1. 02/11/13 FOSTIIMA Business School 1

2. STEP BY STEP GUIDE
1. Formulate the problem
(i) Pick out important information
(ii) Formulate constraints
(iii) Formulate objective function
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
(i) Identify pivotal column
(ii) Find θ-values
(iii) Identify pivotal row
(iv) Identify pivot
(v) Pivot
5. Get the solution
02/11/13 FOSTIIMA Business School 2

3. THE PROBLEM
• A small factory produces two types of toys: cars and
dolls. In the manufacturing process two machines
are used: the moulder and the assembler. A doll
needs 2 hours on the moulder and 1 hour on the
assembler. A car needs 1 hour on the moulder and 1
hour on the assembler. The moulder can be
operated for 16 hours a day and the assembler for 9
hours a day. Each doll gives a profit of Rs.16 and
each car gives a profit of Rs.14. The profit needs to
be maximised.
• How do we formulate this problem?
02/11/13 FOSTIIMA Business School 3

4. STEP BY STEP GUIDE
1. Formulate the problem
(i) pick out important information
(ii) formulate constraints
(iii) formulate objective function
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
5. Get the solution
02/11/13 FOSTIIMA Business School 4

5. PICKING OUT IMPORTANT
INFORMATION
• A small factory produces two types of toys: cars and
dolls. In the manufacturing process two machines
are used: the moulder and the assembler.
• A doll needs 2 hours on the moulder and 1 hour on
the assembler. A car needs 1 hour on the moulder
and 1 hour on the assembler.
• The moulder can be operated for 16 hours a day and
the assembler for 9 hours a day.
• Each doll gives a profit of Rs.16 and each car gives a
profit of Rs.14.
02/11/13 FOSTIIMA Business School 5

6. PICKING OUT IMPORTANT
INFORMATION
• A small factory produces two types of toys: cars and
dolls. In the manufacturing process two machines
are used: the moulder and the assembler.
• A doll needs 2 hours on the moulder and 1 hour on
the assembler. A car needs 1 hour on the moulder
and 1 hour on the assembler.
• The moulder can be operated for 16 hours a day and
the assembler for 9 hours a day.
• Each doll gives a profit of Rs.16 and each car gives a
profit of Rs.14.
02/11/13 FOSTIIMA Business School 6

7. • A doll needs 2 hours on the moulder
and 1 hour on the assembler. A car
needs 1 hour on the moulder and 1
hour on the assembler.
02/11/13 FOSTIIMA Business School 7

8. PICKING OUT IMPORTANT
INFORMATION
• A small factory produces two types of toys: cars and
dolls. In the manufacturing process two machines
are used: the moulder and the assembler.
• The moulder can be operated for 16 hours a day and
the assembler for 9 hours a day.
• Each doll gives a profit of Rs.16 and each car gives a
profit of Rs.14.
02/11/13 FOSTIIMA Business School 8

9. • A doll needs 2 hours on the moulder and 1 hour on
the assembler. A car needs 1 hour on the moulder
and 1 hour on the assembler.
• The moulder can be operated for 16 hours a day
and the assembler for 9 hours a day.
02/11/13 FOSTIIMA Business School 9

10. STEP BY STEP GUIDE
1. Formulate the problem
(i) pick out important information
(ii) formulate constraints
(iii) formulate objective function
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
5. Get the solution
02/11/13 FOSTIIMA Business School 10

11. • A doll needs 2 hours on the moulder and 1 hour on
the assembler. A car needs 1 hour on the moulder
and 1 hour on the assembler.
• The moulder can be operated for 16 hours a day
and the assembler for 9 hours a day.
• Using the decision variables
d = number of dolls
c = number of cars
make two constraints from this information.
02/11/13 FOSTIIMA Business School 11

12. FORMING CONSTRAINT 1
THE MOULDER
• A doll needs 2 hours on the moulder and 1
hour on the assembler. A car needs 1 hour
on the moulder and 1 hour on the assembler.
• The moulder can be operated for 16 hours a
day and the assembler for 9 hours a day.
2d + c ≤ 16
02/11/13 FOSTIIMA Business School 12

13. FORMING CONSTRAINT 2
The assembler
• A doll needs 2 hours on the moulder and 1
hour on the assembler. A car needs 1 hour
on the moulder and 1 hour on the assembler.
• The moulder can be operated for 16 hours a
day and the assembler for 9 hours a day.
d+c≤9
02/11/13 FOSTIIMA Business School 13

14. STEP BY STEP GUIDE
1. Formulate the problem
i) pick out important information
ii) formulate constraints
iii) formulate objective function
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
5. Get the solution
02/11/13 FOSTIIMA Business School 14

15. PICKING OUT IMPORTANT
INFORMATION
• A small factory produces two types of toys: cars and
dolls. In the manufacturing process two machines
are used: the moulder and the assembler.
• Each doll gives a profit of Rs.16 and each car gives a
profit of Rs.14.
02/11/13 FOSTIIMA Business School 15

