An overview of the Qt Model View architecture and practical examples of how to use this architecture for presenting large data sets in your application user interface.

1. PRACTICAL MODEL VIEW
PROGRAMMING
CODE LESS. VIEW MORE.

2. Marius Bugge Monsen,
MSc (NTNU),
Software Developer

3. Contents
● An Overview of the Qt Model View Architecture
● An Introduction to the Item Model Interface
● Customized Item Filtering
● Customized Item Painting
● More Models and Hierarchies

5. The Model View Architecture

6. Item Selections
User Input Item Selection State
User Input
View Item Delegate
Change Notifications Data Changes
Model

7. Item Selections
View View
Model

8. Item Based Views
Table Widget T Widget
ree List Widget

9. Item Based View
View

11. What do you get ?
● Efficiency
● Flexib ility
● M aintainab ility

12. The Model Interface

13. 400 000 000 000 000 cells

14. Model Interface View
Data Structure

15. 0 0 1 2
0 0
1 1
2 2

16. #include <QtGui>
int main(int argc, char *argv[])
{
QApplication app(argc, argv);
int rows = 4;
int columns = 1;
QStandardItemModel model(rows, columns);
for (int r = 0; r < model.rowCount(); ++r) {
QModelIndex index = model.index(r, 0);
model.setData(index, "hello");
}
QTableView view;
view.setModel(&model);
view.show();
return app.exec();
}

17. Model Interface View
hello
? hello
hello
hello
Data Structure

21. // we start with a 4x1 table
QStandardItemModel model(4, 1);
for (int r = 0; r < model.rowCount(); ++r) {
QModelIndex index = model.index(r, 0);
model.setData(index, "hello");
// let's add a 1x1 sub-table
QModelIndex parent = index
model.insertRow(0, parent);
model.insertColumn(0, parent);
// then we can set the data in cell [0,0]
QModelIndex child = mode.index(0, 0, parent);
model.setData(child, “world”);
}

22. Model Interface View
world
hello
? hello
hello
world
world
hello
world
Data Structure

23. Model
Model Interface
Custom API
Data Structure

24. #include <QtGui>
int main(int argc, char *argv[])
{
QApplication app(argc, argv);
QTreeWidget widget;
for (int i = 0; i < 4; ++i) {
QTreeWidgetItem *parent =
new QTreeWidgetItem(&widget, QStringList("hello"));
new QTreeWidgetItem(parent, QStringList("world"));
}
widget.show();
app.exec();
}

25. Model Index
● Row
● Column
● Internal Identifier

26. Model Index
Qt4 Logo

27. Decoration Role Typ e: Im age File
Size: 1 0.5 kB
T ip Role
oolT
Qt4 Logo
DisplayRole

28. QIcon icon(“images/qt4-logo.png”);
QStandardItemModel model(4, 1);
for (int r = 0; r < model.rowCount(); ++r) {
QModelIndex index = model.index(r, 0);
model.setData(index, "hello", Qt::DisplayRole);
model.setData(index, icon, Qt::DecorationRole);
}

29. QIcon icon(“images/qt4-logo.png”);
QTableWidget table(4, 1);
for (int i = 0; i < 4; ++i)
table.setItem(i, 0, new QTableWidgetItem(icon, “hello”));

30. T Model Interface
he
● A Generic Interface to Data Structures
● M od els Are Interchangeab le
● Views Are Interchangeab le
● M od els and Selections Are Sharab le

31. Customized Item Filtering

32. Model

33. Model Proxy View

34. Model Sorting View

35. Model Filtering View

36. class CodeModel : public QStringListModel
{
public:
CodeModel(const QString &fileName, QObject *parent = 0)
: QStringListModel(parent)
{
QFile source(name);
source.open(QIODevice::ReadOnly);
QStringList strings = QString().split("n", QString::SkipEmptyParts);
setStringList(strings);
}
};

37. CodeModel model(sourceFile);
QSortFilterProxyModel proxy;
proxy.setSourceModel(&model);
QTreeView view;
view.setModel(&proxy);
QObject::connect(lineEdit, SIGNAL(textChanged(const QString&)),
&proxy, SLOT(setFilterRegExp(const QString&)));

