T-photon Technology Co., Ltd manufactures and exports privacy glass, PDLC film, LED glass, and glass tools. It offers quality, durable products and honest after-sales service accepted by domestic and international markets. The privacy glass uses a PDLC film and tempered glass to switch between clear and frosted states with a simple on-off mode for energy saving installation in various industrial, financial, medical, electronic, and transportation applications. PDLC film is an intelligent film that can be applied to glass to adjust light transmission between transparent and translucent states according to electric voltage to meet visibility and privacy requirements. LED glass features outstanding brightness and energy saving through LED light sources inserted into glass for decorative applications in shopping and hotels.

1. 2
Company Info:Company Info:
T-photon Technology Co., Ltd®, which professional in manufacture and export
the Privacy-glass, PDLC film, LED-glass and glass-tool, With quality assurance and
together with a wide range of choices of sizes, durable products and honest after-servic
e of T-photon® are well accepted by both the domestic and international markets.

2. 3
Application:Application:

3. 4
About The Privacy Glass:About The Privacy Glass:
Privacy glass also calls switch
able glass or Smart glass, its made
by the PDLC film and the double tem
pered glass with high temperature
and high pressure.
A simple(ON – OFF)mode switche
s the glass from being clear to frost .
This product is simple to install just
like any standard double glazed seal
ed unit.
This energy saving product is compl
etely solid state requiring no mainte
nance or special cleaning require-m
ents.
7 watts /m²Power consumption
off52%
0 ℃ ~55 ℃Working temperatu
re
on81%Visible light
transmittance
Off 5%
Parallel light
transmittance
On 79%
Life time
TransparentTurn on
220v transformerspower control
＜1800*3200mmCustom sizes
50/60 HzFrequency
≈0.4mmPdlc-film
translucentTurn off
ON＞ 50000 hr
3+3,4+4,5+5,6+6,
8+8, 10+10,12+12
Thickness

4. AC60V
5How the Privacy Glass works?How the Privacy Glass works?
AC60V

5. 6
SmartSmart--glassglass®®
SmartSmart--Glass ApplicationGlass Application
Suggestion for application industrial
Construction: advanced hotel, villa, office, meeting room, toilet doors and
windows, shower cubicle, kitchen doors and windows, glass curtain wall,
greenhouse, science residence, business building, factory, laboratory doors
and windows, partition, etc.
Financial & Medical---bank teller windows, ATM safety windows, the room
windows needs transfer between privacy and transmittance
Electronic---freezer, refrigerator, microwave oven
Car window--- car scuttle, metro, high-speed rail
Industries---indoor design application, trade exhibition hall, command
center central projection bulletin, commercial film advertisement, etc.

9. 8
About The PDLCAbout The PDLC--Film:Film:
PDLC filmis an intelligent film, a film that can be stick on glass, which can
adjust light under electric pressure to switch between transparent and mist, and
meet the requirements of glass on penetrability and privacy protection;

10. PDLC SWITCHABLE FILMThickness 0.4mm
Max. Size 1800 x 3000mm
Parallel Light
Transmittance
ON - 79%
OFF - 5%
Visible Light
Transmittance
ON - 81%
OFF - 52%
Haze ON - 8%
OFF - 90%
UV Blocking > 98%
Operating Voltage ON – 70 VAC
Response Time < 1s
Power Consumption ON - 6W/m2
Working temperature 0~70 degree Celsius
Storage temperature - 40~80 degree
Celsius
Electrical Durability > 5million
Life time > 50000 hours

11. Glass type White/Tempered/Typographic
LED light color White/Blue/Green/Red/lvory…
Size Maximum size: 1400mmⅹ2600mm
Shape Any shape, suitable for drilling
Suitable Environment From -20℃ to 70℃
Power Utilization Driving voltage less than DC 60V
Power consumption Depends on the design
Transfer Time Less than 100 milliseconds
UV resistance 99%
IR resistance 40%
Viewing Angle 160°
Visible Light
Transmittance
Transmittance more than 80%
AAbboouutt TThhee LLEEDD GGllaassss::
LED glass is a high-tech product
which inserted with LED luminous
source to make different type and
pattern. LED glass has the feature of
outstanding brightness and energy
saving. The line of the LED glass is
covert on the surface by using special
technology for all kinds of sheet glass,
a variety of design applications meet
customers’ needs. LED glass can block
more than 40% of infrared and 99% of
UV light, it is also a safe glass with
partial sound-damping function.
LLEEDD--GGllaassss

12. 12
The LED Glass ApplicationThe LED Glass Application
Shopping Decoration
Hotel & House Decoration