16. FORMING THE OBJECTIVE
FUNCTION
• Each doll gives a profit of Rs.16 and each
car gives a profit of Rs.14.
• Let Z be the total profit; formulate the
objective function
02/11/13 FOSTIIMA Business School 16

17. FORMING THE OBJECTIVE
FUNCTION
• Each doll gives a profit of Rs.16 and
each car gives a profit of Rs.14.
Z = 16d + 14c
02/11/13 FOSTIIMA Business School 17

18. THE LINEAR PROGRAMMING
PROBLEM
• MAXIMISE Z = 16d + 14c
subject to the constraints:
(i) 2d + c ≤ 16
(ii) d+c≤ 9
(iii) c≥0,d≥0
• VERY IMPORTANT
• DON’T FORGET YOUR NON – NEGATIVITY
CONSTRAINTS !
02/11/13 FOSTIIMA Business School 18

19. STEP BY STEP GUIDE
1. Formulate the problem
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
5. Get the solution
02/11/13 FOSTIIMA Business School 19

20. INTRODUCING SLACK
VARIABLES
To change inequalities (i) and (ii) into
equations we add slack variables s and t
This gives:
(i) 2d + c + s = 16
(ii) d+c+t = 9
02/11/13 FOSTIIMA Business School 20

21. THE NEW LINEAR
PROGRAMMING PROBLEM
• MAXIMISE Z = 16d + 14c + 0s + 0t
subject to the constraints:
2d + c + s + 0t = 16
d + c + 0s + t = 9
c≥0,d≥0,s≥0,t≥0
02/11/13 FOSTIIMA Business School 21

22. STEP BY STEP GUIDE
1. Formulate the problem
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
5. Get the solution
02/11/13 FOSTIIMA Business School 22

23. We want to put all the information in the
form of a table. This is called the
initial tableau.
To form the initial tableau we need to
change the objective function from
Z = 16d + 14c + 0s + 0t
to
Z – 16d – 14c – 0s – 0t = 0
02/11/13 FOSTIIMA Business School 23

24. FORMING THE INITIAL TABLEAU
Label the table with your basic variables, s and
t
and with your non – basic variables, d and c.
BASIC
VARIABLES
d c s t VALUE
s
t
Z
02/11/13 FOSTIIMA Business School 24

25. FORMING THE INITIAL TABLEAU
2d + 1c + 1s + 0t = 16
1d + 1c + 0s + 1t = 9
Z – 16d – 14c – 0s – 0t = 0
BASIC
VARIABLES
d c s t VALUE
s 2 1 1 0 16
t 1 1 0 1 9
Z -16 -14 0 0 0
02/11/13 FOSTIIMA Business School 26

26. FORMING THE INITIAL TABLEAU
BASIC VALUE
VARIABLES
d c s t
s 2 1 1 0 16
t 1 1 0 1 9
Z -16 -14 0 0 0
This is the objective row
02/11/13 FOSTIIMA Business School 27

27. STEP BY STEP GUIDE
1. Formulate the problem
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
(i) Identify pivotal column
(ii) Find θ-values
(iii) Identify pivotal row
(iv) Identify pivot
(v) Pivot
3. Get the solution
02/11/13 FOSTIIMA Business School 28

28. PIVOTAL COLUMN
• We now need to find where to pivot and we start by
entering the basis by choosing the column with the
most negative entry in the objective row.
BASIC VALUE
VARIABLES
d c s t
s 2 1 1 0 16
t 1 1 0 1 9
Z -16 -14 0 0 0
This is the most negative coefficient with corresponding
variable d and it’s column is called the pivotal column. 29
02/11/13 FOSTIIMA Business School
d
is now called the entering variable.

29. STEP BY STEP GUIDE
1. Formulate the problem
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
(i) Identify pivotal column
(ii) Find θ-values
(iii) Identify pivotal row
(iv) Identify pivot
(v) Pivot
3. Get the solution
02/11/13 FOSTIIMA Business School 31

30. FINDING θ-VALUES
• You are now going to find the pivotal row and the
leaving variable.
• You need to find θ-values.
1. Identify positive entries in the pivotal column.
2. Divide each entry in value column by the corresponding
positive entry in the pivotal column.
BASIC VALUE
VARIABLES
d c s t
s 2 1 1 0 16
t 1 1 0 1 9
Z -16 -14 0 0 0
02/11/13 FOSTIIMA Business School 32

31. STEP BY STEP GUIDE
1. Formulate the problem
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
(i) Identify pivotal column
(ii) Find θ-values
(iii) Identify pivotal row
(iv) Identify pivot
(v) Pivot
5. Get the solution
02/11/13 FOSTIIMA Business School 34

32. PIVOTAL ROW
• For row (i) θ = 16
2 = 8
• For row (ii) θ = 9
1 = 9
• The row with the smallest θ-value is called
the pivotal row.
• Here the pivotal row is row (i)
02/11/13 FOSTIIMA Business School 35