38. class ListModel : public QAbstractListModel
{
Q_OBJECT
public:
ListModel(QObject *parent = 0);
~ListModel();
int rowCount(const QModelIndex &parent) const;
QVariant data(const QModelIndex &index, int role) const;
};

39. ListModel::ListModel(QObject *parent)
: QAbstractListModel(parent) {}
ListModel::~ListModel() {}
int ListModel::rowCount(const QModelIndex &) const
{
return 10000;
}

40. QVariant ListModel::data(const QModelIndex &index,
int role) const
{
if (role == Qt::DisplayRole)
return index.row();
if (role == Qt::DecorationRole)
return QColor((index.row() << 4) & 0xFF,
(index.row() << 2) & 0xFF,
(index.row() & 0xFF));
return QVariant();
}

42. class ColorFilter : public QSortFilterProxyModel
{
Q_OBJECT
public:
ColorFilter(QObject *parent = 0);
bool filterAcceptsRow(int sourceRow,
const QModelIndex &sourceParent) const;
public slots:
void setRedFilter(int value);
void setGreenFilter(int value);
void setBlueFilter(int value);
private:
int red, green, blue;
};

43. bool ColorFilter::filterAcceptsRow(int sourceRow,
const QModelIndex &sourceParent) const
{
QModelIndex sourceIndex = sourceModel()->index(sourceRow,
filterKeyColumn(),
sourceParent);
QVariant variant = sourceIndex.data(Qt::DecorationRole);
if (variant.type() == QVariant::Color) {
QColor c = variant.value<QColor>();
return (c.red() > red) && (c.green() > green) && (c.blue() > blue);
}
return true;
}

44. ...
ListModel model;
ColorFilter filter;
filter.setSourceModel(&model);
...
QSlider *redSlider = new QSlider(Qt::Horizontal);
redSlider->setRange(0, 255);
QObject::connect(redSlider, SIGNAL(valueChanged(int)),
&filter, SLOT(setRedFilter(int)));
...
QListView *view = new QListView;
view->setModel(&filter);
view->setItemDelegate(new ColorDelegate(view));
...

46. Customized Item Painting

47. Item Selections
View Item Delegate
Model

48. Qt4 Logo
Im age File
1 0.5 kB
Qt4 Logo
Qt4 Logo

50. class HoverDelegate : public QItemDelegate
{
Q_OBJECT
public:
HoverDelegate(QObject *parent = 0) : QItemDelegate(parent) {}
void paint(QPainter *painter,
const QStyleOptionViewItem &option,
const QModelIndex &index) const
{
if (option.state & QStyle::State_MouseOver)
painter->fillRect(option.rect, Qt::lightGray);
QItemDelegate::paint(painter, option, index);
}
};
...
view.viewport()->setAttribute(Qt::WA_Hover);
...

51. Movie Title

52. <?xml version="1.0" standalone="no"?>
<svg width="100" height="100" viewBox="0 0 100 100"
xmlns="http://www.w3.org/2000/svg" baseProfile="tiny" version="1.2">
<title>Play</title>
<defs>
<linearGradient id="gradient" gradientUnits="userSpaceOnUse" x1="0" y1="0" x2="0" y2="100">
<stop offset="0%" stop-color="#ddddff" />
<stop offset="50%" stop-color="#000000"/>
</linearGradient>
</defs>
<rect x="20" y="0" width="93" height="130" rx="5" fill="none" stroke="#ffffff" stroke-width="3" />
<circle cx="50" cy="50" r="50" fill="url(#gradient)" stroke="#000000" stroke-width="2"/>
<path d="M 30 75 L 30 25 L 80 50 z" fill="#dddddd" stroke="#000000" stroke-width="2" />
</svg>

53. class DemoDelegate : public QItemDelegate
{
public:
DemoDelegate(QObject *parent = 0);
void paint(QPainter *painter,
const QStyleOptionViewItem &option,
const QModelIndex &index) const;
protected:
void drawSvg(QPainter *painter,
const QRect &rect) const;
private:
mutable QSvgRenderer renderer;
};

