTP - an sftp client, i.e. general file transfer sessions much like ftp;
 Plink - a command-line interface to the PuTTY back ends;
 Pageant - an SSH authentication agent for PuTTY, PSCP and Plink;
 PuTTYgen - an rsa and dsa key generation utility.

10. scp / pscp
 A secure way of transferring files from hosts, exactly the same
syntax as cp.
 Copying file to a host:
scp SourceFile user@host:directory/TargetFile
 Copying file from host
scp user@host:/directory/SourceFile TargetFile

11. scp / pscp
 PuTTY too has a version of scp – namely pscp, which will allow you
to shift files from a windows box to your *nix box (and vice-versa)

12. scp / pscp
 An example of pscp:
 *Notice the second command has an agent parameter and no password!

13. ssh authentication
 Two main methods of authentication.....there are more (Kerberos
related etc) but these are what I typically see:
 Enable verbosity (-v) while connecting and you can see the
authentication mechanisms:

14. Password authentication (tunnelled clear-text)
 This is enabled by default and brute-force’able
 Of the many options in sshd_config, this is one of the most
important and most overlooked.

15. Something I’ve Been Working On........
 Script to test a list of given hosts for given creds.
 Loads of work to do on this, but its a start!

16. Password authentication
 I sometimes see keyboard-interactive
 To disable:
- ChallengeResponseAuthentication no
- UsePam no

17. Keyboard-interactive
 This is still brute-force’able*
 *had to amend AllowUsers to include tom 

18. Publickey Authentication
 Public-key authentication lets you prove your identity to a remote
host using a cryptographic key instead of a login password.
 This method is orders of magnitude harder to brute-force than a
password.

19. Publickey Authentication
Create Keys
Enter Password
scp to remote box
Create Keys
Sling public key onto remote box and add to
auth_keys file
Assign a strong pwd

20. Publickey Authentication (PuTTY)
 Puttygen does all this:

21. Publickey Authentication (PuTTY)
 Fire up the agent and authenticate – more on this later
 And then login

22. Authorized_keys file
 AuthorizedKeys file specifies the file containing public keys for
public key authentication; if none is specified, the default is
~/.ssh/authorized_keys.
 Additional security / options can be added here:
 Loads of Options here:
- Command=“command” – useful for backups / dumps etc
- No-x11-forwarding
- No-port-forwarding
- No-agent-forwarding

23. from (man authorized_keys)
from=“pattern”
- The purpose of this option is to optionally increase security:
public key authentication by itself does not trust the network
or name servers or anything (but the key); however, if
somebody somehow steals the key, the key permits an
intruder to log in from anywhere in the world. This additional
option makes using a stolen key more difficult.

24. from
 Change ip address to a value that isn't mine:
 If password authentication is still enabled will default to this method
of authentication; otherwise,

25. Re-cap
 Now we have public key authentication sorted:
- Create public / private key (ssh-keygen)
- [secure] copy publickey to host (scp/pscp/ssh)
- Add publickey to remote authorized_keys file
- Consider additional security through authorized_keys file
- Disable password authentication in sshd_config*
- Bounce the sshd service
1. /etc/init.d/ssh restart
2. kill –HUP `cat /var/run/sshd.pid`

26. Hardening sshd
 Typically, this is held in /etc/ssh/sshd_config*
 Loads of options here to “increase security”, I'll concentrate on a few key ones here
(see man sshd_config for all options)
- PermitRootLogin (H)
- PermitEmptyPasswords (H)
- PasswordAuthentication (M)
- AllowUsers (M)
- Protocol (M)
- MaxAuthTries (M)
- Port (good for thwarting bots e.g. dd_ssh)(L)
*I’ve not included any info on the client config file (/etc/ssh/ssh_config)

27. Automation – sshdcheck.pl
 Still some work to do – but does the job!!
Rubbish
Better

28. ssh & MiTM
 SSH Host Keys act as a protection against Man-In-The-Middle
attacks:

29. MiTM
 Launch a MiTM and get the following:

30. ssh tunnelling
 [ssh] tunneling is a way to tunnel insecure protocols through a
secure communication channel.
 It can also be used to bring into focus devices behind a NAT’ed
device.
 These tunnels can either be Local or Remote:
- An SSH Local Forward is a tunnel from your local machine through the
SSH server.
- An SSH Remote Forward is a tunnel from the remote machine through
the SSH client.
*this assume the default sshd_config of AllowTcpForwarding is set to
yes, which is default.

31. ssh tunnelling – local example
192.168.1.4:445
Ubuntu
192.168.1.3:445
Windows 2k3
Encrypted Tunnel
127.0.0.1:445

32. ssh tunnelling - local example

33. ssh tunnelling – local example

34. ssh tunnelling – remote example
192.168.83.138 - Ubuntu
192.168.83.143:4444 – bt3 192.168.83.140:22 – bt4
Encrypted Tunnel
Could easily have Telnet,
FTP or VNC etc etc here.

35. ssh tunnelling – remote example
bt3
bt4
ubuntu

36. ssh tunnelling (PuTTY)
 As you’d expect – putty can handle this too:

37. ssh tunnelling (PuTTY)
 Open an ssh session as normal, this will create the tunnel:
 Open RDP and tunnel through our Linux box to the remote
windows server:

38. ssh tunnelling (PuTTY)

39. X11 Tunnels
 Traffic between an X server and remote X clients is not encrypted
by default.
 X11 tunnels are similar to regular tunnels. The only difference is
that when you ssh into a remote machine, ssh sets up the
DISPLAY environment variable so it points back to the machine you
are sitting at.

40. X11 Tunnels (PuTTY)

41. X11 Tunnels (ssh)
 Make sure that X11Forward is enabled in sshd_config

42. ssh-agent
 ssh-agent is a program to hold private keys used for public key authentication (RSA,
DSA).
 Why the eval?

43. ssh-agent
 Running ssh-agent by its self isn't enough; you also need to set some environmental
variables, for binding to ports etc.
 Being lazy, I run eval `ssh-agent`

44. Locking The Agent
 It is possible to list the publickey attributes (ssh-add –L), which isn't ideal
– fortunately, you can lock the agent to give nothing away!!
Lock agent
Un-lock agent

45. PuTTY Agent
 As you’d expect, putty has its own version of the agent, pageant.
 Add your private key to the agent and, as discussed earlier you can
ssh-in, scp with out a password etc etc.

46. Conclusion
 ssh / putty is awesome, but by no means perfect!
 It can be made nails, and we, as pen-testers, should make
appropriate recommendations around its use....and use it in a
secure fashion ;-)
 Assuming you have permission, don’t forget to brute-force ssh.

47. Any Questions?

48. Further Reading
 http://www.theregister.co.uk/2010/08/12/server_based_botnet/
 http://www.theregister.co.uk/2009/04/17/ssh_attacks/
 http://aplawrence.com/Security/sshloginattack.html

49. Resources