33. STEP BY STEP GUIDE
1. Formulate the problem
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
(i) Identify pivotal column
(ii) Find θ-values
(iii) Identify pivotal row
(iv) Identify pivot
(v) Pivot
5. Get the solution
02/11/13 FOSTIIMA Business School 36

34. THE PIVOT
The pivot!
BASIC VALUE
VARIABLES d c s t
s 2 1 1 0 16
The pivotal row t 1 1 0 1 9
Z -16 -14 0 0 0
The pivotal column
02/11/13 FOSTIIMA Business School 37

35. STEP BY STEP GUIDE
1. Formulate the problem
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
(i) Identify pivotal column
(ii) Find θ-values
(iii) Identify pivotal row
(iv) Identify pivot
(v) Pivot
5. Get a solution
02/11/13 FOSTIIMA Business School 38

36. PIVOTING
1. Replace the leaving variable with the
entering variable.
2. Divide all entries in the pivotal row by the
pivot. The pivot becomes 1.
3. Add suitable multiples of the pivotal row to
all other rows until all entries, apart from
the pivot, in the pivotal column are zero.
02/11/13 FOSTIIMA Business School 39

37. Step 1 - Replace the leaving variable with the entering variable.
BASIC VALUE
VARIABLES
d c s t
s 2 1 1 0 16
t 1 1 0 1 9
Z -16 -14 0 0 0
Step 2 - Divide all entries in the pivotal row by the pivot. The pivot
becomes 1.
BASIC VALUE
VARIABLES
d c s t
s
d 1 1/2 1/2 0 8
t
Z
02/11/13 FOSTIIMA Business School 40

38. PIVOTING
BASIC VALUE
VARIABLES
d c s t
s 2 1 1 0 16
t 1 1 0 1 9
Z -16 -14 0 0 0
Step 3 - Add suitable multiples of the pivotal row to all other rows until
all
entries, apart from the pivot, in the pivotal column are zero.
row (ii) – ½ row (i)
gives
t 0 1/2 -1/2 1 1
02/11/13 FOSTIIMA Business School 41

39. PIVOTING
BASIC VALUE
VARIABLES
d c s t
d 1 1/2 1/2 0 8
tt 0 1/2 -1/2 1 1
Z -16 -14 0 0 0
x16 16 8 8 0 128
0 -6 8 0 128
02/11/13 FOSTIIMA Business School 42

40. PIVOTING
BASIC VALUE
VARIABLES
d c s t
d 1 1/2 1/2 0 8
tt 0 1/2 -1/2 1 1
Z
02/11/13 FOSTIIMA Business School 43

41. BASIC VALUE
VARIABLES
d c s t
d 1 1/2 1/2 0 8
tt 0 1/2 -1/2 1 1
Z
Z 0 -6 8 0 128
This is our second tableau
02/11/13 FOSTIIMA Business School 44

42. PIVOTING
• Follow the rules for finding a pivot on
your second tableau.
• Pivot as before.
• Continue this process until there are no
negative entries in the objective row.
• This will be your final tableau. This is
called the optimal tableau.
02/11/13 FOSTIIMA Business School 45

43. BASIC
⇓ VALUE
VARIABLES
d c s t
d 1 1/2 1/2 0 8
⇒ tt 0 1/2 -1/2 1 1
Z
Z 0 -6 8 0 128
d 1 0 1 -1 7
c 0 1 -1 2 2
Z 0 0 2 12 140

44. OPTIMAL TABLEAU
BASIC
VARIABLES
d c s t VALUE
d 1 0 1 -1 7
c 0 1 -1 2 2
Z 0 0 2 12 140
• Note there are no negative entries in the
objective row.
• Can you see the solution?
02/11/13 FOSTIIMA Business School 47

45. STEP BY STEP GUIDE
1. Formulate the problem
2. Introduce slack variables
3. Form initial tableau
4. Obtain new tableaux
5. Get the solution
02/11/13 FOSTIIMA Business School 48

46. OBTAINING THE SOLUTION
BASIC
VARIABLES
d c s t VALUE
d 1 0 1 -1 7
c 0 1 -1 2 2
Z 0 0 2 12 140
• Remember that since s and t are now non–basic
variables they are set to zero.
• This corresponds to the solution:
s = 0, t = 0,
d=7
c=2
Z = 140
02/11/13 FOSTIIMA Business School 49

47. THE SOLUTION
• Don’t forget to put your solution back
into the context of the problem.
Z = 140
d=7
c=2
• The maximum profit is Rs.140
• To make this profit the factory should
produce 7 dolls and 2 cars.
02/11/13 FOSTIIMA Business School 50

48. PIVOTING
BASIC VALUE
VARIABLES
d c s t
s 2 1 1 0 16
t 1 1 0 1 9
Z -16 -14 0 0 0
Step 3 - Add suitable multiples of the pivotal row to all other rows until
all
entries, apart from the pivot, in the pivotal column are zero.
row (iii) + 8 row (i)
gives
Z 0 -6 8 0 128
02/11/13 FOSTIIMA Business School 51