54. void DemoDelegate::paint(QPainter *painter,
const QStyleOptionViewItem &option,
const QModelIndex &index) const
{
// draw the item as unselected and without focus rect
QStyleOptionViewItem opt = option;
opt.state &= ~QStyle::State_Selected;
opt.state &= ~QStyle::State_HasFocus;
QItemDelegate::paint(painter, opt, index);
// draw svg over the current item
if (option.state & QStyle::State_HasFocus)
drawSvg(painter, option.rect);
}

56. More Models and Hierarchies

57. struct SimpleNode
{
SimpleNode(SimpleNode *parent) : parentNode(parent) {
if (parentNode)
parentNode->children.append(this);
}
~SimpleNode() {
foreach(SimpleNode *child, children)
delete child;
}
QVariant data() const {
return "node data";
}
SimpleNode *parentNode;
QList<SimpleNode*> children;
};

58. Model Interface View
Data Structure

60. class SimpleModel : public QAbstractItemModel
{
public:
SimpleModel(QObject *parent = 0);
~SimpleModel();
QModelIndex index(int row, int column, const QModelIndex &parent) const;
QModelIndex parent(const QModelIndex &child) const;
int rowCount(const QModelIndex &parent) const;
int columnCount(const QModelIndex &parent) const;
QVariant data(const QModelIndex &index, int role) const;
protected:
QModelIndex indexForNode(SimpleNode *node) const;
SimpleNode *nodeForIndex(const QModelIndex &index) const;
int rowForNode(SimpleNode *node) const;
private:
SimpleNode *root;
};

61. int SimpleModel::rowCount(const QModelIndex &parent) const
{
SimpleNode *parentNode = nodeForIndex(parent);
return parentNode->children.count();
}
int SimpleModel::columnCount(const QModelIndex &parent) const
{
Q_UNUSED(parent);
return 1;
}

62. SimpleModel::SimpleModel(QObject *parent)
: QAbstractItemModel(parent)
{
// Initialize the data structure
root = new SimpleNode(0);
for (int i = 0; i < 10; ++i) {
SimpleNode *topLevel = new SimpleNode(root);
for (int j = 0; j < 5; ++j) {
SimpleNode *secondLevel = new SimpleNode(topLevel);
for (int k = 0; k < 3; ++k) {
(void) new SimpleNode(secondLevel);
}
}
}
}
SimpleModel::~SimpleModel()
{
delete root;
}

63. QVariant SimpleModel::data(const QModelIndex &index, int role) const
{
if (index.isValid() && role == Qt::DisplayRole) {
SimpleNode *node = nodeForIndex(index);
return node->data();
}
return QVariant();
}

64. Model Index
Qt4 Logo

65. QModelIndex SimpleModel::index(int row, int column,
const QModelIndex &parent) const
{
if (hasIndex(row, column, parent)) {
SimpleNode *parentNode = nodeForIndex(parent);
SimpleNode *childNode = parentNode->children.at(row);
return indexForNode(childNode);
}
return QModelIndex();
}

66. QModelIndex SimpleModel::parent(const QModelIndex &child) const
{
SimpleNode *childNode = nodeForIndex(child);
SimpleNode *parentNode = childNode->parentNode;
if (parentNode == root)
return QModelIndex();
return indexForNode(parentNode);
}

67. QModelIndex SimpleModel::indexForNode(SimpleNode *node) const
{
if (node == root)
return QModelIndex();
int row = rowForNode(node);
int column = 0;
return createIndex(row, column, node);
}

68. SimpleNode *SimpleModel::nodeForIndex(const QModelIndex &index) const
{
if (index.isValid())
return static_cast<SimpleNode*>(index.internalPointer());
return root;
}
int SimpleModel::rowForNode(SimpleNode *node) const
{
return node->parentNode->children.indexOf(node);
}

69. int main(int argc, char *argv[])
{
QApplication app(argc, argv);
SimpleModel model;
QTreeView view;
view.setModel(&model);
view.show();
return app.exec();
}

70. What we have covered
● The Qt Model View Architecture
● The Item Model Interface
● Customized Item Filtering
● Customized Item Painting
● Hierarchical Models

71. More Information
http://doc.trolltech.com/4.1/model-view-programming.html
http://doc.trolltech.com/4.1/model-view.html
